Dowel hole drilling machine

Gannomat DB 21

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Nwjdpfx Aoxnlflsmueh Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: used, Year of construction: 2014, complete in standard configuration with: - Fully automatic electronic control with foot pedal for clamping-drilling-unclamping, electric jog operation, - Automatic return of the drilling unit after reaching the preset drilling depth - Automatic extension of drilling depth when end-grain drilling saves the need to adjust drilling depth from flat to end-grain drilling. (+10 mm, e.g. with dowel length 35 mm, drilling depth flat side 14 mm, drilling depth end-grain 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drill feed 0-70 mm) incl. 21 quick-change chucks (Ganner system) for easy bit changes. - Simple swiveling of the drilling unit from 0° to 90°, supported by gas cylinder. - 1 clamping beam, movable in Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop fence 1800 mm for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, with quick-change system, easily swappable from right to left for mirror-image shelf drilling in carcass constructions, also suitable for line boring in System 32. - Side stops and position settings, as well as drilling height position via support table using mechanical digital counters. - Side stops can be easily swiveled away, for the quickest changeover from carcass to frame and line boring. - Clamping arms for clamping beam designed for line boring positions up to max. 300 mm. - Ideal three-stage... Weight: approx. 400 kg gross, approx. 350 kg net. Dimensions (L x W x H): 1.35 m x 1.25 m x 1.40 m Equipment: 1 extraction hood, dust tested, ø 120 mm. 1 set for line boring in System 32 complete with: 1 base fence 1050 mm (aluminum profile 40x40 mm), 1 setting gauge for line boring. 1 frame dowel device complete with: 1 center stop, 1 round stop rod 850 mm long, 2 stops. Location: Nattheim. Nodjyyxkhepfx Amuowh

Condition: new, Year of construction: 2026, Precise and accurate multi boring machine for casegoods, furniture fittings, line drilling and framework in SYSTEM 32 mm. The DB is a semi automatic boring machine with 21, 27 or 35 precision drilling spindles. Short introduction: • Universal drilling machine for panel and solid wood construction • Holes in the SYSTEM 32 mm • Massive precision drilling unit from GANNOMAT • Easy settings via mechanical digital counters for side and front stops and for drilling height position • Tool-less quick-change system for stopping ruler • Dowel holes, row of holes as well as line drilling, all kind of furniture connectors, handle and through holes, hinges, 3- 5- 7-hole groups, boreholes for drawer slides and guides, holes for door frames and table legs, etc. Nedpfxsdxz Nko Amujwh
