Used internal threading machines | nominal diameter size M9 - M12 for sale (21)

Condition: used, Drilling and Tapping Machine FLOTT Model TBZ 15 GL Serial No. 32177027 Year of Manufacture: 1986 Drilling capacity: 15 mm Spindle taper: MT2 Throat depth: 195 mm Quill stroke: 80 mm Table size: 275 x 200 mm Column diameter: 70 mm Spindle speed: 80 - 4500 rpm, 18 steps Motor power: 0.55 + 0.75 kW Power connection: 380 Volt, 50 Hz - Spindle speed selection via 2 motor speeds, 6 belt steps from the motor and 2 belt steps to the spindle - Drilling head height adjustment via crank and rack on the column - Tapping device with guide bush and selector for right- and left-hand threads - 3 guide bushes for right-hand threads: 0.7 mm, 0.8 mm, and 28G included - Tapping possible with or without guide bush - 1 geared drill chuck Ø 1.5 to 13 mm Fjdpfx Asdzp S Nof Djfu - Foot switch for cycle start - Emergency stop - Original metal base included Space requirements (L x W x H): 700 x 350 x 1850 mm Weight: 165 kg Good condition

Condition: excellent (used), Cutting range: M3-M10 in steel M3-M16 in cast iron M3-M18 in light metal and brass Ffjdpfoyg Dhwex Af Dsu Spindle speeds: 120-240-180-360-300-600 rpm Includes 1 new tap chuck Everything works smoothly and well.

Condition: good (used), Year of construction: 2003, Offer 25508 High-table tapping and drilling machine with leadscrew Technical data: - Thread tapping capacity: M2 up to M10 - Threads per hour: up to 2400 - Drilling capacity in steel: 18 mm - Drill spindle mount: Morse taper 2 (MK2) Fodpfxeygk Ido Af Dofu - Drilling depth: 100 mm - Threading depth: 60 mm - Spindle to column distance: 215 mm - 4 drill spindle speeds: 320 – 1600 rpm - Table size: 350 x 290 mm - Spindle to table distance: approx. 150 – 520 mm - Cycle-controlled coolant spray system with pneumatic connection - Drive: 400 V / 0.55 kW - Space requirement: approx. W 580 x H 1430 x D 750 mm - Weight: approx. 150 kg

Condition: good (used), Year of construction: 1998, Offer 20137 Technical data: - 3 stationary, positionable thread tapping machines - Tapping capacity for each up to approx. M 12 - Tapping depth approx. 75 mm - Steplessly adjustable drilling feed - Spindle speeds up to 490 rpm Fodpfx Afjygh Ius Defu - Pneumatic connection 6 bar - Drive 400 V - Required space approx. W 2000 x H 1600 x D 900 mm - Weight approx. 150 kg

Condition: new, thread dia. 12 M max. Ffjdoxabbmjpfx Af Dju turning speeds 400 U/min thread M 3 - M 12 M working area 1600 R max. working range 500 Rmin. weight 16 kg Description: The AT II models have a radius of up to 1600 mm and thanks to their construction a flexible workspace. For professional use. Easy to mount on a worktop. Furnishing: - Tool holder with 6 cutter holders • M3 20111812 DIN 371 19 • M4 20111814 DIN 371 19 • M6 20111816 DIN 371 19 • M8 20111817 DIN 371 19 • M10 20111818 DIN 376 19 • M12 20111820 DIN 376 19 - with slip clutch - Control valve with lubrication - Including compressed air motor / maintenance unit - Adapter connection size 1

Condition: good (used), Threaded snowing machine Hahn and Goebel HG 12E Spindle rotation 180-900 rpm 380v Ffsdped Rkbrefx Af Deu MaschNr.1917/16 M4-M65

Condition: used, Internal threading machine HAGEN & GOEBEL type HG 10 Tapping machine, Vertical tapping machine Machine. No. 4462 Year of construction approx. 1980 Cutting capacity in steel M3 to M10 Cutting capacity in cast iron M3 to M16 Cutting capacity in brass M3 to M18 mm throat depth 250 mm Pinol stroke 80 mm Table size 340 x 240 mm Spindle speed 200-1000 rpm 6 steps Motor power 0.55 and 0.75 kW Mains connection 380 Volt, 50 Hz - 6 speed levels through 2 motor speeds and 3 belt levels - Thread pitch via guide cartridge - 2 guide cartridges with 1.0 mm and 1.25 mm thread pitch - Spindle holder with cone Ø 14.8 to 16 mm and 4 mm keyway - Table height adjustment with toothed rack via hand crank on the round column - Quick-change tapping chuck size 1, Ø 19 mm Fodpfx Aeupbf Djf Dofu Space requirement L x W x H 850 x 550 x 1800 mm Weight 255 kg Good condition

Condition: used, Internal threading machine Hagen & Goebel type HG 124 Machine no. No. 4112 Year of construction approx. 1980 Cutting capacity in steel M3 to M10 Cutting capacity in cast iron M3 to M15 Cutting capacity in brass M3 to M17.5 throat depth 250 mm Pinol stroke 80 mm Table size 345 x 245 mm Spindle speed 200 - 1000 rpm Motor power 0.55 / 1.0 kW Mains connection 380 Volt, 50 Hz - 6 speed levels via belt change (3 levels via belt + 2 motor speeds) Fjdpfxjhgnd Aj Af Dsfu - Thread pitch via guide cartridge - 2 guide cartridges with 0.8 mm and 28 G per inch thread pitch - Table height adjustment with toothed rack via hand crank on the round column - Spindle holder with cone Ø 14.8 to 16 mm - Gear rim drill chuck Ø 1 to 13 mm Space requirement L x W x H 900 x 500 x 1800 mm Weight 260 kg Good condition

Condition: good (used), Hagen & Goebel HC 22 E / Thread Cutting Machine - Speed range: 56 - 355 rpm - Table dimensions: 600x500 mm - Year of manufacture: 1988 Dimensions: LxWxH 1.1x0.7x2 meters / Weight 900 kg Subject to errors and input mistakes. Fodpjx Edbmefx Af Defu

Condition: used, Year of construction: 2020, functionality: fully functional, metric thread diameter (min.): 3 mm, metric thread diameter (max.): 12 mm, working range: 1,900 mm, overall weight: 13 kg, rotational speed (max.): 400 rpm, torque: 28 Nm, Tapping Range: M3 - M12 Rotation Speed: 400 rpm Max. motor torque: 28 Nm Air pressure: 6 - 8 bar Working range: 150 - 1900 mm Machine weight: 13 kg Year: 2020 The pneumatically driven thread tapping machine DUMETA D-JSC-12A is designed for thread cutting in the range of M3 to M12. It features a compressed air motor and a quick-change chuck. Ffjdpow Smr Aefx Af Dju The sturdy working arm can be mounted directly onto a workbench using the integrated flange. This allows the tap to be positioned flexibly at various locations on the workpiece without the need to reposition the workpiece itself. The design includes an adjustable angle, enabling the quick-change chuck to be tilted, so that both vertical and horizontal tapping operations are possible. Optional: Workbench with dimensions 2210 mm (L) x 940 mm (W) x 820 mm (H).

Condition: like new (used), Year of construction: 2012, functionality: fully functional, Clamping table, head adjustable by 400 mm, as new, high-performance thread cutting machine up to M10. Ffsdpfx Afsx Dm Rhs Dju

Condition: new, thread dia. M3 - M16 metrisch 312 U/min. working area max. 1100 mm engine output 0,6 kW weight 30 kg dimensions 700 x 600 x 200 mm Electric tapping machines for M3 - M16 threads, Includes connection for cutting oil supply! Adjustable angle. Quick-change chuck with slip clutch. Display adjustable: Variable speed, adjustable depth, material selection, selection of main rotation direction, thread selection. Documentation in English! Optional: Fedpfx Aet Eahpof Dofu Tiller table type: FL-WB

Condition: new, thread dia. M3 - M16 metrisch 250 U/min. 0 6 - 8 bar working area max. 1100 mm weight 15 kg Ffjdpfjhiptgsx Af Dou dimensions 700 x 280 x 250 mm Pneumatic tapping machine Type with an adjustable angle, horizontal tapping possible Pneumatic tapping machines for M3 - M16 threads, angle adjustable. 8 pcs. quick-change chuck with slipping clutch. Documentation in English! Optional: clamping table with grooves type: FL-WB

Condition: used, thread dia. 3 - 10 mm Tools speed 120 - 600 U/min table-size 250 x 350 mm throat 250 mm voltage 380 V threading length 80 mm total power requirement 0,55 kW Fjdpfx Ajlwlk Ajf Dsfu weight of the machine ca. 0,35 t dimensions of the machine ca. 0,7 x 0,7 x 1,9 m

Condition: new, thread dia. 12 mm 375 U/min. Fsdpfx Afjfg U Sps Dsfu working area 180 - 1000 mm engine output 0,7 kW

Condition: new, thread dia. M3 - M16 metrisch 312 U/min. working area max. 1100 mm engine output 0,6 kW weight 30 kg dimensions 700 x 600 x 200 mm Electric tapping machines for M3 - M16 threads, Angle adjustable. Quick-change chuck with slip clutch. Adjustable via display: Fjdjt Eabijpfx Af Dofu variable speed, adjustable depth, material selection, choice of Main direction of rotation, thread selection. Documentation in English! Options: Clamping table with grooves Type: FL-WB

Condition: new, thread dia. M3 - M12 metrisch 400 U/min. 0 6 - 8 bar working area max. 1100 mm weight 15 kg dimensions 700 x 280 x 200 mm Pneumatic tapping machine Type with an adjustable angle, horizontal tapping possible Pneumatic tapping machines for M3 - M12 threads, angle adjustable. 8 pcs. quick-change chuck with slipping clutch. Fedpfxjhiptce Af Djfu Documentation in English! Optional: clamping table with grooves type: FL-WB

Condition: used, thread dia. M3 - M12 mm Ffsdpfefg U Smsx Af Dou 400 U/min. 25 Nm air pressure 6 - 8 bar working area Radius 1000 mm weight of the machine ca. 12 kg Demonstration machine! Pneumatically driven tapping machine for M3 - M12 thread with: - stable and flexible working arm. - 6 pcs. Quick-change chuck with slip clutch. Documentation in English !! optional: - Clamping table with T-slots clamping surface 900 x 600mm

Condition: new, thread dia. M16 - M42 metrisch 50 - 200 U/min. working area max. 1300 mm engine output 1,2 kW weight 105 kg dimensions 0,85 x 0,85 x 0,3 mm Fsdpfjwinywox Af Dofu Electric tapping machines for M16 - M42 threads, Angle adjustable. 8 pcs. Quick-change chuck with slip clutch. Adjustable via display: variable speed, adjustable depth, material selection, choice of Main direction of rotation, thread selection. Documentation in English! Options: Clamping table with grooves Type: FL-WB

Condition: new, thread dia. M5 - M24 metrisch max. 200 U/min. working area max. 1200 mm engine output 1,2 kW weight 25 kg dimensions 740 x 800 x 400 mm Electric tapping machines for M5 - M24 threads, Angle adjustable. Quick-change chuck with slip clutch. Adjustable via display: variable speed, adjustable depth, material selection, choice of Main direction of rotation, thread selection. Documentation in English! Ffsdpfxsvblh Rj Af Dsu Options: Clamping table with grooves Type: FL-WB

Year of construction: 2022, condition: new, pneumatic tapping arm Model: R1950-08 Power: M2-M8 speed (rpm): 700 Air demand: 750l/min pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Structure parallel arm: Stable arm structure (hard aluminum profile 38x29) Weight: 23kg Adapter mounting: TCS 1B Model: R1950-12 Power: M3-M12 Speed (rpm): 400 Air demand: 750l/min Pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Structure parallel arm: Stable arm structure (hard aluminum profile 38x29) Weight: 23kg Adapter mounting: TCS 1B Model: R1950-16 Power: M3-M16 Speed (rpm): 300 Air demand: 950l/min Pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Parallel arm structure: Stable arm structure (hard aluminum profile 38x29) Weight: 27kg Adapter mounting: TCS 2B Model: R1950-020 Power: M3-M20 Speed (rpm): 150 / 400 Air demand: 950l/min Pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Parallel arm structure: Stable arm structure (hard aluminum profile 58x40) Weight: 39kg Adapter mounting: TCS 2B Model: R1950-022 Power: M3-M22 Speed (rpm): 120 / 300 Air demand: 950l/min Pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Parallel arm structure: Stable arm structure (hard aluminum profile 58x40) Weight: 39kg Adapter mounting: TCS 2B Model: R1950-027 Power: M3-M27 Speed (rpm): 70 / 220 Ffjdpfxoipmr Ij Af Dju Air demand: 950l/min Pressure: 6-7bar Working range: Rmin 300mm - Rmax 1950mm Parallel arm structure: Stable arm structure (hard aluminum profile 58x40) Weight: 39kg Adapter mounting: TCS 2B Standard accessories for all models: - Parallel arm - Air motor - 6 safety quick change tapping collet of your choice - Guide column with mounting flange - Radial boom (for a more flexible working range) - Maintenance unit - Pneumatic oil for initial filling
