Beam size: mm
Punching capacity: kN
air pressure - required: 8 bar
total power requirement: 14 kW
machine weight ab.: 80-170/je Maschine kg
MULTIFUNCTION PUNCH PRESS for alloy windows construction
- for Schüco alloy window frame, post and beam profiles S65
- for Schüco alloy wing profiles for alloy window system ROYAL S 55, S 65 and S 70
- for Schüco alloy door profiles Royal S65 door base profiles
- foot operation
- pneumatic air gun
- drilling automat for window constr...
Round: from Ø 12 mm to Ø 80 mm
Square: from 10 x 10mm to 70x70mm
Rectangular: 80 x 60mm
Full bar cutting: from Ø 12 mm to Ø 30 mm
Max cutting lenght: 3.000 mm
Min cutting length: 50 mm
Max. tube Thickness: 3 mm
Blade Ø: 250 mm
Blade Thickness: 2 mm
Automatic Tube Charger
round bar steel 33 mm
square edge steel 30 mm
L-beam 60 x 8 mm
hole diameter in sheet thickness 20 in 13 mm
hole punhing press: pressure 35 t
hole punching press: throat 320 mm
hole punching press: max. length of stroke 24 mm
hole punching press: capacity (dia. x thick.) 25 x 11 mm
hole punching press: capacity (dia. x thick.) 20 x 13 mm
total power requirement 1,5 kW
weight of the machine ca. 1,7 t
dimensions of the machine ca. 1,5 x 0,7 x 1,8 m
Type: HBP 530
Made in: 1996
Cutting range - Circle: 530 mm
Cutting range - square: 700x530 mm
Engine power (saw drive): 7.5 kW
Engine power - hydraulic pump: 2.2 kW
Lenght: 4100 mm
Width: 1300 mm
Height: 2300 mm
Weight: 3800 kg
PLC - controlled automatic punching machines for processing hollow sections and tubes up to dimensions of 80 x 80 mm or Ø 80 mm (punching machines for larger cross-sections can also be supplied on request).
SIEMENS® PLC - control with 15" color touch screen - including remote maintenance module
Punchable wall thicknesses 1 to 6 mm depending on punching diameter
Largest profile length 6,000 mm to 9,000 mm
- Two profiles or two tubes can also be transported with one feed carriage.
Plasma cutting machine for pipes and profiles
Plasma cutting machine for cutting pipes and profiles. The cutting contour is defined and create by the software. The created CNC code can send to the machine via USB or network. The program can be easily choose via the 12"touch display. The automatic cutting process is started after manual insertion of the workpiece.
- Tube length: max. 6000mm
- for round tube up to OD = 150mm max
- for square tube up to 101.6x101.6mm (4 "x4") max
- maximum pipe wei...
round bar steel 25 mm
square edge steel 22 mm
L-beam 70 x 7 mm
cutting capacity 100 x 10 mm
plate thickness 10 mm
total power requirement 1,3 kW
weight of the machine ca. 0,6 t
dimensions of the machine ca. 1,1 x 0,65 x 1,5 m
