Machining center

HERMLE C30 U

Condition: reconditioned (used), Year of construction: 2008, CNC Vertical Machining Center HERMLE C 30 U Equipped with Heidenhain iTNC 530 contouring control Year of manufacture: 2008 Travels: X 650 Y 600 Z 500 mm Speed range: 20 – 18,000 rpm, stepless (HSK 63) Including the following accessories: - NC rotary tilting table Ø 630 mm - Vertical tool changer with 32 magazine stations (HSK 63) - Standard version linear axes Lhsdpfx Ajx Hg Ubsf Sjr - Spindle center air blast - Blowing device - Through-spindle coolant 40 bar, paper band filter for coolant system - Scraper belt conveyor - Manual cabin door, manual cabin roof - Polycarbonate safety windows - Electronic thermal compensation iTNC 530 - Electronic hand control module iTNC - 3D measuring probe Heidenhain - Various HSK 63 tool holders with mounted tools - Rotating clear-view window - Oil mist extraction unit - Chip rinsing gun - 4 height-adjustable machine feet - Operating manuals

Condition: excellent (used), Year of construction: 2000, TECHNICAL DETAILS CNC Control: HEIDENHAIN TNC430 X-axis travel mm: 600 Y-axis travel mm: 450 Z-axis travel mm: 450 A-axis travel mm: +/- 110 C-axis degrees: +/- 360 Lhsdpexak A Hjfx Af Sjr Number of pallets: 1 Table dimensions mm: - Max. table load kg: - Feed rate mm/min X, Y, Z: 20,000 Max. rapid traverse m/min X, Y, Z: 35,000 Spindle speed rpm: 50 - 10,000 Spindle power kW: - Taper type: ISO-SK40 Torque Nm: - Tool changer type: Chain Tool changer positions: 30 Max. tool diameter mm: - Max. tool diameter with adjacent pockets empty: - Max. tool length mm: - Max. tool weight kg: - Coolant tank capacity l.: - Through-spindle coolant bar.: - EQUIPMENT: Zero-point clamping system: EROWA MTS / EROWA MTS RENISHAW OMP60 probe MACHINE DIMENSIONS Length mm: 2,130 Width mm: 2,300 Height mm: 2,750 Weight kg: 6,500

Condition: excellent (used), Year of construction: 2004, PLC software: 07.08.2020 iC30V2_1.10 SP1 NC software: 07.08.2020 340 422 14 SP5 Machine specification: - Heidenhain iTNC530 03/04 Lhedpfx Afjrwpdnj Sor - Main spindle 18,000 1/min 03/04 - HSK-A63 03/04 - 32 tool positions 03/04 - Linear axes standard versi03/04 - NC swivel rotary table ø 630m03/04 - specified - T-slots - Internal coolant supply 40 - Paper belt filter - Scraper belt conveyor - Basic cabin design - Manual cabin door - Manual cab roof - Polycarb. safety shield - 50 Hz - BLUM tool breakage/ measurement - Renishaw measuring probe Other accessories - Electrical heat compensator - Manual control module - Blow-off device - Oil mist extraction - Flange for suction unit - Chip flushing gun - Sealing air for scales - Chip cart 200 liters - Automatic cabin door - Pneumatic extension clamping / release - Automation interface Programs - 6-fold rotary feed-through / SRT630 - Commissioning included - Transportation free kerbside on request, but excluding unloading and installation of the machine.

Condition: ready for operation (used), Year of construction: 2006, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: TC 530, spindle motor power: 15,000 W, swivel angle C-axis (max.): 360 °, number of axes: 5, Control Unit Brand HEIDENHAIN Model TC 530 Ljdpjx D I Saefx Af Sshr Main Drive Spindle motor power 15 kw Spindle bore 18000 Number of axis 5 Movement X-Axis Movement 650 mm Y-Axis Movement 600 mm Z-Axis Movement 500 mm C-Axis Movement 360º table rotation Media Chip conveyor Yes This HERMLE C30U Vertical Machine Center was made in the year 2006. It is equipped with a HEIDENHAIN TC 530 control unit and has 5 axis. The machine has a spindle speed of 18000 rpm. There are 2 identical units available. Application Types Milling

Condition: good (used), Year of construction: 2004, operating hours: 109,078 h, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 45,000 m/min, rapid traverse Y-axis: 45,000 m/min, rapid traverse Z-axis: 45,000 m/min, controller model: Siemens 840 D, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Hermle C30 U Siemens 840D Machine HOURS: 109,078 h Spindle HOURS: 22,117 h - Spindle HSK-A63 10,000 rpm - 32 tool pockets - Rotary table SRT 280 mm with integrated clamping system SK50 (if not required, this can be closed or alternatively converted for use as a zero-point clamping system) - External coolant supply - Internal coolant supply with paper band filter, 80 bar - Swarf flushing pistol - Chip conveyor - Handheld control unit - Automatic cabin door - 32 tool pockets plus 87 additional ZM87 positions - Thermal compensation - BLUM tool measurement on carriage - Renishaw probe - Chip container - Status indicator light Ledpfx Afexcp Sls Sehr The machine has been thoroughly inspected, and there is a geometry inspection protocol as well as circularity test measurements available. The machine can be viewed and tested under power at any time. Very well-maintained condition.

Condition: used, Year of construction: 2013, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t dimensions of the machine ca. 15 x 7,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 30 U Lodeuyl Tbopfx Af Sehr Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Automatic cabin door Rotating transparent window - incl. 32x HSK 63 holders - incl. 10x collets Also available as a production cell (2x Hermle C 30 U + Kuka Automation)

Condition: ready for operation (used), Year of construction: 2006, Control Unit Brand HEIDENHAIN Model iTNC 530 Lhjdpfxex D Ew Hj Af Ser Main Drive Spindle speed range 18000 rpm Tool taper SK 40 Additional Equipment Tool Magazine: Additional magazine ZM157 Tool Breakage/Measurement: BLUM tool breakage/measurement Measuring Probe: Heidenhain Event Messenger: Available Electrical Heat Compensation: Provided External Blowing Air: Provided / Oil Mist Extraction: Provided / Chip Trolley: 450 liters Rotating Transparent Window: Available Additional Accessories: Manual control module, flange for extraction 1, bed flushing, sealing air for scales, machine license TCS-Soflex This 5-axis HERMLE C30U + RS Automation was manufactured in 2006, offering advanced capabilities for precision machining. Ideal for complex geometries, this vertical machining centre represents a significant asset for enhancing your production efficiency. Consider the opportunity to buy this HERMLE C30U vertical machining centre. Contact us for more information. Application Types Milling

Condition: good (used), Year of construction: 2006, operating hours: 119,571 h, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 45,000 m/min, rapid traverse Y-axis: 45,000 m/min, rapid traverse Z-axis: 45,000 m/min, controller model: Siemens 840 D, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Hermle C30 U Siemens 840D Machine ON: 119,571 h, Spindle ON: 56,792 h Lhsdjxcp Srspfx Af Sor - Spindle HSK-A63 10,000 rpm - 32 tool stations - Rotary table SRT 280 mm with integrated clamping system HSK100 (if not needed, it can be covered or alternatively converted to a zero-point clamping system) - External coolant supply - Internal coolant supply with 80 bar paper band filter - Chip flushing gun - Chip conveyor - Handheld control module - Automatic cabin door - 32 tool stations plus 87 additional stations ZM87 - Thermal compensation - BLUM tool measurement on the side - Renishaw probe - Chip container - Status light The machine has been thoroughly inspected and comes with a geometry report as well as circularity test measurements. The machine can be viewed and tested under power at any time. Very well-maintained condition.

Condition: used, Year of construction: 2014, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t Lhodeuyl Thspfx Af Ssr dimensions of the machine ca. 15 x 7,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 30 U Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Automatic cabin door Rotating transparent window - incl. 32x HSK 63 holders - incl. 10x collets Also available as a production cell (2x Hermle C 30 U + Kuka Automation)

Condition: used, Year of construction: 2013, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg Ljdpfx Aeuwv Dlsf Sehr number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t dimensions of the machine ca. 15 x 7,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 30 U - 2x Hermle C 30 U Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Automatic cabin door Rotating transparent window - 1x Kuka KR 180 R2900 prime 6 axes Load capacity: 180 kg Reach: 2,896 mm 66x spaces for workpiece pallets 2x changing places 1x turning station 8x gripper spaces - incl. 1x Schunk gripper - incl. 66x workpiece pallets - incl. 64x HSK 63 holders - incl. 20x collets Also available as a single machine Hermle C 30 U.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 48,702 h, functionality: fully functional, machine/vehicle number: 16261, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller model: Siemens Sinumerik 840 D pl , spindle speed (max.): 28,000 rpm, TECHNICAL DETAILS Travel Paths X-axis travel: 650 mm Y-axis travel: 600 mm Z-axis travel: 500 mm Main Spindle Spindle speed range: 20 – 28,000 rpm Spindle drive power: 23 / 18 kW Max. torque: 79 Nm Tool taper: HSK-A63 NC Rotary Swivel Table Clamping surface: Ø 630 mm Swivel range A: +30° / -115° Rotatable C: 360° Max. table load: 500 kg Max. workpiece dimensions: Ø 630 x 313 mm Table rotation speed A: 25 / C: 65 rpm Tool Changer Number of tool stations: 117 Max. tool diameter: 90 mm Max. tool length: 300 mm Feed Rates Rapid traverse (X / Y / Z): 60 m/min Acceleration: 10 m/s² Feed force: 8.5 kN MACHINE DETAILS Control: Siemens Sinumerik 840 D pl Space Requirement & Weight Required space approx.: 8.5 x 5.5 x 3.0 m Machine weight approx.: 10,500 kg Ledpfxjxbz A Hs Af Sjhr Total power requirement: 43 kVA Operating hours: 48,702 h EQUIPMENT - Documentation - High-pressure cooling - Coolant system - Internal coolant supply: 80 bar / 1,300 l - Electronic handwheel - Fully enclosed cabin - FASTEMS pallet pool / 15 positions - Chip conveyor - Paper band filter - Renishaw probe - Tool breakage monitoring Note: Transport lifting gear must be provided by the buyer. The pallet system cannot be observed under power. The Fastems controller is defective.
