Universal Milling Machine

KORRADI UW 10

Condition: good (used), x-travel 315 mm y-travel 180 mm z-travel 320 mm taper in main spindle ISO 40 table surface area 600 x 250 mm T-slots 5 Stk. turning speeds 45.0 - 1950 U/min feed stepless 10 - 170 mm/min voltage 400 V total power requirement 5.1 kW weight of the machine ca. 1300 kg range L-W-H 1000 x 1400 x 1800 mm From a training workshop (vocational school) Well maintained (!!) Blsdpfjxl E Sgex Ac Nsc Features: - Robust electric motor universal milling machine - HEIDENHAIN 3-axis digital display - Rotatable universal milling head (right/left = 90°) - Manual milling spindle feed, with lock - Stable T-slot clamping table - Axis feed with rapid traverse in Y-axis * Rapid traverse continuously adjustable - Manual axis adjustment in Z+X axis - Control cabinet, installed on the left - Coolant device

Condition: excellent (used), Year of construction: 2007, Universal Milling Machine, gear type, feed range X/Y/Z 500/350/400 mm, table size 800x400 mm, rotary / tilting table 600x300 mm, motor 3 KW, 18 speeds 40-2000 rpm., ISO 40, quill travel 60 mm, boring capacity Ø 40 mm, digital readout on 3 axis, automatic and rapid feeds, horizontal milling head, collant systen, halogen lamp, + round- / tilting table, dimensions 1500x1700x1750 mm, weight ca. 2200 kg; ex demonstration machine Bsdpfx Acefvci Ej Nslc

Condition: used, x-travel 315 mm y-travel 180 mm z-travel 320 mm 5 14 mm ISO 40 DIN 2079 45 - 1950 U/min flute distance 10 - 170 mm/min no. of flutes 4 m/min total power requirement 5,1 kW distance between table/spindle 1400 kg diameter of rotary table 3000 x 2700 x 1800 mm - Robust/powerful universal milling machine - HEIDENHAIN digital display - Coolant device Blsdpfexwdvhex Ac Nsc

Condition: good (used), functionality: fully functional, Infinitely variable feeds on all axes Quill stroke 60 mm Table surface 600 x 250 mm Spindle speeds 45 - 1950 rpm Feeds 10 – 470 mm/min...infinitely adjustable... : Bsdjx A S Dqepfx Ac Nolc Longitudinal travel (X) 315 mm Cross travel (Y) 180 mm Vertical travel (Z) 320 mm .

Condition: good (used), x-travel 300 mm y-travel 350 mm z-travel 350 mm taper in main spindle ISO 40 table surface area 625 x 380 mm T-slots 8 Stk. turning speeds 40.0 - 2.000 U/min transmission ratio 18 Stk. feed stepless 0 - 500 mm/min quill stroke 60.0 mm distance spindle nose and table min 50 / max 400 mm voltage 400 V Bsdoxl E Stepfx Ac Nolc total power requirement 5.1 kW weight of the machine ca. 800 kg range L-W-H 1400 x 1100 x 1700 mm from a training workshop (vocational school) Well maintained (!!) Features: - Robust electric motor universal milling machine - HEIDENHAIN 3-axis digital display - Rotatable universal milling head (right/left = 90°) - Manual milling spindle feed, with lock - Stable T-slot angle/clamping table * Swiveling +/- 30 degrees - Axis feed with rapid traverse in X+Z+Y axis * Rapid traverse continuously adjustable - Swiveling machine light - Control cabinet, installed on the left - Coolant device

Condition: used, Year of construction: 1975, Technical details: x-travel: 300 mm y-travel: 350 mm z-travel: 350 mm quill stroke vertical: 60 revolution per minute: 40 - 2000 U/min feed:: 12,5 - 500 / 18 step mm/min. tool taper: SK 40 headstock adjustment: schwenkbar 90° rechts/links mm headstock adjustment: Y-Weg: 175 mm table surface area: 600 x 285 mm distance spindle nose and table: min./max.: 50 / 400 mm distance spindle center to column: min./max.: 170 7 345 mm total power requirement: 1,6 kW weight of the machine ca.: 0,8 t dimension machine xH: 1,4 x 1,1 x 1,7 m Bjdpfxju T Navo Ac Nslc Spindle vertical tool holder SK 40 Quill stroke 60 mm Speed 40 - 2000 rpm with 18 transmission steps Spindle horizontal Tool holder SK 40 Speed 40 - 2000 rpm with 18 transmission steps Equipment: 3-way display Heidenhain Coolant system *

Condition: good (used), Year of construction: 2005, travel distance X-axis: 560 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 400 mm, feed rate X-axis: 2,400 m/min, feed rate Y-axis: 2,400 m/min, feed rate Z-axis: 2,400 m/min, table width: 450 mm, table length: 950 mm, Fixed table 950 x 450 mm Feeds all direction ISO-40 and 3kW 3 Axis Digital Read Out Systsem CE-Safety  Coolant system with semi closed lower base  X-Axis: 560mm Y-Axis: 320mm Z-Axis: 400mm Table Length: 950mm Table Width: 450mm Table load: 350 Spindle speeds: 2240Rpm Blodpfsxdltbjx Ac Noc Feed rate X-Axis:2400mm/min. Feed rate Y-Axis:2400mm/min. Feed rate Z-Axis:2400mm/min. Stroke pinole: 0 - 95mm Length: 1800mm Width: 1600mm Height: 1900mm Weight: 1700kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: reconditioned (used), functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 25 rpm, Dear Sir or Madam, For sale is a Deckel FP2 milling machine. This newer model is especially notable for its stepless speed control, while still maintaining a very simple construction. Operation is extremely straightforward. The machine has undergone extensive partial refurbishment in our workshop and is therefore in excellent condition. You are welcome to inspect the machine in person. --- Currently, we have 3 units available --- Delivery time: on request Machine no.: 2202-xxxx Table: fixed angle table or rotary-tilt-swivel table Travel ranges: X 400 mm / Y 220 mm / Z 400 mm Drive power: 3 kW Number of spindle speeds: 16 Speed range: 25–2500 rpm Tool holder: SK40 Draw system: S20x2 Feed: stepless Equipment and accessories: Heidenhain 3-axis digital readout, stepless feed adjustment in all 3 axes, coolant system, central lubrication, technical documentation, leveling feet, safety devices (optional) Bsdpfx Ajx Hr Dzjc Nslc Our service promise to you: - We are a certified master engineering company - All machines are thoroughly inspected - All lubricants and any worn parts are replaced beforehand - On request, we can fully or partially overhaul your selected machine - On request, you can order additional accessories such as tools, etc., directly - On request, we can install additional features such as safety devices directly - We are happy to arrange shipping and/or installation for you
