Condition: used, Year of construction: 2024, machine/vehicle number: DC-2217, Langlochbohrmaschine mit drehendem Tisch • Bohreinheit drehbar • 2 x Exzenterspanner • Höhenanzeige • Mechanische Dübeleinrichtung (16-22-25-32 mm Lochabstand) • 2 Geschwindigkeiten: 1440 / 2880 U/min • Motorleistung 1,5 kW 1.1 Arbeitstisch mm 800x400 1.2 Motor kW 1,5 1.3 Spindeldrehzahl U/min 2880 1.4 Max. Langlochhöhe über dem Tisch mm 160 1.5 Max. Längsarbeitslauf mm 345 1.6 Max. Querarbeitslauf mm 245 1.7 Spindelhub mm 160 1.8 Spanndurchmesser des Werkzeuges mm 0-20 1.9 Max. Werkzeuglänge mm 175 1.10 Spannexzenter Stück 1 1.11 Längskipptischneigung ° 1.12 Spindeldrehung ° 1.13 Drehen des Tisches ° +/- 45° 1.14 Abmessungen der Maschine mm 1500x1100x950 1.15 Maschinengewicht kg 345 P 41 55 Absaugstutzen 1 P 41 25 2. Spannexzenter 1 P 41 20 Mechanische Dübelbohreinrichtung 1 P41 07 2 Geschwindigkeitsmotor 1,5/1,9kW 1440/2880 U/min Cebowd U U Do Ed Ulvogt P41 34 Mechanische nummerische Abmessung der Spindelhöhe

Condition: used, Year of construction: 1988, Dowel hole drilling device: Pitch 16, 22 25, 32 Drilling depth: 145 mm Slot length: 240 mm Height adjustment range: 135 mm Motor power: 1.5 kW Speed: 2800 rpm Downholder: manual Suction connection: 100 mm Machine length: 1280 mm Machine width: 960 mm Weight: 200 kg Cgeb Esqx Ig Aod Ulvot

Condition: used, Hole rows + fitting drilling machine LAUTENSCHLÄGER Meplamat 300 pneumatic hold-down device, pressing device, stop rulers Ceb Ed Ujvtm Ayelvjgt

Condition: excellent (used), Year of construction: 2020, Functionality: fully functional, overall weight: 1,060 kg, total height: 1,800 mm, total width: 1,830 mm, total length: 2,000 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 800 mm, feed length Z-axis: 50 mm, spindle speed (min.): 3,200 rpm, workpiece weight (max.): 25 kg, air demand: 750 m³/h, operating pressure: 6 bar, number of spindles: 13, Equipment: USB port, Technical Specifications: 3-Axis Programmable Drilling Machine For sale: 3-axis controlled programmable drilling machine. Construction compliant with CE regulations. Head Configuration: Independent vertical spindles: 9 Double horizontal spindles (X-axis) for front/rear drilling: 2 Saw blade unit for grooving on X-axis. Control System and Software: Software: Easy-Smart-Touch with "NO TEXT" system (Maggi). Interface: 12-inch touchscreen. Operating System: Linux kernel based. CNC Memory: Capacity for 1,000 programmes. Connectivity: USB Port, Ethernet Port (for file import, remote assistance, updates). Includes remote assistance software. Panel Handling and Worktable: Handling system: Triple suction cup. Cgebowdubwe Ed Ulvet Positioning: Panel end reader, manual aligner. Table surface: Scratch-resistant material. Conditions of Sale: Reason for sale: Replacement with larger capacity equipment. The machine is in production right now. Availability: From July 2025 onwards. Transport: Machine supplied at its current location. Loading and transport are the buyer's responsibility. Contact us for further information

Condition: new, Year of construction: 2024, Functionality: fully functional, VD 20 R Slot drilling machine with rotating table, 2.2 kW Basic equipment: 1.1 Work table mm 800x400 1.2 Motor kW 1.5 1.3 Spindle speed rpm 2880 1.4 Max. Slot height above the table mm 160 1.5 Max. Longitudinal travel mm 345 1.6 Max. Transverse travel mm 245 1.7 Spindle stroke mm 160 1.8 Clamping diameter of the tool mm 0-20 1.9 Max. Tool length mm 175 1.10 Clamping eccentric piece 1 1.11 Longitudinal tilting table inclination ° 1.12 Spindle rotation ° 1.13 Rotation of the table ° +/- 45° 1.14 Machine dimensions mm 1500x1100x950 1.15 Machine weight kg 345 Additional equipment installed on this machine: Cob Eju Rnw Dod Ulvogt - Suction nozzle - 2nd clamping eccentric - Mechanical dowel drilling device - 2 speed motor 1.5/1.9kW 1440/2880 rpm - Mechanical numerical dimension of the spindle height

Condition: excellent (used), Year of construction: 2015, Throughfeed drilling machine WEEKE BHT 500 with destacking device HOMAG mod. TSH 250/QR/25/12 Cgjb Eowfia Dod Ulvst

Condition: excellent (used), Row hole drilling machine 2 drilling beams Cgsb Edjwaapro Ulvet

Condition: as good as new (ex-display), Year of construction: 2022, Power: 750W / 230V Drilling capacity steel: 11mm diameter Speed range: 100 - 3000 rpm Cgjboiixxke Ed Ulvot Speed steps: stepless spindle mounting: B16 Drilling stroke: 60 mm spindle throat: 235mm table size: 290 x 290 mm Quick chuck: 1 - 13 mm Weight: 51 kg

Condition: new, Bench drill OPTIMUM D 23 Pro-Set OPTIdrill - Exhibition machine - ----- Technical data ----- Number of speeds: 12 steps, Speed range: 200 - 2,440 rpm, Spindle stroke: 80 mm, throat depth: 180 mm, Table size: 280 x 245 mm, max. drilling capacity in steel: 25 mm, Motor: 750 watts, Columns Ø: 73 mm, Dimensions (LxWxH): 615 x 330 x 1,015 mm, Weight: 63.5 kg, Spindle holder: MK 2 Bench drill with V-belt drive - Industrial motor - User-friendly safety switch in accordance with IP 54 - Digital drilling depth and speed display integrated in the housing - Separate emergency stop switch - Precision spindle bore - Safety electrics with 24 V DC voltage - Guaranteed concentricity of less than Cob Edeu R S Exo Ulvogt 0.02 mm measured in the drill sleeve - Drill spindle with precision ball bearings - High-quality quick-action drill chuck - Drilling depth stop - Precisely machined, stable drill table with diagonal T-slots running diagonally and circumferential cooling water channel - V-belt cover with safety switch - One-piece cast aluminum Die-cast quill lever with soft-grip handles - Largely dimensioned, height-adjustable safety screen with safety switch - Heavy-duty design of the entire machine - GATES quality belt - Right/left rotation -- Scope of delivery Quick-action drill chuck 1 - 16 mm Morse taper MK 2 / B16, T-nuts Special offer set including machine vice BMS 100 - new exhibition machine -

Condition: excellent (used), POINT TO POINT BORING machine with CN model MASTERWOOD SPEEDY 207 second hand machine for custom furniture manufacturing, kitchen furniture, bathroom furniture, and various processes Boring head with 5 independent vertical chucks and 1 double horizontal chuck Saw for longitudinal cuts Machine table with 1390 x 750 mm boring capacity and two side jump up stops handled by the control unit to execute with only one program and one intermediate hold panels up to 2800 x 750 mm size Possibility of boring 2800 mm panels Pneumatic tool displacement mm 60 Max panel thickness mm 50 Spindles rotation rpm 4500 Saw rotation rpm 6000 Vacuum pump motor Hp 1,5 Vacuum cup diameter mm 80 Front stop complete with 4 locking cylinders for drilling narrow workpieces and strips Multitasking control complete with interactive graphic programming, 9" video, boring programs, optimizing working cycle, graphic, parametric, diagnostic modes Overall dimensions - Machine : mm 2500 x 1800 x 1800 h - Weight kg 850 Cgeb Ed Uewd Irvslvst Overall dimensions - Electric board : mm 800 x 520 x 1200 - Weight Kg 120

Condition: good (used), Year of construction: 1995, Long hole drilling unit for mounting on an existing machine or wall without base frame Ceb Eov D Ilked Ulvegt

Condition: good (used), Code: 0555 Brand: STEMA 2 BR Model: INSERMATIC CB/86 - CE Standard Drilling and inserting machine for furniture hinges , kitchens, cabinets, furniture in general - CE Standard Cjb Eshhix Rod Ulvjgt Technical data: Drilling unit: Electropneumatic unit with motor Hp 2- 3000 rpm - Works from bottom to top, from under the panel - Drilling head: 3 spindles for hinges - 2 spindles for mounting plates Hinge insertion unit: N°1 single loader Worktable: rubber-coated rollers width 500 mm N° 6 mechanical stop blocks Suction 1 mouth diameter mm 80 Panel clamping: N° 2 vertical pressers Volt 380/50 Compressed air 6 atm Overall dimensions: mm 3600 x 1300 x 1300 h Weight kg 530

Condition: good (used), Year of construction: 2000, Manufacturer: Rilesa (Danish company specializing in the production of woodworking machines, in particular drilling and milling machines) Drilling machine data: Type: VLG 2224 Series: 06041125 Year of production: 2011 Voltage: 3x400+N+PE Hz: 50 Feeder data: Model: VAKMIX 3000 Cgsbovwbr Re Ed Ulvst Year of production: 2000 Serial number: 26119926 Hz: 50 Amp: 28 Pressure: 7 bar Rilesa VLG 2224 is a multi-spindle carpentry drilling machine, often used in production lines of furniture, doors, windows or other elements made of wood and wood-based materials. Use in series production where repeatability and precision are required, e.g. for holes for dowels, hinges, fittings, confirmats and other connectors.

Condition: as good as new (ex-display), Year of construction: 2025, Power: 0.85, 1.5kW Speed range: 300 - 4000 rpm Cgeb Eohpmbbsd Ulvst Speed steps: stepless spindle mounting: MK-3 Drilling stroke: approx. 105 mm spindle throat: 200 mm Weight: 152 kg

Condition: new, Drilling and milling machine OPTIMUM OPTImill MB 4 - Exhibition machine - This offer is an equipment package. The following items and options are already included in the price: - OPTImill MB 4 Optimum precision drilling and milling machine - Machine base MSM 3 Optimum - Collet chuck set MK 4/ ER 32 - M16 Optimum - End mill set HSS IMUM - Precision machine vice FMS 100 Optimum - new exhibition machine - Csbju R Tfts Ed Ulvegt

Condition: excellent (used), Year of construction: 1982, with 2 drilling beams Cobov Trlms Ed Ulvsgt Used, good condition Make Scheer Type DB 3 Year of construction 1982 Machine no. 73021 Number of spindles: 25 Number of drill beams: 2 Spindle spacing/grid: 32 mm Drilling from above Hydraulic feed brakes: 2 Linear stop: 1 approx. 2500 mm Working width: approx. 800 mm (768 mm) Drilling depth: approx. 100 mm stroke Drill chuck: M 10 Pendulum stops: 3 Clamps: 3 Drill programs: 4 Space required: approx. 1400 mm x 1300 mm x 1800 mm Weight: approx. 1000 kg Location: Arrives at the end of April at warehouse 54634 Bitburg - free on freight - Handed over in the current condition, as seen, without overhaul, without warranty or guarantee

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1300x1200x1200 mm Weight 700 kg Total power requirement 1,9 kw Csb Esv A Hyded Ulvjgt

Condition: new, Year of construction: 2022, Power: 750 W / 400 V Drilling capacity steel: 25 mm Speed range: 60 - 3050 rpm Speed levels: 12 infinitely variable levels Spindle holder: MK3 Quill stroke: 95 mm Spindle projection: 209 mm Table size: 308 mm x 308 mm Quick-action chuck: 1 - 16 mm Csb Edsir Embe Ulvegt Weight: 107 kg

Condition: excellent (used), Year of construction: 1996, The SCHEER DB 4 universal dowel hole drilling machine is specially designed for drilling structural holes, drilling rows of holes in a 32-hole grid system, and drilling various types of fittings. It enables all of these tasks to be performed quickly, precisely, and without extensive setup times. Simple operation via icons and 4 program presets allows for rapid changeover to the new work process. Central adjustment of the removable side stops ensures constant flushness at the front edge and precise drilling of left and right workpieces. It doesn't matter whether the parts are cut to size or at an accurate angle. The doweled corner joint is always flush, both on the edge and on the surface! No other CNC machine can achieve this with the simplicity and speed of a SCHEER DB 4. Safety clamping device across the entire table width allows workpieces to be clamped directly to the drilling beam. Stop rail with three adjustable folding stops. Continuous table supports facilitate pushing and drilling long workpieces, while fold-up workpiece support tables facilitate row and hinged drilling. Cgjb Edjv Trk Nj Ulvst 2 drilling units Drill motor type BM 602-230/400 volts, 50 Hz, n=2860, 2.2 kW power 25-spindle drive unit Spindle pitch 32 mm For surface and end-face drilling. Gantry clearance: max. 950 mm Working length: max. 2360 mm Location: Arrives at the end of April at warehouse 54634 Bitburg Sold as is - no warranty - no guarantee - freight prepaid -

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2800x1100x2200 mm Weight 1100 kg Total power requirement 8,8 kw Horizontal and vertical drilling machine MULTI MZ3x8 - Max. Center Distance Between Holes 2440(L)mm x 300(W) mm - Min. Center Distance Between Holes 220(L)mm x 32(W) mm - cess length 2440 mm - cess length 220 mm Cob Esvz Hwasd Ulvogt - Plate thickness 12~40 mm - Total number of drilling bit 32pcs - Horizontal backside drilling rows 4 rows - Max. drilling dia. 35 mm(Single bit) and 13 mm (Multi) - Max. drilling depth 50 mm - Dia. of drilling bit shaft 10 mm - Length of drilling bit 57 mm/70 mm - Drilling bit speed 2840 rpm - Qty of horizontal L&R drilling rows 2 rows - Qty of vertical up drilling rows 2 rows - Air pressure 0.5~0.6 Mpa - Total power 8.8 kw - Net weight 1100 kg - Overall dimension 2800 x 1100 x 2200 mm

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3500x2300x1780 mm Weight 4000 kg Total power requirement 27,2 kw Cjb Ed Uovz Hrdolvjgt

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1000x740x1260 mm Weight 240 kg Cgjbovz Hm Io Ed Ulvet Total power requirement 2,4 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1160x750x1080 mm Weight 260 kg Cjbsvz Hmbe Ed Ulvsgt Total power requirement 2,2 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 720x900x1160 mm Cobovz Hk Te Ed Ulvsgt Weight 120 kg Total power requirement 2,2 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2700x2500x1760 mm Weight 1500 kg Cjb Edevz E Dxj Ulvogt Total power requirement 4,5 kw
