Center Lathe

COLCHESTER MASTER VS 3250

Condition: ready for operation (used), Colchester Master 3250 Lead-/Feed-Screw Lathe | Lathe | Turning Machine Swing over bed: 350 mm Dedpfx Ajy Nknksffeut Swing over cross slide: approx. 196 mm Center height: 170 mm Spindle bore: 42 mm Spindle speed: approx. 20–3250 rpm Distance between centers: 1250 mm Main motor: 7.5 kW (10 HP) Thread cutting: - Metric pitch 0.2 – 14 mm (51) - Inch thread T.P.I. 2–56 (56) - Module threads, pitch 0.2 – 3.5 (20) - Diametral pitch (D.P.) 8–56 (20) You are welcome to arrange a viewing appointment. We can also organize cost-effective shipping for you! You will receive a proper invoice. For international customers, we can also provide a net invoice. A valid VAT ID number is required. Subject to prior sale. Visit our shop and check out our other listings. Brand names and trademarks mentioned are property of their respective owners and are used for identification and description purposes only. Deviations in technical data and errors in article description may occur and are subject to change.

Condition: new, The Servoturn 500/1000, a remarkable addition to the Conventional Horizontal Lathes category, exemplifies the innovative approach of KNUTH in the Servo-conventional Lathes group. This machine integrates cutting-edge feed technology with the reliability of traditional engineering. Its electronic hand wheels and ball screw drives enhance precision, enabling high-torque servo motors to execute feed movements with unrivaled dynamics, surpassing standard lathe capabilities. The user-friendly interface allows operators to select feed and thread pitches effortlessly, while the rapid traverses minimize downtime, ensuring high productivity. A robust machine frame and heavy-duty tailstock guarantee stability and performance, making it suitable for heavier materials. The Servoturn 500's standard equipment includes a quick-change tool holder, a 3-axis position indicator, and a reliable coolant system. Experience unparalleled turning with this advanced machine. To learn more, request a quote today and elevate your machining capabilities with the Servoturn 500/1000, a stellar choice in the Servo-conventional Lathe market. Duedpfol Iy Sisx Affst

Condition: new, Year of construction: 2026, 0350 mm 196 mm 0650 mm Dedpfx Afexxb Azjfjut 170 mm 42 mm 7,5 kW

Condition: excellent (used), Swing over bed 360 mm Distance between centers 650 mm Spindle speeds 20-3250 rpm Misc. accessories Dedsrx Rwnepfx Affsut MARCELS MASCHINEN CH

Condition: new, Year of construction: 2025, tube diameter 48,3 mm wall strength 3,25 mm bending radius min. max. 180 mm Bending speed 20 °/sec Duedoxcuicspfx Affot total power requirement 2,4 kW weight of the machine ca. 700 t dimensions of the machine ca. 3880 x 800 x 1250 m Description: Round tube steel (S235): 60.0 x 6.0 mm Round tube stainless steel (S 355): 60.0 x 4.0 mm Square tube steel: 50 x 50 x 4.0 mm Rectangular tube steel: 60 x 40 x 2.0 mm max. usable length: 3048 mm Bending speed: 10°/sec including tools (see photos) Mandrel is no longer available, can be retrofitted

Condition: new, Year of construction: 2025, control type: CNC control, degree of automation: automatic, actuation type: electric, pipe diameter (max.): 65 mm, pipe length (max.): 3,000 mm, tube wall thickness (max.): 3 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, number of axes: 5, warranty duration: 12 months, Equipment: CE marking, documentation/manual, emergency stop, foot remote control, STANDARD EQUIPMENT • 3 sets of dies (1 set of rolling die and 2 sets of bending dies, or 3 sets of bending dies, according to required dimensions) • 5-axis servo control (Y, B, C, H, V) • Servo motor-driven feeding axis • Servo motor-driven rotation axis • Servo motor-driven bending axis • Servo motor-driven H and V axes Djdpfsxircgjx Affjut • 21” TFT touchscreen mobile CNC control unit • Rolling capability • 3D bending simulation • Collision simulation • Daily, weekly, and monthly total operation status reports • Calculation of working material length • Calculation of estimated bending time • Conversion from X-Y-Z to Y-B-C • Mobile foot pedal with emergency stop feature • Remote assistance • Bending with or without mandrel • Safety plate behind the bending head • Hydraulic clamping • Hydraulic mandrel • Hydraulic support • Hydraulic linear slide system • Hydraulic claw clamp • Electrical panel safety lock and main switch panel lock • Electrical system cooler • Overload protection • Automatic dispatch of detailed operation reports OPTIONAL EQUIPMENT (Not included in price) • Additional die sets • Safety mat (750 x 1000 mm) • Safety mat (1000 x 1500 mm) • Hydraulic oil heater • Additional mandrel length (up to 6 m, priced per meter) • Ball mandrel and wiper die set • Automatic mandrel lubrication system (for suitable tube diameters) • Hydraulic oil cooler CAPACITY MB-65 CNC/5 AXIS Maximum capacity mm: Ø65x3mm Maximum bending radius mm: 250mm Maximum bending angle °: 190° Hydraulic pressure bar: 50-200 Working length mm: 3000 Rotation tolerances: Adjustable Bending power kW: 22.5 Dimensions LxWxH mm: 6350x1400x1600 Weight kg: 3950

Condition: good (used), functionality: fully functional, Year of construction: 2009, Used tube bending machine from Jutec Dujdpfoyfmwxjx Affst Type: 5000 Capacity: up to approx. 40 mm Mandrel length: 4500 mm CNC controlled Automatic head Manually rotatable head with hydraulic clamping Incl. 3 sets of tools Year of manufacture: 2009 Very little used

Condition: used, turning diameter over bed 410 mm Duodjwz Ruzopfx Affet turning diameter over slide rest 260 mm turning length 1000 mm turning speeds 40 - 2000 U/min centre height 205 mm spindle bore 50 mm total power requirement 4,5 KW weight of the machine ca. 1,6 t dimensions of the machine ca. 2,4 x 1,3 x 1,5 m Leadscrew lathe - with copying device - 200mm 3-jaw chuck - 2x Multifix quick-change tool holders - Live center - Machine light - Chip tray

Condition: as good as new (ex-display), The Numturn S 560/1500 is a state-of-the-art CNC Flat Bed Lathe designed for the Lathes category, offering high performance for large workpieces. This machine boasts a robust box-way design that ensures maximum precision while facilitating heavy machining tasks. Its powerful Siemens servo motor drives the main spindle through a 4-step transmission, allowing for infinitely variable spindle speeds and high torque across various speeds. Equipped with an 8-station VDI tool changer, the Numturn S 560/1500 maximizes productivity and flexibility in operations. The user-friendly Siemens 828D control enables quick setup through two electronic hand-wheels, resembling manual lathe operation for enhanced user experience. With a hydraulic tailstock featuring high clamping force and a reliable automatic central lubrication system, maintenance is efficient and straightforward. For those looking to enhance their productivity, the Numturn S 560/1500 represents an excellent solution in CNC Flat Bed Lathes. To learn more about this machine or to request a quote, don’t hesitate to contact us. Dsdpfx Afeuyg Erofout

Condition: new, Cesurbend Mandrel Bending Machine/Tube Bending Machine PBNC-90 A Technical Specifications Max. Tube Diameter (mild steel): 90 mm Max. Tube Wall Thickness (mm): 4 Max. Bending Angle (°): 190 Tube Bending Rate (d/min): 3-6 Dodpfx Afjxvzursfout Max. Hydraulic Pressure (bar): 200 Max. Bending Radius (mm): 250 Tube Loading Length (mm): 3000 Bending Motor Power (kW): 15 Hydraulic Motor Power (kW): 5.5 Machine Width (mm): 1400 Machine Length (mm): 4500 Machine Height (mm): 1600 Machine Weight (kg): 3000 Features • On our standard NC machines, the distance and rotation after bending are achieved using the operator assistance and parallelism device. • You can bend more quickly and accurately by monitoring the progress and rotational positions of the bends carried out with our machines equipped with the NC Car System.
