Contour measuring device, contour measuring device, contourograph, contourograph, roughness measuring device, roughness measurement, roundness measurement
-Manufacturer: optacom, contour measuring device type VC-10 with granite measuring plate
-Measuring plate: 950 x 380 mm
-Delivery: without computer and screen, see photos for accessories
-Transport dimension: 950/480/H775 mm
-Total weight: 182 kg
tank capacity: 2x40 l
work height max.: 750 mm
output: 3 kW
dimensions LxWxH: 1,4x0,9x1,7 m
Test Station for moving components of all kind
application: two sided plant to install flexible mounting and test procedure sequences and - / or as a test bench for hydraulic systems/devices
2 x hydraulic pack Rexroth; motor capacity 2 x 1,6kW, tank volume 2x40 liter
table : 2 x both sides size 1240x400mm
mounting wall : grid wall , 2 x both sides, size 920x750mm
Catalog No. : 6331
Type: M918 Techno
Made in: 2019
Measuring range: 900x180 mm
Max. dimension of the part: 925x240 mm
Max. weight of the part: 60 kg
Width: 920 mm
Depth: 1030 mm
Height: 2000 mm
Weight: 431 kg
Workpieces are fed in as bulk material, inspected, bad parts are sorted out and good parts are transferred to containers as bulk material.
Workpiece: Bolt, Ø 6 - 12 mm
Workpiece length: 33 - 56 mm
Cycle time: 1.8 s
Camera inspection (dimensions and surface defects)
- high-resolution matrix camera (21 Mp), dimensions
- line scan camera (4K), surface inspection
parts bunker SKAKO, 71 l volume
up to 125 kg storage
New price: € 230.000,-.
dist. between pillars (left to right) 600 mm
stroke 50 mm
max. loading 100 kn
total power requirement kW
weight of the machine ca. 1500 kg
dimensions of the machine ca. m
Universal tensile tester, Software ZWICK Testexpert
Terminal and trim box, road cell
-Terminal box: for up to 4 load cells
-Inputs and outputs: via PG screw connections
-Protection class: IP 65
-4 inputs, cable gland M12 for cable diameter: 2 to 6.5 mm
-1 output, cable gland M20 for cable diameter: 7 to 12 mm
-Number: 2x available
-Price: per piece
-Dimensions: 205/110/H70 mm
-Weight: 0.8 kg
Thickness sorter Gerber DS 200
it sorts and measures all small parts made of various materials.
The sorting is based on the smallest dimension of a part, which can be delimited by
two parallel surfaces.
In the thickness sorter, these parallel surfaces are formed by the ring-shaped measuring edges of two slowly rotating bells.
bells. The width of the measuring gap can be set precisely, parts below the set dimension pass through the gap. By gradually increasing the measuring gap, it is possible t...
checking height: mm
workpiece weight: kg
total power requirement:
machine weight approx.: auf Anfrage kg
dimension machine xH: auf Anfrage m
dimensions electric cabinet: m
Surface measuring and recording device SP6
2x feeding device PRK 6720702
1x measuring stand PST-Ue ( transverse = 165mm and vertical adjustment = 440mm) table size 650 x 450mm
1x measuring stand PST-Ve (vertical adjustment 450mm, motorized) + manual control unit; table size 65...
Tesa Scan 25 shaft measuring system
Optical shaft measuring system for fast measurement of asymmetric turned parts / shafts
up to a length of 250 mm
and min 0,5 mm - max 25(52) mm in diameter
very fast measurements
of different diameter
thread, thread pitch, flanks
and much more
high precision (0,005mm)
Inclusive measuring computer (Windows2000) and software Measure ect
Plant can be inspected under power.
Measuring Instrument for Measuring Contours and Roughness .
The machine was used by an international automotive company and is still at its original premises. The machine was inspected and secured for transport by Jenoptik. It is equipped by the manufacturer with a new PC with Windows 10 & software update to latest version of TURBO FORM
AF 40: 40 x 40 mm, bore 0 20 mm AF 50: 50 x 50 mm, bore 0 25 mm Modular clamping and fixing system for almost all applications in 3D measurement technology Profile lengths 400/800 / 1,600 / 5,000 [mm] Extensive accessories available: quick connectors, couplings, plug-in sockets, base plates + air bearing plates, Support bracket and much more
x-axis: 500 mm
z-axis: 685 mm
diameter: 300 mm
air pressure - required: 5 bar
tool table-turnable: 360°
Tool table: Dm=745 mm
tool diameter: ca. 290 mm
total power requirement: 0,5 kW
weight of the machine ca.: ca. 0,15 t
space requirement of the machine approx.: 2,38x1,45x1,94 m
Adjustment- and Measuring Device
- measuring range z = 680mm
- measuring range x = 500mm
- pneumatical slide clamping
- manual endless fine adjustment
- turret rotating table
- 220V/; 50/60Hz
For sale is the following item:
- Our offer number: 1/126
- inspection camera pipe inspection camera
- Manufacturer: Rothenberger
- Type: ROCAM
- Serial number : 970670820019
- power : 24 V DC/1 A
- with 30 m cable
- Camera head 30 mm
- Monitor in black / white
- With battery 18 V
- With power supply
- Dimensions : W x D x H 400 x 400 x 600 mm
- Weight : 14 Kg
- Optical condition according to photos
The goods offered here usually come from company liquidation...
Rothenberger Rocam 4 plus tube inspection camera, tube camera 30m
made by Rothenberger ROCAM 4 Plus
1 piece of 30 m cable,
1 40 mm camera head
1 CAS charger, EU - RO BC 14/36 - 50/60 Hz 85W Max. 3.0 A
1 db CAS battery, 18 V / 4 Ah;
1 guide ball 40 mm
1 control adapter for the camera head
1 GB SD card 4 GB
1 USB data cable
2 pcs ROCASE 4414
1 ROCASE transport truck
Display size: 10.4 "(Height: 19.81 mm Width: 26.42 mm)
- Easy to use, premium touch screen.
The form measuring center is not in use and can no longer be operated by anyone, therefore sell as defective / spare parts carrier.
Device must be picked up.
technical data according to manufacturer:
travel 300 mm
length 360 mm
Measuring force at 74 mm probe arm length 0,02 - 0,2 N
Measuring uncertainty Roundness deviation = 0.08 µm
axial runout = 0.12 µm
Straightness deviation Z = 0.19 µm/100 mm
Parallelism Z / C = 0.25 µm
Straightness deviation R = 0.19 µm/100 mm
Perpendicularity R / C...
Simply put on - measure - read off!
Small, intelligent coating thickness gauge with integrated probe.
Measuring range: 0 to 1,000 μm
NEW! LCD color display with auto-rotation function (lockable)
Now also one-point calibration possible
Mean value calculation (from up to 99 measured values)
Up to 60 measurements per minute!
Robust, durable ruby top
Available in two versions:
for non-magnetic layers (e.g., paint, varnish, chrome, etc.) on steel
Type: exaCT M150 HE
Year of manufacture: 2009
General overhaul 2017
Operating hours: 200
Fields of application:
Measurement and testing technology of small to medium sized components.
The exaCT M is particularly suitable for non-destructive testing (NDT) of plastics, light metals, composites and multi-materials.
Shock test machine
Here we offer a shock test machine.
Max speed 10160 mm per second without load
7239 mm per second with 68 Kg load
Up to 8 cycles per minute
Connection 230 V 50 Hz 1 phase
Air pressure : 7 - 9 bar
Memory for up to 10 test programs
H 1600 mm x W 813 mm x D 813 mm
Type: SM-105-MP +shock pad
Weight: 1547 Kg
Condition: used / used
Scope of delivery: (See picture)
(Changes and errors in the technical data, specifications are reserved!)
PALAS Mask test stand PMFT 1000
Mask test stand from the manufacturer PALAS, model PMFT 1000 with the following equipment:
- Integrated additional test device Promo® LED 2300
The mask tester PMFT 1000 (Protective Mask Filter Tester) is suitable for production monitoring of half masks. The overall penetration test is better than the standard, and the efficiency measurement is carried out in the range from 100 nm to 3 µm. The PMFR 1000 tests respirators better than EN 149/EN 13274-7 standards wi...
Convergence measuring tape, band extensometer, extensometer
-Manufacturer: Interfels, convergence measuring tape type KM-15
-Reading accuracy: 0.01 mm
-Accessories: see photos
-Dimensions transport box: 560/220 / H180 mm
-Weight: 6.8 kg
DIGI SM-5500B System Scale
SM-5500B, the advanced PC-based system scale printer that provides you with multiple retail solutions. Increases operational turnover, improves operations with integrated queuing and collection system through various innovative features of SM-5500B. Experience true retail solutions offered by DIGI's PC scales.
- Linerless printing with integrated automatic cutter
- Watermark printing
- Speed ID
- InfoTag and electronic signage e.Label
- Integrated queuing and collecti...
there are a total of 9 outside micrometers for sale.
They are from the drm. 0 - 200 mm
- Drm. 0 - 25
- Drm. 25 - 50
- Drm. 50 - 75
- dia. 75 - 100
- Drm. 100 - 125
- Drm. 125 - 150
- Drm. 150 - 175
- Drm. 175 - 200
Offered for sale, on behalf of a Major European Leasing Company
Olympus Industrial Endoscope
- Olympus iPLEX IV9000G Video Base Unit, SN: Y002101
- Olympus iPLEX IV9635G Endoscope Control Unit, SN: Y002448
- IV96G-AT 120D/FF iPLEX Tip
- (2) NC2040N029 Li-Ion Batteries
- Associated Charges and Cables
- Manuals and Paperwork
- Wheeled Travel Case
Bought directly from Olympus UK, July 2021for more than £25,000 GBP (Exc. VAT)
Location: Leeds, UK (Shipping Options available,...
Hommel Dura measuring plate / control plate made of natural hard stone
Hommel Dura measuring plate made of hard stone (granite plate)
length: 3000 mm
width: 1000 mm
thickness: 300 mm
1 x T-slot
More measuring plates in other sizes - new and used - you will find in our store!
