Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Weight 1800 kg Total power requirement 6 kw Cob Edsvz E Dfj Ulvegt

Condition: used, Motor power: 2.0 HP (1.5 kW), Year of manufacture: 2023, Motor voltage: 3x 400 V, Motor frequency: 50 Hz, Maximum precision when drilling dowel holes with the Felder FD 21 professional, With 21 high-quality drilling spindles in a 32 mm grid for drill bits with a maximum diameter of 35 mm, exact rows and dowel holes are guaranteed, The welded stand in combination with the solid cast iron table, stable side and longitudinal stops, as well as pneumatic workpiece hold-down devices and ergonomic controls make the FD 21 professional a top-class dowel hole drilling machine. Ceb Ed Ulounu Uvsvogt

Condition: used, machine/vehicle number: 006048, Max. panel width: 3200 mm Max. panel length: 2300 mm No of Bottom Units: 6 Csb Edowayltj Ulvjgt No of injectors: 6

Condition: used, Year of construction: 2009, machine/vehicle number: A0908/7866, working width: 250 mm, KOCH SBD-B Saw-Mill-Drill - Pass-Through Machine The machine has the following functions - loading magazine - 2 units with a formatting saw diameter 400/30 mm - 4 milling units with oscillation 4KW 18,000 rpm adjustable pneumatic oscillation - 2 horizontal drilling supports head 7 spindles (2 in the 32 mm module, 5 in the 16 mm module) Cgjb Ed Uswd Rlfjlvst - 3 vertical drilling supports head 14 spindles (12 in the 32 mm module + 2 extreme angular in the 32 mm module - 3 horizontal drilling supports Y axis 2 heads 16 spindles (14 spindles in the 32 mm module + 2 angular in the 32 mm module + 1 head 8 spindle (7 in the 32 mm module + 1 middle angle 32 mm - Return belt to the operator - Supports for long elements The machine does not have doweling units Dimensions of processed elements L- 350-2500 W- 30-200 Gr- 15-75 Machine configured for processing table elements, sample elements in the attachment

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Cgeb Eewc T Nwjd Ulvet

Condition: excellent (used), Year of construction: 2006, Functionality: fully functional, Device description Table width - 850mm Drill stroke - max 70mm Number of spindles - 21 Distance between spindles - 32mm 4 pneumatic clamps Cgjb Eevzapcsd Ulvst Drilling depth adjustment Vertical, horizontal and angle drilling 1.5kW main engine Pneumatically adjustable drilling speed Pneumatically adjustable drilling angle Quick-release drill attachment

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2700x2500x1760 mm Weight 1500 kg Cob Ejvz Ewxed Ulvegt Total power requirement 5,9 kw

Condition: good (used), Year of construction: 2017, Functionality: fully functional, Availability: Immediately This 3-axis BIESSE BREMA EKO 2.1 drilling machine was manufactured in 2017. It features a tool changer with 8 positions, a milling unit of 5.5 kW, and a drilling unit with 23 tools. The working table includes a counter-pressure system and pliers with a thickness measuring system. Ideal for handling panel sizes up to 2600 mm in length and 900 mm in width, the BIESSE BREMA EKO 2.1 represents a robust addition to any workshop. Contact us for further details. Additional Equipment - Working table with counter-pressure - Pliers with system for measuring thickness - Laser-based reading system for recognizing zero joints and panel ends - Top reading system of photo cells for recognizing panel heights - Tool changer with 8 positions - Milling unit of 5.5 kW - Drilling unit with 23 tools - Software: bSolid Additional Information Machine Benefits Technical Machine Benefits: - Precision in z - Compensation length tolerances through correcting of panel measures in x - Corrections in y - Panel length: 200 - 2600 mm (optional 3200 mm) - Panel width: 35 - 900 mm Csb Ejt E Suzod Ulvsgt - Panel thickness: 8 - 60 mm - Vector speed x-y: 65 m/min - Vector speed z: 20 m/min Qualitative Machine Benefits: - High precision and accuracy in drilling and boring operations

Condition: excellent (used), Balestrini double-sided oscillating drill operates in automatic mode table height adjustment 120 mm table angle adjustment in the range of 0-20 degrees oscillation adjustable with a numerical indicator maximum oscillation stroke 145 mm smooth oscillation speed adjustment extraction nozzles 2 x 80 mm spindle drive motor 2.2 kW oscillation drive motor 0.37 kW Cgob Ed Uewc Tmpslvet power supply 380 V, the machine is fully functional

Condition: good (used), Year of construction: 1998, Hettich Blue Max 8 FS Hardware Drilling Machine Year of manufacture ~1998 8 spindle drilling heads (5 in row with 32 pitch / 3 in front with 52 / 5.5) Integrated hole sequence stops 2 stop ruler extensions, 2000 mm long Folding stops Csb Edswb Dado Ulvegt Drilling depth adjustment Connection: 16 A / 380 V Pneumatic connection 2 pneumatic material clamps Foot switch Emergency stop Motor: 1.6 kW Dimensions: 800 x 600 x 880 mm (W x D x H) measured without stops

Condition: good (used), Year of construction: 1996, Double-sided double-spindle drilling and grooving machine Balestrini Pragma Top Characteristic Overall dimensions, mm - 1600х1600х1300 Power, kW - 4,5 Machine weight, kg - 1500 Drill diameter, mm - 16 Table height, mm - 950 Distance from the table to the spindle, mm - 100 Clamp - pneumatic Cgobeh Tfc As Ed Ulvst

Condition: like new (used), Year of construction: 1990, Functionality: fully functional, GANNOMAT JUNIOR 320 Dowel and Slot Drilling Machine Very good condition, as good as new. The machine comes from an assembly company and has been used very little. It can mill slots and drill dowel holes on two levels without re-clamping. 380V, 1500W 2800 rpm Built in 1990 With this machine, you can mill slots for lock cases and similar items, or create all types of frame dowel joints, at right angles, butt joints, and miter joints. Ideal for producing dowel joints in timber frame construction, furniture, door, window, and staircase construction, and similar applications. Drilling on two levels, the grids and stops, and the machine's design allow dowel joints to be produced in a very short time, making it very economical. The machine requires a 6-bar compressed air supply (air consumption is very low). Clockwise rotation Milling and drilling Very good and clean. Cebewb U H Is Ed Ulvegt With 2 angle stops (a center stop and a side stop that can be used on both sides) and a 45° miter stop. You also get a 2000mm long stop rail with 2 folding stops. This stop rail can also be extended. The workpiece is clamped with 2 pneumatic clamping cylinders. The height adjustment from one drilling level to the other is also pneumatic. The pneumatic switch for this is located at the front of the machine, ensuring quick adjustment of grids and drilling levels. With a 12mm precision grid rail, which has a center grid and 12 grids on the left and right. Can be quickly converted to mortise milling. The machine can then be used without a grid. With 2 adjustable stops on the left and right, it then has a working width of max. 420mm. The machine has conical stop rings at the front of the machine table, which can be rotated downwards if necessary. The maximum hole height is 100mm. The maximum The hole depth is 150 mm with stop and scale. The maximum workpiece height is 160 mm. Everything works perfectly. The machine will be delivered and demonstrated by us personally throughout Germany for €220.00, so you have no risk when purchasing. Delivery to Austria and the EU is also possible upon request. The machine table is 870 mm wide, 140 mm deep at the sides, and 350 mm deep in the middle. Professional tool, not hardware store junk. You can start working with the machine immediately. With 2-jaw drill chuck up to 20 mm. Very stable and durable construction. The precision guides with the play-free ball bearing bushings are OK and operate smoothly.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Cjbevz Evze Ed Ulvsgt Weight 1800 kg Total power requirement 5,2 kw

Condition: like new (used), Functionality: fully functional, AUTOMATIC BORING machine 35 spindles SCM TOP 35 second hand machine working condition : Excellent electric movement of boring head 0° / 90° technical details : n. 35 spindles center distance between spindles mm 32 center distance between first and last spindle of the drill head mm.1088 max. stroke of boring unit mm. 140 n.02 motors Hp 3 each one operating pressure atm 6-8 Cgjb Edjvhbl Es Ulvst weight kg.800 volt. 380/50

Condition: excellent (used), Hello! I would like to offer you the following machine: 1 used Panhans Type 116 mortising machine - Dowel drilling attachment for linear hole drilling with 16/22/25/32 mm grid roller High-precision milled grid, secured via spring-loaded grid pins - Miter stop 90° to 45° left and right - Workpiece stop up to approx. 1.50 m usable on the left and right for series machining - Cast iron table with heavy-walled and highly ribbed construction - Smooth-running cross slide with adjustable ball bearings - Röhm two-jaw drill chuck with 1-20 mm protective sleeve and operating key - Left and right mortise drilling stop for mortise lengths up to 240 mm - Drilling depth stop up to 145 mm - 1.5 kW 380 volt Siemens motor, 3000 rpm - Mobile unit - 2 m 380 volt power cable with 16 AH plug - Weight: 200 kg New parts: - Angle stop magnifying glass (€50 + 19% VAT) Special equipment: included - Single-lever operation (new price: €330 + 19% VAT) - Pneumatic clamping cylinder with manual slide valve (new price: €400 + 19% VAT) - Price: €3,300 + 19% VAT The machine has been technically checked, cleaned, adjusted, and repainted. Very good condition. Cable and plug included and ready for immediate use. Bank transfer before shipping or cash upon pickup. Shipping is possible. Cebowb Idao Ed Ulvjgt The machine is sold without any warranty or guarantee. Please send me a short message. Thank you!

Condition: used, Year of construction: 1999, Dowel hole drilling device: Pitch 16, 22, 25, 32 Drilling depth: 145 mm Slot length: 240 mm Height adjustment range: 135 mm Motor power: 1.5 kW Speed: 2800 rpm Extraction connection: 100 mm Cobev S Diuj Ed Ulvsgt Machine length: 1280 mm Machine width: 960 mm Weight: 250 kg

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Weight 2000 kg Total power requirement 6 kw Cgebsvz Evue Ed Ulvet

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1480x1150x1250 mm Weight 550 kg Cgeb Eevz Evnsd Ulvet Total power requirement 3 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1050x1050x110 mm Cgeb Ed Uljvz Er Asvot Weight 350 kg Total power requirement 1,5 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Weight 1800 kg Total power requirement 6 kw Cjb Edsvz Eq Ee Ulvjgt

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 5000x2250x1650 mm Weight 2600 kg Cgsb Ed Uevz Elielvot Total power requirement 11,8 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1300x1100x1350 mm Cjb Ed Uovz Eizjlvegt Weight 500 kg Total power requirement 3,5 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1320x1220x1400 mm Weight 275 kg Cgob Edovz Eibe Ulvet Total power requirement 1,5 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Weight 2000 kg Cobsvz Ehdj Ed Ulvjgt Total power requirement 11,8 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3900x2500x1760 mm Cgeb Eovz Eg Tsd Ulvet Weight 2000 kg Total power requirement 9 kw
