CNC lathe HEYLIGENSTAEDT - NDC 710 / 180

HEYLIGENSTAEDT NDC 710 / 1800

Condition: used, turning diameter over bed 2400 mm turning diameter over slide rest 2200 mm turning length 10000 mm power capacity 185 kW faceplate diameter 1650 mm turning speeds 1,5 -150 U/min max. workpiece weight 70000 kg clamping diameter 1400 mm Technical data Working range Maximum turning diameter over support: 2200 mm Maximum swing diameter over bed: 2400 mm Maximum turning length: 10,000 mm Clamping diameter in the headstock faceplate: 300 - 1,600 mm with special jaws up to 2,050 mm Clamping diameter in the tailstock faceplate: 300 - 1,400 mm Maximum workpiece weight: 70000 kg Main drive, faceplate Faceplate diameter: 2000 mm Faceplate speeds, continuously adjustable in 4 stages: 1.5 - 150 rpm Maximum torque at rated speed: 220,000 Nm Nodsxddvnspfx Af Sswr Drive power of main motor: 185 kW Flange centre point angle: 70° Supports Travel of the plunge slide: 500 mm Travel of the face slide: 1400 mm Quick adjustment, longitudinal: 2000 mm/min Quick adjustment, face: 800 mm/min Infinitely variable feed, longitudinal: 0.6 - 300 mm/min Infinitely variable feed, face: 0.3 - 120 mm/min Max. cutting force at support: 20,000 kg Tailstock Faceplate diameter (removable): 1650 mm Faceplate clamping diameter: 1400 mm Flange centre point angle: 70° Quick adjustment: 1250 mm/min Special equipment Copying device for first support Copying length 8500 mm Max. copying depth in one pass 500 mm Boring device: Boring bar 460 x 390 mm Drilling diameter 600 - 1000 mm Maximum drilling depth in one pass 2700 mm At Ks of 200 kp/mm² - s max. = 1.5 mm/rev a = max. chip cross-section 30 mm² at a projection of 1000 mm Reduced chip cross-section with increasing drilling depth A guide ruler for cone turning, adjustment angle up to 8° and a maximum cone length (in one pass) of 2000 mm, adjustment accuracy ± 5 minutes. A guide ruler for cone turning, adjustment angle up to 15° and a maximum cone length (in one pass) of 1000 mm, adjustment accuracy ± 5 minutes. 125 kg auxiliary crane on spindle box.

Condition: good (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, rotational speed (max.): 5,000 rpm, table length: 4,000 mm, table width: 2,000 mm, Sachman PX 120 Travelling column milling and boring machine with: - X-axis travel 6000 mm - Y-axis travel 1200 mm - Z-axis travel 2000 mm - Heidenhain TNC 530 control unit Nedjv Acatspfx Af Sjwr - CNC rotary-translating table 2000 x 2000 mm - Stolle table 4000 x 2000 mm - KOSMO 3 automatic head 0.02° x 0.02° - 60-place tool magazine - chip conveyor - standard accessories Free extension in 12/24 months

Condition: used, Year of construction: 2000, x-travel 4300 mm y-travel 1000 mm z-travel 1700 mm Nwjdpfx Aeww Ngusf Sor Control TNC430 ja

Condition: excellent (used), turning length: 5,500 mm, Make: WEIPERT Type: W1400 Control: R&D MTC3 DBC Turning Length: 5500mm Swing over bed Ø: 1400mm Swing over cross slide Ø:960mm Length: 9000mm Width: 2900mm Height: 2900mm Nodpfx Afjwzhzls Sjwr Weight: 32000kg

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / 2-machine package: Froriep deep hole drilling machine & Irle finishing machine Perfectly matched duo for deep hole drilling and precise finishing of large workpieces A specialised machine package is available for sale – two perfectly matched systems for the complete machining of long, heavy workpieces with the highest demands on precision and efficiency. MACHINE 1 Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Nwedeuddimjpfx Af Sor Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring MACHINE 2 Irle machine – high-precision finishing Power: 129 kW Control: Siemens NC control Speed range: 2 – 300 rpm (stepless) Feed: 3 – 4,500 mm/min (in steps) Centre distance: 11,000 mm Swing diameter over bed: 1,250 mm Clamping range of steady rests: 150 – 1,100 mm Workpiece length: up to 11,000 mm Workpiece weight: up to 10 tonnes Max. outer diameter: 850 mm With up to 50,000 Nm torque, perfect for smooth drilling, honing and demanding finishing processes. Your advantages at a glance - Complete solution from a single source – from pre-drilling to finishing - Large workpieces up to 11 metres and 10 tonnes in weight - High process reliability thanks to perfect machine synchronisation - Ready for immediate use, well maintained and from ongoing operation - Ideal for mechanical engineering, energy, oil & gas, hydraulics and large parts manufacturing

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,300 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 6,000 rpm, spindle speed (min.): 36 rpm, table length: 4,000 mm, table width: 1,500 mm, tank capacity: 500 l, SHW PowerSpeed 5 Travel Ranges • X-axis (bed): 4,000 mm • Y-axis (vertical): 2,100 mm • Z-axis (spindle horizontal): 1,300 mm Control System • CNC control: Heidenhain iTNC 530 Feed Speed • X, Y, and Z axes: 2 - 30,000 mm/min • Acceleration: 3.5 m/s² Universal Milling Head in Orthogonal Design • Milling head swivel range (mounting): 360 x 1 degree • Milling head swivel range: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 – 4,000 rpm o Short-term: 36 – 6,000 rpm Automatic Tool Changer • Tool magazine for 48 tools Clamping Plate • Clamping surface: 4,000 x 1,500 mm Chip Conveyor • Fork length: 4,000 mm Coolant System • Tank capacity: 500 l Splash and Chip Protection • One-sided, with 2 manually sliding doors About the Company MBM Nodpfx Aew I Rz Hef Sewr MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is on tool milling machines. Our services include, among others, spare parts delivery, on-site customer service, machine overhauls, and control system modernization. Services: - Used machines - Spare parts - Customer service - Machine servicing - Machine overhauls - CNC control modernization ----- _____ Used machine – used milling machine – used traveling column milling machine – orthogonal milling head – metalworking – tool milling machine – milling head – SHW machine – SHW spare parts – used milling machine – used cnc milling machine – used boring and milling machine – used metal milling machine – used metal mill – used metal machining center – used cnc mill – cnc milling machines – milling machinery – large part machining – cnc large part machining – milling – shw – PS5 – PS 5 – Powerspeed – SHW PSZ 5 – SHW Powerspeed – SHW Powerspeed 5 – PSZ 5 – Heidenhain – MBM milling machine – MBM machine – column-type milling machine

Condition: excellent (used), Year of construction: 2002, x-axis 4000 mm y-axis 3500 mm z-axis 1500 mm Control SIEMENS 840 D w-axis 1500 mm column daylight 2500 mm surface area 3000 x 2000 mm workpiece weight 10000 kg spindle turning speed range 5-6000 U/min transmission ratio 2 power capacity - milling spindle 45 kW dist. cutter spindle - workpiece spindle 3500 mm max. torque on the spindle 1250 Nm tool change unit 200 -fach tool diameter 135 / 250 mm weight of tools max. 50 kg tool length - max. 400 mm tool taper ISO SK-50 the portal milling machine is in very good condition. Nodpfevwgmmex Af Sowr ADDITIONAL EQUIPMENT DRILLING/MILLING Angle milling head yes automatic tool clamping yes Tool clamping yes Ball screws yes Guideway cover yes Coolant system yes High-pressure cooling system (internal cooling) yes Full work area panelling yes Portal machining centre with tool changing system and second table top.

Year of construction: 2014, condition: ready for operation (used), - USED - TRAVELLING COLUMN CNC MILLING MACHINE WITH ROTARY AND SHIFTING TABLE LONGITUDINAL TRAVEL: 4000 mm Nwodpfswl R Amjx Af Ssr TRANSVERSAL TRAVEL: 1600 mm VERTICAL TRAVEL: 3000 mm RAPID FEEDS L-T-V: 30 m/min TRANSVERSAL TRAVEL OF THE TABLE: 1500 mm PALLET: 2000 x 2500 mm; 1200 rpm; 8000 Nm MAX ADMITTED LOAD: 30000 Kg HEAD: A/B AXIS AUTOMATIC ; MILLESIMAL POSITIONING ; ISO 50 ; 6000 rpm; 38 kW TOOL MAGAZINE: CHAIN-TYPE ; 80 POS CONTROL UNIT: HEIDENHAIN iTNC 530 HIGH PRESSURE COOLANT: 20 Bar ACCESSORIES: SWARF CONVEYOR ; TOOL SETTER

Condition: used, Year of construction: 2004, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,400 mm, CNC HEIDENHAIN iTNC 530 X-AXIS STROKE 6000 MM Y-AXIS STROKE 1400 MM Z-AXIS STROKE (VERTICAL) 2500 MM SPINDLE CONNECTION ISO 50 DIN 69871-B50 SPINDLE SPEED 5000 RPM MOTOR POWER S1 37 KW - S6 56 KW AUTOMATIC INDEX HEAD 1 ° X 2.5 ° TOOL CHANGER 40 PLACES COOLANT TROUGH THE SPINDLE AND EXTERNAL CHIP CONVEYOR ANCHORING PLATE 8000 X 2000 MM PERIMETER PROTECTIONS Njdpfxexhqivj Af Sewr

Condition: used, Year of construction: 1988, turning diameter over bed 2000 mm Nwedpfx Afoxn Tz Io Sor turning diameter over slide rest / mm turning length / mm - Type 1 K 671 320 F3 - Year of manufacture 1988 (first commissioned in 1998) - Turning length 10,000 mm - Turning diameter over bed 2,000 mm (modified) - Faceplate diameter 1,950 mm - Faceplate clamping range 400 - 1,350 mm - Speeds 1.00 - 140 rpm - Torque 125,000 Nm - Main cutting force 130 kN max. - Automatic swiveling tailstock - Max. workpiece weight 70 tonnes - Max. workpiece weight with steady rest 100 tonnes - Drive power 100 kW - Number of bed ways 4 - Dimensions 22,000 x 6,200 x 2,900 mm - CNC control SIEMENS 840D (2010 for €220,000.00) - Support feed X-Z 0.3 - 4,000 mm/min. - Support rapid traverse X-Z 4,000 mm/min. - Inner cone dimensions 140 x 1:7 - The machine complies with CE guidelines - Includes 2 steady rests, 1 roller block, 4 jaws, boring device - Condition: very good condition
