Universal lathe

Rogi WM410Ex1000

Condition: used, Year of construction: 2020, DOOSAN LYNX 2100LYA Year: 2020 Lhsdpfjx Id D Aox Aaxjb FANUC touch control Specification: Max spindle speed: 6000 rpm Max turning length: 510 mm Max bar diameter: 51 mm Max turning diameter: 300 mm Y-axis: 105 (±52.5) C-axis: 360° Turret: BMT45P 24 positions - Programmable tailstock - Tool probe - LNS chip conveyor - Driven tool holders: 4 pcs (2/2) - Standard tool holders: 6 pcs Operating hours: 3177 hours

Condition: new, Center length ----- 1000 mm Center height ----- 180 mm Spindle diameter ----- 360 mm Main spindle passage ----- 40 mm Bed width ----- 260 mm Spindle speed ----- 40-1800 rpm Motor ----- 2.4 KW Weight ----- 1000 kg INCLUDED * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOE5 with 4 pockets * 3 Chuck 200 mm * 4 Chuck 200 mm * Clamping plate 250 mm * LED working light and cooling system * Fixed and moving glasses Lodsga Ty Ejpfx Aaxohb HEAVY DUTY VERSION WITH CAST IRON FRAME

Condition: new, Center length ----- 1000 mm Center height ----- 230 mm Turning diameter ----- 460 mm Passage of main spindle ----- 58 mm Bed width ----- 300 mm Spindle speed ----- 25-2000 rpm Motor ----- 5.5 KW Weight ----- 1750 kg INCLUDING * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOB2 with 4 attachments * Self-centering 3 chuck 250 mm * Independent 4 chuck 320 mm * chuck 350 mm * Fixed and moving grips Lsdpek Iug Tefx Aaxohb * LED work light and cooling system * Electric brake (CE) * Foot brake * Box with various tools

Condition: new, ELMAG universal lathe PREMIUM CU 630 RD - Vario center distance 1000mm incl. RÖHM lathe chuck Performance data and holders: - Turning Ø 325-1,320 mm, without bridge 440-1,500 mm - Turning size via slide Ø 190-940 x 6,000 mm - Drive motor: 2,200-22,000 W, 400 V, high torque - Lathe chuck holder: DIN 55027 - Quill holder: MK 3 - MK 6 Standard equipment: - RÖHM three-jaw lathe chuck - Quick-change steel holder set, 5-piece - Halogen machine lamp - Emergency stop button / zero voltage release - Chuck guard with safety switch - Tool slide with splash guard - Underframe / chip tray / splash guard - Tool set / operating instructions / CE Standards PREMIUM CU series: - Heavy gray cast iron machine bed, good vibration damping - Dismountable bridge - Prismatic guides - Hardened and precision-ground turning spindle, high concentricity, adjustable precision bearings - Smooth-running rotary spindle and feed gear with oil bath - Gear wheels made of chrome-nickel steel, hardened and precision-ground - Feed reversal circuit - Covered trapezoidal thread lead screw, hardened, precision ground - Tool slide with lock nut - Precise slide guides, adjustable - Solid tailstock with taper turning adjustment - Lathe accuracy according to DIN Special accessories: - SINO digital position indicator for 3 axes - Insert turning tool set 25 x 25 mm, 7-piece - 7-piece insert set, 25 x 25 mm - Grooving tool set incl. plates, 6 pieces - Machine shoe Ø 160 mm, 6 pcs. on request: - Steady rest - Steady rest - Steady rest with ball bearing guide - Faceplate - 4-jaw faceplate chuck ADVANTAGES Rotary spindle and feed gearbox with quick-change elements Feed reversal Sliding protective cover Gear plate Halogen lamp Coolant pump Emergency stop button Rapid traverse motor Longitudinal slide TECHNICAL DATA Center width 2000 mm Center height 315 mm Turning diameter over bed 630 mm Turning diameter over carriage 430 mm Turning diameter without bridge 830 mm Machine bed width 400 mm Cross slide travel 315 mm Top slide travel 130 mm Turning tool cross-section, max. 32x32 mm Lathe chuck holder (DIN 55027) no. 11 Ljdpfot Hhbyjx Aaxohb Spindle holder (turning spindle) 120 mm Spindle bore 103 mm Speed range 1, infinitely variable 16 - 63 rpm Speed range 2, infinitely variable 63 - 250 rpm Speed range 3, infinitely variable 315 - 1250 rpm Longitudinal feeds (120) 0.04 - 12 mm/rev Transverse feeds (120) 0.02 - 6 mm/rev Metric thread dimension (64) 0.5 - 120 mm Metric modular thread (64) 0.125 - 30 mm Inch thread, threads G (64) 60 - 1/4 G/' Inch modular thread, threads G (64) 240 - 1 G/' Quill holder MK 5 Quill diameter 90 mm Quill stroke 230 mm Motor power 11000 W Mains connection 400/50 V/Hz Length (total) 3600 mm Height (total) 1400 mm Weight 3310 kg

Condition: new, Year of construction: 2026, functionality: fully functional, travel distance X-axis: 585 mm, travel distance Y-axis: 185 mm, travel distance Z-axis: 320 mm, total height: 2,245 mm, total width: 1,340 mm, total length: 1,140 mm, table width: 240 mm, table length: 1,000 mm, type of input current: three-phase, rotational speed (max.): 2,000 rpm, rotational speed (min.): 100 rpm, overall weight: 1,000 kg, working range: 650 mm, input voltage: 400 V, distance table to spindle center: 370 mm, input frequency: 50 Hz, Equipment: documentation/manual, rotational speed infinitely variable, Drilling capacity in steel ----- 50 mm Milling capacity in steel ----- 25 mm Shell milling capacity ----- 100 mm Longitudinal travel (X) ----- 585 mm Cross travel (Y) ----- 185 mm Vertical travel (Z) ----- 320 mm Horizontal motor ----- 1.5 KW Vertical motor ----- 2.2 KW Horizontal milling spindle ----- 60 ~ 1350 rpm (9) Vertical milling spindle ----- stepless 100-600 / 350-2000 rpm Spindle taper ----- ISO 40 Table ----- 1000 x 240 mm Weight ----- 1000 KG INCLUDES * DELTA frequency inverter Lhedpfsga Twfsx Aaxjb * 3-axis digital readout SINO * Automatic longitudinal and cross feed for the work table * LED lighting * Cooling system * Premium control cabinet * Tiltable milling head left/right 0 - 45 degrees * Rotatable work table * Various holders in case

Condition: new, Center length ----- 1000 mm Center height ----- 230 mm Turning diameter ----- 460 mm Main spindle passage ----- 80 mm Bed width ----- 336 mm Spindle speed ----- 25-1800 rpm Motor ----- 5.5 KW HEAVY DUTY VERSION - WEIGHT 2400 KG INCLUDED * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOB2 with 4 tines * 3 Chuck 250 mm * 4 Chuck 320 mm * 350 mm clamping plate * Fixed and moving glasses Lhsdpfjga Tz Usx Aaxsb * LED working light and cooling system * Electric brake CE * Box with various tools

Condition: new, Sawing band --- 2925 x 27 x 0.9 mm Sawing speed --- variable 20 ~ 80 M/min Motor --- 400V - 2.2 kW Weight --- 495 kg Cutting capacity 90 ----- 270 mm / 260 x 320 mm Cutting capacity 60 ----- 140 mm / 140 x 140 mm Cutting capacity 45 ----- 230 mm / 220 x 220 mm Cutting capacity -45 ---- 200 mm / 220 x 150 mm Lhjdega Tzuopfx Aaxeb INCLUDED Saw band Workpiece stop Pedestal Pressure gauge for sawbelt tension Saw band guide with carbide inserts Quick Release Clamp Cooling pump Hydraulic cylinder Motor protection switch Automatic end stop

Condition: new, Center length ----- 1500 mm Center height ----- 250 mm Spindle diameter ----- 500 mm Main spindle passage ----- 80 mm Bed width ----- 405 mm Spindle speed ----- 36-1600 rpm Motor ----- 7.5 KW HEAVY DUTY VERSION - WEIGHT 3250 KG INCLUDED Lhjdpfx Aaega Tz Rsxsb * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOC3 with 4 ridges * 3 Chuck * 4 Chuck * Clamping plate * Fixed and moving glasses * LED working light and cooling system * Box with various tools

Condition: new, Center length ----- 1500 mm Center height ----- 230 mm Spindle diameter ----- 460 mm Lhodpfx Aaega Tv Esxsb Main spindle passage ----- 58 mm Bed width ----- 300 mm Spindle speed ----- 25-2000 rpm Motor ----- 5.5 KW Weight ----- 2220 kg INCLUDED * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOB2 with 4 tines * 3 Chuck 250 mm * 4 Chuck 320 mm * 350 mm clamping plate * Fixed and moving glasses * LED working light and cooling system * Electric brake * Foot brake * Box with various tools

Condition: new, functionality: fully functional, spindle bore: 52 mm, turning diameter: 410 mm, turning diameter over top slide: 250 mm, center height: 205 mm, turning length: 1,500 mm, total length: 2,440 mm, total width: 915 mm, total height: 1,550 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 45 rpm, bed width: 250 mm, Turning diameter in gap: 580 mm, overall weight: 1,400 kg, three-jaw chuck diameter: 200 mm, Centre distance ----- 1500 mm Centre height ----- 205 mm Turning diameter ----- 410 mm Spindle bore ----- 52 mm Bed width ----- 250 mm Spindle speed ----- 45-1800 rpm Motor ----- 3 kW INCLUDES * 3-axis digital readout, brand SINO * Quick change tool post type Multifix TOOB2 with 4 tool holders * 3-jaw chuck 200 mm * 4-jaw chuck 250 mm * Face plate 350 mm Ljdpfx Aeh U Nxmjaxjhb * Fixed and travelling steady * LED work lamp and coolant system * Electric CE brake * Box with various tools
