Used dowel boring machines for sale (92)

Condition: good (used), Spindles, machining unit, automatic drilling machine, drilling machine, pillar drilling machine, multi-spindle drilling machine, row drilling machine, dowel drilling machine -Max. feed rate: Stroke 60 mm -Drive: 1.1 kW Ncodpfjb A Iiasx Aa Est -Recording: 10 x 17 mm -Number: 2x quill processing units available Price: per piece -Weight: 25 kg/piece

Condition: new, Year of construction: 2023, New machine Year of manufacture: 2023 Multi-spindle universal dowel drilling machine with 3 CNC axes (+/- 0.1 mm) with horizontal and vertical drilling capability electronic adjustment of height, depth, and drilling angle (0-90°) with 7" color touchscreen with memory for up to 1000 programs with parallel fences with numerical adjustment Ncsdpfx Aolk R Epea Eot with 21 drilling spindles (10 left, 11 right) Spindle spacing: 32 mm Maximum drilling distance: 640 mm Maximum tool diameter: 40 mm Maximum drilling depth: 65 mm Maximum horizontal drilling height: 35 mm Working height: 860 mm Maximum panel thickness: 60 mm Maximum panel size: 900 x 3000 mm Motor: 1.5 kW - 2800 rpm Pneumatic connection: 6/8 bar Compressed air consumption per work cycle: 5 NL Extraction port: 80 mm Machine footprint: 1580 x 950 x 1400 mm Net weight: 340 kg Availability: short-term Location: Flörsheim

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Ncedsxwaz Hspfx Aa Eet

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. Ncjdpoxnlfljfx Aa Ejt - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: used, Year of construction: 1985, Used machine Year of manufacture: 1985 Ncsdjwka Hfspfx Aa Est Features and technical data: - For construction drilling horizontally and vertically - For vertical row drilling with 32 mm spacing - Vertical drilling unit with freely positionable double spindle drill heads on index shaft - 1.5 kW motor with 1400 rpm - 1.5 kW motor with 2800 rpm - Drill heads with pneumatic stroke - Pneumatic material clamps - Pass-through width approx. 850 mm - Includes various stops and drill bits Availability: short notice Location: Röllbach

Condition: used, Year of construction: 1989, Used machine Year of manufacture: 1989 Equipment and technical data: - 2-jaw drill chuck for up to 20 mm shank diameter - Pneumatic position adjustment on 2 levels, 0-100 mm - Max. drilling depth 150 mm - Precision indexing rail 12 mm - Central locking and cross adjustment - 2 pneumatic safety clamping cylinders - Motor 1.5 kW - Speed 2800 rpm Dimensions (without stop): 1100 x 1100 x 1500 mm Weight: approx. 310 kg Availability: short-term Storage location: Röllbach Nodpfxowkba Ho Aa Eoct

Condition: used, Year of construction: 1997, Used machine Ncodey Tczkjpfx Aa Est Year of manufacture: 1997 Condition: Well-maintained/Functionally tested Equipment and technical data: Number of drilling spindles: 21 pcs. with 32 mm spacing Drilling direction: Bottom and end face Swivel range: 0-90 degrees, manually adjustable Pneumatic material clamps: 3 pcs. Passage: Max. 100 mm in height and max. 640 mm in width Motor: 1.5 kW Dust extraction diameter: 120 mm Includes a variety of stops (see pictures) Availability: short-term Location: Röllbach

Condition: used, Year of construction: 1993, Used machine Year of manufacture: 1993 Features and technical data: 2-jaw drill chuck up to 20 mm shank diameter Nsdpfsw I Uy Tox Aa Ejct Pneumatic positioning adjustment on 2 levels 0-100 mm Max. drilling depth: 150 mm Precision indexing rail 12 mm Center locking and cross adjustment 2 pneumatic safety clamping cylinders Motor 1.5 kW Speed: 2800 rpm Long hole drilling device, lowerable, with 2 program cams Machine weight approx. 310 kg Machine dimensions (W x D x H): 1100 x 1100 x 1500 mm (without stop) Availability: short-term Location: Röllbach

Condition: used, Year of construction: 1997, Used machine Year of manufacture: 1997 Condition: well-maintained Features and technical data: Njdpoxwz Ihjfx Aa Eoct - Number of drilling spindles: 21 pcs, 32 mm pitch - Drilling direction: from below and from the end face - Swivel: 0-90 degrees, adjustable by handwheel - Pneumatic material clamps: 3 pcs - Clearance: max. 100 mm height and max. 640 mm width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a variety of stops (see pictures) Availability: short notice Storage location: Röllbach

Condition: used, Year of construction: 1996, Drilling head with 21 spindles, 32 mm pitch Working width: 640 mm Portal clearance: approx. 750 mm Drilling stroke: 100 mm Drilling unit position adjustment: 0–45 mm Hole row position adjustment: 0–300 mm Spindle speed: 2800 rpm Shank diameter of drill bit: 10 mm Maximum clamping height of workpieces: 100 mm Motor: 1.5 kW Working height: 850 mm Compressed air connection: 6 bar Weight: approx. 400 kg Storage location: Supplier Ncedpfey Dd I Hox Aa Eet

Condition: used, boring spindle 21 Ncjdowp E Uxspfx Aa Eot dividing 32 mm hollow max. 1.000 mm swivable pneumatisch °

Condition: used, Year of construction: 2005, Used machine Year of manufacture: 2005 Nodpfx Aaey Si Als Esct Features and technical specifications: - Motor 400V-50Hz-3Ph, 1.5 kW - Pneumatic single-head boring machine with 23 spindles - Aluminum fence with 4 stops (2 profiles each right/left, 1500 mm each) - Equipped with quick-change chuck - 2 patented accident-safe pneumatic clamping cylinders - Connection for dust extraction unit according to EU standards - Aluminum boring beam with spindle spacing of 32 mm - Worktable made of MDF and cast iron - Patented spiral system for fine adjustment of drilling depth - Pneumatic drilling head swiveling with lock at any position between 0° – 90° - Foldable side stops with fine adjustment via mechanical counters with decimal display - Drill height setting via mechanical counters with decimal display - Rear fence, travel up to max. 300 mm - Fixed stops at 37 mm for insertion of concealed hinge drill bits - Complies with EU standards - Max. drilling width: 704 mm - Max. drilling depth: 65 mm - Max. workpiece width: 960 mm - Max. workpiece length: 3000 mm - Max. workpiece thickness: 60 mm Availability: short notice Location: 63934 Röllbach

Condition: like new (used), This used SCHEER DB 4 universal dowel boring machine has been functionally tested, worn parts have been replaced and the machine geometry has been readjusted to ensure maximum precision. The SCHEER DB 4 universal dowel hole drilling machine is specially designed for drilling construction holes, for drilling holes in rows in a 32 mm grid system and for drilling a wide variety of fittings; it enables all these tasks to be carried out quickly, precisely and without long set-up times. Extremely simple operation via symbols and 4 program preselection controls for changing over to the new work process in seconds. Central adjustment of the removable side stops, therefore always flush at the front edge, precise drilling of left and right workpieces. It does not matter whether the parts are cut to size or at the correct angle. The doweled corner joint is always flush, both on the edge and on the surface! No CNC machine can achieve this as easily and quickly as a SCHEER DB 4. Safety clamping device across the entire table width, clamping of the workpieces directly on the drilling beam. Stop rail with three adjustable folding stops. Continuous table supports make it easier to push through and drill long workpieces, fold-up workpiece support tables facilitate line drilling and hardware drilling. 2 drilling units Drill motor type BM 602-230/400 Volt, 50 Hz, n= 2860, 2.2 kW output 25-spindle attachment gearbox Spindle pitch 32 mm (other spindle pitches on request) For surface and face drilling. The vertical drilling unit is equipped with an oil brake for tear-free drilling through rows of holes. The control cabinet of the machine has been completely rebuilt and converted to the new SIEMENS LOGO CONTROL. This ensures the operational safety of the machine for the future! Gantry passage: Ncjdpfx Aaju Rqi Aj Est max. 950 mm Working length: max. 2360 mm

Condition: used, Year of construction: 2014, complete in standard configuration with: - Fully automatic electronic control with foot pedal for clamping-drilling-unclamping, electric jog operation, - Automatic return of the drilling unit after reaching the preset drilling depth - Automatic extension of drilling depth when end-grain drilling saves the need to adjust drilling depth from flat to end-grain drilling. (+10 mm, e.g. with dowel length 35 mm, drilling depth flat side 14 mm, drilling depth end-grain 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drill feed 0-70 mm) incl. 21 quick-change chucks (Ganner system) for easy bit changes. - Simple swiveling of the drilling unit from 0° to 90°, supported by gas cylinder. - 1 clamping beam, movable in Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop fence 1800 mm for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, with quick-change system, easily swappable from right to left for mirror-image shelf drilling in carcass constructions, also suitable for line boring in System 32. - Side stops and position settings, as well as drilling height position via support table using mechanical digital counters. - Side stops can be easily swiveled away, for the quickest changeover from carcass to frame and line boring. - Clamping arms for clamping beam designed for line boring positions up to max. 300 mm. - Ideal three-stage... Weight: approx. 400 kg gross, approx. 350 kg net. Dimensions (L x W x H): 1.35 m x 1.25 m x 1.40 m Equipment: 1 extraction hood, dust tested, ø 120 mm. 1 set for line boring in System 32 complete with: 1 base fence 1050 mm (aluminum profile 40x40 mm), 1 setting gauge for line boring. 1 frame dowel device complete with: 1 center stop, 1 round stop rod 850 mm long, 2 stops. Location: Nattheim. Ncjdpjyyxkhjfx Aa Est

Condition: ready for operation (used), Year of construction: 1987, functionality: fully functional, Schleicher DBS 1300 A36: Ncedpfx Aey S Ry Ssa Est +36 drilling spindles +approx. 1240–1300 mm working width +32 mm grid spacing +swiveling unit +horizontal and vertical drilling +pneumatic clamping Price: negotiable, €400 Shipping via freight forwarder possible.

Condition: good (used), Year of construction: 1999, functionality: fully functional, For sale is a high-quality dowel drilling machine, a GANNOMAT OPTIMA 21, Type 510, manufactured in 1999. The machine operates cleanly and precisely and is perfectly suited for dowel joints, hole patterns, and carcass processing. Technical data: +Manufacturer: GANNOMAT / Ganner +Model: OPTIMA 21 +Type: 510 +Year of manufacture: 1999 +21 drilling spindles +32-mm system +Drilling width: approx. 640 mm +Pneumatic workpiece clamping +Horizontal and vertical drilling possible +Foot pedal operation +Spindle speed: approx. 2,800 rpm +Motor power: approx. 1.5 kW +Connection: 400 Volt high voltage +Compressed air connection required +Robust industrial design +Weight: approx. 400 kg Condition / Equipment: +Fully functional +Well-maintained condition +Ready for immediate use +Heavy-duty professional design +Precise stops and easy operation Perfectly suited for: -Furniture manufacturing -Kitchen manufacturing Ncjdpoy Szhyofx Aa Ejt -Interior design -Carcass production -Series drilling -Dowel joints Price: €2,950 net Inspection and test run possible at any time by arrangement. Loading can be assisted, or shipping via a freight forwarder is possible. You will receive an invoice with VAT shown.

Condition: used, Year of construction: 2014, Used machine Year of manufacture: 2014 Equipment and technical specifications: Complete in standard configuration with: - Support with linear guide consisting of: Ncodpfx Ajy Ih Skja Est 1 pc. single-spindle horizontal drilling unit, 0.65 kW motor, stroke 70 mm Tool speed selectable via operator software (3,000/5,000/8,000 rpm) 1 pc. blow-out, glue application, and dowel insertion station for dowels Ø 8 mm, dowel length 25-50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1,300 mm, feed speed max. 105 m/min - Z-axis adjustable manually via mechanical digital counter, position via support table 5-40 mm - Dowel insertion projection adjustable 7-20 mm via mechanical digital counter, drilling depth 0-35 mm (with drill length GL 70 mm) is automatically set in conjunction with insertion projection - Closed glue system with 6 bar glue pressure via glue nozzle, for adhesives with viscosity 150 to 350 mPas - Glue quantity infinitely adjustable via operator software - Selector switch GLUE/WATER for flushing the glue system, each with: 1 stainless steel container for 7.5 kg glue and 7.5 l water - Control lamp for glue level indication in the glue container - 1 pc. left side fence, 1 pc. right side fence, and 1 pc. center fence (all removable) - 4 pcs. start buttons for individual operation with 1-4 workpieces - 4 pcs. pneumatic angled clamping cylinders 10° for workpiece thickness up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. extraction funnel, connection Ø 80 mm 1 pc. TCT control with: Integrated industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, 15" capacitive TFT industrial touchscreen display, operating system: WINDOWS 7 - Programming via menu-guided user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensioning, automatic workpiece mirroring and process optimization, 4 work areas can be assigned with different programs, graphical workpiece representation, parametric programming, zero-point offset, programmable work lists, error diagnosis with plain text Options: 1 Electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 pc. glue nozzle 1 Z-axis with NC-controlled dynamic positioning for height adjustment of the drilling and dowel insertion station (programmable from 5-40 mm) travel speed max. 30 mm/sec 1 Single-spindle vertical drilling unit from above, 0.65 kW, (3,000/5,000/8,000 rpm), position (Y) manually adjustable via mechanical digital counter from 5-40 mm, drilling depth (Z) max. 30 mm (with drill length GL 57 mm), workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (incl. drilling depth compensation, e.g., for Häfele Minifix) 4 Vertical-angled clamping cylinders 10° with holders, additional 1 Keyboard with holder Availability: by arrangement; currently being overhauled at Ganner factory Location: Austria

Condition: used, Table model, maximum milling depth: 70 mm, minimum workpiece width: 10 mm, minimum workpiece height: 8 mm, maximum workpiece height: 110 mm. Dimensions: 560 x 620 x 770 mm. Weight: approx. 30 kg. Storage location: Nattheim. Ncodpfx Ajy Hryvja Eot

Condition: new, Year of construction: 2026, Pitch 32 mm Working width 896 mm Boring depth max. 65 mm Motor output 2x1,5 kW Ncsdpjy Ehz Hsfx Aa Ejt Overall size 1122x1040x1250 mm Weight 380 kg Number of boring spindles 29 St.

Condition: new, Year of construction: 2026, Pitch 32 mm Working width 704 mm Boring depth max. 70 mm Nsdpfx Aoy Ehzgoa Eoct Motor output 1,5 kW Weight 310 kg Number of boring spindles 23 St.

Condition: new, Year of construction: 2026, Pitch 32 mm Njdpfjy Ehyvsx Aa Eoct Working width 1088 mm Boring depth max. 85 mm Motor output 2x1,5 kW Overall size 1320x1040x1250 mm

Condition: good (used), Code: 0359 Brand: MASTERWOOD Model: TEKNOMAT 2000-P - CE Standard Electronic anuba inserting machine with 2 controlled axis for inserting anuba hinges – CE Standard Technical specifications: Nedpfxsy Eg T Uo Aa Esct Working stroke length 3100 mm – Displacement speed 72 mt/min Working stroke height 350 mm – Displacement speed 15 mt/min Working stroke depth 150 mm - Displacement speed 15 mt/min Working table mm 150 x 3800 N° 2 rear stops with manual positioning N° 4 rear bracket-type clamps with reference stops Side stops with manual positioning 1 right - 1 left 2 pneumatic front clamps Anuba unit with double magazine for male female anuba hinges - Diameter 14 mm Tilting head - 7 + 90° Double stem anuba screw device Front fences on machine table for machining of assembled doors and windows Control CNC 2: Microprocessor control unit – Digital display – Multitasking operating system – Programming of manual and automatic anuba inserting – Inserting of single, anuba – Step by step execution Installed electrical power 7,62 Kw Compressed air 6-7 atm Machine Overall dimensions m 4400 x 1600 x 1600 h Weight kg 1650 Electrical cabinet overall dimensions mm 1050 x 550 x 1100 h Weight kg 390

Condition: excellent (used), Year of construction: 1988, Scheer dowel drilling machine DB 12 used Nedpfjy Ahuhox Aa Ejct 3 spindles 32 mm drilling center distance Motor 1.1 kW Max. drilling depth 70 mm Location: ex stock 54634 Bitburg - immediately available -

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, Drilling machine with automatic angle adjustment Nsdpfxjy Iaize Aa Ejct

Condition: good (used), Year of construction: 1980, Dowel drilling machine for frame production Ncsdpfx Aeyy I Snoa Eet
