DOOSAN Puma 2600 SY II

DOOSAN Puma 2600 SY II

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees on both spindles, 24 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter, LNS barfeed unit. Pgodpfezt Spnox Appot

Condition: used, Year of construction: 2010, turning length: 1,495 mm, spindle speed (min.): 35 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, workpiece weight (max.): 300 kg, total height: 2,577 mm, total length: 5,088 mm, total width: 2,450 mm, spindle nose: A2-6, spindle diameter: 660 mm, Equipment: documentation/manual, CNC Control Mazatrol Matrix Turning diameter 660 / 260 mm Turning length 1495 mm Spindle bore diameter 65 mm Spindle nose A2-6 Spindle nose sub spindle A2-6 Turning speed spindle 35 - 5.000 R/min Turning speed sub spindle 35 - 5.500 R/min Milling head speed 15 - 21.500 R/min Movement X-axis 580 mm Movement Y-axis 160 mm Pgodpfjzqt Umex Appst Movement Z-axis 1.545 mm B-axis travel 225° C-axis indexing 0,0001 (360) ° Tool taper Capto C6 Tools in tool magazine 120 Barfeeder Irco-Breuning ILS-MUK If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: like new (used), Year of construction: 2020, functionality: fully functional, turning length: 760 mm, turning diameter over cross slide: 630 mm, turning diameter: 376 mm, spindle motor power: 18 W, spindle speed (min.): 40 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 81 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, type of input current: three-phase, bar passage: 81 mm, total height: 2,170 mm, total length: 4,400 mm, total width: 2,100 mm, overall weight: 6,650 kg, spindle diameter: 254 mm, Equipment: documentation/manual, rotational speed infinitely variable, USED ​​6-axis CNC lathe with counter spindle, live tools and Y-axis and FANUC 0i-TF PLUS CNC Pgodozrmiaopfx Appjt

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning diameter over cross slide: 630 mm, turning length: 760 mm, turning diameter: 376 mm, spindle bore: 92 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 105 mm, travel distance Z-axis: 830 mm, spindle motor power: 15 W, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,163 mm, total length: 3,560 mm, total width: 1,945 mm, turning diameter over bed slide: 780 mm, overall weight: 6,550 kg, bar passage: 81 mm, Equipment: documentation/manual, I am offering a Doosan Puma 2600 SY II CNC lathe, a high-productivity machine equipped with a Y-axis, main spindle, and sub-spindle, ideal for complete machining operations in a single setup. The machine is fitted with a bar feeder and numerous accessories, is fully operational, and can be seen running by appointment. The lathe is in excellent operating condition, regular maintenance has been performed, and it can be demonstrated in idle mode by appointment. Pgodoymdt Tepfx Appst Included accessories: . Top Automazioni bar feeder model X-Files S380SX . Chip conveyor . Tool presetting system . Bellegrandi collet chucks on main and sub-spindle . Workpiece pick-off arm with conveyor belt . Static and driven tool holders

Condition: excellent (used), Year of construction: 2014, turning length: 700 mm, travel distance X-axis: 205 mm, travel distance Z-axis: 700 mm, spindle motor power: 22,000 W, total height: 2,800 mm, total length: 6,000 mm, total width: 3,900 mm, overall weight: 9,800 kg, Complete machining with twin spindel, upper and lower turrets Kitagawa 3 chuck left and right Tool holders with driven tools axial and radial Large jaws cabinet with inserts OGL Gantry loader with ca 10 Kg load capacity Chip conveyor Paper Filtration Pressure Tank Max. turning Ø: 400mm X-Axis: 205mm Z-Axis: 700mm Spindle bore: 62mm Speedrange: 6000Rpm Spindle power: 22kW Subspindle speeds: 6000Rpm Subspindle bore: 62mm Subspindle power: 15kW ATC / revolver: 16 Speed live tools: 6000Rpm Positions lower revolver:16 Speed live tools: 6000Rpm Pedsyn Em Repfx Appogt Power live tools: 7kW Chip conveyor: yes Tool eye: yes Length: 6000mm Width: 3900mm Height: 2800mm Weight: 9800kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 13-13, The BLOMAX 4 Blowmoulding machine is of the model 13-13. The machine has no defects and operates in excellent condition with full functionality. Power : 400V/150A/60000W Pgedpfst Akgwex Appst Year of construction : 2000

Condition: used, Year of construction: 2014, x-axis 1.200 mm y-axis 3.000 mm z-axis 1.000 mm solution 0.0001 mm max. workpiece height 1.200 mm max. workpiece weight 3.000 kg Pedpfjzbc Hhsx Appegt In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: as good as new (ex-display), Year of construction: 1988, machine/vehicle number: 1116/87, MANUFACTURER: ELTERMA/IPSEN Pjdpfsm E Tvhjx Appegt MODEL: VDFC-413 DESCRIPTION: Vacuum tempering furnace YEAR OF PRODUCTION: 1988 STATUS: New unused, need revamping of the obsolete parts ( Cabinets ) Max Load Dimensions: 610x900x500mm Max Load Weight: 500 kg Working temperature: 150-750⁰C Approximate warm-up time of the vacuum chamber at 550 ° C for 30 minutes

Condition: excellent (used), Year of construction: 2011, operating hours: 2,450 h, travel distance X-axis: 6,000 mm, travel distance Y-axis: 12,001,400 mm, travel distance Z-axis: 18,001,790 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece weight (max.): 3,000 kg, total height: 4,700 mm, total length: 12,700 mm, total width: 7,800 mm, rotary table diameter: 2,200 mm, rotational speed (max.): 200 rpm, overall weight: 57,000 kg, spindle speed (max.): 8,000 rpm, operating hours of spindle: 2,450 h, coolant supply: 40 bar, number of slots in tool magazine: 60, tool length: 460 mm, Equipment: chip conveyor, documentation/manual, CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 6000 Y-axis travel mm: 1200/1400 Z-axis travel mm: 1800 (H) / 1790 (V) C-axis degrees: 360º (0,001) A-axis degrees: ±180° B-axis degrees: ±180° Rapid traverse m/min: 30 Worktable Table dimensions mm: 6000x1235 Milling/turning table nc: Table dimensions mm: Ø2200 Max. workpiece weight kg: 3000 Table rotation speed rpm: 200 max. torque Nm: 4600 Spindle Spindle speed rpm: 8000 Spindle drive power kW: 33/24 (40%ED/cont) Spindle torque Nm: 382/278 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 900 Tool system Tool holder: HSK-A 100 Tool magazine slots: 60 With free neighboring places mm: 200 With occupied neighboring places mm: 104 Max. Tool Length mm: 460 Max tool weight kg: 25 Chip-to-chip time s: 9.8 Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Workarea light DXF import function Pgjdszb H Tfjpfx Appet Paper band filter Automatic door Indexing Head Set Up for Shaft Machining Axles can be hydraulically locked using the M function Machine running times Under power: 29447 Spindle Working: 2450 Basic machine dimensions / weight Length mm: 12700 Width mm: 7800 Height mm: 4700 Weight kg: 57000

Condition: ready for operation (used), Year of construction: 2022, spindle speed (max.): 2,800 rpm, travel distance X-axis: 280 mm, travel distance Z-axis: 830 mm, spindle motor power: 30,000 W, total height: 1,915 mm, total width: 2,035 mm, overall weight: 5,650 kg, product length (max.): 3,821 mm, number of axes: 3, This 3-axis DOOSAN Puma GT 3100 M was manufactured in 2022. It features a maximum turning diameter of 376 mm and a turning length of 725 mm. The machine is equipped with a 12-station tool turret and a three-jaw power chuck diameter of 305 mm. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma GT 3100 M horizontal turning machine we have for sale. Contact us for further details. • Siemens S828D control touchscreen with ShopTurn 15-inch display • 3-axis CNC horizontal turning machine with driven tools and tailstock • C-axis main spindle: 360° resolution 0.001° • C-axis speed: 200 rpm • C-axis torque: approx. 1162 Nm • Swing diameter over bed: 720 mm • Swing diameter over cross slide: 590 mm • Max turning diameter: 376 mm • Max turning length: 725 mm • Main spindle bore: 115 mm • Bar capacity: 103 mm • Spindle nose: ASA A2-11 • Max torque: approx. 1112 Nm • Rapid traverse X-axis: 24 m/min • Rapid traverse Z-axis: 30 m/min • Feed force X-axis: 9465 N • Feed force Z-axis: 17379 N • Three-jaw power chuck diameter: 305 mm with soft jaws • 12-station tool turret with BMT65P tool holders • Max driven tool speed: 5000 rpm • Driven tool power: approx. 7.7 kW • Driven tool torque: approx. 75 Nm • Tailstock with quill diameter: 100 mm • Quill stroke: 100 mm • Hydraulic clamping system with hollow cylinder • Monoblock cast iron machine bed, Meehanite construction • 30° slant bed design • Hardened and ground guideways with low-friction coating • Automatic central lubrication • Coolant system: 7 bar pressure • Coolant tank capacity: approx. 235 liters • Hydraulic tank: approx. 20 liters • Full enclosure with working area lighting • Bar feeder interface • Oil skimmer • Electronic safety clutch for X and Z axes • Electrical connection: 400 V, 3-phase, 50 Hz • Total power: approx. 47 kVA • Unused (like new) • OPTIONAL: HALTER LoadAssistant Universal Big 70 (Robot) • Gripper for Doosan Universal Big 70 • Rotation Station • Workpiece Support • Base Plate 23 mm / 175 mm Big 70 • Machine Interface Box • () Technical Specification Counter Spindle No Driven Tools Yes Pedpfjy E I Hiox Appsgt
