CNC Lathe

Mazak QT Smart 200M

Year of construction: 1999, condition: used, ja VDI 20 number 3 Stück im Paket +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Itedpshr Sv Tjfx Ah Uel Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: ready for operation (used), Year of construction: 2010, controller manufacturer: MAZATROL, controller model: MATRIX, This 3-axis Mazak QTN 250 M X 1000 horizontal turning machine was manufactured in 2010. If you are looking to get high quality turning capabilities consider the Mazak QTN 250 M X 1000 machine we have for sale. Contact us for more information. Machine Benefits Technical Machine Benefits • Max. Capacity: 640 • X-axis rapid traverse speed: 36000 / z-axis rapid feed speed: 36000 / c-axis rapid feed speed: 555 Itedpfx Aheyalpce Usl • Machinable diameter: 380 • Maximum machinable length: 600 • Bar capacity: 76 • Self-centring dimensions (main spindle): 250 • Stroke: 1000/cone: cm 4 • Coolant tank: 300 l

Condition: good (used), Year of construction: 2004, functionality: fully functional, Equipment: rotational speed infinitely variable, Citizen C16-VII CNC Swiss Lathe Year of manufacture: 2004 Control: Mitsubishi Meldas 635 Max. machining diameter: 16 mm C-axis: Main and sub-spindle 5 controllable servo axes: X1/Z1/Y1/X2/Z3 4 driven tools on the vertical holder C-axis: Main and sub-spindle Includes accessories: LNS Express 220 loading magazine, 16 mm and 10 mm conversion kit Itsdev Rhd Hepfx Ah Uel Donaldson Torit extraction system Chip conveyor - Available immediately -

Condition: excellent (used), Year of construction: 2008, turning diameter over bed 32 mm spindle passage 32 mm turning length 125 mm Control YASKAWA SIEMENS 840 DI V2 clamping diameter 32 mm spindle turning speed range 7000 U/min Isdpovwgmyefx Ah Uetl workpiece length - max. 150 mm feed 0 - 2000 mm/min weight of the machine ca. 5,7 t dimensions of the machine ca. 10,5 x 2 x 1,9 m The sliding headstock automatic lathe is in good condition and ready for immediate use. with tool holders and spare parts. >> Two identical STAR 32T sliding headstock lathes are available

Year of construction: 1988, condition: ready for operation (used), I sell the flader orbital brushing machine. Model Quickwood Fladder Iedpfsf Rth Tox Ah Ujtl Working width 1060mm Mechanically adjustable rotation and feeding speed. Suitable for rustical brushing and patina surface. Profiles possible. Made in Denmark Hansen - Hundebol AS

Condition: used, Tool turret TER Type:0.5.480.525 The article is used, comes from an industrial machine dismantling and was in operation until the dismantling. Please note that this is a sample image, which may have different traces of use and/or software. Brand names, trademarks and registered trademarks are the property of their legal owners and are used here for descriptive purposes only. Further information can be found on our homepage Itsdpfxjvi Hvlo Ah Uel *

Condition: ready for operation (used), Year of construction: 2007, spindle motor power: 5,500 W, spindle speed (max.): 8,000 rpm, overall weight: 3,200 kg, This CITIZEN M32V Swiss Type Turning was manufactured in the year 2007 in Japan. The machine has a spindle speed of 8000 rpm. Official brochure attached for more details. Machine Benefits Technical Machine Benefits • Max chucking barstock: Ø 32 mm • Max machining lenght: 320 mm • Max drilling diameter main spindle: Ø 12 mm • Max back-spindle drilling: Ø 10 mm • Max. Back-spindle rotating speed: 7000 rpm Iodpfxeyi Eine Ah Uotl • Max. Back-spindle power: 2 kw • Gang rotary tool: 5 fixed tools • Turret tools: 10 positions • Bar feeder: iemca boss 332 e/r type 37ll • Equipment: chip conveyor.

Condition: used, Year of construction: 2023, turning diameter 380 mm turning length 1000 mm control Mazatrol SmoothG max. swing diameter over bed 695 mm Standard machining diameter 276 mm bar material dia. max. 80 mm x-axis 234 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 21 m/min z-axis 1090 mm rapid traverse Z-axis 33 m/min w-axis 1050 mm rapid travel W 30 m/min turning speeds 35 - 4000 U/min spindle nose A2-8 spindle bore 91 mm Motor output (30-min. rating) 26/22 Max. Torque 465 (15% ED) Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (25%ED) 11 Itodpfszzd Rtsx Ah Uel Max. Torque 90 (15% ED) Nm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 x 2,5 coolant tank 270 l Chuck diameter main spindle 10 '' Chuck diameter counter spindle 8 '' total power requirement 37 kW weight of the machine ca. 6,6 t dimensions of the machine ca. 3,6 x 2 x 1,9 m Machine in standard configuration, equipped with the following optional equipment: Air blast through the turret Automatic operator door – opening and closing Air blast system at the main spindle chuck Chip conveyor High-pressure coolant system, 15 bar Robot interface (ADVANCE / Ethernet/IP) C-axis on the sub-spindle, input resolution (contour/indexing): 0.0001° Additional push buttons on the CNC control panel Sub-spindle tailstock function Rectangular 3-colour LED signal light Preparation for oil mist extraction, mechanical flange only, Ø 98 mm Absolent 10C oil mist extraction system Preparation for bar feeder Overload monitoring system Drilling cycle with torque-dependent chip breaking Engraving function Thread re-cutting function All dimensions, weight and performance specifications are non-binding. Used machine – sold without warranty.

Condition: excellent (used), Year of construction: 2015, MAZAK QUICK TURN SMART 250ML 1000U Max. turning diameter: 360 mm Max. machining length: 1,024 mm Max. milling speed: 4,500 rpm Max. spindle speed: 4,000 rpm Max. bar diameter: 80 mm Machine is equipped with: - CNC control: Mazatrol Smart - KITAGAWA 3-jaw chuck BB-210, diameter 254 mm - Tool Eye - C-axis - Interface for bar loader magazine - Automatic parts catcher - NC tailstock - Reinforced coolant pump Isdpfxozy Um Ao Ah Ustl - Chip conveyor, discharge to the side - 8 pcs. fixed tool holders - 2 pcs. driven tool holders

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 225 mm, travel distance Z-axis: 535 mm, overall weight: 4,380 kg, number of axes: 2, Horizontal turning machine manufactured in 2007. This Mazak QuickTurn Nexus 200 CNC lathe features an 80 mm spindle bore and comes equipped with a bar feeder, collet chuck, and Matrix control. The machine has a weight of 4380 kg and includes tooling. If you are looking to get high-quality turning capabilities, consider the Mazak QuickTurn Nexus 200 machine we have for sale. Contact us for further details. • Spindle bore: 80 mm • Tailstock: Without tailstock Itjdpszyub Hofx Ah Usl Additional equipment • Bar feeder • Collet chuck • Tooling (unspecified) Technical Specification Counter Spindle No Driven Tools No
