Bevel Gear Testing Machine

KLINGELNBERG T60A

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm Ibjdpfxeukitxs Ad Njc total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2,35 x 2,24 x 2,5 m

Condition: used, Year of construction: 2012, Technical details: max. wheel diameter: 260 mm gear width: 320 mm max. module: 5 weight of the machine ca.: 21 t dimensions of the machine ca.: 8,71 x 5,97 x 3,49 m no. of teeth: 1...999 max. helix angle: +45/-45 ° pitch min.: 0,1 mm pitch max.: 1000 mm X-axis: 345 mm y-axis: 250 mm Ibedpfx Asy Amllsd Njc Z-axis: 320 mm b-axis: 360 ° c-axis: 360 °

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 32006, input voltage: 480 V, The Sprinter for Gears with Short Face Widths up to 100 mm The 100S Gear Shaping Machine is ideally suited for small face widths, for shaping spur and helical gears, internal and external, and for crowned and tapered gears. With only 6 m2 the 100S is one of the most compact machines of its class. Equipped with: Siemens Sinumerik 840D SL Control Hydraulic System 180 Degree Load System HSK-63 Spindle Auto Stroke Adjustment Chip Conveyor Chip Basket Flexlink Automation Festo Pneumatics Rittal Panel Conditioners Chiller 480/3/60, 35 KvA Motor & Controls Specifications: Workpiece With External Gear: -Largest Module (Steel W/Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Diameter: 100 mm Workpiece With Internal Gear: -Largest Module (Steel With Approximate 600 N/mm2): 3 mm -Maximum Width: 26 mm -Maximum Swing Diameter: 150 mm -Maximum Internal Diameter: 100 mm Tool: -Locating Cone In The Cutter Spindle: HSK-D63 -Diameter Shaping Spindle: 85 mm -Maximum Stroke Length: 30 mm Machine Travel Distances: -Radial (X-Axis): 180 mm -Column Tilting (B-Axis): -1 - +11 Degrees Machine Workpiece Table: -External Diameter: 220 mm -Clamping Diameter: 160 mm -Bore: 63 mm Speeds: -Feed Rate X-Axis: 12,000 mm/min -Workpiece Table (C-Axis): 0-400 min-1 -Cutter (C2-Axis): 0-300 min-1 -Spindle Stroke (A-Axis): 500-3,000 min-1 Electrical Equipment: -Operating Voltage: 480V -Supply Voltage: 115V -Control Voltage: 24V -Frequency: 60 Hz -Connected Load of Machine: 35 kVA -Cable Cross-Sectional Area: 35 mm2 -Protection: 80 A Machine Overall Dimensions (L x W x H): 3,380 x 3,950 x 3,015 mm Weight of Machine: 7,800 kg Ibjdpfjrtrvyex Ad Nec

Condition: ready for operation (used), Year of construction: 2019, travel distance X-axis: 540 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 700 mm, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 5, This 5-axis DMG Mori Seiki LaserTec 50 was manufactured in 2019. It features a Celos with Siemens 840D sl Operate control, integrated ytterbium cw fiber laser, and a compact design with a 4 m² footprint. Ideal for machining diamond tools with dimensions up to Ø 355 mm and 420 mm in length. If you are looking to get high-quality laser machining capabilities, consider the DMG Mori Seiki LaserTec 50 machine we have for sale. Contact us for more information. • Control: CELOS with Siemens 840D sl Operate; 21.5" ERGOline Control with multi-touch screen • Processes: Laser fine cutting, laser drilling, laser welding • Work capacity: Machining diamond tools up to Ø 355 mm and 420 mm in length • Axes/table: NC swivel rotary table; 5-axis transformation; high-dynamic torque motors in B and C axes • Drives: Linear drives in X/Y with acceleration > 1 g • Laser source: Integrated ytterbium CW fiber laser; 450 W QCW ytterbium fiber laser with 4,500 W pulse peak power and 450 W average power • Processing head: 80 mm focal length; collision switch • Vision: Camera through beam path for fiber laser • Construction: Solid mineral cast base • Footprint: Approx. 4 m² • Condition/usage: ~100 working hours (as new) • Notes: CNC precision laser machine with high-speed processing; highly dynamic and precise Additional equipment Iedjyfv Tvopfx Ad Nobc • Fanuc robot automation • Keller automatic extraction system • Basement exhaust extraction system

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 1028, Thread Rolling Machine LEISTRITZ RT 400-CCA Year of manufacture: 2004 / Control system retrofit in 2019 Connection voltage: 3x400 V Frequency: 50 Hz Isdpfxoxytmhj Ad Njbc Rated power: 65 kW Main fuse: 125 A Operating pressure: Air: 6 bar, Oil: 270 bar Control voltage: 24 VDC Maximum shaft length: 275 mm Minimum shaft length: 125 mm Maximum roll set diameter: Tool Ø69.85: 215 mm, Tool Ø80: 210 mm Minimum roll set diameter: Tool Ø69.85: 176-178 mm, Tool Ø80: 176 mm Maximum rolling force: 40 t Space requirement: 3.4 m x 2.9 m x 2.2 m Weight: 4900 kg Accessories: - Coolant filtration system - Second spindle pair (1x for tools Ø69.85 mm, 1x for tools Ø80 mm)

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, CNC Spiral Bevel Gear Cutting Machine Gleason No 631 Year of manufacture: 2011 Control: SIEMENS 840d Retrofitted in 2011/2012 with new control, drives, etc. The machine was fully overhauled in 2011. A new control system and drives were installed. Ibjdpfxsw Tfb Ss Ad Noc

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Ibsdpfxjw N S E Aj Ad Njc Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2007, pressure 20 - 300 kN adjustment of rolling slide 50 mm diameter of rolling spindle 120 mm Ibjdpfx Adjw E Nmkj Njc roll spindle height over machine bed 200 mm Control SIN 840 D taper length of the roll spindle 200 mm rolling spindle turning speeds 0 - 50 1/min torque per rolling spindle 2700 Nm power capacity 2 x 8,4 kW distance between rolling spindles min. 271 / max. 368 mm rolling tool outer diameter max. 300 mm total power requirement 26 kW weight of the machine ca. 7,1 t dimensions of the machine ca. 9,70 x 4,50 x 3,80 m CNC machine for gear cold rolling / thread rolling Hydraulic rolling process Felsomat loader cell Complete housing

Condition: excellent (used), Year of construction: 2007, max. wheel diameter 400 mm weight of the machine ca. 4 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : Iedpfxjxvdrys Ad Nebc KLINGELNBERG Single- and double-flank rolling test machine with structure-borne sound testing model R 30 year 2007 _____ Workpiece outer diameter min. / max. 36 / 300 mm Center distance between workpiece and counter wheel 135 - 290 mm Spindle speeds max. 3.000 rpm Drive torque max. up to 2196 rpm 20 Nm Drive torque max. 2196 – 3.000 rpm 14,7 Nm Spindle drive 4,62 kW Total drive approx. 10 kW - 400 V - 50 Hz Total weight approx. 4.000 kg Accessories / Special Features: • The machine is a universal rolling tester designed for the following testing procedures: o Single-flank rolling test o Double-flank rolling test o Structure-borne noise testing in single and double-flank contact o Helix testing in double-flank contact • WINDOWS PC control for measurement data acquisition and analysis with the NoisyS32 testing software • SIEMENS control panel for operating the machine and evaluating the test cycles • Complete enclosure with electrically monitored sliding doors • Attached control cabinet, various accessories, operating instructions • Unfortunately, the license dongle for activating the measurement software is currently missing. We hope to receive it from the supplier of the machine. Condition : very good condition ! Almost unused ! Soon : Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection gear machines – CNC or conventional - available. Please let us know your requirements.

Condition: used, Year of construction: 2003, max. wheel diameter 275 mm gear width 58 mm max. module 13 min. module 2 Control SINUMERIK 840 D number of teeth 5 - 200 ratio of transmission 10:1 cutter diameter max. 228 mm x-axis 25 - 350 mm y-axis +/- 175 mm z-axis 125 - 600 mm b-axis -5 / +90 ° total power requirement 75 kW weight of the machine ca. 11,7 t dimensions of the machine ca. 12,5 x 3,0 x 3,0 m Both Spindles retrofitted in 07/2026 Equipped for dry milling Isdpfxox R U E Nj Ad Nsbc Pressure deburrer Deburring device with driven brush Integrated magnetic chip conveyor Promot Cellmaster Cartridge pulse filter system User interface control works with Gleason Summary
