Table boring machine

TOS VARNSDORF WHQ 13 CNC

Condition: good (used), Year of construction: 2003, travel distance X-axis: 14,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 2,500 rpm, feed length W-axis: 900 mm, spindle diameter: 152 mm, FPT MAR-X 3, 2003 CNC SELCA 4045 PLUS DIGITAL, Built 2003, CNC can be changed to Heidenhein 620. Hsdpfx Aswdm A Hjh Uenw FPT TRT25. Rotary Table, 25 Ton. Two axis Head, 144 x 144. X, Column travel 14.000 mm Y, Headstock vertical travel 4.000 mm Z, Ram stroke 1.500 mm W, Spindle Ø 152,4 mm 900 mm Spindle taper ISO 50 Spindle speed 0 - 2.500 rpm Spindle motor 48 kW Automatic tool changer 40 Tools FPT TRT25. Rotary Table, 360.000° 2.500 x 2.500 mm Rotary Table longitudinal travel 2.000 mm Table load 25 Ton

Condition: used, Year of construction: 1982, spindle diameter 90 mm x-travel 900 mm y-travel 900 mm z-axis 1200 mm w-axis 800 mm table surface area 900 x 1200 mm rotation movement 360 Grad table load 6,0 t turning speeds 25 - 1400 U/min spindle taper ISO 40 voltage 380 V / 50 Hz drive milling spindle 9,2 kW total power requirement 35 KVA weight of the machine ca. 10 t dimensions of the machine ca. 4,5 x 2,8 x 2,5 m • Machine had been completely refurbished in 1994 by the manufacturer • new switch cabinet, • new Servo-drive BOSCH and HEIDENHAIN-control TNC 360,(3D control) • valve plate Ø 600 mm. • traverse distance: 150 mm Hnedjtv H Ucepfx Ah Ujw The machine is currently not ready for demonstration due to a fault in the electrical system.

Condition: used, Year of construction: 2000, x-travel 4300 mm y-travel 1000 mm z-travel 1700 mm Control TNC430 ja Hnedpfxsww Ngue Ah Usw

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / 2-machine package: Froriep deep hole drilling machine & Irle finishing machine Perfectly matched duo for deep hole drilling and precise finishing of large workpieces A specialised machine package is available for sale – two perfectly matched systems for the complete machining of long, heavy workpieces with the highest demands on precision and efficiency. MACHINE 1 Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, Hnsdpfx Ahjuddimo Usw steering ring MACHINE 2 Irle machine – high-precision finishing Power: 129 kW Control: Siemens NC control Speed range: 2 – 300 rpm (stepless) Feed: 3 – 4,500 mm/min (in steps) Centre distance: 11,000 mm Swing diameter over bed: 1,250 mm Clamping range of steady rests: 150 – 1,100 mm Workpiece length: up to 11,000 mm Workpiece weight: up to 10 tonnes Max. outer diameter: 850 mm With up to 50,000 Nm torque, perfect for smooth drilling, honing and demanding finishing processes. Your advantages at a glance - Complete solution from a single source – from pre-drilling to finishing - Large workpieces up to 11 metres and 10 tonnes in weight - High process reliability thanks to perfect machine synchronisation - Ready for immediate use, well maintained and from ongoing operation - Ideal for mechanical engineering, energy, oil & gas, hydraulics and large parts manufacturing

Condition: excellent (used), turning length: 5,500 mm, Make: WEIPERT Type: W1400 Control: R&D MTC3 DBC Turning Length: 5500mm Hsdpswzhzlsfx Ah Ujnw Swing over bed Ø: 1400mm Swing over cross slide Ø:960mm Length: 9000mm Width: 2900mm Height: 2900mm Weight: 32000kg

Condition: used, Year of construction: 1992, Technical details: spindle diameter: 100 mm x-travel: 1500 mm y-travel: 1450 mm z-axis: 930 mm w-axis: 506 mm B-axis (table): 360 ° control for program: HdH TNC 407 tool taper: SK50 number of spindle speeds: 5 - 1.600 / stufenlos table load: 4,0 t table-size: 1100 x 1400 mm table rotating: 360 ° feed steps: X/Y/W/Z-Achse: 2 - 2000 mm/min Rapid feed X axis: X/Y/W/Z-Achse 5000 mm/min. total power requirement: 40 kW dimensions electric cabinet: 2000 x 600 x 2000 mm machine dimensions LxWxH: 4,9 x 3,7 x 3,8 m weight of the machine ca.: 14 t Hodpfxou Idqbo Ah Uonw CNC drilling-milling machine with hydraulic power unit. Working paths from the table: X-axis table transverse 1500mm W-axis table longitudinal 1000mm 9x T-slots according to DIN 650 Equipment: measuring probe electronic handwheel hydr. weight compensation Y-axis universal milling head And some accessories, ask for them! i.D. *

Condition: excellent (used), Make: HEYLIGENSTAEDT Type: NDC 710 / 1800 Hjdpfx Ajwzh A Ash Uonw Control: R&D MTC3 4 Chuck 1400 mm Steady rest 3 units Ø 100-1050 Roller steady open 2 units Ø 1120 KNOLL Chip conveyor 2022 Boring bar Ø 260 x 3500 mm Boring bar Ø 200 x 1500 mm Boring bar Ø 150 x 1100 mm DBC Turning Length: 8250mm Swing over bed Ø: 1400mm Swing over cross slide Ø:1120mm Spindle power: 100kW Workpiece load: 16000 Length: 14000mm Width: 3500mm Height: 2900mm Weight: 32000kg

Condition: excellent (used), Year of construction: 2002, x-axis 4000 mm y-axis 3500 mm z-axis 1500 mm Control SIEMENS 840 D w-axis 1500 mm column daylight 2500 mm surface area 3000 x 2000 mm workpiece weight 10000 kg spindle turning speed range 5-6000 U/min transmission ratio 2 power capacity - milling spindle 45 kW dist. cutter spindle - workpiece spindle 3500 mm max. torque on the spindle 1250 Nm tool change unit 200 -fach tool diameter 135 / 250 mm weight of tools max. 50 kg tool length - max. 400 mm tool taper ISO SK-50 the portal milling machine is in very good condition. ADDITIONAL EQUIPMENT DRILLING/MILLING Angle milling head yes automatic tool clamping yes Tool clamping yes Ball screws yes Guideway cover yes Coolant system yes High-pressure cooling system (internal cooling) yes Full work area panelling yes Portal machining centre with tool changing system and second table top. Hnjdpfxevwgmmj Ah Usw

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 3220, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,300 mm, Mechanical general overhaul in 2025 Base machine – Travel paths X = 2,000 mm / Y = 1,300 mm / Z = 1,300 mm Machine column Torsion-resistant welded construction with three hardened compact roller guides, protected against chips and coolant. Spindle carriage Cast design with hydraulic weight compensation, guided on compact roller guides. Machine bed Self-supporting Hydropool composite structure, no foundation required. Precision compact roller guides on the X-axis. CNC rotary table (motorized) Ø1600 mm clamping area, 8 longitudinal T-slots (22 mm), 2 alignment slots, T-slot pitch 160 mm, centering bush Ø50 H7, runout 0.010 mm, flatness 0.020 mm. Indexing accuracy ±4”, max. rotation speed 5 rpm, tilting moment 60,000 Nm, maximum table load 6,000 kg, max. workpiece swing diameter 2,300 mm (up to 320 mm above table). Table top shows normal wear. Automatic tool changer Chain magazine for 48 tools, max. Ø 125 mm (250 mm if adjacent slots are free), max. length 400 mm, max. weight 25 kg. Tool interface SK50 DIN 69871, spindle position horizontal, fixed position coding and pneumatic spindle taper blow-out. Spindle head with universal milling head (UFK) Automatic 360 × 1° and 180 × 1° swivel, 64,800 programmable positions. Tool interface SK50. Hydromechanical quick tool clamping (pull force 20 kN). Main drive liquid-cooled, 30 kW at 100% duty cycle (41 kW at 40% duty cycle), speed range 36–6,000 rpm. Digital feed drives AC individual drives, infinitely variable 2–30,000 mm/min on all axes, acceleration up to 2 m/s². Operation / control Swiveling control panel with Heidenhain iTNC 530 CNC control. Measuring systems Hjdpfx Ahow N Nx Hs Ujnw Direct, contactless linear measuring systems. Electrical equipment According to EN 60204 / VBG 4, 400/230 V, 50 Hz, total connected load approx. 50 kVA. Control cabinet IP54 with control and switching devices, wired via plug-in system. Lubrication Guides: centralized impulse lubrication. Main spindle: permanent grease lubrication. Paintwork Machine/control cabinet RAL 7035, milling head/spindle head RAL 5021, DD textured paint (silk gloss, oil/soda resistant). Work area enclosure 2 angular sliding doors at the front + roof, rear wall with protective cover, side viewing window. Power connection 400 V, 3-phase, 50 Hz, 50 kVA, 125 A slow-blow, compressed air 4–6 bar (incl. filter pressure regulator & condensate separator). Coolant system Switchable coolant supply (nozzle ring/internal for SK DIN 69871 AD). Compact paper band filter unit, adjustable flow through bypass valve. Pump capacity 32 l/min at max. 20 bar. Tank capacity 500 l. Chip conveyor Travel distance approx. 2,000 mm, feed width approx. 350 mm, discharge height approx. 1,250 mm. External electronic handwheel (HR 410) Switchable to 3 axes (optionally up to 5 axes, not for universal head axes). Collision monitoring Single-channel system for monitoring machine and, to a limited extent, tool collisions.

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, table length: 4,000 mm, table width: 1,500 mm, tank capacity: 500 l, SHW PowerSpeed 5 Travel Ranges • X-axis (bed): 4,000 mm • Y-axis (vertical): 2,100 mm • Z-axis (spindle horizontal): 1,300 mm Control System • CNC control: Heidenhain iTNC 530 Feed Speed • X, Y, and Z axes: 2 - 30,000 mm/min • Acceleration: 3.5 m/s² Universal Milling Head in Orthogonal Design • Milling head swivel range (mounting): 360 x 1 degree • Milling head swivel range: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 – 4,000 rpm o Short-term: 36 – 6,000 rpm Automatic Tool Changer • Tool magazine for 48 tools Clamping Plate • Clamping surface: 4,000 x 1,500 mm Chip Conveyor • Fork length: 4,000 mm Coolant System • Tank capacity: 500 l Splash and Chip Protection • One-sided, with 2 manually sliding doors About the Company MBM MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include, among others, spare parts delivery, on-site customer service, machine overhauls, and control system modernization. Services: - Used machines - Spare parts - Customer service - Machine servicing - Machine overhauls - CNC control modernization ----- _____ Hnedpfxjw I Rz Ho Ah Uew Used machine – used milling machine – used traveling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used cnc milling machine – used boring and milling machine – used metal milling machine – used metal mill – used metal machining center – used cnc mill – cnc milling machines – milling machinery – large part machining – cnc large part machining – milling – shw – PS5 – PS 5 – Powerspeed – SHW PSZ 5 – SHW Powerspeed – SHW Powerspeed 5 – PSZ 5 – Heidenhain – MBM milling machine – MBM machine – column-type milling machine
