Vertical lathe

EMAG VL 3

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: 109242, Technical specifications: Work Area - Chuck diameter: 260 mm - Maximum weight: 150 kg - Swing diameter: 280 mm - Max. workpiece diameter/height: 200/200 mm - X-axis stroke (effective travel): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN - Z-axis stroke: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN - Loading time: 5–6 sec - Standard closed automation (number of loading positions per workpiece diameter): 14/(80...200), 18/(30...160), 30/(30...85) Main Spindle - Spindle interface according to DIN 55026: Size 6 - Max. speed: 4,500 rpm - Power at 100% / 40% duty cycle: 25 / 18 kW - Torque at 100% / 40% duty cycle: 280 / 200 Nm Tool Turret with Driven Tools Ndodpfx Ahexxit Usvod - Tool holder with cylindrical shank per DIN 69880: 12 positions - BMT65 - Number of tool stations: 12 - Max. tool length (incl. holder): 200 mm - Max. speed: 6,000 rpm - Max. torque (10% duty cycle): 27 Nm, (100% duty cycle): 14 Nm Electrical System - Operating voltage: 400 – 480 V, 100 A - Connected load: 36 kVA Dimensions - Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm - Weight: 9,000 kg Main Features and Capabilities: - Vertical design: Optimized for efficient chip removal and easy part loading/unloading - CNC control: GE Fanuc FS 32i B - High precision: Positioning accuracy (X/Z axes) ±0.001 mm; equipped with Heidenhain linear scales - Powerful main spindle: High output and large speed range - In-process measurement: Marposs T25 probing system - Fully automated loading/unloading: EMAG O-Type—parts are loaded and removed by integrated automation - Live tooling: Allows for drilling and milling operations beyond standard turning - Tool life monitoring with sister tool management - Chip conveyor and coolant filtration unit: Micron filter with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, illuminated for safe and easy operation - Documentation: Electronic documentation available (hard copy not complete) Machine status: Operational (in production)

Condition: ready for operation (used), Year of construction: 2010, operating hours: 49,479 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 210 mm, turning length: 100 mm, TECHNICAL DETAILS Max. turning diameter: 210 mm Max. turning length: 100 mm Max. swing diameter over bed cover: 210 mm Travel X-axis: 400 mm Travel Z-axis: 200 mm Max. workpiece length: 100 mm Max. workpiece diameter: 27 workpieces with 30–85 mm or 18 workpieces with 30–130 mm Max. main spindle speed: 7,500 rpm Main spindle power at duty cycle 10–40/100% max.: 25/16 kW Nodpjxu Ekbofx Ahvsdd Main spindle torque at duty cycle 10–40/100% max.: 200 Nm Main spindle front bearing diameter: 80 mm Main spindle flange size: Size 5 (DIN 55026) Axes at main spindle unit: X/Z Turret: bottom Number of stations/driven stations: 12/12 Tool mounting in turret: VDI 40 Rapid traverse speed X-axis: 60 m/min Rapid traverse speed Y-axis: 30 m/min Feed force in X/Z main spindle unit: 5,000 N Direct linear measuring system main spindle unit: X/Z MACHINE DETAILS Control: Fanuc 18i TB Electrical Data Operating voltage: 400/50 V/Hz Main fuse: 80 A Total connected load: 36 kVA Dimensions & Weight Machine dimensions (LxWxH): approx. 2,500 x 1,900 x 2,300 mm Overall system footprint (LxWxH): approx. 3,600 x 1,900 x 2,300 mm Machine weight: approx. 6,000 kg Operating hours: approx. 49,479 h EQUIPMENT Full-stroke cylinder on main spindle Splash guard enclosure with fully encapsulated working area Work area lighting Oil/emulsion mist extraction system Hinged belt chip conveyor (discharge height: 1250 mm) Coolant system Circulating parts storage conveyor Automatic central lubrication

Condition: excellent (used), Year of construction: 2005, Fanuc 18 iTB control Swing diameter 210 mm, X/Z travel 400/200 mm, Spindle speed 7500 rpm, 12-station turret with driven tools. Chip conveyor belt, 3-jaw chuck Chip conveyor Nedpfew Rdcpsx Ahvodd

Condition: used, Year of construction: 2001, functionality: fully functional, input voltage: 400 V, We offer 4 pieces Emag VL 3 for sale. Three machines with Lifetool. One machine without Lifetool. Year of construction of the machines 2000-2001 General description: Manufacturer: Emag Machine type: VL3 Technical data: Nodpfx Ahotrdlaovsdd Control: Fanuc 21i-T and Fanuc 18i-T Rotation diameter: approx. 210 mm Maximum speed 6,500 1/min Turret: VDI 40 mm, 12 stations Hinged belt chip conveyor Spindle holder: GR. 5 Circulating parts conveyor. Machine weight: approx. 5.5 t A used three-jaw chuck is included with every machine. The description is non-binding and should be checked during an inspection.

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: 109239, Technical characteristics: Work Area # Chuck diameter: 260 mm # Maximum workpiece weight: 150 kg # Swing diameter: 280 mm # Maximum workpiece diameter/height: 200/200 mm # X-axis travel (working stroke): 760 mm / Rapid traverse in X: 60 m/min / Feed force: 6.9 kN # Z-axis travel: 415 mm / Rapid traverse in Z: 30 m/min / Feed force: 18.7 kN # Loading time: 5-6 sec # Standard enclosed automation (number of loading stations based on workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle # Spindle according to DIN 55026: Size 6 # Maximum speed: 4,500 rpm # Power at 100% / 40% duty cycle: 25 / 18 kW # Torque at 100% / 40% duty cycle: 280 / 200 Nm Turret with Driven Tools # Tool shank interface according to DIN 69880: 12 positions - BMT65 # Number of tool stations: 12 # Maximum tool length including holder: 200 mm # Maximum speed: 6,000 rpm # Maximum torque: 27 Nm at 10% duty cycle, 14 Nm at 100% duty cycle Electrical Equipment # Operating voltage: 400 - 480 V, 100 A # Connected load: 36 kVA Dimensions # Overall dimensions: Length = 5,300 mm (with chip conveyor), Width = 2,300 mm, Height = 3,650 mm # Machine weight: 9,000 kg Main Features and Capabilities: # Vertical design: Optimized for chip removal with easy loading/unloading. # CNC control: GE Fanuc FS 32i B. # High precision: Positioning accuracy in X, Z axes ±0.001 mm with Heidenhain linear scales. # Powerful main spindle: High power and broad speed range. # In-process control: Marposs T25 measuring probe. # Fully automated loading/unloading: Emag O-Type; workpieces are automatically loaded and unloaded via integrated automation. # Driven tools: Enables drilling and milling operations within the machine. # Tool life monitoring with sister tool management. Ndedpfxoxxir Ds Ahvsd # Chip conveyor and coolant filtration unit: Micron filter with paper filter, 40 bar pumps (suitable for filtering two machines). # Fully enclosed work area, internal work light. # Documentation: Electronic version available (book version incomplete). Machine status: OPERATING

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, input voltage: 400 V, year of last overhaul: 2023, ATTENTION: THIS MACHINE AT A ONE-TIME SPECIAL PRICE. General description: Year of construction: 2001/2023 Manufacturer: Emag Machine type: VL3 Technical Data: Control: Fanuc 21i-T Rotation diameter: approx. 210 mm Maximum speed 6,500 1/min Turret: VDI 40 mm, 12 stations The machine does not have a life tool. Hinged belt chip conveyor Ndsdpfx Ahstpu Szevjd Spindle holder: GR. 5 Circulating parts conveyor. Machine weight: approx. 5.5 t The following work was carried out during this overhaul in 2023: -Machine was completely dismantled, cleaned and repainted, The main spindle was re-supported -The guides and guide shoes were replaced in the X-axis and Z-axis -The ball screw in the X-axis and Z-axis was replaced -New unit for central lubrication and new hoses -Hydraulic unit was checked and serviced. Drive coupling between motor and pump was replaced -Cooling unit was checked and serviced: Temperature difference controller was replaced - Clamping cylinder was re-mounted and sealed. Gearbox of the A-axis was re-mounted and coupling between motor and gearbox was replaced -Electrical cabinet was cleaned -Control panel was replaced -New screen -New interior lighting -Turret was dismantled, wearing parts checked, cleaned and resealed -Cleaned turret encoder and encoder wheel -Length measuring systems in X-axis and Z-axis disassembled and cleaned -Pick-up station springs replaced -X-axis and Z-axis motors were checked for bearing damage -The windows on the work door were replaced. -The chip conveyor was completely dismantled, re-stored, cleaned and painted -Of course, various small parts of the machine were also replaced The product has been described by us with the utmost care. The description is non-binding and should be checked during an inspection.

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 108113, Technical Characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse Z: 30 m/min - Standard automation with closed system (number of loading nests by workpiece diameter: 14/(80–200), 18/(30–160), 30/(30–85)) Main Spindle - Spindle interface per DIN 55026: Size A5 - Maximum spindle speed: 6000 rpm - Power (100% / 40% duty cycle): 18.1 / 13.9 kW - Torque (100% / 40% duty cycle): 77 / 59 Nm Tool Holder with Driven Tools - Tool shank per DIN 69880: 12 – BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque (10% duty cycle): 27 Nm; (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Total dimensions (L x W x H): 4350 mm (with chip conveyor) x 1600 mm x 2500 mm Ndsdpfsxxip Aox Ahved - Weight: 5500 kg Main Features and Capabilities: - Vertical Design: Optimized for chip removal and easy loading/unloading - CNC Controller: GE Fanuc FS 32i B - High precision: Positioning accuracy in X and Z axes ±0.001 mm with Heidenhain linear scales - Main spindle: High power and broad speed range - In-process control: Marposs T25 measuring probe - Automated loading/unloading: Integrated automation for feeding and removing parts - Live tools: Capability for drilling and milling operations - Tool life monitoring and sister tool management - Chip conveyor & Knoll coolant filtration unit with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, with work area lighting - Documentation: Electronic version available, printed booklet incomplete Machine Status: - NOT WORKING - LT motor defective, repairable - Operator panel, safety switch, and two buttons broken and need replacement

Condition: repair required (used), Year of construction: 2006, functionality: not functional, machine/vehicle number: 00592, Technical Specifications: Work Area - Maximum clamping plate diameter: 200 mm - Maximum machining diameter: 130 mm Ndsdpfx Ahjxwlbxsvod - Maximum workpiece length: 110 mm - X-axis travel: 400 mm / Rapid traverse X: 60 m/min - Z-axis travel: 200 mm / Rapid traverse Z: 30 m/min - Standard closed automation (number of loading stations by workpiece diameter): 14/(80...200 mm), 18/(30...160 mm), 30/(30...85 mm) Main Spindle - Spindle to DIN 55026, Size 6 - Maximum speed: 7,500 rpm - Power at 100%/40% duty cycle: 18 / 27 kW - Torque at 100%/40% duty cycle: 202 / 303 Nm Tool Turret with Driven Tools - Tool shank DIN 69880: 12x VDI40 - Number of turret stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6,000 rpm - Maximum torque: 37 Nm (10% DC), 26 Nm (25% DC), 14 Nm (100% DC) Electrical Equipment - Operating voltage: 3x 400–480 V, 50A - Connected load: 31 kW Dimensions - Overall dimensions: L = 2,680 mm (3,820 mm with chip conveyor), W = 2,040 mm, H = 2,400 mm - Weight: 5,500 kg Main Features and Capabilities: - Vertical design for optimal chip evacuation and easy loading/unloading - Control: GE Fanuc Series 18i-TB - High precision: Positioning accuracy in X, Z, and Y axes ±0.001 mm with Heidenhain linear scales - Main spindle: High power and wide speed range - Automated loading/unloading: Integrated automation for part feeding and removal - Driven tools: Enables drilling and milling operations - Chip conveyor - Documentation: Electronic documentation unavailable, hardcopy/manual available Machine Condition: NOT OPERATIONAL - Driven tool motor defective - Driven tool gearbox defective
