Plate boring mill

IMB Horizontal

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, Cylindrical grinding machine – external / Manufacturer: WMW / Type: SA 6U x 3000 / YOM/Completely overhauled: 2013 (machine overhauler/carried out by SerWeMa/Germany) Range of parts: Straightening rollers, grinding spindles, general shaft machining. Special feature: Machining with up to 6 steady rests. Ledpexymdaefx Aaxorg The machine can be inspected under power by appointment. TECHNICAL DATA: Working range: - Centre height: 260 mm - Max. swing diameter: 515 mm - Max. grinding length: 3.000 mm - Max. grinding diameter: 515 mm - Max. workpiece weight: 500 kg Workpiece headstock: - Speed continuously variable: 12.5 - 355 rpm - Centring tip: Morse K5 Tailstock: - Max. quill stroke: 40 mm - Centring tip: Morse K5 Grinding headstock: - Grinding wheel: * Max. outer diameter: 630 mm * Width max.: 125 mm EQUIPMENT: - Extraction system - Documentation - CE marking No guarantee is given for the completeness and accuracy of the technical data and equipment. - Subject to prior sale -

Condition: refurbished (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 193 34-41, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,600 mm, table load: 2,500 kg, spindle diameter: 102 mm, spindle speed (min.): 4 rpm, spindle speed (max.): 1,600 rpm, total height: 3,500 mm, total length: 6,500 mm, total width: 4,700 mm, table length: 1,400 mm, table width: 1,250 mm, year of last overhaul: 2025, Equipment: rotational speed infinitely variable, The machine was overhauled and modernized in 2025 and is immediately ready for operation! Travel paths: - Table cross travel (X-axis): 1600 mm - Spindle head vertical travel (Y-axis): 1250 mm - Table longitudinal travel (Z-axis): 1475 mm (restriction due to large table) - Quill travel (W-axis): 710 mm - Table rotation (B-axis): 360 degrees Clamping table: - Clamping surface: 1250 x 1400 mm - Table load capacity: 2.5 t Spindle: - Diameter: 102 mm - Tool holder: DIN2080, SK 50 - Infinitely variable speed: 4 – 1600 rpm - Drive power: 13 kW Feed: - X, Y, Z axes, stepless: 1 – 4000 mm/min Rapid traverse: - X, Y, Z axes: 4 m/min Power consumption: 42 kW Weight: 10 t Space requirements (L x W x H): 6.5 x 4.7 x 3.5 m Equipment: - Heidenhain TNC 320 Ledpfx Ajw Rn R Rjaxsrg - Coolant device

Condition: ready for operation (used), Year of construction: 1978, travel distance X-axis: 4,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 2,066 rpm, table width: 1,000 mm, table length: 6,100 mm, overall weight: 19,000 kg, 3-axis Newall display with variable feed rate 50-speed head with continuously variable spindle speeds, max. 1,500 rpm 6100 x 1,000 mm table 4500 x 1,000 x 1,000 mm stroke Lrsdpfx Asvz Aydeaxeg 19-ton weight

Condition: used, Year of construction: 1961, ram hammer weight 750 kg ram hammer stroke 660 mm no. of strokes 100 /min impact energy 2040 kJ distance lower die block / ram gudeway 6600 mm Throat 750 mm steel forging - rectangular up to 240 mm steel forging - diameter up to 270 mm power requirement 75,0 kW weight of hammer 16,5 t weight of anvil 15,5 t weight 32,0 t Lodpevuulljfx Aaxorg dimensions (WxDxH) 3,2 x 1,45 x 3,45 m Forging hammer with pneumatic drive can only be offered without putting into operation in our warehouse video at seller's site before dismantling available

Condition: like new (used), turning diameter: 1,500 mm, MAXIMUM WORK DIAMETER : 1600 mm. MAXIMUM WORKING LENGTH : 3000 mm. DIAMETER OF LANTERN SHAFT : 83 mm. OUR MACHINE IS ACTIVE WITHOUT ANY PROBLEMS ALL REVOLUTIONS AND AUTOMATICS ARE IN VERY GOOD CONDITION Lrsdpfxjr Ui R Nj Aaxsg

Condition: excellent (used), functionality: fully functional, Year of construction: 2012, Load capacity 4,500 kg Overall height 2,705 mm Lredpowvtf Sefx Aaxjg Lifting height 5,675 mm Mast type Triplex Fork length 2,400 mm Drive Electric Incl. fork positioner Incl. sideshift New UVV inspection & maintenance

Condition: like new (used), MACHINE DATA TORNI TACCHI FTC model 51 OVERALL DIMENSIONS Center distance 4000 m/m Height 1550 m/m Width 1400 m/m Length 6200 m/m Weight 10.000 Kg Swing over bed 1120 m/m Swing over carriage 810 m/m Swing over gap 1350 m/m Hole through spindle 123 m/m Number of speeds 18 Range of speeds 7-550 / 1’ Ledpfx Aod Tm D Eeaxjrg Horsepower of motor 25HP Morse taper № 6 Metric threads – inch – module – pitch 3 jaw chuck 450 m/m Face plate 850 m/m Extra face plate 1420 m/m Good condition

Condition: good (used), Centre distance: 6500 mm Lodpsw R Avbsfx Aaxsrg Centre height: 665 mm Swing diameter over bed: 1270 mm Turning diameter over cross slide: 1000 mm Spindle speed: 3.55-710 rpm Faceplate diameter: 1200 mm X-axis travel: 600 mm Main spindle bore: 128 mm Tailstock quill diameter: 200 mm Tailstock quill travel: 350 mm Tailstock quill taper: DIN 55028 Main spindle nose: DIN 55027 Accessories: 3 steadies, documentation

Condition: as good as new (ex-display), Year of construction: 2025, Max. over bed diameter: 330 mm Max. swing diameter without bed bridge: 476 mm Max. swing diameter over cross slide: 198 mm Center height: 165 mm Turning length: 500 mm Spindle end: D1-4/DIN55029 Spindle bore: D38 mm Can be cut threads: Metric, Whitworth, Module Spindle speed: 70 – 2000 rpm Lsdpsxb Axcsfx Aaxerg Tailstock taper: Morse 3 Motor power: 1.1/1.5 kW Machine weight: 500 kg Machine dimensions: 1320 x 610 x 1400 mm Accessories, Equipment - 3-jaw D160 mm chuck - 4-jaw D200 mm chuck - 4-station tool post - Electromechanical spindle brake - Follow and stationary steady rest - Coolant system - Halogen work light - Feed guard - Splash guard - Manuals The machine is in brand new condition. Operating hours are 0. Showroom machine.

Condition: used, Year of construction: 1985, functionality: fully functional, travel distance X-axis: 4,700 mm, travel distance Y-axis: 2,250 mm, travel distance Z-axis: 1,300 mm, total width: 3,000 mm, total length: 8,710 mm, total height: 5,250 mm, spindle diameter: 130 mm, table load: 16,000 kg, table length: 2,200 mm, table width: 2,200 mm, overall weight: 40,000 kg, Accessories: 2 different heads 1 faceplate Ledpew Hr Hpefx Aaxjrg
