Condition: used, Year of construction: 1989, functionality: fully functional, turning diameter over cross slide: 700 mm, turning length: 700 mm, turning diameter: 600 mm, spindle bore: 130 mm, spindle speed (max.): 3,550 rpm, spindle speed (min.): 22 rpm, rotational speed (min.): 10 rpm, rotational speed (max.): 1,600 rpm, OEHRINGER VDF 400 C-F CNC lathe with C-axis and driven tools Heavy-duty CNC lathe for complete machining of turning, milling, and drilling operations. The machine features a C-axis, driven tools, and a 12-position turret, making it ideal for machining large and heavy workpieces. Technical data: * Manufacturer: BOEHRINGER * Type: VDF 400 C-F * Year of manufacture: 1989 * Control system: Philips B3T * Swing over carriage: 750 mm * Swing over cross slide: 700 mm * Z-axis travel: 1,000 mm * Spindle bore: 130 mm * Max. spindle speed: 3,550 rpm * Drive power: 60 kW * Spindle head: Size 15 DIN 55026 * Chuck: FORKARDT 3 NHF 500, Ø 500 mm Tool turret: * VDI 60 tool interface * 12 tool positions * 6 driven tool stations Equipment: Dsdpozb A S Dofx Apdokn * C-axis with separate servo motor * Driven tools * Milling and drilling operations possible * Coolant system * Integrated chip conveyor * Full hydraulic cylinder * Various tool holders Machine weight: approx. 17.5 t Machine from ongoing production. Inspection possible by appointment. More pictures and information available upon request.

Condition: used, Technical details: travel -y axis: Schlitten auf Balken: 200 mm spindle taper ISO: SK 40 spindle head swivable left - right: je 90° ° quill stroke: 80 mm turning speed range: 90 - 900 / 5 step U/min distance table - lower edge spindle: min./max.: 50 / 400 mm table surface area: Anbaufläche:760 x 200 mm table surface area: Spannfläche: 630 x 200 mm max. table load: 100 kg x-travel: Tisch längs: 320 mm z-travel: Tisch vertical 350 mm table swivelabel +/-: re/li je 30° distance table - lower edge spindle: min./max.: 50 / 400 mm feed:: Tisch: stufenlos 14 - 71 mm/min Dksdou Ndb Ajpfx Apden total power requirement: 4,0 kW weight approx.: 1.200 kg dimension machine xH: 1,3 x 1,5 x 1,8 m Equipped with Heidenhain DRO for X and Y travel Swiveling work spindle The feed works via variator gear. The table is swivelable. Spindle speeds operate in 3 levels via gears and in 2 levels electrically. Cooling device diverse tool holders SK40 Der Fräsbalken ist um ca. 350mm ausfahrbar. The machine vise is not included in the delivery scope (see picture), but can be purchased additional! *

Condition: excellent (used), 1 used, very well-maintained fixed lathe carriage with rollers Center height: 310 mm Internal diameter: 325 mm Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 Dsdpfx Apjzaixujdekn DE - 44143 Dortmund-Wambel / Germany

Condition: excellent (used), 1 used, very well-maintained, fixed facing head with rollers Maximum workpiece height: 285 mm Internal diameter: 325 mm Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund-Wambel / Germany Dodpjzaixhjfx Apdskn

Condition: new, Technical data: Capacity: 160 t Installation height: 1100 mm Max. working area: 1100 x 350 mm Ram stroke: 400 mm Advance speed: 6.2 mm/s Return speed: 6.8 mm/s Motor power: 5.5 kW Width: 1640 mm Depth: 1000 mm Height: 2550 mm Weight, approx.: 1300 kg Equipment: - Laterally adjustable cylinder via rack, pinion, and handwheel - Spacious working area Dedpfxjk Nz Ntj Apdskn - Height-adjustable table - Torsion-resistant design with welded steel construction - Manometer - Fine pressure adjustment - Additional hand pump Support prisms available at extra cost.

Condition: used, Year of construction: 2009, greates pass round over bed 640 mm swing diameter over face slide 435 mm control Siemens SINUMERIK 810D pl turning speed range 3 - 2.500 U/min centre distance 1.500 mm spindle bore 70 mm spindle diameter in front bearing 100 mm Lathe - cycle-controlled | VDF-BOERHRINGER - DUS 630 ti The machine is in good condition and can be inspected under power at any time. Dkodpezaf Hnsfx Apdon Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DUS630ti | DUS 630ti | DUS 630 ti

Condition: used, Year of construction: 1991, Technical details: turning diameter over bed: 570 mm turning diameter over slide rest: 365 mm turning length: 2000 mm feed per revolution: 0,06 - / 0,03 - 28 mm spindle turning speed range: 11,2 - 2240 U/min spindle bore: 62 mm spindle head: 8 nach DIN 55022 total power requirement: 15 kW weight of the machine ca.: 4,8 t dimensions of the machine ca.: 4,5 x 1,5 x 1,4 m with digital readout HEIDENHAIN rapid feed, MULTIFIX toolholder system fixed steady dia. 160 mm 3 jaw chuck RÖHM TR 250 coolant attachment diverse toolholders, diverse jaws * Djdpfx Asx D Ufmjpdskn

Condition: used, Year of construction: 1981, Technical details: x-travel: 400 mm y-travel: 420 mm z-travel: 380 mm table surface area: 710 x 400 mm max. table load: 120 kg range of revolution per miute: 45 - 2240 / 18 step U/min feed continuous: 6,3 - 600 / 2 steples mm/min quill stroke vertical: 100 mm quill stroke: horizontal: 100 mm spindle taper: vertical/horizontal: SK 40/SK40 spindle head swivable left - right: 90 ° distance table/horizontal spindle: min./max.: 200 / 325 mm distance table/vertical head: min./max.: 150 / 730 mm total power requirement: 5,5 kW Dkjdpeu Nc Hkjfx Apdsn weight of the machine ca.: 1,95 kg machine dimensions LxWxH: 1,7 x 1,4 x 1,9 m dimensions electric cabinet: 850x500x1500 mm The milling machine is equipped with a 3-measuring path display. incl. machine feet and operating instructions *

Condition: not inspected (used), Year of construction: 1965, functionality: unexamined, machine/vehicle number: 80-0117-2582, spindle speed (max.): 5,000 rpm, This Heidenreich and Harbeck VDF 21R0 lathe with accessories will be auctioned off in our online auction "Zink Feinmechanik-Sondermaschinen GmbH - CNC machining centers - tool holders - tools - workshop equipment". Dkodpfey Uvl Esx Apdjn You can find this and many other items from the field of precision engineering machinery, workshop equipment, CNC technology, CNC accessories, tool holders, and more on our RESTLOS auction platform!

Condition: excellent (used), Year of construction: 1972, Precision lathe, lathe, lead screw lathe, lead screw lathe Dkedjw Sxgxopfx Apdsn -Manufacturer: VDF Heidenreich Harbeck, lead screw and feed screw lathe type 24R0 -Machine bed: hardened -Turning length: 1230 mm -Rotation diameter over bed: 500 -Turning diameter over support: 290 mm -Spindle bore: Ø 56 mm -Spindle speeds: 19 - 2000 rpm -Wedge bar chuck: Forkardt Ø 250 mm -Tailstock mount: MK4 -Drive: 5.5 kW -Accessories: 1x bezel, 7x Multifix tool holders, see photos -Dimensions: 1180/3050/H1345 mm -Weight: 1907 kg

Condition: excellent (used), Steadies for lathe VDF BOEHRINGER Type: V 800 1. Fixed steady 1. Travelling steady In very good condition. Dksdpfsyfny Usx Apdsn

Condition: used, Year of construction: 1975, Technical details: turning diameter over bed: 500 mm turning diameter over support: 260 mm turning length: 950 mm Dkodpfx Aev A Sqhopdjn center height measured in bed: 220 mm centre distance: 1000 mm revolution per minute: 11,2 - 2240 / 24 step U/min spindle bore of work spindle: 62 mm tailstock quill adjustment:: 210 mm longitudinal feeds:: 0,045 - 1,6 mm/U - 32 step cross feed: 0,02 - 0,71 mm/U - 32 step total power requirement: 11 kW weight of the machine ca.: k.A. t dimension machine xH: 3,3 x 1,2 x 1,6 m The machine is in a very good condition (very quiet spindle run) in Leipzig. Top slide rotatable 360° 3-jaw lathe chuck Ø 315mm with jaws (inside/outside) for speed 2000 rpm. Thread cutting: metric, modular thread, inch Chip protection wall Chuck protection (mechanical) MULTIFIX steel holder with Ø 40mm drill steel holder Chip collection tray Coolant supply with pump Protective device for lead screw Machine base UVV is pre-equipped ( UVV=Accident Prevention Regulations) *

Condition: used, Year of construction: 1998, Technical details: turning diameter over bed: 600 mm turning diameter over support: 400 mm turning length: 2000 mm center height over support: 300 mm centre distance: 1600 mm revolution per minute: 3 - 2.500 U/min tailstock taper MT: MK 5 spindle bore of work spindle: 62 mm quill stroke: 190 mm longitudinal feeds:: ca.0,001-10 einstellbar mm/U cross feed: ca. 0,001-5 einstellbar mm/U Rapid feed X axis: bis zu 5000 m/min. total power requirement: 40 KVA weight of the machine ca.: 5,6 t dimension machine xH: 4,0 x 2,0 x 1,9 m incl. accessories see picture Dksdow Rkt Ispfx Apdon *

Condition: used, plate width 6400 mm plate depth 1870 mm plate height 400 mm Dedpfx Apogrm Ngsdokn

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 365 mm, spindle bore: 62 mm, turning length: 2,000 mm, turning diameter: 57 mm, swing diameter over cross slide: 365 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 10 m/min, spindle speed (min.): 3 rpm, spindle speed (max.): 2,500 rpm, bed width: 360 mm, total length: 5,000 mm, total width: 2,100 mm, total height: 2,000 mm, workpiece weight (max.): 1,600 kg, travel distance cross slide: 345 mm, overall weight: 5,000 kg, rotational speed (min.): 3 rpm, rotational speed (max.): 2,500 rpm, The VDF Boehringer DUS 560 Ti is, in terms of turning diameter, the most popular teach-in lathe from VDF Boehringer. With a standard chuck size of 315mm or larger, these machines offer optimal machining efficiency for single-piece and small batch production. This machine is currently set up in our showroom and can be viewed on site! Comes as standard with: - Original documentation - Set of tool holders + drill chuck Dsdpfjyvuhzex Apdjkn - Fixed steady rest - 3-jaw Forkardt 315-F Ø315mm chuck Weight & dimensions: - 5,500 kg - 5,000 x 2,100 x 2,000 mm (LxWxH) For all specifications of this machine, please see the last images!
