Used Doosan Dx180Nlc for sale (253)

Condition: used, Year of construction: 2023, operating hours: 113 h,

Condition: used, Year of construction: 2023, operating hours: 2 h,

Condition: ready for operation (used), Year of construction: 2022, travel distance X-axis: 1,050 mm, travel distance Y-axis: 570 mm, travel distance Z-axis: 510 mm, controller manufacturer: FANUC, controller model: i Series, overall weight: 6,500 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 18,500 W, number of slots in tool magazine: 30, number of axes: 3, This 4-axis DOOSAN DNM 5700 was manufactured in 2022. It features an X-axis travel of 1,050 mm, Y-axis travel of 570 mm, and Z-axis travel of 510 mm. The machine is equipped with a spindle speed of 12,000 rpm and a tool magazine capacity of 30 tools. If you are looking to get high-quality machining capabilities, consider the DOOSAN DNM 5700 vertical machining centre we have for sale. Contact us for further details. • Rapid traverse X/Y/Z: 36 / 36 / 30 m/min • Spindle torque: 118 Nm • Through-spindle coolant: 12 bar • Power supply: 380 V, 3-phase, 50/60 Hz • Standard-height column • Tool breakage detection Gjdpsz Rw U Aofx Ahdjbu • Ball screw nut cooling • Coolant level sensor Additional equipment • 4th axis • Hydraulic system (3A + 1B) • Automatic doors • Robot interface • Chip conveyor • Oil skimmer • Mist collector interface Technical Specification Taper Size BT 40

Condition: excellent (used), Year of construction: 2010, Turning diameter 376mm, turning length 760mm, Gbsdpfx Aez Rzzaohdsu bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees, 12 station turret , 22KW Motor, Main spindle 4,000 rpm, sub-spindle 4,500 rpm, 3 jaw chuck, parts catcher, toolsetter,

Condition: like new (used), Year of construction: 2022, functionality: fully functional, turning length: 725 mm, turning diameter over cross slide: 590 mm, turning diameter: 376 mm, spindle motor power: 30 W, spindle speed (max.): 2,800 rpm, spindle bore: 115 mm, travel distance X-axis: 280 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, torque: 1,112 Nm, bar passage: 103 mm, bar diameter (max.): 103 mm, quill stroke: 100 mm, quill diameter: 100 mm, quill travel distance: 100 mm, swing diameter over cross slide: 590 mm, spindle nose: A 2-11, swing diameter over bed slide: 720 mm, feed force X-axis: 9,465 N, feed force Z-axis: 17,379 N, Equipment: documentation/manual, rotational speed infinitely variable, As-new machine, only used for commissioning and combined with a Universal BIG 70 LoadAssistant holder. Can also be purchased separately. Gbjdpfx Aeyud Uashdju

Condition: excellent (used), Year of construction: 2017, operating hours: 2,742 h, functionality: fully functional, machine/vehicle number: MV0061-000661, travel distance X-axis: 762 mm, travel distance Y-axis: 516 mm, travel distance Z-axis: 570 mm, controller manufacturer: Fanuc, workpiece length (max.): 800 mm, workpiece width (max.): 550 mm, workpiece height (max.): 460 mm, total height: 2,580 mm, total length: 3,260 mm, total width: 3,130 mm, table width: 570 mm, table height: 880 mm, table length: 860 mm, overall weight: 9,200 kg, distance table center to spindle nose: 720 mm, spindle motor power: 15,000 W, number of slots in tool magazine: 30, input voltage: 380 V, type of input current: AC, Equipment: chip conveyor, documentation/manual, Doosan VC 510 (2017) – Vertical Machining Center with APC High-productivity 40-taper vertical machining center featuring a heavy-duty column-moving design and an integrated 2-pallet automatic pallet changer (APC). Key Specifications: Year: 2017 Control: Fanuc Travels (X / Y / Z): 762 × 516 × 570 mm Pallet Size (×2): 860 × 570 mm (Rotary APC, ~6 sec swap) Max Workpiece Size: 800 × 550 × 460 mm Max Table Load: 350 kg per pallet Spindle Motor (kW): 15(30min)/11(CONT.) Gbjdpfx Ahjz Atqrjdou Max. Torque (Nm): 191.1(30min) Tool Changer (ATC): 30 Tools Rapid Traverse (X/Y/Z): 40 / 40 / 32 m/min Guideways: Heavy-duty Roller LM Guides Machine Weight: ~9,200 kg Excellent condition, fully maintained, and built for continuous high-speed production. Contact for inspection and further details.

Condition: used, Year of construction: 2020, operating hours: 426 h, functionality: unexamined, machine/vehicle number: 1, spindle bore: 65 mm, spindle motor power: 18 W, rotational speed (max.): 4,500 rpm, total height: 1,700 mm, total length: 2,800 mm, total width: 20,001,700 mm, type of input current: DC, overall weight: 3,700 kg, swing diameter over bed slide: 600 mm, distance table center to spindle nose: 590 mm, spindle nose: 65, For the 2020 GT2100 Plus series, the screen-on time is 1260 operating hours, with 427 hours of active use. Gbsdsz Hc Tzopfx Ahdsu

Condition: used, Year of construction: 2022, operating hours: 1,000 h, functionality: fully functional, machine/vehicle number: 2, turning diameter over cross slide: 600 mm, turning length: 600 mm, turning diameter: 390 mm, spindle bore: 65 mm, travel distance X-axis: 230 mm, travel distance Z-axis: 600 mm, spindle motor power: 18 W, total length: 3,200 mm, total width: 2,000 mm, type of input current: DC, overall weight: 4,200 kg, spindle nose: 65, Equipment: documentation/manual, 2022 model, in excellent condition, with low mileage. Gbodpfxsz Hdbmo Ahdsu

Condition: good (used), Year of construction: 2012, functionality: fully functional, Machine parameters: Travel in X, Y, and Z axes: 1270 x 670 x 625 mm Table clamping area: 1300 x 670 mm Description: The machine is in good technical condition, and testing is possible by prior arrangement. It features a FANUC control system. The machine has a cast iron construction, linear guides, travel in the X/Y/Z axes of 1270/670/625 mm, table dimensions with clamping "T" slots of 1300 x 670 mm, table load capacity of 1000 kg, and a tool changer with 30 positions. Extensive accessories include: a 4th axis (rotary table), a hydraulic vice, a RENISHAW tool and workpiece probe, an oil skimmer, a three-color light signaling system, a chip conveyor, a Filtermist 6002 emulsion mist extractor, tool holders, etc. Gedoz Iw Ddopfx Ahdobu

Condition: ready for operation (used), Year of construction: 2020, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 105 mm, travel distance Z-axis: 830 mm, spindle motor power: 22,900 W, overall weight: 6,550 kg, controller manufacturer: SIEMENS, controller model: 828D, number of slots in tool magazine: 12, number of axes: 6, This 6-axis DOOSAN PUMA 2600 SY II was manufactured in 2020. It features a maximum turning diameter of 376 mm and a turning length of 760 mm. The machine is equipped with a powerful spindle speed range of 20–4,000 rpm and a robust turret with 12 tool stations. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA 2600 SY II horizontal turning machine we have for sale. Contact us for further details. • Controlled axes: X, Z, Y, B, C1, C2 • Slant bed: 30°Travels and rapid traverse • B-axis (sub-spindle) travel: 830 mm • C1-axis: ±360° • C2-axis: ±360° • Rapid traverse (X / Z / Y / B): 30 / 30 / 10 / 30 m/minMain spindle • Spindle nose: ASA A2-8 • Hydraulic chuck: 254 mm, 3-jaw Gbsdpfxez N Dhte Ahdsu • Max. torque: 730 Nm • Spindle bore: 91 mm • Drawtube ID: 82 mm • Integrated built-in spindle motor • C1 positioning resolution: 0.001°Sub-spindle • Spindle nose: ASA A2-5 • Hydraulic chuck: 170 mm, 3-jaw • Speed range: 60–6,000 rpm • Motor power: 18.2 kW • Max. torque: 220 Nm • Spindle bore: 62 mm • Drawtube ID: 50 mm • Built-in motor • C2 positioning resolution: 0.001° • Part ejector stroke: 120 mmMachining capacity • Max. swing over bed: 780 mm • Max. swing at front door: 680 mm • Max. swing over carriage: 630 mm • Max. turning diameter: 376 mm • Max. turning length between centers: 760 mm • Max. bar capacity, main spindle: 81 mm • Max. bar capacity, sub-spindle: 49 mm • Off-center milling capacity (Y-axis): 105 mm (±52.5 mm) • Max. cantilever workpiece weight: 260 kg • Max. workpiece weight using sub-spindle: 520 kgTurret and driven tools • Turret type: BMT-65 • Turret indexing positions: 24 • Tool stations: 12 (all 12 driven) • Indexing time: 0.15 / 0.65 sec • Turning tool size: 25 × 25 mm • Boring tool capacity: Ø50 mm / Ø32 mm • Driven-tool speed: 50–5,000 rpm • Driven-tool power: 4.1 / 7.79 kW • Max. driven-tool torque: 79.8 Nm • ER-32 capacity: Ø3–20 mm • Rigid tapping: Yes Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 2013, functionality: fully functional, Technical data, prices, and images can be found in the PDF files attached. Gbjdpfx Ahszuddyodju

Condition: like new (used), Year of construction: 2019, operating hours: 2,352 h, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: FANUC, controller model: 31i-B, workpiece weight (max.): 700 kg, table width: 500 mm, table length: 1,000 mm, table load: 700 kg, rotational speed (max.): 20,000 rpm, spindle speed (max.): 20,000 rpm, operating hours of spindle: 2,352 h, coolant supply: 30 bar, spindle motor power: 22,000 W, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, DOOSAN NX 5500 II VERTICAL MACHINING CENTER YEAR OF MANUFACTURE: 2019 CNC FANUC 31i-B SPINDLE: 20,000 RPM, 22KW, HSK-A63 TRAVEL: X 900, Y 550, Z 500 MM RANDOM TOOL CHANGER: 30 TOOLS, TOOL-TO-TOOL CHANGE TIME: 1.6 S DUAL CHIP CONVEYOR ELECTRONIC HANDWHEEL INTERNAL COOLANT SYSTEM: 30 BARS Gbjdpey Tvbkjfx Ahdou LASER PROBE FOR TOOL MEASUREMENT: RENISHAW NC4 PROBE FOR WORKPIECE MEASUREMENT: RENISHAW OMP60 WEIGHT: 9000 KG

Condition: good (used), Year of construction: 2010, operating hours: 115,503 h, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 670 mm, travel distance Z-axis: 625 mm, torque: 100 Nm, controller manufacturer: Fanuc, workpiece width (max.): 670 mm, workpiece weight (max.): 1,000 kg, total height: 2,940 mm, total width: 2,750 mm, table width: 670 mm, table length: 1,400 mm, table load: 1,000 kg, spindle speed (max.): 12,000 rpm, coolant supply: 8 bar, spindle motor power: 15,000 W, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 420 V, type of input current: three-phase, Equipment: documentation/manual, BT 40. No chip conveyor. Gjdpfxjyx U Nws Ahdebu

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, DIESEL COMPRESSOR DIESEL DOOSAN 7/20, recently serviced!!! Compressor with documentation for registration in Poland. Technical specifications: capacity: 2.00 m3/min; working pressure: 7 Bar; engine: KUBOTA operating hours: 295h!!! year: 2023 Gjdpfxez Rvzno Ahdsbu Compressor is in perfect working order, ready for operation, with warranty. net price: 27,500 PLN gross price: 33,825 PLN Below is a link to a video showing the machine in operation.

Condition: like new (used), Year of construction: 2015, operating hours: 2,500 h, functionality: fully functional, AVAILABLE FOR INSPECTION DURING PRODUCTION DOOSAN HORIZONTAL MACHINING CENTER Model: HM1250 Year: 2015 Gjdpfx Ahoz Ihnasdsbu Control Unit: FANUC 31I-B X-axis travel: 2100 mm Y-axis travel: 1500 mm Z-axis travel: 1500 mm Table length: 1250 mm Table width: 1250 mm Max. workpiece dimensions: DIAMETER 2300, HEIGHT 1725 Max. workpiece weight on table: 40000 kg Spindle speed: 6000 rpm Spindle connection: ISO 50 Torque (continuous / 10 min): 1989 Nm Number of tools: 90 positions High pressure: 70 bar

Condition: used, Year of construction: 2006, CNC lathe, 2-axis Doosan S280N, year 2006 Fanuc Oi Mate TB control Chuck diameter: 210mm (8 inches) Spindle bore: 51mm Gsdsz Rpg Depfx Ahdebu Turning length: 320mm Max. turning diameter: 280mm 10-tool turret Tailstock Parts catcher Chip conveyor with tank and pump Machine documentation

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,300 mm, travel distance Y-axis: 670 mm, travel distance Z-axis: 625 mm, controller manufacturer: Fanuc, controller model: Fanuc, table width: 670 mm, table length: 1,500 mm, table load: 1,300 kg, spindle speed (min.): 12,000 rpm, number of spindles: 1, Manufacturer: Doosan Model: DNM 6700 Year: 2018 Condition: (Used) Excellent Gedpfx Ahezwhtksdsbu Control: Fanuc Control Accessories: Kitagawa 4th Axis, Renishaw Spindle Probe, Tool Probe, Swarf Conveyor, Mist Extraction Unit & Manuals. LOCATION: COVENTRY, UNITED KINGDOM MACHINE SPECIFICATIONS Control: Fanuc Control X Axis Travel: 1300mm Y Axis Travel: 670mm Z Axis Travel: 625mm Max Workpiece Weight: 1300kg Spindle Speed: 12,000rpm Table Size: 1500 x 670mm Tool Change Capacity: 30 ATC Tool Size: BT40

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 510 mm, feed rate X-axis: 36 m/min, feed rate Y-axis: 36 m/min, feed rate Z-axis: 36 m/min, controller manufacturer: FANUC, controller model: i Series + Easy Operation Package, total height: 2,950 mm, total length: 2,160 mm, total width: 2,615 mm, table width: 450 mm, table length: 1,000 mm, table load: 600 kg, overall weight: 5,000 kg, spindle speed (min.): 0 rpm, spindle speed (max.): 8,000 rpm, operating hours of spindle: 5,025 h, coolant supply: 20 bar, spindle motor power: 18,500 W, spindle nose: SK40 (DIN69871), number of spindles: 1, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, We acquired this machine in working condition directly from the first owner, after it had completed its production cycle. The Doosan DNM 4500 from 2016, equipped with a FANUC control system, is a reliable 3-axis vertical CNC machining center. It is particularly suitable for general milling operations, working with steel/stainless steel/aluminum, and for series production. The machine will be fitted with 2 new original windows (currently on order)! Additional options & accessories: - Internal cooling (20 bar) - Electronic handwheel - DOOSAN Easy Operation Package - Chip conveyor - HAIMER 3D probe - AOF mist extraction system - Oil skimmer - Preparation for a 4th axis - All original documentation. Gbedpezzdh Eefx Ahdeu

Condition: good (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: ML0271-000198, spindle speed (max.): 6,000 rpm, spindle motor power: 15 W, total height: 1,600 mm, total length: 2,325 mm, total width: 1,600 mm, feed rate X-axis: 36 m/min, feed rate Y-axis: 36 m/min, feed rate Z-axis: 36 m/min, type of input current: three-phase, bar passage: 65 mm, Equipment: documentation/manual, We are offering for sale a DOOSAN LYNX 220LSYC CNC lathe with a tailstock, in good condition, manufactured in 2015. It operated for 2 years in medium-volume series production, and since then, it has been used to produce smaller series and custom parts. The machine is equipped with a chip conveyor, tool measuring device, a chuck with collet mounting, and a 3-jaw hydraulic chuck. It has powered tool holders (3 pieces). It includes an LNS bar feeder, capable of handling bars up to 3 meters in length (included in the price). Other features include: workpiece ejector, workpiece catching and delivery system, tool load monitoring, and an oil separator, which extends the coolant's lifespan. It also has a highly rigid cast iron machine bed and a turret with 12 tool positions (24 positions). The dimensions refer only to the lathe itself. Weight: 2900 kg (the weight of the bar feeder is separate). Gbsdoy Uwgqspfx Ahdju Net price. If you have any questions or require further information, please send us a message.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, ITALIAN — DOOSAN DVF-6500 Brand: DOOSAN Model: DVF-6500 Machine Type: 5-axis CNC machining center Year of construction: 2019 CNC control: Heidenhain TNC-640 X-axis travel: 750 mm Y-axis travel: 785 mm Z-axis travel: 600 mm B-axis travel: -120° / +120° C-axis travel: 360° continuous Rapid traverse rates X / Y / Z axes: 45,000 mm/min Working feed rates X / Y / Z axes: 20,000 mm/min B-axis rapid speed: 25 rpm C-axis rapid speed: 50 rpm Spindle mounting: ISO-40 Tool holder and pull stud: DIN 69871 A40 – DIN 69872 A40 Maximum spindle speed: 18,000 rpm Maximum spindle power: 30 kW Maximum spindle torque: 155 Nm Tilting rotary table: Ø 650 × 600 mm Maximum workpiece size: Ø 840 × H 500 mm Maximum workpiece weight: 600 kg Tool magazine: 60 positions Maximum tool diameter with adjacent positions occupied / free: Ø 75 / 125 mm Maximum tool length: 300 mm Maximum tool weight: 8 kg Machine dimensions: 3,700 × 2,450 × H 3,100 mm Machine weight: 14,500 kg Chip conveyor: Included Coolant tank: Complete with washing pumps Through-spindle coolant (CTS): High-pressure pump with external unit Measuring systems: Heidenhain scales on X / Y / Z axes Cooling unit: For spindle Tool presetter: Renishaw Workpiece probe: Renishaw Mist extractor: Included Magnetic table: Included Zero point clamping system: Included Tooling: Set of shanks/pull studs and various tools Documentation: Manuals, electrical diagrams and CE Declaration ENGLISH — DOOSAN DVF-6500 Brand: DOOSAN Model: DVF-6500 Machine Type: 5-axis CNC machining center Year of manufacture: 2019 CNC control: Heidenhain TNC-640 X-axis travel: 750 mm Y-axis travel: 785 mm Z-axis travel: 600 mm B-axis travel: -120° / +120° C-axis travel: 360° continuous X / Y / Z rapid traverse: 45,000 mm/min X / Y / Z working feed: 20,000 mm/min Gedez Atwfjpfx Ahdebu B-axis rapid speed: 25 rpm C-axis rapid speed: 50 rpm Spindle taper: ISO-40 Tool holder / pull stud: DIN 69871 A40 – DIN 69872 A40 Maximum spindle speed: 18,000 rpm Maximum spindle power: 30 kW Maximum spindle torque: 155 Nm Tilting rotary table: Ø 650 × 600 mm Maximum workpiece size: Ø 840 × H 500 mm Maximum workpiece weight: 600 kg Tool changer: 60 positions Maximum tool diameter with adjacent positions occupied / free: Ø 75 / 125 mm Maximum tool length: 300 mm Maximum tool weight: 8 kg Machine dimensions: 3,700 × 2,450 × H 3,100 mm Machine weight: 14,500 kg Chip conveyor: Included Coolant tank: Complete with washing pumps Through-spindle coolant (CTS): High-pressure pump with external unit Measuring systems: Heidenhain scales on the X / Y / Z axes Cooling unit: For spindle Tool presetter: Renishaw Workpiece probe: Renishaw Mist extractor: Included Magnetic table: Included Zero point system: Included Tooling: Set of shanks/pull studs and various tooling Documentation: Manuals, electrical diagrams and CE declaration

Condition: like new (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: ML0377-000140, turning length: 1,280 mm, turning diameter: 376 mm, spindle bore: 780 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 105 mm, travel distance Z-axis: 1,350 mm, spindle motor power: 22,900 W, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (min.): 200 rpm, turning diameter over bed slide: 780 mm, type of input current: three-phase, We offer this Doosan PUMA 2600LY II CNC turning and milling center in like-new condition, manufactured in 2020. The machine has not been put into operation and has not been turned on since it was new. Power-on time: 0 Model: PUMA 2600LY II Serial number: ML0377-000140 Supply voltage: 380 V Number of phases: 3 Frequency: 50/60 Hz Rated power: 49.06 kVA Interrupting capacity: 5 kA Current at full load: 74.65 A Short-circuit capacity: 10 kA Circuit diagram version: P210SYH840A07 Weight: 7400 kg Gedpfjy Nmdnox Ahdjbu Date of manufacture: 2020-11 - Hydraulic chuck 255 mm (10”) – 3-jaw, with a set of soft jaws and a set of hard jaws - Hydraulic unit - Coolant system with a high-pressure pump (min. 7 bar) - Box guideways for all axes – induction hardened - Slant bed (min. 30°) - Work area lighting - Front door safety switch - Leveling pads - Color monitor - Conversational/Graphic programming support - Turret (min. 12 stations) - Tool holder kit: min. 2 straight driven holders; 2 angular driven holders; 8 static holders for drills and boring bars - Full telescopic covers for guideways - Full machine enclosure - Programmable tailstock (MT5 center) - 3-color status light (stack light) - Automatic tool presetter / tool probe - Tool monitoring system - Electrical filter - Bar feeder interface - Automatic parts catcher and parts box - Thermal compensation function - Direct drive spindle - Spindle speed: min. 4000 RPM - Built-in network card (Ethernet) - USB port - Hinged belt-type chip conveyor - Oil skimmer - Toolbox - Radial driven tool holder x2, Axial driven tool holder x2 If you have any questions or require additional information, please send us a message or contact us by phone.

Condition: ready for operation (used), Year of construction: 2000, overall weight: 12,500 kg, Vertical, heavy-duty CNC turning machine with Fanuc control; 630 power chuck; 850 mm turning diameter; no driven tools; good condition; chip conveyor; various tool holders; Gedsz Ea E Eopfx Ahdebu machine manuals and documentation; without coolant tank and pumps – can be retrofitted if required; ideal for dry machining.

Condition: excellent (used), Year of construction: 2013, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, nominal power (apparent): 54 kVA, torque: 117 Nm, controller manufacturer: Fanuc, controller model: i Series, workpiece height (max.): 200 mm, workpiece diameter (max.): 300 mm, total height: 300 mm, total length: 2,465 mm, total width: 2,835 mm, table width: 200 mm, table load: 60 kg, rotary table diameter: 200 mm, overall weight: 5,500 kg, spindle speed (min.): 120 rpm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 11,000 h, coolant supply: 20 bar, spindle nose: DIN40, number of spindles: 1, number of slots in tool magazine: 30, tool length: 300 mm, tool diameter: 125 mm, tool weight: 8 g, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 2013 Doosan DNM 200/5AX 5 Axis CNC Machining Centre Used 2013 Doosan DNM 200/5AX (4+1) 5-axis CNC machining centre with Fanuc i Series control, probe, tool holders, spindle chiller, transformer, swarf conveyor and only 11,000 run time hours. Manufacturer: Doosan Model: DNM200/5AX Machine Type: 5 Axis (4+1) Machining Centre Year: 2013 Control: Fanuc Series i Control Hours: 11,000 Run Time Hours Machine Description 2013 Doosan DNM 200/5AX CNC Machining Centre, a compact, high-performance 4+1 - 5-axis vertical machining centre ideal for precision engineering, toolmaking, aerospace, medical, motorsport, mould and die, and complex component machining. This machine is fitted with a Fanuc i Series CNC control and has only 11,000 run time hours, making it an excellent opportunity for manufacturers looking for a reliable used 5-axis machining centre with strong capability, premium features and valuable accessories included. The Doosan DNM 200/5AX is well known for combining compact footprint, rigid construction and 5-axis positioning. It is ideal for reducing setups, machining complex parts and increasing productivity compared with conventional 3-axis machining. Key Features 2013 Doosan DNM 200/5AX 4+1 5 Axis CNC Machining Centre Fanuc i Series Control Only 11,000 Run Time Hours Includes Renishaw OMP60 probe Includes tool holders Includes spindle chiller Includes transformer Includes swarf conveyor Compact 5-axis machining solution Ideal for complex component machining Technical Specifications X Axis Travel: 400 mm Y Axis Travel: 435 mm Z Axis Travel: 500 mm A Axis Travel: 150 Deg (+30 to -120Deg) C Axis Travel: 360 Deg Table Diameter: 200 mm Max Load on Table: 60 kg Max Workpiece: 300mm Dia x 200mm High Spindle Speed: 12,000 rpm Spindle Taper: DIN40 Pullstud: Nikken PS-806 Tool Capacity: 30 Station ATC Rapid traverse (X, Y): 36000mm/min Rapid traverse (Z): 30000mm/min Rapid traverse: (A - tilt axis) 20 rpm Rapid traverse: (C – rotary axis) 30 rpm Maximum feedrate: (X, Y, Z) 15000mm/min Maximum feedrate: (A, C) 7200 deg/min Feedback system: Absolute encoder Max Tool Diameter: 125mm Max Tool Length: 300mm Max Tool Weight: 8kg Spindle motor AC: 11/18.5kW Axis motor (XYZ): AC 4.0kW Axis motor (A axis): AC 3.0kW Axis motor (C axis): AC 1.6kW Power Requirements: 54.0 kVA Air Pressure: 6kgf/cm2 Machine Dimensions: 2465 x 2835 x 3091mm Approx. Machine Weight: 5,500 kg Run Time Hours: Approx. 11,000 hours Gedpfxoy St Sdj Ahdobu Included With This Machine Renishaw OMP60 Probe Tool holders Spindle chiller Transformer Swarf conveyor Fanuc i Series CNC control Why Buy This Doosan DNM 200/5AX? This machine is a strong choice for companies searching for a used 5 axis CNC machining centre, used Doosan machining centre, Doosan DNM 200/5AX for sale, or compact 5-axis vertical machining centre. The 4+1 machining capability allows users to machine multiple faces of a component in fewer setups, helping to reduce handling time and increase production efficiency. With a compact table, high spindle speed and Fanuc control, this machine is particularly suited to small to medium batch production and complex prismatic parts. Applications This Doosan DNM 200/5AX is suitable for: Aerospace components Medical components Motorsport parts Toolroom machining Mould and die work General subcontract machining Complex 4+1 machining Notes: *Specifications are given in good faith but not guaranteed*

Condition: good (used), Year of construction: 2014, operating hours: 8,035 h, functionality: fully functional, machine/vehicle number: MH0017-000100, travel distance X-axis: 1,400 mm, travel distance Y-axis: 1,050 mm, travel distance Z-axis: 1,200 mm, controller manufacturer: fanuc, controller model: 31i, operating hours of spindle: 6,000 h, New Doosan horizontal machining center type NHP 8000 with Fanuc control unit type 31i Included equipment and options: Pallet centering system 800*800 Coolant supply with hand gun High-pressure coolant 70 bar, 7.5 kW with cyclonic filtration Automatic tool changer Tool load management Chip conveyor Gbodpowu Rgqsfx Ahdeu Renishaw RMP60 workpiece probe TS27R tool probe

Condition: ready for operation (used), Year of construction: 2017, operating hours: 2,738 h, travel distance X-axis: 650 mm, travel distance Y-axis: 765 mm, travel distance Z-axis: 520 mm, controller manufacturer: FANUC, controller model: i series, spindle speed (max.): 12,000 rpm, number of axes: 5, This 5-axis DOOSAN VC 630/5AX was manufactured in 2017. It features an impressive X-axis travel of 650 mm, Y-axis travel of 765 mm, and Z-axis travel of 520 mm. The machine includes a robust table size of Ø 630 mm and can accommodate workpieces up to Ø 730 x 500 mm with a maximum weight of 500 kg. If you are looking to get high-quality machining capabilities, consider the DOOSAN VC 630/5AX vertical machining centre we have for sale. Contact us for further details. • A axis travel: +30° ~ -120° • C axis travel: 360° • Rapid feedrate (X/Y/Z): 40 / 40 / 36 m/min (1574.8 / 1574.8 / 1417.3 ipm) • Rapid feedrate (A/C): 20 / 30 r/min • Table size: Ø 630 mm (Ø 24.8 in) • Max. workpiece size: Ø 730 x 500 mm (Ø 28.7 x 19.7 in) • Max. workpiece weight: 500 kg (130.1 lb) • Total operating hours (ACCESO): 5679 H 6 M • Total working time (TMP LAV): 2748 H 23 M 44 S • Total cutting time (TEMPO TAGLIO): 2400 H 32 M 35 S • Total parts count (PEZZI TOTALI): 103 Additional equipment • Chip conveyor Gbsdpfx Ahjz Hwgpsdeu
