Medium duty cnc lathe

HURCO TM 8 i

Condition: like new (used), Year of construction: 2019, operating hours: 3,450 h, functionality: fully functional, turning diameter over cross slide: 300 mm, turning length: 525 mm, turning diameter: 356 mm, spindle bore: 64 mm, spindle speed (max.): 4,000 rpm, Machine in excellent condition. Year of manufacture: 2019. TM8i machine specifications Travels and working range: Distance between centers: 597 mm Swing over bed: 525 mm Swing over cross slide: 300 mm Maximum turning diameter: 356 mm Maximum turning length: 525 mm Maximum bar diameter: 64 mm X/Z axis travel: 203 / 550 mm Spindle: Maximum spindle speed: 4,000 rpm Maximum torque (high gear): 133.83 ft·lbs at 1,000 rpm (100.7 Nm at 1,000 rpm) Spindle power: 25.48 hp (19 kW) Spindle nose: A2-6 Chuck diameter: 210 mm Turret: Tool type: slotted disk Capacity: 12 stations Indexing time (adjacent stations): 1.3 s Indexing time (furthest stations): 3.6 s Feeds: Rapid traverse X/Z axes: 30 m/min Dimensions: Maximum installation area: 4336 × 3114 mm Machine height: 2193 mm Machine weight: 4,030 kg Lrsdpfx Asyfhynsb Eoi Workpiece gripper dimensions: 150 × 95 × 70 mm

Condition: used, Year of construction: 2010, Milling machines Travel distance X: 760 mm Travel distance Y :510 mm Travel distance Z: 610 mm HSC-machines Number of axis: 3 milling machine / machining center Control: Hurco WinMax spindle chuck: SK - A40 spindle revolutions: 12000 rpm table size X: 1020 mm table size Y: 508 mm max. workpiece weight: 1350 kg tool changer: 24 - time input Power : 13,5 kW Lodpfx Asv D U Apob Eeri Torque: 214 Nm Rapid traverse: 35 m/min spindle cooling chip conveyor

Condition: used, Year of construction: 2017, operating hours: 1,200 h, functionality: fully functional, turning diameter over cross slide: 256 mm, turning length: 527 mm, spindle bore: 52 mm, spindle speed (max.): 4,800 rpm, Equipment: rotational speed infinitely variable, Description: For sale is a HURCO TM8i VDI CNC lathe with MAX5 single control, year of manufacture 2017, with only approx. 1,200 operating hours. The machine is in excellent condition, has been regularly serviced, and is immediately ready for operation. Ideal for precise turning applications in small and medium-sized batch production. Accessories / Equipment: Ljdpfx Aoxfgkkeb Eori • Tool presetter • Chip conveyor • Coolant system • Three-jaw chuck • Collet chuck with various collets • Mist extraction unit Condition: • Lightly used (only 1,200 hours) • Regularly serviced • Immediately available • Inspection by appointment possible

Condition: used, Year of construction: 2007, TECHNICAL DATA Travel X 760 mm Travel Y 510 mm Travel Z 610 mm Table clamping surface 1020 x 510 mm T-slots / table 5 x 18 mm x 100 mm Distance spindle to table min./max. 150/762 mm Spindle taper steep taper DIN 69871 ISO 40 Spindle speeds 10–10000 rpm Drive power (30 min/continuous duty) 11 kW Max. torque 236 Nm Constant power from 500 rpm Coolant tank 190 l Linear guides with ball bearings in X, Y, Z axes Rapid traverse X/Y/Z 30 / 30 / 20 m/min Ledpfxowud Afe Ab Ejri Feedrates programmable 3.0–7600 mm/min Positioning accuracy ±0.01 mm Repeatability ±0.005 mm Automatic tool changer (double-arm) 24 positions Internal cooling Chip conveyor

Condition: used, Year of construction: 2008, Technical details: turning diameter over bed: 600 mm turning dia. over face-slide: 540 mm turning length: 550 mm longitudinal traverse (z-axis): 800 mm facing movement (x-axis): 260 mm control: Fanuc 18i-TB spindle bore: Ø 73 mm bar material dia.: Ø 65 mm revolution per minute: 0 ... 5000 steples U/min max. torque on the spindle: max. 250 Nm rapid traverse in x-y-z axis: X/Z: 30 m/min. / Y: 12 m/min. rapid traverse c-axis: 1000 U/min. tool turret - number of stations: 12 (Sauter) operating pressure: 6,0 bar electrics - voltage/frequency: 3 x 400 / 50-60 V/Hz operating pressure: 6 bar total power requirement: 40 kVA Weight approx.: 5,7 t dimension machine xH: 2,2 x 3,4 x 2,4 m Lodpfxjvvtpxe Ab Ejri dimension swarf conveyor LxWxH: ca. 2,9 x 0,6 x 0,55 (0,38 to) m dimensions LxWxH: Spänewanne: ca. 1,6 x 1,3 x 0,25 (0,2 to) m transport measurements machine: ca. 3,3 x 1,9 x 2,2 m The machine has a C-axis, E-axis, Y-axis, and W-axis. Powered tools can be used in all positions. Distance between spindle and counter spindle = 1050 mm. Counter spindle: A2-6, travel distance 800 mm, spindle diameter 105 mm, torque 250 Nm. Control cabinet equipped with Rittal cooler With hinged chip conveyor Chip tray Compressed air gun The machine has NO lathe chucks on sale as is! *

Condition: used, various tool holders from , mazak, sandvik, mimatic, gerardi, ews, nikken and others. turning-milling tools with the VDI 40 holder only for sale per pallet pallet5 euro 2730 total 3x driven tools vdi 40 euro 580/pc 11x tool holder vdi 40 euro 90/pc pallet 6 euro 2640 total 3x driven tools vdi 40 euro 580/pc Ljdpfxevry T Ne Ab Eeri 10x tool holder vdi 40 euro 90/pc pallet 7 euro 2640 total 3x driven tools vdi 40 euro 580/pc 10x tool holder vdi 40 euro 90/pc pallet 8 euro 2730 total 3x driven tools vdi 40 euro 580/pc 11x tool holder vdi 40 euro 90/pc

Condition: used, Year of construction: 1990, 15282 90 band length 4600 - max. 4750 mm Fabr. Ideal Lrjdpsic Hqhofx Ab Eoi weight ca. 890 kg dimensions of the machine ca. 130 x 850 x 2300 mm +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: used, Various tool holders from Mazak, Sandvik, Mimatic, Gerardi, EWS, Nikken and others. Turning and milling tools with VDI 40 interface. Only for sale per pallet. Pallet 1: EUR 3,220 total 4x driven tool VDI 40 at EUR 580/each 10x tool holder VDI 40 at EUR 90/each Pallet 2: EUR 3,130 total 4x driven tool VDI 40 at EUR 580/each (1x new) Lrsdpfx Abovpvmtj Eji 9x tool holder VDI 40 at EUR 90/each Pallet 3 is sold Pallet 4 is sold

Condition: used, Year of construction: 1995, cutting diameter 260 mm saw band length 3830 x 27 x 0,9 mm cutting range flat 310 x 260 mm cutting range square 260 x 260 mm cutting speed stufenlos 19-110 m/min feed length 750 mm multiple feeding length 6750 mm height of material-table 700 mm weight of the machine ca. 1,4 t Lrjdpfx Abewhqxms Esi dimensions ca. 2100x2300x1720/1300 mm incl. several band saw blades incl. chip conveyor

Condition: used, Year of construction: 2001, functionality: unexamined, travel distance X-axis: 610 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, total height: 2,500 mm, total length: 2,200 mm, total width: 2,400 mm, table length: 760 mm, table width: 510 mm, table load: 1,000 kg, For sale is a 3-axis CNC milling machine from the Hurco brand and the type VMX 24 Technical data: - Year of manufacture: 2001 - Control: Winmax 4 - X axis: 610.0 mm - Y axis: 510.0 mm - Z axis: 610.0 mm - Table length: 760.0 mm - Table width: 510.0 mm - Max. part weight: 1000.0 kg - Length: 2200.0 mm - Width: 2400.0 mm - Height: 2500.0 mm - Weight: 4700.0 kg - Number of tool pockets: 24.0 Pull bolts, which can be seen in pictures, are not part of the offer Transport and loading can be organized throughout Europe on request for an additional charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machine purchase/sale Lrsdsv Tcfkspfx Ab Esi PURCHASE/SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit us on our website
