PUNCHING MACHINE FICEP 604 N

FICEP

Condition: used, Year of construction: 2008, FICEP Tipo B 251 sheet metal processing center Year of construction 2008 - sheet metal processing center - Plate size max. 6000x2500mm - 1 drilling unit - 6-fold changer incl. marking tool - 1 punching unit (currently without function) Lhedpfxsy E N Dpo Am Teh - 12-fold tool changer for punching tools - Conveyor belt for finished parts - Hypertherm HPR 260 plasma source - Donaldson Torit DCE extraction system - Machine weight according to manufacturer approx. 23 tons Main Technical Specifications Plate specifications on infeed side: • Length max. mm 6000 min. mm 2500 • Width max. mm 2540 min. mm 500 Work piece specifications on outfeed side: • Length min. mm 200 • Width min. mm 150 Punching Capacities (on 400N/mm² plates) • Punching force kN 1000 • Maximum stripping force kN 100 • Maximum hole diameter in punching mm 100 • Max. diameter on 20 mm thickness mm 38 Other Specifications : • Thickness of the large plate min. mm 6 • Thickness of the large plate (punching operations) max. mm 25 • Thickness of the large plate (thermal cutting) max. mm 32 • Thickness of the large plate (drilling operations - with optional device) max. mm 100 • Positioning weight max. kg 5000 • Linear weight of the large plate max. kg/m 750 • Max. vectorial traverse speed max. m/min. 30 • Cross positioning speed m/min. 40 • Working level’s height mm 1100

Year of construction: 2007, condition: like new (used), FICEP 601 DZB CNC DRILLING LINE with 4 way SCRIBING FACILITY I-Beams (without camber): Web height minimum 60mm maximum 610mm. Flange width minimum 30mm maximum 310mm. UNP Channels (web downwards): • Web height minimum 60mm maximum 610mm. Flange width minimum 30mm maximum 300mm. Angles • Flange height (unequal flanges as well) minimum 50 x 50 x 5mm maximum 250 x 250 x 40mm. Lsdpfxjh N Taas Am Tjhh Flats • Width minimum 100nn maximum 610mm. Square tubes • Size minimum 60 x 60mm maximum 300 x 300mm. Rectangular tubes • Size minimum 60 x 30mm maximum 600 x 300mm. All beams • Maximum thickness that can be drilled 50mm. Maximum length (infeed) 12000mm.

Year of construction: 2012, condition: good (used), Ficep Gemini HD36 GANTRY PLATE Lsdpjivfc Refx Am Tshh PROCESSING CENTRE, AUTOMATIC CNC DRILLING, MILLING AND THERMAL CUTTING SYSTEM, serial no. 33275, year of manufacture 2012, 127mm max. thickness, 520N/mm² tensile strength, with fitted eight head tool holder, Hypertherm HyPerformance plasma HPR260XD power supply unit, galvanised steel ducting, Autchazioni AVV.2KW fume extraction unit, approx. 3.5m x 1.75m x 3.9m high, machine bed approx. 9.4m x 3.8m wide

Condition: excellent (used), Year of construction: 2011, Ficep 1003 DZB CNC Drilling / Sawing Line – Year 2011. 3 Spindles. Automatic Tool Changer. Scribing. Ledpfx Aexmvnusm Tehh Short Piece Removal. Hard Stamping. Gripper feed. Infeed and Outfeed Cross Transfers. 1000mm Section Capacity.

Condition: used, Year of construction: 2006, Web height min 80mm. max 1220mm. Flanges height min 42mm.max. 600mm. U channels min. 80mm 1200mm Flanges height min.45mm max 300mm. Angles min. 80x80x8mm max.300x300x50mm Flats min.100mm max.1220mm Square tubes min.80x80mm max.600x600mm Rectangular tubes min. 80x40mm max.1200x600mm Positioning weight max. 15000Kg Linear weight of the section to be handled max. 750Kg/m Carriage speed max. 30m/min. No. of drill heads 3 - two horizontal Drill Heads with single spindle - one vertical Drill Head with single spindle Max. drilling diameter 50 mm. - with tapered adaptor No.4 Max. thickness that can be drilled 75 mm. Spindle rotation motor per head (a.c.) 15 kW Spindle R.P.M. (with continuous adjustment by program) RPM 180 - 3000 Positioning stroke to suit the gauge line :- vertical drilling unit 20 to 1200 mm.- horizontal drilling units 10 to 600 mm. TOOL CHANGE - number of tools change devices n. 3 - number of tools to be changed n. 6 - adaptor size ISO 45 Model 1260 BH for sections cold sawing : Ljdjx N Iclspfx Am Tehh - sawing capacity at 90° min. 80 x 10 mm - sawing capacity at 90° 1250 x 600 mm - sawing capacity at 45° 800 x 600 mm - sawing capacity at 60° 500 x 500 mm - sawing band motor 11 kW - sawing speed 20÷100 m/min. - band size 67 x 1.6

Year of construction: 2010, condition: good (used), Main Technical Specifications Profiles to be processed • Max. section volume mm 1100 x 1100 • Bar length max. metres 12 Drilling Capacity • Drill heads no. 1 Lsdpfoig T Axex Am Tshh • Spindles per vertical drill head no. 1 • Drilling diameter max. mm 31.75 • Drilling diameter (with reduced feed) max. mm 40 • Power per head (a.c.) kW 5,5 • Program controlled spindle rotation speed with continuous variation RPM 180 - 1000 Other Specifications • X axis positioning speed (portal) mt/min. 20 • Y axis positioning speed (drill head) mt/min. 4

Year of construction: 2007, condition: excellent (used), 603 LBH Technical Description Lsdpfxel Si Uuo Am Tjhh Main Technical Specifications • Minimum sawing capacity at 90° min.mm 60 x 10 max.mm 610 x 310 • Sawing capacity at 45° mm 400 x 310 • Sawing capacity at 60° (available on two flanges only with relevant option) mm 250 x 250 • Mitering angles +45° / -60° • Toothed band size mm 34 x 1.1 • Toothed band speed m/min. 78 • Band motor power kW 4 • Working level height mm 850

Condition: like new (used), Year of construction: 2017, HYDRAULIC PUNCHING MACHINE FICEP MOD. SP 40 Good used in excellent conditions cCE. Power exerted: Ton 40 Maximum punching diameter on thickness: mm 32 x 10. Recess: mm 510 Working height: mm 955 Stroke length (punch) from 0 up to mm 40 Lhjdpswm Emvsfx Am Tsh Net weight: kg 860 Dimensions: mm 1365 x 665 x 1700 (h) Motor power kw 4. Large hole device up to diameter 46mm included in the supply.

Condition: used, Year of construction: 2016, machine/vehicle number: 0401-230047, The FICEP Tipo G31 sheet metal processing center for the economical processing of sheet steel and flat steel in steel construction and the steel trade. Lhsdpfx Ajrr Sqlsm Teh The Ficep Tipo G31 LG can drill, center punch, thread, countersink, mark, mill, oxy-fuel cut and plasma cut flat steel or sheet metal with a maximum sheet width of 3,100 mm and a sheet length of 14,000 mm in a single system. The CNC-controlled sheet metal processing center is equipped with two 26 kW drilling units. 2 tool changers, each with 24 tool stations for ISO 40 tool holders, are available for automatic tool changes. The system is suitable for sheet sizes: Sheet width: minimum 200 mm, maximum 3100 mm; sheet length: minimum 2500 mm and maximum 14,000 mm. A powerful and modern Hypertherm HPR 400 XD plasma source is available for plasma cutting. The system also has an oxyfuel cutting unit for thick material thicknesses. The drilling unit with a high torque and a spindle speed of up to 6,000 rpm is designed for drilling with carbide tools such as solid carbide drills, Nenok Multiplex interchangeable insert tools as well as for use with HSS coolant channel drills with a drilling diameter of 10 mm to 40 mm. The Ficep Tipo G31 machine is in very good condition and has only a few operating hours.

Condition: used, Year of construction: 2016, machine/vehicle number: 0605-240010, FICEP Flex FRC 1201 coping robot The Ficep FRC 1201 coping machine is part of the latest process in automatic CNC controlled thermal coping process. This modern CNC-controlled coping robot system is suitable for fast thermal cutting and notching of profile types H / U / L / flat and square tubes. The steel profile is positioned in the system at the position to be cut using a pulling gripper measuring carriage via the roller conveyor. A robot arm with the cutting units (oxyfuel or plasma) cuts the profiles at the selected position. The cut or notched finished components either fall into the collecting tray or are pushed out of the system by the measuring arm. Thermal cutting units: This Ficep profile support notching system Flex FRC 1201 is equipped for thermal cutting with oxyfuel and/or plasma. A Hypertherm HYPERFORMANCE PLASMA HPR 260 XD suitable for material thicknesses up to 32 mm is used as the plasma power source. Thicker material thicknesses or phase cuts greater than 32 mm are cut with the oxyfuel cutting unit. Transport system: On the infeed side in front of the Ficep Flex FRC notching system is a chain drag cross conveyor with a length of 11,150 mm. The profiles (components) can be conveyed in both directions. The profiles are then transported into the machine on a stable roller conveyor with a gripper measuring carriage. The system is designed for 12 m long profiles and therefore has 12 m roller conveyors with a roller conveyor width of 1. 300 mm on the infeed side and 12 m on the outfeed side.300 mm. 4 chain tractors with a length of 6,450 mm are available after the notching system to transport the finished components to the outfeed side. Lsdotwm Ubepfx Am Tjhh Mitrol CNC control and Pegaso software: The system is controlled by a modern CNC control system from Mitrol. The reliable CNC control is from Ficep's own manufacturer Mitrol with the Pegaso software including remote maintenance option and data transfer interface. Torit DCE filter unit The filter unit for the dirt extraction is from Donaldson Torit DCE Safety: via fence and light barriers Max. profile cross-section: 1,220 mm. Profile cross-section : 1,220 x 600 mm Min. material length : 2,500 mm Working height : 865 mm Weight: 7000 kg Weight of cover firing unit : 1200 kg This modern Ficep Flex FRC 1201 coping robot system is in very good condition.
