Used thread rolling machines for sale (45)

Year of construction: 1998, condition: excellent (used), machine/vehicle number: ExCello Serial Number 3888, MICHIGAN Rotoflo Type 3237 Cold Forming Machine. Original Serial Number: 4590 ExCello Serial Number 3888 New 1975 rebuilt by ExCello late 1990’s Country of Origin: USA For the coldforming of profiles for serrations (straight or angular), spiral teeth, oil grooves, threads and knurls. Capacity: Maximum slide stroke 1065 mm Maximum rack length 915 mm Maximum profile diameter 50 mm Maximum profile length 125 mm Standard module range 0.3 to 1.25 Motor size 15 kW Hydraulic tank capacity 1000 l Overall floorspace width of machine 5014 mm Width of machine 2768 mm Depth with outboard support 4165 mm Ndodpfx Aofnk Ehof Sjf Height 2000 mm Approximate weight of machine 11,700 kgs Complete with: Hydraulically operated outer support assembly to accommodate part length universal headstock, Universal rack holding feature.

Condition: excellent (used), Year of construction: 2009, Machine-Details : Stock-No. 1022-2352 Type of machine Gear Hobbing Machine - Horizontal Make MONNIER & ZAHNER Type KOEPFER MZ 120 Year of manufacture 2009 Type of control CNC Storage location Monheim (Germany) Country of origin Switzerland Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details : max. wheel diameter 2-45 mm gear width 250 mm max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information : The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= Njdjx Nh Stepfx Af Sjdf 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: excellent (used), Year of construction: 2015, Roll pressure infinitely adjustable from 117 kN feeds - fine adjustment 0,5-45 mm/min turning speeds 0-80 U/min Swivel angle of the roller heads 11 ° Diameter of the roller spindles 69,85 mm Stroke - Roller screw slide 0-150 mm min. dist. - roller screws 138 mm max. dist. - roller screws 285 mm min. diameter - Rolling tools 230 mm max. diameter - Rolling tools 135 mm min. dia. 2 mm max. diameter 55 mm thread length at plunge operation 200 mm thread length at continiuous operation 2000 mm maximum thread pitch 4 mm total power requirement 14 kW weight of the machine ca. 2,4 t dimensions of the machine ca. 2,0 x 2,5 x 1,9 m Rolling time continuously adjustable from: 0.1s Pause time continuously adjustable from: 0.1s Rolling spindle length: 200mm Machine bed height: 810mm Rolling spindle height above machine bed: 200 mm Height of support bearings: 115 mm Ndjdpfx Afjxukrqe Ssf Largest pitch for serrated teeth: 2.5 mm (up to 70 kg/mm2 Strength of the material)

Condition: good (used), Year of construction: 1998, thread length: 65 mm, Treading machine ORT Italia - RT 10 MACH-ID 9322 Make: ORT Italia Type: RT 10 Control: Siemens SIMATEC Year: 1998 Maximum pressure: 10T Max. workpiece: 30Ø Min. workpiece: 2Ø Min. Threading lenght:2mm Max. Threading length:65mm Ndodpjx H Rmujfx Af Sof Pitch / lead: 30mm Shaft Ø: 85 - 135mm Length: 1600mm Width: 1400mm Height: 1800mm Weight: 2300kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1997, Technical details: Njdpfex Iu Ifox Af Ssdf pressure: 10 t workpiece diameter - max.: 50 mm threading length: 100 mm max. rollable pitch: 3 mm rolling power: 100 kN workpiece diameter min/max: 117/175 mm revolution per minute: 0 - 150 U/min Weight approx.: 2550 t dimensions of machine: 1,25 x 1,38 x 2,15 m *

Condition: used, Year of construction: 2007, pressure 20 - 300 kN adjustment of rolling slide 50 mm diameter of rolling spindle 120 mm roll spindle height over machine bed 200 mm Control SIN 840 D taper length of the roll spindle 200 mm rolling spindle turning speeds 0 - 50 1/min torque per rolling spindle 2700 Nm power capacity 2 x 8,4 kW distance between rolling spindles min. 271 / max. 368 mm Ndsdpow E Nmksfx Af Sjf rolling tool outer diameter max. 300 mm total power requirement 26 kW weight of the machine ca. 7,1 t dimensions of the machine ca. 9,70 x 4,50 x 3,80 m CNC machine for gear cold rolling / thread rolling Hydraulic rolling process Felsomat loader cell Complete housing

Condition: used, Thead Roller TLM RP8 TLM TORTONA Year: 1995 Diameter range: 3-8 mm Shaft length under head: 90 mm Max. thread length: 52 mm Njdpfxsx Aqprs Af Ssdf Dies size:130/115x54

Condition: good (used), Year of construction: 1998, functionality: fully functional, FOR SALE Ndodoxv Dcxepfx Af Sef Thread rolling machines Escofier H20Z

Condition: used, Thread rolling machine ORT RP18 2-roll Spindles diameter 69.95mm Ndjdpfot Apugsx Af Sof See video The machine is in our warehouse in Gussago BS, under power Test run possible Mimu Machine Tools Italy Power (Ton): 18 Number of rollers: 2

Condition: like new (used), functionality: fully functional, Thread rolled both ends the same time! Diameter range M6-M16 Max total length 600 mm. Max threaded length 60 mm. Adjustment is not difficult at all. We could offer machine with dies according to your wish, be made by our factory too. We are located at Athens, Greece, near to the center. You can view machine under power after appointment. Ndodpfx Aswalx Eof Sof

Condition: used, Year of construction: 1988, Technical details: pressure: 10 t workpiece diameter - max.: 40 mm threading length: 70-80 mm workpiece diameter min/max: 3 / 40 mm revolution per minute: 47-94 U/min feed speed: 0,5 - 6 mm/s work stroke: max. 7 mm total power requirement: 4,68 kW Weight approx.: 1,4 t dimensions of machine: 1,4 x 1,4 x 1,7 B T H m dimensions of hydaulic: 0,8 x 1,2 m Hydraulic drive Nodpfx Afow D Aq Tj Sedf manual and automatic cycle adjustable roller speed max. thread diameter 40mm min. thread diameter 3mm up to 3.5 mm pitch max. pitch 1.75mm roller width min. 80 mm max. 120mm shaft speed 47-94 roller shaft diameter 40 various rollers as accessories *

Condition: used, TECHNICAL DETAILS - Min./max. diameter of workpieces : 2 / 18 [mm] - Max. thread : 2 [mm] - Max. plunge length : 40 [mm] - Power : 6 [t] Ndsdpsxbt Izjfx Af Sof - Min./max. diameters of the rollers : 70 / 100 [mm] - Standard cam travel : 5 [mm] WEIGHT & DIMENSIONS - Machine floor space : 775 x 555 [mm] - Machine height : 1100 [mm] - Machine weight : 650 [kg]

Condition: new, Year of construction: 2025, functionality: fully functional, thread length: 12,000 mm, overall weight: 5,000 kg, workpiece diameter (max.): 90 mm, spindle diameter: 80 mm, type of input current: three-phase, roll diameter: 250 mm, spindle speed (max.): 50 rpm, spindle speed (min.): 20 rpm, total height: 2,000 mm, total length: 2,400 mm, total width: 2,000 mm, 60 ton hydraulic thread rolling machine with swivel spindles for infeed and thru-feed rolling Ndedpfx Aev Rb Apef Sof Download PDF file for photographs

Condition: ready for operation (used), functionality: fully functional, Technical Data – SENY D75B: Njdpfx Aexm Stgef Ssdf Rolling Pressure: 220 kN Workpiece Diameter: min. 3 mm – max. 70 mm Maximum Pitch: 6 mm Maximum Groove Pitch: 2.25 mm Maximum Roll Width: 160 mm Roll Diameter: min. 133 mm – max. 170 mm Roller Shaft Rotational Speeds: 24 – 30 – 38 – 45 – 62 – 72 – 90 – 114 rpm Roll Holder Shaft Diameter: 54 mm standard – 69.85 mm special Distance Between Shafts: min. 135 mm – max. 230 mm Working Stroke: max. 15 min Feed Rate: 0.5 mm/s – 6 mm/s Rolling Time: 0.1 s – 100 s Pause Time: 0.1 s – 100 s Main Motor Power: 5.5 kW Electrical Consumption: 8.6 kW Reservoir Capacity: 130 liters Weight: approx. 2,100 kg. Additional rolls available: M4.5 x 0.75 ISO. M6 ISO. M10 ISO.

Condition: refurbished (used), Year of construction: 2009, ORT RP30 MS 2-roll 30 tons Nodpfx Afjuykz Do Sedf thread rolling, knurling, small gears 2009 = YOM Electronic overhaul and electronic retrofit with Siemens PLC (2025) The machine is visible working in our warehouse in Gussago BS. Possibility of proof M i m u Machine Tools Power (Ton): 30 Number of rollers: 2 PLC: Yes

Condition: used, 2 Used Thread Rolling Machines WMW UPW25 ---Only 10.000,00 Euro--- Njdpfx Aox Dmnyef Ssdf

Condition: used, Thread rolling machine, cold rolling machine, thread rolling machine, profile rolling machine Manufacturer PEE-WEE Type P 24 Q serial no. LC2403099 year of construction 2004 Rolling force max. 24 ton. Tool diameter max. 200 mm Rolling spindle diameter 69,85 mm Tool bore diameter 70 mm (nominal diameter) Tool length, tool length max. 180 mm Workpiece diameter max. 50 mm Rolling spindle speed 22 - 44 - 95 - 190 rpm Motor power hydraulics approx. 3 kW Motor power roller drive 5.5 kW Ndedpfjh A S Htox Af Sef Mains connection 400 Volt, 50 Hz - Swivel roller spindle for threaded continuous rollers - Rolling spindle speed in 4 stages via gear changeover - Hydraulic system integrated in the machine bed Space requirement L x W x H 2000 x 1750 x 2550 mm Weight approx. 3 tons good condition Grooving rollers: The thread rolling tools with the same pitch as the workpiece form the thread by penetrating into the workpiece up to the nominal diameter. The thread length is maximum as long as the rolling tools are wide. Continuous rolling: When the thread length is greater than the rolling tool width. Through-feed tools have 3 sections - the infeed, the calibration section and the outfeed. Grooved rollers have no pitch and are swiveled with the pitch angle of the profile to be rolled. Pitch rollers differ from grooved rollers in that they have a pitch in the profile. The sum of the pitch angle and the swivel angle gives the pitch angle in the workpiece.

Condition: used, TECHNICAL DETAILS Njdpfoxbt Iuex Af Ssdf - Min./max. diameter of workpieces : 2 / 40 [mm] - Max. thread : 5 [mm] - Maximum length in plunge : 54 [mm] - Power : 12 [t] WEIGHT & DIMENSIONS - Machine floor space : 2000 x 1750 [mm] - Machine weight : 2100 [kg]

Condition: good (used), Maximum pressure 25tn Ndedpfegqumpjx Af Sjf • 69 and 85mm axles • Machine in very good condition, completely revised

Condition: refurbished (used), CNC thread rolling machine - electronic retrofit with Siemens PLC and touchscreen Thommen PR17 CNC 2-roll Rollers rotation speed electronically managed Position and speed managed electronically Spindles diameter 54mm 2 pairs of supports (closed and open) The machine is in our warehouse in Gussago BS, under power Test run possible Mimu Machine Tools Italy Nsdpsilh Tiefx Af Ssdf Power (Ton): 17 Number of rollers: 2 CNC: Yes

Condition: used, Thread Rolling Machine, Cold Rolling Machine, Thread Rolling Machine, Profile Rolling Machine Manufacturer: PEE-WEE Model: UPW 24 Serial No.: P07 Year of manufacture: 2007 Maximum rolling force: 24 tons Maximum tool diameter: 270 mm Roll spindle diameter: 69.85 mm Tool bore diameter: 70 mm (nominal diameter) Maximum tool/reception length: 180 mm Maximum workpiece diameter: 50 mm Hydraulic motor power: 3 kW Roll drive motor power: approx. 5.5 kW Electrical connection: 400 Volt, 50 Hz, 10 kW - Pivotable roll spindle for through-feed thread rolling - Roll spindle speed adjustable in 4 steps via gearbox shift - Hydraulic unit integrated in the machine base - Operating manual with electrical schematic Space requirements (L x W x H): 2,000 x 1,450 x 1,900 mm Weight: approx. 3 tons Very good condition Nodpfx Afjuz If No Sjdf Plunge Rolling: The thread rolling tools, having the same pitch as the workpiece, form the thread by penetrating the workpiece up to the nominal diameter. The maximum thread length is limited to the width of the rolling dies. Through-feed Rolling: Used when the thread length is greater than the width of the rolling dies. Through-feed tools are divided into three sections – entry, calibration, and exit. Knurling rolls have no pitch and are swiveled at the lead angle corresponding to that of the profile to be rolled. Lead angle rolls differ from knurling rolls by having a pitch in the profile. The sum of the lead angle and swivel angle results in the effective lead angle in the workpiece.

Condition: used, ORT RP18B overhauled Njdpfsuua H Rjx Af Sodf

Condition: refurbished (used), Thread rolling machine ORT RP18 B 2-roll overhauled See video The machine is in our warehouse in Gussago BS, under power Test run possible Mimu Machine Tools Italy Nsdpfxsvxa Dbe Af Sodf Power (Ton): 18 Number of rollers: 2

Condition: used, Year of construction: 2003, Thread rolling machine ESCOFIER H20Z 2-roll 2 moving heads (in sync) 2 - 20 Ton rolling pressure workpiece diameter: 75mm max. tool diameter: 140-200 mm Max plunge width 160 mm Shafts dia: 69.95 Swivelling: +/-6°, Nedpfet Hmv Njx Af Sjdf New: 2003 under power in our warehouse, M i M u machine tools

Condition: used, Thread rolling machine ORT RP30U 2-roll 30 ton Nodjt H Ty Uepfx Af Sjdf swiveling heads variable speed drive #1331 Under power in our warehouse in Gussago BS. Test run possible M i m u Machine Tools Italy Rolling is a mechanical process without chip removal that can be performed cold or hot, having as a purpose the improvement of the surface finish (therefore the fatigue behavior Power (Ton): 30 Number of rollers: 2
