Used CNC lathes 600-699mm turning diameter for sale (49)

Condition: used, Year of construction: 2000, turning diameter over bed: 600 mm turning dia. over face-slide: mm turning length: 210/610 mm centre distance: mm faceplate diameter: mm turning diameter over support: mm center height over support: mm x-axis tool holder: mm longitudinal traverse (z-axis): mm control: 810D/840D revolution per minute: 1 - 6300 steples U/min spindle passage: Ø 42 mm external spindle dia. in forward position: Ø 80 mm max. torque on the spindle: 86 Nm feed motor: X/Z: 5000 / 7000 N rapid motion - x-axis: X/Z: 16 / 20 m/min tool turret - number of stations: 12 / VDI 30 tailstock taper ISO: MK4 tailstock adjustment: 500 (Hub) mm Main spindle capacity: 7,5 (100%=11kW) kW Dpshkn operating hours - idle run: h electrics - voltage/frequency: 3/PE ~ 400V und 50/60Hz V/Hz total power requirement: 20 kVA Weight approx.: 4,0 t dimension machine xH: 3,0 x 2,0 x 1,9 m Die Maschine befindet sich derzeit in der technischen Abteilung.

Condition: ready for operation (used), Year of construction: 1999, General Data Measurements width 1900 Measurements depth 2700 Measurements height 1885 Machine weight 5400 Main Drive Number of spindles 1 (implied) Spindle speed range 35 - 3500 min-1 Dpqzwx Spindle bore 120mm Number of axis 2 Movement X-Axis Movement 300 Z-Axis Movement 675 Workpiece Workpiece drm over bed 620mm This Okuma LB400 was manufactured in 1999. A robust lathe featuring a swing over bed and carriage of 620mm, and a maximum turning diameter of 420mm by a length of 650mm. It includes a V12 turret with 12 tools, enhancing versatility. Spindle speeds range from 35 to 3500 min-1, ensuring adaptability for various materials. Ideal for precision tasks, the Okuma LB400 lathe we have for sale is a reliable addition to any workshop. Contact us for more information. Application Types Turning

Condition: good (used), Year of construction: 2014, Catalog No. : 7324 Type: LYNX 220 LSYC Producer: DOOSAN Made in: 2014 Characteristic: Control system: FANUC Maximum travel length in the X-axis: 205 mm Maximum travel length in the Y-axis: 105 mm Maximum feedrate in the Z axis: 560 mm Maximum power of the main spindle: 11 kW Bk0Ocx3Cqhv Diameter of the spindle bore: 76 mm Maximum spindle speed: 4500 1/min Weight: 4000 kg Equipment: Chip conveyor Bar feeder

Condition: used, Year of construction: 2005, turning diameter over bed 0280 mm turning length 515 mm control 810D Siemens turning diameter over bed slide 280 mm spindle turning speed - stepless 0- 6000 U/min- rpm spindle bore 80 mm feeds 0- 15/24 m/min Cnzccm07Ge voltage 400 V connected load 32 KW face slide travel 200 mm longitudinal travel 570 mm dimensions of the machine ca. 2,1 x 1,4 x 1,8 m taper diameter VDI 20 mm main drive motor 24 kW weight of the machine ca. 2,5 t Machine has 16 position turret with 8 pos. live tooling. Machine is without tailstock ! We will supply holder also for live tooling and a chuck along with the machine.

Condition: like new (used), Year of construction: 2012, CNC LATHE PINACHO RHINO 325 x 2000 mm. Distance between centers 2000 mm. Dps3Yb Turning diameter on bed 660 mm. Turning diameter on longitudinal slide 585 mm. Turning diameter on cross slide 368 mm. Bed width 425 mm. Bar passage 105 mm. ASA 8" head - 1700 Rpm. Automatic turret 8 positions. Chip extractor. Fagor 8055i control.

Condition: good (used), Year of construction: 2003, Workpiece Dimensions: Ø 560 x 900mm Axes: 4-Axes Tool Turrets: Two 12-Position Tool Turrets X-Travel: -5 to +290mm Tailstock: Yes Steady Rest: Yes CNC Control: Siemens Sinumerik 840D Dppmi9 Weight: Approx. 7.5 tons Chip Conveyor: Yes

Condition: used, Year of construction: 2000, swing diameter 650 mm turning length 1000 mm Dpmnfh control Rexroth Indramat BVT 20 x-travel -15 / 660 mm y-travel -150 / 200 mm main spindle: 150 spindle bore 92 mm bearing diameter 150 mm turning speed range - main spindle 0 - 3.800 min/-1 tool turret: number of tool places 12 Pos. total power requirement 70 kW In our opinion, the machine is in very good used condition and can be inspected under power by appointment. Accessories, tools and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well Subject to prior sale!

Condition: good (used), Year of construction: 2012, - Control system: SIN 840 D sl + postprocessor - Running diameter above bearing: 640 mm J7Hfwamo - Running diameter above the caliper: 480 mm - Max. workpiece length: 2500 mm - Spindle drilling: 100 mm - Speed range: 0-2500/min - Cooling: 17 bar - Movable lunette: 30-250 mm - Chuck: ROHM KFD 400/3 - DNC net: yes - Tool head: 12 positions / 6 driven - Chip conveyor: yes - Power: 28 / 42 kW - Machine weight: 16 800 kg

Condition: reconditioned (used), Year of construction: 1989, turning diameter over bed 640 mm turning diameter over slide rest 385 mm turning length 3000 mm center height over bed 315 mm centre distance 3000 mm digital readout 3-Achsen HEIDENHAIN bed width 450 mm spindle taper KK 8 DIN 55022 spindle bore 82 mm Dpkqgt turning speed range 9 - 1800 U/min power requirement 22 kW 3-jaw-chuck diameter 400 mm quick change toolholder MULTIFIX Typ C taper in tailstock-quill MK 6 dia. of quill 100 mm quill stroke 280 mm coolant voltage 400 V total power requirement 22 kW weight of the machine ca. 6,5 t dimensions of the machine ca. 5,70 x 1,80 x 1,90 m - Serial-No.: 01192-01-808 - NEW Bearings on Main Spindle - Main gearbox rebuilt, all gear shaft bearings renewed - guide ways of cross slide grinded and scraped - rapid traverse for Z, Z0 and X-Axis - autom. feed in top support - 3-jaw Chuck, wedge type SMW Ø 400 mm - 3-axis digital readout Heidenhain - quick change tool holder MULTIFIX - fixed steady rest - coolant equipment - machine lamp

Condition: ready for operation (used), Year of construction: 2009, Control Unit Brand Siemens Model Sinumerik 810 Main Drive Spindle speed range 60-4200 Spindle motor power 15/18 kW Spindle bore 73 mm Tool taper KK 6 Movement X-Axis Movement 65 mm X-Axis Working Feed 24 m/min X-Axis Feed Force 5000 N Z-Axis Movement 210 mm Z-Axis Working Feed 24 m/min Z-Axis Feed Force 7000 N Workpiece Workpiece drm over bed 600 mm Workpiece drm over support 360 mm Workpiece drm 680 mm Media Chip conveyor Yes Control Unit Dpnpox Brand Siemens Model Sinumerik 810 Main Drive Spindle speed range 60-4200 Spindle motor power 15/18 kW Spindle bore 73 mm Tool taper KK 6 Movement X-Axis Movement 65 mm X-Axis Working Feed 24 m/min X-Axis Feed Force 5000 N Z-Axis Movement 210 mm Z-Axis Working Feed 24 m/min Z-Axis Feed Force 7000 N Workpiece Workpiece drm over bed 600 mm Workpiece drm over support 360 mm Workpiece drm 680 mm Media Chip conveyor Yes This EMCO TURN E 65 lathe was manufactured in 2009. It features a swing diameter over bed of 600 mm and a maximum turning diameter of 680 mm. The spindle supports a max. chuck size of 250 mm and operates with a speed range up to 4200 min^-1. Ideal for precision tasks, the EMCO TURN E 65 machine we have for sale offers robust performance with its AC motor and hydraulic tailstock. Contact us for further details regarding this lathe. Application Types Turning

Condition: excellent (used), Year of construction: 2008, USED HAAS MODEL SL-40 CNC 2 AXIS LATHE WITH HAAS CONTROL . This Haas CNC Lathe is in fabulous condition, with extremely low hours usage. It was originally installed at the University of Sheffield Advanced Manufacturing Research Centre (AMRC) and had been well maintained. It is now for sale from T W Ward CNC Machinery Ltd in Sheffield. MACHINE CONSTRUCTION & FEATURES • ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY • 2,400 RPM HIGH POWER MAIN SPINDLE • 10 STATION AUTO INDEXING TURRET • TOOL SETTING ARM Os0Bzaycm • COOLANT SYSTEM • TOOL HOLDER PACKAGE • FILTERMIST MIST EXTRACTION UNIT • 2 AXIS MACHINE WITH LINEAR GUIDE WAYS • SWARF AUGER MACHINE CAPACITIES Swing Over the Bed Ø 1016 MM Maximum Turning Diameter Ø 648 MM Distance between Centres 1295 MM Maximum Turning Length 1118 MM Bar Capacity Ø 100 MM SPINDLE Chuck Size Ø 15” / 380 MM Spindle Speed (Rpm) 2,400 RPM Motor (Max / Cont.) 30 KW Spindle Type GEARED Spindle Nose A2-8 Spindle bore Ø 117 MM FEED Travel X 1117 MM Travel Z 864 MM TURRET Number of Tools 10 Tool Size - OD 32 MM² Tool Size - ID Ø 32 MM POWER SUPPLY Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 4,900 X 2,500 MM Height (Includes Filtermist unit) 2,750 MM Weight 11,000 KGS

Condition: used, turning length / mm turning diameter over bed / mm turning diameter over slide / mm control / Dpn737 Operating hours: 296 hours The lathe is as good as new and is fully functional.

Condition: used, Year of construction: 1991, Metal turning machine, lathe Model: CNC Manufacturer: YAM, Yang Ironworks (Taiwan) Type:&nbsp CK-3B Year of manufacturing:&nbsp 1991 Controller:&nbsp Fanuc 0T + C-Axis Max. Turning-diameter slide:&nbsp 650mm Max. Turning-diameter&nbsp bed:&nbsp 390mm Bvvpzazezo Max. Turning-Length:&nbsp 1220mm Center-distance: 1320mm Spindle-hole: 74mm X-Axis travel: 255mm Z-Axis travel: 1230mm Spindle-speed: 3000rpm Spindle-power: 15kW Turret: 8 driven tools Incl. peripherals, tools, driven tools, 4-jaw-chuck chipconveyor and more Machine-weight: 7500kg Machine-dimensions: 4400x2400x2500mm

Condition: good (used), Year of construction: 2005, The machine is in good technical condition, by prior agreement the possibility of testing, including the bar feeder LNS . Dpskrh Max. turning length 600 mm Max. diameter per turn 350 mm Max. diameter above the bed 580 mm Diameter above cross ram 400 mm Type CNC Fanuc X-axis 205 mm Z-axis 630 mm Spindle calibre 76 mm Number of lathe heads 10 Adjustable speed 4000 rpm Shaft motor power 15 kW

Condition: excellent (used), New 2008 Buokaiwl Swing over bed - 600 (Ø 23.62) Diameter × length - Ø 300 × 600 (Ø 11.81 × 23.62) Max. diameter - Ø 380 (Ø 14.96) Max. travel range of Z/X axis - 600 / 240 (23.62 / 9.44); Z-axis: FANUC 2.8 kW (4 HP) /3000 rpm; X-axis: FANUC 2.8 kW (4 HP) /3000 rpm Diameter of spindle bore/Draw bar bore - STD: Ø 77 / Ø 52 (Ø 3.03 / Ø 2.04); OPT: Ø 86 / Ø 77 (Ø 3.38 / Ø 3.03) Spindle speed - STD: 8” chuck 3500 rpm; OPT: 8” chuck 4500 rpm, 10” chuck 3500 rpm Chuck diameter - STD: Ø 8” ; OPT: Ø 10” Hydraulic Tailstock – travel 465 (18.3) MT. No.4 VDI Tool stations - OPT: 8 STD: 10 Coolant Chip conveyor Power requirement - 208-220 volts / 100 Amps / 3 Phases / 60 Cycles Floor area (L × W × H) - 4080 ×1675 × 1842 (160.62 × 65.94 × 72.51) Gross weight (approx.) - 5200 kg (11440 Ibs)

Condition: ready for operation (used), Year of construction: 2014, General Data Measurements width 242 cm Measurements depth 646 cm Measurements height 267 cm Machine weight 13563 kg Dphn9P Main Drive Spindle speed range 2400 rpm Spindle motor power 29,8 kW (41,0 kW with XP OPTION) Spindle bore 117,3 mm Number of axis 2 Movement X-Axis Movement 432 Z-Axis Movement 2032 Workpiece Workpiece drm over bed 648 mm Workpiece drm over support 2032 mm Additional Equipment Max Torque: 1898.0 Nm 150 rpm (2847.0 Nm 150 rpm with XP OPTION) Max Thrust X: 24465 N / Max Thrust Z: 40034 N Feedrates : Rapid Traverse X: 18.0 m/min Rapid Traverse Z: 8.1 m/min Workpiece: Chuck Size: 381 mm / Bar Capacity: 102 mm Number of Tools: 12-Station BOT / OD vs ID Tools: Any Combination (will vary with turret) / Boring Bar Rear Clearance: 111.0 mm Coolant Capacity: 360 L Air Requirements: Air Required: 113 L/min 6.9 bar / Inline Air Hose: 3/8 in / Coupler (Air): 3/8 in / Air Pressure Min: 5.5 bar Electrical Specifications: Input AC Voltage (3 Phase) - Low: 220 VAC / Full Load Amps (3 Phase) - Low: 105 A / Input AC Voltage (3 Phase) - High: 440 VAC / Full Load Amps (3 Phase) - High: 53 A This HAAS ST40L lathe was manufactured in 2014. It features a swing diameter over front apron of 876 mm and a maximum cutting length of 2032 mm. Equipped with a 12-station BOT turret and a 2-speed gearbox, it offers a spindle speed up to 2400 rpm and a spindle power of 29.8 kW. Ideal for handling large and complex parts, the HAAS ST40L machine we have for sale. Contact us for further details regarding this lathe. Application Types Turning

Condition: good (used), Year of construction: 2005, Operating hours: 25,217 h, Functionality: fully functional, Machine/vehicle number: R7AT0601, Turning length: 744 mm, Turning diameter: 600 mm, Rotational speed (max.): 7,000 rpm, Bar passage: 65 mm, Number of slots in tool magazine: 24, TECHNICAL DETAILS Specification: 7 axes, 2 spindles, 2 turrets Control: SIEMENS 840D Turning diameter: max. 600 mm Length of the workpiece: max. 744 mm Turning diameter on the slide: 500 mm Distance between spindle noses: 975 mm Turning diameter: 430 mm Diameter of bar passage: 65 mm Travel distance X/X2 axis: 280/205 mm Z/Z2/Z3 axis travel: 900/750/750 mm Y-axis travel: 100 (upper turret) ± 50 mm Main spindle speed: 0 - 5000 rpm Torque: max. 250 Nm Main spindle power: 29 kW Counter spindle speed: 0 - 7000 rpm Torque: max. 130 Nm Power of the counter spindle: 22 KW C-axis indexing: 0.001 ° Rapid traverse of the C-axis: 1000 rpm Upper turret: 12 motorized VDI40 stations Turret indexing time: 0.2 s Lower turret: 12 motorized VDI40 stations Switching time of the turret: 0.2 sec. Drive power of the motorized tools 6.7 kW MACHINE DETAILS Switch-on hours: 52,581 h Spindle hours: 25,217 h Dpjxh2 Machine dimensions: 3,400 x 2,550 x 2,300 mm Total weight: approx. 9,500 kg Connected load: 46 kVA EQUIPMENT - LNS MOVE bar feeder - 2 collet chucks - Various tool holders, including motorized axial and radial holders - Pneumatic parts reloader with conveyor belt - 300-liter high-pressure coolant system 2 pumps, 2.2 kW - Oil cooler for spindle - Air-conditioned cabinet - Complete manual and diagrams

Condition: used, Year of construction: 2012, turning diameter:420 turning length:1230 mm swing over bed:700 mm swing diameter over slide rest:550 mm centre distance:1390 mm y-axis:+/- 60 mm turning speeds:3500 1/min turret (x-stations):12 power capacity:22 / 18,5 kW :1 / 12 x BMT rapid traverse x + z axis:20 / 24 m/min :76 mm total power requirement:50 kVA weight:7,8 t dimensions of the machine ca.:4,10 x 2,05 x 2,21 m CNC lathe with Y-Axis and driven tools, C-axis, tool eye, hydraulic 3-chaw-juck D= 250 mm, reinforced pump 15 bar, pressure-compensated clamping cylinder , 2 step clamping pressure, prepared for steady (without steady), progr. tailstock (dragging device), live tool device (3,7 kW, 3.000 rpm), chipconveyor, 1 pcs. live tool included approx. 15.500 working hours Bjegwtfyew

Condition: new, Functionality: fully functional, Turning length: 2,300 mm, Turning diameter: 650 mm, Spindle bore: 165 mm, Spindle speed (max.): 1,150 rpm, Travel distance X-axis: 360 mm, Travel distance Z-axis: 2,400 mm, Spindle motor power: 3,700 W, Rapid traverse X-axis: 24,000 mm/min, Rapid traverse Z-axis: 16,000 mm/min, Total height: 2,290 mm, Total length: 5,245 mm, Total width: 2,360 mm, Type of input current: AC, Torque: 95 Nm, Overall weight: 13,500 kg, Chuck outer diameter: 508 mm, Spindle nose: A2-15, Tailstock quill diameter: 120 mm, Tailstock quill mount: MK 6, Tailstock quill stroke: 150 mm, Equipment: Documentation/Manual, Available ex works: Fanuc 0i-TF PLUS 8.4" LCD control unit 12-fold turret Options: - Manual Guide i - Hydraulic clamping cylinder with 166.5 mm passage Dpf3Nr - Hydraulic 3-jaw chuck 20" (508 mm) - Hydraulic steady rest SMW - SLU - 4 (Ø 30 - Ø 245 mm) - Hydraulic tailstock MK 6 (Ø 120 mm / stroke 150 mm) - Foot pedal for tailstock control - Renishaw Toolsetter HPRA - Chip cart - Coolant gun - 7 bar coolant pump - Oil skimmer - Air gun The machine has a high turning and drilling capacity. Application examples: - Shafts - sleeves - cones

Condition: good (used), Year of construction: 2005, Functionality: fully functional, Machine/vehicle number: LVD1036, Turning diameter: 740 mm, Spindle speed (max.): 2,000 rpm, Travel distance X-axis: 380 mm, Travel distance Z-axis: 760 mm, This advanced CNC lathe machine is designed for precision and efficiency in industrial machining. It features a maximum swing diameter of 800 mm, with turning capabilities up to 740 mm in diameter and 760 mm in length. NC system: FANUC 18I TB Main Technical Data Maximum Swing Diameter: 800 mm Maximum Turning Diameter: 740 mm Maximum Turning Length: 760 mm Axis Movements X-Axis Travel: 380 mm Z-Axis Travel: 760 mm Motor Power X-Axis Motor: AC servo, 3 kW Z-Axis Motor: AC servo, 7 kW Rapid Traverse Rates X-Axis: 20 m/min Z-Axis: 20 m/min Main Spindle Spindle Type: ASA A2-11 Front Bearing Diameter: 160 mm Max Spindle Speed: 2000 RPM Spindle Motor Power: AC 30 kW / 37 kW (presumably peak power) Maximum Torque: 2434 Nm Turret Tool Stations: 12x2 (double turret, each with 12 stations) Tool Size: 25x25 mm, Ø 40/60 mm Boring Tool Size: Ø 50 mm Tool Change Time: 0.43 s Tool Holders External Turning Holders: 4x(HO10-25RL) Face Turning Holders: 2x(HF10-25RL) Internal Turning Holders: 4x(HB10-40N) + 2x (HB10-50N) Dpiu9J Reduction Sleeves: 2 sets (BS 40 -10, -12, -16, -20, -25) weight of machine : 19.000kg LxWxH : 3700 x 29500 x 3370mm

Condition: ready for operation (used), Microcut 2260 560 x 1500 With steady rest 2x Dnvbnt Fagor Toolholders

Condition: ready for operation (used), Year of construction: 2020, Control Unit Brand Fanuc Main Drive Spindle speed range 2000 Movement X-Axis Movement 325 mm Z-Axis Movement 1205 mm Biihwse3Im Workpiece Workpiece drm 630 mm Turret Number of turrets 1 Number of tool slots 10 Additional Equipment Chip conveyor: Hinged_right side Bucket Tower lamp: 3 color This Hyundai Wia L400C lathe was manufactured in 2020. It features a robust 15" chuck, a 2000 RPM spindle with a 2-step gear type, and a box guideway for enhanced precision. The machine includes a 10-station turret, a tail stock, and a chip conveyor on the right side. Ideal for handling a max work length of 1170mm and a diameter of 630mm. For more information about this lathe, please reach out to us. Application Types Turning

Condition: ready for operation (used), Year of construction: 2003, Make: MAZAK Type of machine: Integrex 300SY Year of manufacture: 2003 Control system: Mazatrol PC Fusion CNC 640 MT Machine's weight: 9.800 kg Tool holder: KM 63 Speed range: 35-3.500 U/min Cutting diameter: 610 mm Turning length: 1.137 mm Overall dimensions: 6,00 x 2,80 x 2,70 m Bodk7Sygm2O Tool turret - slots: 40 C-axis: 0°-360°/0,001 ° Y-axis: +/- 115 mm

Condition: excellent (used), Year of construction: 1991, Functionality: fully functional, TECHNICAL DETAILS Control: Fanuc 0T Turning diameter: 650 mm Center distance: 1,320 mm Turning length: 1,220 mm C-axis: available Tool holder: 8 places Driven tool positions: 8 Spindle motor: 15 kW MACHINE DETAILS Machine dimensions: 4,400 x 2,400 x 2,500 mm Weight: 7,500 kg Ccbwmbs EQUIPMENT Chip conveyor Pallet tools Accessories 4-jaw chuck Jaws Tool holders Driven tool holders collets and more

Condition: ready for operation (used), Year of construction: 2018, Control Unit Brand MAZAK Model Mazatrol SmoothG CNC Main Drive Number of spindles 2 Spindle speed range 5000 Bojylzlirjm Movement X-Axis Movement 234 mm Y-Axis Movement 100 mm Z-Axis Movement 625 mm W-Axis Movement 585 mm Workpiece Workpiece drm 695 mm Turret Number of tool slots 12 This 4-axis Mazak QUICK TURN COMPACT 200 MSY L was manufactured in 2018. It features a maximum swing of 695 mm and a machining diameter of 380 mm. Equipped with a Mazatrol SmoothG CNC control system, it ensures precision and efficiency. The main spindle supports up to 5000 rpm, while the second spindle reaches 6000 rpm. A great opportunity to buy this Mazak QUICK TURN COMPACT 200 MSY L lathe. Contact us for further details. Application Types Turning
