Used Cylindrical grinding machines 600-1099mm grinding length for sale (185)

Condition: excellent (used), Year of construction: 1988, Functionality: fully functional, (Delivery time: immediately in stock) The K11 was completely repaired and checked by us. Painting work was carried out. Of course, we are available to answer any questions you may have. You can also purchase spare parts from us at any time. Technical data / equipment: External grinding, internal grinding Center distance: 650 mm Center height: 180 mm Workpiece weight: 70 kg flying, 250 kg between centers Grinding wheel diameter: 400 mm Workpiece spindle: MK 4, speed continuously adjustable 30-450 rpm, swivel range 0 - 90 ° Tailstock: MK4, quill stroke 45 mm Quill force: 200-600 N Table inclination: 10 degrees Adjustment path of feed spindle: 80 mm Rapid traverse path: 50 mm Coarse adjustment of air cushion: 280 mm Grinding spindle motor outside: 4 KW Grinding spindle motor inside: 2.2 KW Workpiece spindle motor: 0.55 KW Machine weight: net 3600 Kg Feed drive via DC motor Air cushion-assisted quick adjustment of the grinding headstock for quick and safe approach to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic work process, feed movement via compass rose switch: Rapid forward, rapid reverse, grinding operation, feed stop, mym feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Fgjb Hafevz Aq Ne Ehob Workpiece headstock with continuously adjustable drive with rotating and lockable spindle. Feed control for longitudinal grinding and plunge grinding, input for retrieval, feed amounts, feeds, spark-out times, idle strokes New digital display for axes can be retrofitted (option) comparable to Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat

Condition: new, Year of construction: 2025, Functionality: fully functional, center height: 155 mm, workpiece weight (max.): 150 kg, grinding length: 1,000 mm, center width: 1,000 mm, grinding wheel diameter: 400 mm, total length: 1,000 mm, grinding diameter: 300 mm, quill stroke: 25 mm, workpiece weight between centers: 150 g, type of input current: three-phase, workpiece diameter between centers: 300 mm, workpiece length between centers: 1,000 mm, grinding wheel width: 50 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 5 rpm, feed rate X-axis: 4,000 m/min, feed rate Z-axis: 6,000 m/min, grinding spindle motor power: 5,700 W, warranty duration: 12 months, rapid traverse X-axis: 4 m/min, rapid traverse Z-axis: 6 m/min, workpiece spindle speed (max.): 600 rpm, space requirement height: 2,290 mm, Equipment: rotational speed infinitely variable,  Easy-to-use Z-Control system with high levels of comfort  Automatic infeed with dressing amount compensation  Fully automatic grinding cycle with dressing cycles  Grinding cycles: • Cylindrical grinding • Roughing / finishing / sparking  Simple operation via touchscreen  Large, clearly arranged 12.4" color screen  Electronic handwheel, effective on the X and Z axes, switchable in four steps to 0.0002; 0.001; 0.01; and 0.1 mm  Robust cast construction of all machine components  High machine weight for maximum rigidity Fjb Hafewax Rbs Ehsgb  Preloaded linear guide system in the X-axis (Bosch Rexroth) for outstanding precision  Ground sliding guides in the Z-axis as V-shaped flat guides ensure excellent damping properties and high-quality grinding pattern  Electromechanical longitudinal and transverse movement  Direct measuring system on the X-axis (Heidenhain) for precise positioning  Rotary encoder on the Z-axis  Maintenance-free belt filter system with a 270-liter tank capacity and a 3.5-bar pressure pump for effective cooling and rinsing  Upstream magnetic separator for pre-filtration  Power supply: 400 volts, 3-phase, 50 Hz  Continuously variable grinding spindle motor  Grinding spindle motor with constant cutting speed across the entire working range of the grinding wheel (vconstant)  Roller-bearing mounted grinding spindle guarantees a long service life  2 machine lights (LED)  Holder for dresser on the machine table for high accuracy and a permanently mounted dresser with the option of holding 3 dressing diamonds  Automatic Central lubrication in the Z-axis (slideway oil) and the X-axis (grease)  Fully enclosed machine with service and maintenance doors  Effective splash protection with easy accessibility  Pneumatically controlled tailstock Standard accessories consisting of:  Grinding wheel holder  Grinding wheel 400 x 50 x 127 mm  Complete documentation  CE declaration of conformity  Acceptance report according to DIN 8630  Leveling elements  Balancing mandrel  Roller support  Adapter flange for workhead  MT 4 center (tailstock)  MT 5 center (workhead)  1 set of turning centers

Condition: refurbished (used), Year of construction: 2025, IMMEDIATELY AVAILABLE Feb Hafefg Tbre Ehogb Studer S20-2 - Mechanically Reconditioned Grinding length: 400 mm Center height: 100 mm Table adjustment: 30° Bore diameter: 127 mm Grinding wheel dimensions: 350 x 32 mm WSS taper: MT4 (stationary and live center) RST taper: MT2 Quill stroke: 20 mm Workpiece weight: 20 kg Tailstock with manual cylinder error correction Other possible options: - Glass scale in X and Z axes - Internal grinding attachment - Grinding wheel flange - LED spotlight with flexible arm - Coolant system - Safety device

Condition: good (used), Distance between centers: 760 mm Maximum travel on the Z axis: 650 mm Maximum grinding length: 430 mm Maximum grinding diameter: 250 mm Fsbev Tmtlo Haf Ehjgb Height of centers: 125 mm Maximum grinding wheel diameter: 500 mm Maximum travel on the X axis: 320 mm CNC brand: FANUC CNC model: 18TB Main motor power: 7.5 kW Z and X axis resolution: 0.1 µmm Workhead taper: MORSE 5 Workhead hole diameter: 38 mm Tailstock taper: MORSE 4 Workhead rotation speed: 8 to 800 rpm Dimensions (length x width): 2500 x 2000 mm Weight: 4700 kg

Condition: used, Functionality: fully functional, For sale is a universal cylindrical grinding machine from the Strausser-kellenberger brand Technical data: Manufacturer: Strausak AG Maschinenfabrik (Switzerland) Model: 57U Voltage: 380V / 50 Hz Fjb Haf Ejv E Ivfshjgb Machine purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, visit us on our website

Condition: ready for operation (used), Year of construction: 2003, Control: Heidenhain Grinding length 1000 mm Center height 175 mm B-axis Feb Hafer Dbltj Ehegb Grinding wheel dimension 400 mm Grinding spindle speed 2000 rpm Cooling system Measuring probe Hydrostatics

Condition: used, Technical details: grinding length: 600 mm Fgjberkr U Ej Haf Eheb centre height: 180 mm swing dia.: 360 mm workpiece weight: 80 kg max. dia. of grinding wheel: 500 mm grinding wheel width: 80 mm grinding wheel hole diameter: 203,2 mm peripheral speed: 45 m/sec There is also a 3200 liter coolant tank including cooling unit + fire extinguishing system. *

Year of construction: 1971, Condition: good (used), 1 used cylindrical grinding machine, make Cincinnati, type R 75, year 1971 centre height 130 mm grinding length 760 mm Fgeb Haehf I Icjf Eheb spindle bore 38 mm grinding wheel diameter 300 mm, width 40 mm Workpiece weight 75 kg. max. grinding spindle double swivelling

Condition: used, Year of construction: 1986, grinding diameter 350 mm grinding length 600 mm centre height 175 mm Very well maintained machine. The machine comes from a precision grinding shop from the Black Forest. Can still be viewed under power for a short time at the seller's premises. In 2022, the machine was partially overhauled and serviced in-house with production of the geometry according to the manufacturer's protocol. Equipment: -2-axis digital readout FAGOR -sine bar -tailstock with fine adjustment -Hydraulic tailstock -Surface grinding device -Internal grinding device -Fischer UJ70 internal grinding spindle -Paper belt filter -automatic sequence: roughing-finishing-firing-retur Fob Haev Tqqnjf Ehogb Translated with (free version)

Condition: used, Year of construction: 2010, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm Control Fanuc 310is Completely machanically overhauled with grinding process and setup of one part. Original photo taken on the EMO 2010. CNC control GE Fanuc 310is Hand panel for CNC control GE Fanuc Wenger loader optional Turned part with automatic indexing 1° Grinding head UR 1-2-3 Grinding wheel equipment left 500 x 80 mm Grinding wheel equipment right 400 x 63 mm Operating unit for one high-speed internal grinding spindle MFV / MFZ High-frequency internal grinding spindle MFN 1090 Coolant supply through the workpiece spindle Dressing unit on the upper table Swivelling holder for PCD diamond plates Basic module for KEL-TOUCH gate sensor and KEL-BALANCE balancing devices KEL-TOUCH lead sensor for universal grinding head variants R / RS / UR / URS KEL-TOUCH on the workpiece headstock for internal and external grinding Preparations for Movomatic ESZ 400 or Marposs P7 ME measuring controls Preparation for external filters Cooling lubricant switch-off for table devices Full casing emulsion Emulsion sanding mist extraction system Maintenance unit for additional pneumatic functions Fgsbjvdk N Ej Haf Eheb Preparation for KEL-VITA gantry loader KEL-POS, MOVOMATIC: C25 measuring probe Hydraulic preparation for arobo bezel

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Basis: Kellenberger Kel-Varia UR175-1000 Schleifkopf UR mit T1-T2-T3 Grundausstattung: -T1 500mm Schleifscheibendurchmesser -T2 400mm Schleifscheibendurchmesser -B-Achse hochauflösend -Marposs Messeinrichtung zur Werkzeugvermessung -Werkzeugvermessung -Aktive Längspositionierung -GAP an T1 berührungslos -Reitstock mit Handrückzug -Werkstückspindelstock MK5 mit Kurzkegelaufmahme DIN 55026 -Innenschleifeinrichtung riemengetrieben Optionen gegen Aufpreis: - neuer Werkstückspindelstock hochgenau mit Torqueantrieb - Innenschleifeinrichtung für Hochfrequenzspindeln Durchmesser 120mm -HF-Innenschleifspindel Fischer MFM-1224/42/31 D-21 -HF-Spindel mit HSK-Aufnahme 24.000 U/min mit integriertem GAP Sensor. (Lieferzeit) -CNC-gesteuerte C-Achse -Unrundschleifen -hydrostatische Gewindespindel in x -neues Hydrostatikaggregat mit nur 1 Pumpe und Druckspeicher somit bessere Energieeffizienz. -Überwachung des Wasseranteils im hydrostatischen Systems Weitere Optionen auf Anfrage möglich Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung mit BEMA Runschleifoberfläche -Neu aufgebauter Schaltschrank Fjb Haf Eeinflvohegb -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse)

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Kellenberger Kel-Varia Baureihe mit Kelco 90 Steuerung. Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung -Neu aufgebauter Schaltschrank -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse) Standardausstattung: -WSS mit Konus MK5, optional mit Adapter MK5/Kurzkegel -RST mit MK4 Konus. Optional mit Feinverstellung -Schleifspindelstock T1/T2/T3 -T1 Schleifscheibendurchmesser 400mm -T2 Schleifscheibendurchmesser 300mm -T3 Innenschleifeinrichtung riemengetrieben. -Schleifspindelmotor 4,4kW -B-Achse hochauflösend -Marposs Messsystem zur Schleifscheibenvermessung. -Längspositionierung Marposs -GAP Control (Sensor am Schleifspindelstock) Optionen gegen Aufpreis: -HF Innenschleifspindel -Hochgenauer, höchst kippsteifer Werkstückspindelstock -Messteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 Fsb Haf Ejuwv H Tjhjgb genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0-9,99 mm/Ø 0-9,99 mm/Ø ±8 ° longitudinal feed of the table 1100 mm Fjb Haf Esuxfupehsgb table speeds 0,02-6 m/min 130 kg cross travel max. 270 mm 130 inkl. Spannung kg 80 mm tailstock quill taper MT 3 quill travel 30 mm total power requirement 6,5 kW weight of the machine ca. 3,05 t dimensions of the machine ca. 4 x 2 m Overhauled according to Kellenberger guidelines including new, modern and future-proof control system. Photo of already delivered machine in centre distance 1000mm. -Operation via the touch panel is extremely simple. -The symbols on the control panel are practically identical to the original original control system, so there is no need for familiarisation. -Diagnostic function with display of PLC messages and digital I/O -Dressing function can be extended or changed at the customer's request. -Orientated spindle stop of the workpiece spindle possible on request. -New maximum infeed of 40 mm can be extended on request. -Digital display in 2 axes. Resolution x-axis 0.5my Options: -Encoder with digital display in the workpiece headstock -Rotary encoder with digital display in the grinding headstock (no height adjustment with spindle possible) with spindle possible) -New stable internal grinding device diameter 80mm or 100mm with height adjustment. -Increase of the centre height to max. 225mm -Speed control for the grinding spindle Included: -Operating tool -Clamping tube for chuck Further accessories on request. The x-axis of the machine has an electronically controlled infeed system with stepper motor drive. Hydraulic longitudinal and rapid traverse table movement. Versatile application in production for external cylindrical and internal internal grinding or for external, face and internal grinding in one clamping clamping of individual parts. Possible options: -Semi-automatic dressing cycles for external and internal grinding -automatic dressing compensation. -Measuring control

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Kellenberger Kel-Varia Baureihe mit Kelco 90 Steuerung. Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung -Neu aufgebauter Schaltschrank -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse) Standardausstattung: -WSS mit Konus MK5, optional mit Adapter MK5/Kurzkegel -RST mit MK4 Konus. Optional mit Feinverstellung -Schleifspindelstock T1/T2/T3 -T1 Schleifscheibendurchmesser 400mm -T2 Schleifscheibendurchmesser 300mm -T3 Innenschleifeinrichtung riemengetrieben. -Schleifspindelmotor 4,4kW -B-Achse hochauflösend -Marposs Messsystem zur Schleifscheibenvermessung. Fob Haf Eouwv H Hohegb -Längspositionierung Marposs -GAP Control (Sensor am Schleifspindelstock) Optionen gegen Aufpreis: -HF Innenschleifspindel -Hochgenauer, höchst kippsteifer Werkstückspindelstock -Messteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, Year of construction: 2002, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m Photos of identical machine with centre height 225mm Base: Kellenberger Kel-Varia UR175-1000 Kelco 120 Grinding head UR with T1-T2-T3 Fjbouxfucj Haf Ehegb Basic equipment: -T1 500mm grinding disc diameter -T2 400mm grinding wheel diameter -Infinitely variable, high-resolution axis -Marposs measuring device for tool measurement -Active longitudinal positioning -GAP on T1 and T2 from ELASO contactless integrated in the control interface Semi-automatic balancing from ELASO integrated into the control interface -Tailstock with manual retraction -MK5 workpiece headstock with short taper DIN 55026 Belt-driven internal grinding device Options at an extra charge: - New high-precision workhead with torque drive - Internal grinding device for high-frequency spindles diameter 120mm -HF internal grinding spindle Fischer MFM-1224/42/31 D-21 -HF spindle with HSK holder 24,000 rpm with integrated GAP sensor. (delivery time) -CNC-controlled C-axis non-circular grinding -hydrostatic threaded spindle in x -new hydrostatic unit with only 1 pump and pressure accumulator thus better energy efficiency. -monitoring of the water content in the hydrostatic system -Suction system Further options available on request Mechanical overhaul: -Complete machine overhauled according to Kellenberger measurement protocol -New service-friendly cab -repainting Electrical overhaul: -New modern CNC CIRCULAR GRINDING MACHINE control with BEMA rough grinding surface -New control cabinet -New drive technology -Replacement of all electrical cables Berus pressure switches etc. -New absolute glass scales in x and z -New absolute rotary encoder (for B-axis) Control system: The grinding software consists of a basic licence and various options that are possible depending depending on the equipment of the machine. Basic software - External and internal pendulum grinding - External and internal plunge-cut grinding - External and internal pendulum grinding - External and internal plunge-cut grinding - External and internal taper pendulum grinding - External and internal radius grinding, radius dressed on disc - Semi-automatic pendulum grinding - Workpiece zeroing - Grinding wheel zeroing - Measuring the dressing diamonds - 2 moulding diamonds - 1 shaped diamond or dressing roll (dressing roll required) - Moulding roller (dressing roller required) - 3 Flat dresser - Corrections - Z-position measurement (probe required) - GAP probing (grinding device required) OPTIONS at an extra charge: Software profile plunge-cut grinding: - External and internal profile plunge-cut grinding with profile disc Profile grinding software: - External and internal profile grinding with straight disc Software thread grinding: - Single and multi-start external and internal thread grinding with thread on the disc disc Dressing. Dressing of single and multi-groove discs. Flank angle freely selectable. Trapezoidal thread grinding software: - Additional dressing of trapezoidal threads possible External and internal non-circular plunge-cut grinding: - External and internal non-circular plunge-cut grinding Non-circular grinding software: A prerequisite for non-circular grinding is that the workpiece axis is equipped with a high-resolution rotary encoder so th...

Condition: used, grinding diameter 250,350,450 mm grinding length 1000 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±8 ° longitudinal feed of the table 1300 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg Fjb Hafet Ii Nus Ehjgb 70 mm total power requirement 6,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 4,2 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Geometrically overhauled with new paint and original electrics. Foto of a 600U which we already have delivered. -Digital display in 2 axes. Resolution of x-Achse 0,5my Options: -Encoder with digital display in workpiece spindle head -Encoder with digital display in grinding spindle head (Height adjustment with spindle not possible) -New stable internal grinding diameter 80mm oder 100mm with height-adjustment. -Increase the center heigh to max. 225mm -Speed control of the grinding spindle Including:: -Adjustment tool -Draw tube for chucks other accessories on reqeust Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, Year of construction: 1987, grinding diameter 350 mm grinding length 650 mm centre height 175 mm - Well-maintained cylindrical grinding machine for internal and external cylindrical grinding - 7072 operating hours - Retrofitted in 2013 with a cooling lubricant belt filter system, capacity 300 L, manufacturer Knoll. - Including machine accessories, e.g. holders, flanges, collet chuck set, etc. - The machine has been serviced regularly, technically and visually in good condition - ready for use! Fob Haommmtfsf Ehegb

Condition: used, grinding diameter 450 mm grinding length 1000 mm centre height 225 mm As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machine will be delivered overhauled. Mechanical overhaul: • Overhaul of the entire machine according to Kellenberger measuring protocol • A new service-friendly cabin • Repainting Electrical overhaul: • New, modern CNC cylindrical grinding machine control system Fgob Haf Eeuwv Hyjhob • New built up control cabinet • New drive technology • Exchange of all electric lines, Berus pressure switch, etc. • New absolute glas scales in X- and Z- axis • New absolute rotary encoder (for B-axis) Please remark that the pictures show an already delivered machine with other options. Wheelhead variant UR/RS: • Grinding wheel arrangement for external and angular plunge grinding in a row • Thus, in each case 400mm grinding wheel diameter • Thus, substantially lower risk of collision • Easier programming • Grinding wheel equipment in each case 400x63x127mm • HF-Spindle for internal grinding • B-axis CNC-controlled for external-, surface and internal grinding at one setting. • Swivel range +10°/-270° • C-axis for polygon grinding • Tight lower part • Grinding head motor 10,0 kW • Tailstock • Marposs measuring system for grinding wheel alignment • Marposs lateral positioning system

Condition: used, grinding diameter 250,350,450 mm grinding length 1000 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±8 ° longitudinal feed of the table 1300 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 4,2 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your sion R: Maschine hat Zentralschmierung und Rollenführung in der Flachbahn der x-Achse sowie Luftabhebung im Schleifspindelstock. Beispielfoto einer von uns überholten 600U -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter weiteres Zubehör auf Anfrage. Overhauled with geometric KELLENBERGER protocoll. Standard with: -2-axis DRO -Paper filtration Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Fgjb Haed Ih D Hof Ehob Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW Fgjb Hafjd Ih D Rj Ehob weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your metrisch überholt und neu lackiert mit original Elektrik. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter -Spitze MK3 -Spitze MK5 -Futterflansch weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, internal diameter 340/440 mm grinding depth 99999 mm grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your metrical overhauled and repainted with: -Neuem CE konformem Schaltschrank. -Neuem Werkstückspindelmotor und Regler in Drehstromtechnik. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter Fgobed Ih Dxo Haf Ehob weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, Year of construction: 2006, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm weight of the machine ca. 3,5 t Machine completely overhauled with 12 months warranty Mechanically and optically like new Photos from the last overhauled machine with different options Fanuc 21i control -Grinding head UR 1-2-3 external/internal/plan -Axis automatic 1° Hirth serration -Active longitudinal positioning KEL-POS Movomatic -Semi-automatic balancing device KEL-BALANCE -Grinding wheel equipment left 400mm diameter -Grinding wheel equipment right 300mm diameter -Internal grinding unit with belt drive Fgjb Hast Ii Nbof Ehob -Tailstock with micro-adjustment -fine adjustment upper table -Paper belt filter SBP4 240l

Condition: used, grinding diameter 350 mm grinding length 600 mm centre height 175 mm grinding wheel diameter 400 mm grinding wheel width 50 mm Fgebouxft Eo Haf Eheb bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0-9,99 mm/Ø 0-9,99 mm/Ø ±10 ° longitudinal feed of the table 1100 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannung kg cross travel max. 270 mm 80 mm tailstock quill taper MT 3 quill travel 30 mm total power requirement 6,5 kW weight of the machine ca. 3,05 t dimensions of the machine ca. 4 x 2 m Overhauled according to Kellenberger guidelines including new, modern and future-proof control system. Photo of already delivered machine in centre distance 1000mm. -Operation via the touch panel is extremely simple. -The symbols on the control panel are practically identical to the original original control system, so there is no need for familiarisation. -Diagnostic function with display of PLC messages and digital I/O -Dressing function can be extended or changed at the customer's request. -Orientated spindle stop of the workpiece spindle possible on request. -New maximum infeed of 40 mm can be extended on request. -Digital display in 2 axes. Resolution x-axis 0.5my Options: -Encoder with digital display in the workpiece headstock -Rotary encoder with digital display in the grinding headstock (no height adjustment with spindle possible) with spindle possible) -New stable internal grinding device diameter 80mm or 100mm with height adjustment. -Increase of the centre height to max. 225mm -Speed control for the grinding spindle Included: -Operating tool -Clamping tube for chuck Further accessories on request. The x-axis of the machine has an electronically controlled infeed system with stepper motor drive. Hydraulic longitudinal and rapid traverse table movement. Versatile application in production for external cylindrical and internal internal grinding or for external, face and internal grinding in one clamping clamping of individual parts. Possible options: -Semi-automatic dressing cycles for external and internal grinding -automatic dressing compensation. -Measuring control

Condition: used, grinding diameter 250,350,450 mm grinding length 1000 mm centre height 125,175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±8 ° longitudinal feed of the table 1300 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,5 t Feb Heuxftxeaf Ehjgb dimensions of the machine ca. 4,2 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your o von Kürzlich gelieferten Maschinen mit zusätzlichen Optionen wie: -Spritzschutztüren -Kabine x-Achse -Schwenkwinkelanzeige Schleifspindelstock Geometrisch überholt und neu lackiert mit original Elektrik. Maschine hat Zentralschmierung und Rollenführung in der Flachbahn der x-Achse sowie Luftabhebung im Schleifspindelstock serienmäßig. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, grinding diameter 350,450 mm grinding length 600 mm centre height 175,225 mm grinding wheel diameter 400 mm grinding wheel width 50 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines. Foto von bereits gelieferter Maschine mit eventuell anderen Optionen. Maschine hat Zentralschmierung und Rollenführung in der Flachbahn der x-Achse sowie Luftabhebung im Schleifspindelstock serienmäßig. BEMA Standard serienmäßig: -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my -Drehzahlanzeige Schleifspindel -Stufenlose Drehzahl Schleifspindel 70-100% -Stufenlose Drehzahl Innenschleifspindel 70-100% -Werkstückspindelantrieb durch Drehstrommotor stufenlos regelbar über Frequenzumrichter Mögliche Optionen gegen Aufpreis: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Sinuslineal -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter Natürlich erhalten Sie auf unsere generalüberhalten Maschinen 12 Monate Gewährleistung. (Nur Anrainerstaaten) weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Fgjb Hsd Ih D Esaf Ehjb Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln
