Zeiss CNC coordinate measuring machine - overhauled in 2018 - run less than 2 h weekly
According to Zeiss technician, machine is in top condition. Especially ceramic plate and guide rails are in mint condition. In addition, provision incl. latest software update.
TECHNICAL DETAILS
measuring range X x Y x Z: 900 x 1.800 x 700 mm
table height: 700 mm
MEASURING SYSTEM
Sensor system: RDS-CAA-select locking swivel joint
with +/- 180° adjustment range each and an increment of 2.5°, this results ...
Z-axis travel range: 200 mm
Bvpef7lwti
X-axis travel range: 200 mm
Tool diameter: 100 - 400 mm
Tool height: 50 - 200 mm
Manually rotatable using an ergonomic handwheel: D = 400 mm
colour: Gray
Description: Suitable for measuring axial runout of facing cutters. Can be tested and preset manually and tactilely with the dial guage. Accessories: Centering pin D32 mm, Ergonomic handwheel, Pneumatic spindle brake
x-travel 1400 mm
y-travel 1200 mm
z-travel 1000 mm
Control ZM
0ghxbkgv
total power requirement 0,5 kW
weight of the machine ca. 2 t
dimensions of the machine ca. 2 x 1,5 x 2 m
Espec temperature and climate test chamber
Here we offer an Espec temperature and climate test chamber.
Air cooled
Temperature and humidity chamber
Temperature range: -45°C to +180°C
Rate of change heating 6.3K /min
Cooling rate of change 4.8K /min
Humidity range: 10 to 98% r. h.
Inner dimensions: width 850 mm × height 1000 mm × depth 800 mm
External dimensions: width 1050 mm × height 1955 mm × depth 1805 mm
approx 680 liters
AC 400V 3φ, 50Hz 22A
Own weight approx. 510 kg
Refrigerant: R452A...
unused (Pinstamp) markingsystem. THe stand is not included with this offer!
The PINSTAMP TMP 1700/420 is a pneumatic single needle marker for permanent marking of components with 2D-Matrixcodes and text.
Features:
Markinghead TMP 1700
- Range: 38 mm x 63 mm
- Speed: 6 letters/sec
- Position accuracy: 0,025 mm
- Marking: 4-79 Punkte/cm
Wmzssf2f
- Depth of marks: 0,06-0,56 mm
- Max. height of letters: 36 mm
- Levelling of surface of up to 6 mm
- Materials can be marked: plastics and metal of up ...
Traverse X-axis: 200 mm
Y-axis travel: 350 mm
Z-axis travel: 250 mm
A-axis speed: 60 rpm
Workpiece holder: ISO 50
Workpiece diameter: 3 - 200 mm
Workpiece length: Max. 300 mm
Workpiece weight: max. 40 kg
Connected load: approx. 2kW (230 v / 50 Hz)
Dimensions W x D x H: 1245 x 1900 x 1470 mm
Weight: approx. 2400 kg
2szefe
colour: light gray RAL 7035
Suitable for fully automatic and touch-less measuring of cutting tools of all kinds. By means of 2 CCD matrix cameras, reflected-light and transmitte...
3D-Scanner ZEISS COMET - Steinbichler Typ LED 5M Blue LED
Ca90ffxwow
COMET 5M
Resolution 2448 x 2050
Measuring volume in mm³
Measuring field 45: 45 x 38 x 30
Measuring field 75: 74 x 62 x 45
Measuring field 100: 118 x 98 x 60
Measuring field 250: 255 x 211 x 140
Measuring field 500: 481 x 404 x 250
3D point spacing in µm
Measuring field: 45 / 75 / 100 / 250 / 500
18 / 30 / 48 / 105 / 196
Shortest measuring time in seconds ~ 1
Working distance in mm 760 for measuring fields 45 / 75 / 100 / 250...
Zeiss
Ck0r0ttc
Here we offer a used Zeiss multisensor coordinate measuring machine.
Technical data:
ZEISS 0-1 NSPECT 543 CNC multisensor coordinate measuring machine Measuring range: X= 500 mm, Y = 400 mm, Z = 300 mm Length measuring deviation according to ISO 10360-2:2009
for VAST XXT:
MPE_EO XN/2 {1 D) = {1.6 + U250)µm
MPE_EO XY {20) = {1, 7 + U250)µm
MPE_EO {30) = {1.9 + U250)µm,
Single probe scanning deviation Form according to ISO 10360-5:2010 MPE_PFTU = 1.9µm
Scanning probe deviation acc...
The measuring device DH exxactly.QS is used where a tape measure is too imprecise
and a caliper gauge is too short. Ideal for measuring panels made of wood,
aluminum, steel, plastic and glass as well as pipes, profiles and bars.
- Design as tabletop unit or on mobile base frame
- For dimensional inspection in the machine room, incoming goods or quality assurance
- Smooth-running guide for exact and fast measuring
- Safe measuring of long workpieces by one person
Rae7f
- Measuring range up to 7,0...
Workpiece diameter max.: 250 mm
Z-axis length: 42 - 360 mm
X axis Ø: 310 mm
Max. Tool weight: 45 kg
Workpiece length max.: 360 mm
tool holder: SK 50
Issra0aow
Repeatability: +/- 0.002 mm
projector: 20x magnification
Connected load approx.: 230 V / 50 Hz
Dimensions W x D x H approx.: 1030 x 580 x 930 mm
Weight approx: 95 kg
colour: Grey / blue
Suitable for measuring and presetting cutting tools. Accessories: 2-axis digital display TMA 32.
tank capacity: 2x40 l
work height max.: 750 mm
Biegzityph
output: 3 kW
dimensions LxWxH: 1,4x0,9x1,7 m
Test Station for moving components of all kind
application: two sided plant to install flexible mounting and test procedure sequences and - / or as a test bench for hydraulic systems/devices
consisting of:
2 x hydraulic pack Rexroth; motor capacity 2 x 1,6kW, tank volume 2x40 liter
table : 2 x both sides size 1240x400mm
mounting wall : grid wall , 2 x both sides, size 920x750mm
cabinet sectio...
Offered for sale, on behalf of a Major European Leasing Company
Olympus Industrial Endoscope
Comprising;
- Olympus iPLEX IV9000G Video Base Unit, SN: Y002101
- Olympus iPLEX IV9635G Endoscope Control Unit, SN: Y002448
- IV96G-AT 120D/FF iPLEX Tip
- (2) NC2040N029 Li-Ion Batteries
H7daryyh
- Associated Charges and Cables
- Manuals and Paperwork
- Wheeled Travel Case
Bought directly from Olympus UK, July 2021for more than £25,000 GBP (Exc. VAT)
Location: Leeds, UK (Shipping Options available, ...
Coordinate measuring machine Zeiss Prismo 10 - CNC
Year of manufacture: 2010
Current software version
Acceptance protocol from 2022
Measuring machine was little in use
Technical data:
Travels:
X-axis: 1.200mm
Y-axis: 2.400mm
Z-axis: 1.000mm
Probe: Vast Gold
Ciudj9jcew
With extensive probe and clamping accessories
The measuring device DH exxactly.TRP is used where a tape measure is too imprecise
and a caliper gauge is too short. Ideal for measuring panels made of wood,
aluminum, steel, plastic and glass as well as pipes, profiles and rods.
Design as tabletop unit or on mobile base frame
For dimensional inspection in the machine room, incoming goods department or quality assurance department
For daily control of own machine lines
Smooth-running guide for exact and fast measuring
Safe measuring of long wor...
Z-axis travel: 450 mm
X-axis travel: 200 mm
Workpiece diameter max.: 250 mm
Workpiece length max.: 450 mm
snap gauge diameter: 70mm
pneumatic connection: 6 bar
Workpiece holder: SK 50
Connected load: 230 V / 50 Hz
Itjse92
colour: silver grey/anthracite
Suitable for measuring and presetting all types of cutting tools and for measuring grinding wheel packs. The extensive and comprehensive software solution with intuitive graphic user guidance guides users quickly and reliably to precise measuremen...
Coordinates measuring machine
Manufacturer: Zeiss
Type: 0-INSPECT 5/4/3
Year of manufacture: 2016
Software: ZEISS CALYPSO
Technical data
Measuring range X/Y/Z: 500x400x300
Permissible temperature range: 18-22 °C
Operating hours: 462 h
Ciseokikzy
quantity 210 STK
amount 0
Various limit gauges
for the most part still original silicone protective cover available.
Limit gauge one-sided and double-sided version
various nominal dimensions from approx. 3 mm - 102 mm
various tolerances
P9ihdi0p
Complete overview on request
Tool measuring device presetting device Zoller smile400
Make: Zoller
Year of manufacture 2012 (new purchase 12/2012)
Was only about 14 days total in use, plant has only been unused covered.
Measuring range Z:400mm
Measuring range D:400mm
Equipment:
Ciluvd8zur
Windows 7 installed, upgrade to newer software or operating systems, such as Windows 10 possible.
You acquire a fully functional device. By possible upgrade of the software the device can be
conditions the device can be brought close to new...
Z-axis travel: 420 mm
Traverse X-axis: 200 mm
Workpiece diameter: Max. 420 mm
Workpiece length: Max. 400 mm
Max. Snap gauge diameter: d = 100mm
Workpiece holder: SK 50
Tool weight: Max. 10 kg
Repeatability: +/- 0.002 mm,
Display accuracy: 0.001 mm
Concentricity: 0,005 mm
Connected load: 230 V / 50 Hz
Compressed air connection: approx. 6 bar
Dimensions W x D x H: 1300 x 625 x 1600 mm
Weight: approx. 200 kg
colour: silver gray / anthracite
Suitable for measuring and presetting all types of cutting...
amount 201 STK
Cilfyswvws
- Various scrap thread ring gauges (approx. 85 pcs.)
Various tolerances and gauges Ø from approx. 10 mm - 29 mm
- Various good thread ring gauge (approx. 116 pcs.)
various tolerances and diameters Ø from approx. 10 mm - 26 mm
Complete overview on request
Terminal and trim box, road cell
-Terminal box: for up to 4 load cells
-Inputs and outputs: via PG screw connections
-Protection class: IP 65
-4 inputs, cable gland M12 for cable diameter: 2 to 6.5 mm
-1 output, cable gland M20 for cable diameter: 7 to 12 mm
Glu8rat
-Number: 2x available
-Price: per piece
-Dimensions: 205/110/H70 mm
-Weight: 0.8 kg
x-travel 1500 mm
y-travel 800 mm
z-travel 600 mm
total power requirement kW
weight of the machine ca. 2,7 t
Chggv9g3
dimensions of the machine ca. 2,66 x 1,60 x 3,10 m
Installation and calibration of the machine can be supplied by the
manufacturer MDM at site of installation at extra costs.
CNC-controlled Coordinate Measuring Machine for fully automatic
measuring of workpieces. Incl. Measuring Software MDM Metrosoft
Level 2 for measuring of:
- Points, surfaces, circles, cylinders, cones, ...
Here we offer you a Köhler Kesternich tester.
Overview technical data HK
HK 300 M
Power supply 16A,230V/50Hz
Compressed air 5,5 - 8,0 bar
Deionized water connection Automatic
Drain Automatic
Ventilation Automatic
Under table Includes
Inner dimensions 750 mm x500 mm x750 mm
External dimensions 920 mm x515 mm x1000 mm
Gf0nwch
Weight 40 kg
Type: HK 300 M
Condition: used / used
Scope of delivery: (see picture)
(Changes and errors in the technical data, specifications are reserved!)
Further questions...
Computer tomograph
Manufacturer: Wenzel
Type: exaCT M150 HE
Year of manufacture: 2009
General overhaul 2017
Operating hours: 200
New tube
New detector
Ciqbnupy
Fields of application:
Measurement and testing technology of small to medium-sized components.
The exaCT M is particularly suitable for non-destructive testing (NDT) of plastics, light metals,
composites and multi-materials.
.
Schenck Hydropuls 100kN test pulling station
Manufacturer [manufacturer]: Schenck GmbH Germany
Type [type]: Hydropuls
100kN
+software
Jyydj3
+PC, monitor, computer
+Complete documentation is available.
Viewing under power can be done at short notice.
For further questions we are at your disposal. Price, ex stock here plus VAT.
Condition: good - ready for demonstration
Delivery: ex stock - as viewed
Payment: net - after receipt of invoice
Subject to prior sale, errors excepted.
We ask for ...
quantity 206 Stück
Various plug gauges according to DIN 2245
Most of them still have their original silicone protective coating.
Various diameters from approx. 20 mm - 100 mm
2u878m
various tolerances
Complete overview on request
Measurement data acquisition device, test device, communication system, data acquisition system
Pq0fw38b
-DSM: Nanoserver 96M1566L
-suitable for: mobile applications
-Input: 8-30 V DC, 15 A
-Dimensions: 245/220/H120 mm
-Weight: 2.8 kg
