Universal machining center

QUASER UX 600/15

Condition: ready for operation (used), Year of construction: 2011, operating hours: 39,737 h, machine/vehicle number: 302E110064, travel distance X-axis: 885 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 500 mm, controller model: HEIDENHAIN iTNC 530, workpiece diameter (max.): 640 mm, workpiece weight (max.): 500 kg, table width: 500 mm, table length: 600 mm, spindle speed (min.): 15,000 rpm, operating hours of spindle: 10,687 h, number of slots in tool magazine: 48, tool length: 280 mm, tool diameter: 125 mm, Equipment: documentation/manual, Machine for sale: Quaser UX600 15C - universal machining center - manufactured in 2011 in Taiwan. - 5-axis machine with direct measurement on all axes - control unit: Haidenhain iTNC 530 Operating hours: 39,737 Purpose: milling Machine length: 3700mm Machine width: 4000mm Machine height: 3100mm Machine weight: 12,100 kg Number of spindles: 1; spindle speed range: 15,000 1/min Strokes: X axis: 885mm; Z axis: 500mm; Y axis: 800mm Table Ndjdswlpywjpfx Abcod external length: 600mm external width: 500mm Tool maximum tool length: 280mm maximum tool weight: 7 kg maximum tool diameter: 125mm tool holder: SK 40 internal cooling: yes The machine works in 3 shifts - every day! The machine comes with 20 SK40 holders!

Condition: used, CNC Gantry-Type Boring and Milling Machine ANAYAK Type HVM-3800-P Ndedpfxoxcgtgo Abced Bed type milling machine, structure similar to a plate-type boring mill with fixed table Machine No.: M-20021203 Year of manufacture: 2002 ("Refurbished 2025") The machine will be completely workshop overhauled in 2025 and can then be inspected in storage at 37235 Hessisch Lichtenau. Travel distances: X: 3,200 mm, Y: 1,200 mm, Z: 1,500 mm Table size: 3,800 x 1,200 mm T-slots: 8 pieces, 22 mm, spacing 130 mm Table load: max. 25 tons (stationary table – virtually unlimited load capacity) Spindle taper: ISO 50 (DIN69871-A) (drawbar: DIN 69872-B) Spindle speed: 60 – 4,000 rpm, stepless Feed rate: up to 10,000 mm/min, stepless Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Electrical connection: 400 Volt, 50 Hz, 50 kVA - Automatic tool changer for 30 tools - Spindle drive with 2 speed ranges - With automatic tool changer and tool magazine - Orthogonal milling head with hydro-mechanical tool clamping - Orthogonal milling head fully automatic swiveling in two 45° planes – B+C axis - HEIDENHAIN iTNC 530 control, with electronic handwheel - Prepared for wireless touch probe (probe and receiver not included) - Additional HF-spindle, 18,000 rpm – for attachment - Free-standing control cabinet - Chip conveyor positioned between the gantry bed and the machine table - 32,078 operating hours recorded - Coolant system - Free-standing hydraulic unit - Operating manual with circuit diagrams Installation area (L x W): approx. 1,000 x 700 cm Installation height: approx. 410 cm Weight (total): approx. 33 tons Good condition

Condition: used, Year of construction: 2005, x-travel 500 mm y-travel 450 mm z-travel 400 mm control Heidenhain iTNC 530 c-axis 360 b-axis -5/+110 ° turning speeds 20- 10000 U/min power capacity - milling spindle 13 kW tool taper SK 40 Ndsdsw Eyg Iepfx Abcod no. of workpieces in the magazine 16 Stück rapid traverse 24 m/min table surface area 630 x 500 mm table load 200 kg weight of the machine ca. 4,0 t dimensions 2,3x 3,2 x 2,75 m 3 + 2 axis Milling Center - Turn-/swiveling table full programmable - electr. hand wheel - new spindel in 2015

Condition: ready for operation (used), Year of construction: 2000, General Data Measurements width 6000 mm Measurements depth 7000 mm Measurements height 3000 mm Machine weight 12200 kg Control Unit Brand HEIDENHAIN Model TNC 426 Main Drive Spindle speed range 8000 rpm Spindle motor power 15 / 10 kW Tool taper SK 50 Number of axis 4+1 Movement X-Axis Movement 1250 mm X-Axis Rapid Traverse 40 m/min Y-Axis Movement 880 mm Y-Axis Rapid Traverse 40 m/min Z-Axis Movement 800 mm Z-Axis Rapid Traverse 40 m/min Table Number of tslots 9 Table load 2000 kg Tools Number of station 30 Max weight 20 kg Max tool diameter 110 mm Max tool length 420 mm Media Chip conveyor Yes Additional Equipment Documentation Coolant System High-pressure Coolant (40 bar) Through-spindle Coolant Electronic Handwheel 90° Swivelling Milling Head (H/V) 30-position Tool Magazine Touch Probe M&H RMP 2000 Hydraulic System Ndsdpfowygn Ijx Abcod Oil Mist Extraction This 5-axis DECKEL MAHO DMU 125 P hi-dyn was manufactured in 2000. It features a Heidenhain TNC 426 control, a swiveling head, and a NC rotary table with a 360° B-axis rotation. The main spindle supports up to 8,000 rpm with a power of 15 kW. It includes a 30-position tool magazine and a high-pressure coolant system. If you are looking to get high-quality milling capabilities consider the DECKEL MAHO DMU 125 P hi-dyn machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 2015, Technical details: x-travel: 960 mm y-travel: 600 mm z-travel: 480 mm rotary table:: D 350 mm table load: 200 kg spindle turning speed range: 12.000 1/min drive capacity - spindle motor: 14/10 kW control: HEIDENHAIN iTNC 530 rapid traverse: 32 / 32 / 24 m/min Tool changer: 30- fach spindle taper ISO: BT 40 weight of the machine ca.: 7,4 t total power requirement: 45 kVA dimensions of the machine ca.: 3,1 x 2,3 x 3,1 m 5-axis simultaneously universal-machining center, NC-rotary-swivelling table dia. 350mm, Ndsdpfx Ajrm Txbjbcjd A-axis (120/-42°), C-axis 360°, Internal coolant supply, el. handwheel, chipconveyor, direct measuring system, Hour meter: approx. 9.000 h "machine on", approx. 3.500 h "spindle on" *

Condition: excellent (used), New 2006 Brother CNC-B00 Control Pallet Change time 3.4 seconds Ndedpferfxr Uex Abcod Pallet Size 600 x 425mm X axis 550mm Y axis 400mm Z axis 415mm Spindle speed 12000rpm 40 Station ATC BT30

Condition: used, Year of construction: 1979, x-travel 1800 mm y-travel 1200 mm z-travel 900 mm total power requirement 50 kW weight of the machine ca. 15 t dimensions of the machine ca. m Nodet Hw Enepfx Abcedd

Condition: good (used), Year of construction: 2000, CNC 5-Axis Universal Machining Center Deckel Maho DMC 80U hi-dyn Year of manufacture: 2000 Control: Heidenhain TNC 430 Travel range: X = 800 mm Y = 700 mm Z = 600 mm Speed range: 0 - 12,000 rpm Tool holder: ISO 40 Tool changer: 60-station tool magazine Table: 800 x 635 mm Drive: 10.0 kW milling spindle Pallet changer Internal coolant system with high-pressure pump and compact filter system Chip conveyor Spindle cooling Blohm tool dimensioning Ndedpfxsv Rvqbs Abcjd
