Used Grob G550 for sale (6)

Condition: excellent (used), Year of construction: 2013, operating hours: 9,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,020 mm, For sale is a 5-axis machining center from the world market leader, GROB. Model G550 with pallet changer. Year of manufacture: 2013. Location: Switzerland. The machine is in unparalleled, extremely good condition, has been used very little, and was only used for experimental purposes in an experimental toolmaking department. Control system: Siemens SINUMERIK 840D sl Machining type: 5-axis simultaneous machining Horizontally arranged motor spindle Swiveling rotary table Automatic pallet changer Travel distances: X-axis: 800 mm Y-axis: 950 mm Z-axis: 1,020 mm Rapid traverse rates: X-axis: 65 m/min Y-axis: 50 m/min Z-axis: 80 m/min Maximum axis acceleration: 9 m/s² Maximum feed force: 8 kN Positioning accuracy: Positioning uncertainty X/Y/Z: 0.006 mm Repeatability X/Y/Z: 0.004 mm Main spindle: Motor spindle Tool interface: HSK-A63 / SK 40 Maximum spindle speed: 16,000 rpm Spindle power ED 100 % / 40 %: 25 / 35 kW Maximum spindle torque ED 100 % / 40 %: 160 / 223 Nm Spindle bearing diameter front: 80 mm Chip-to-chip time: approx. 4.2 seconds Tool magazine: Pick-up disk magazine Tool interface: HSK-A63 Number of tool positions: 60 Maximum tool length: 465 mm Maximum tool diameter without restriction of adjacent positions: 72 mm Maximum tool diameter with free adjacent positions: 160 mm Maximum tool weight: 8 kg Maximum tilting moment: 12 Nm Workpiece area: Maximum pallet load: 700 kg Maximum table load: 800 kg Maximum workpiece diameter: 800 mm Maximum workpiece height: 900 mm Pallet system: Automatic pallet changer Pallet size: 630 x 630 mm 2 pallets Coolant and media supply: High-pressure internal coolant system: 80 bar Minimum quantity lubrication: Lubrix V7 Switching between MMS and coolant Pressure booster: 10 bar Compressed air storage tank: 20 liters Kedpfx Aiezp Rqijcjdr Chip conveyor Coolant and filter system Electrical connection data: Connection voltage: 3/PE 400 V AC Frequency: 50 Hz Rated current: 55 A Fuse rating: 160 A Power requirement: at least approx. 42 kVA Required air pressure: approx. 5 bar Machine weight: Approx. 24,000 kg including pallet changer Equipment: 5-axis simultaneous machining Siemens SINUMERIK 840D sl Motor spindle with 16,000 rpm HSK-A63 tool interface Automatic pallet changer Pallets 630 x 630 mm Tool magazine with 60 positions High-pressure internal cooling 80 bar Minimum quantity lubrication Lubrix V7 Pressure booster Compressed air storage tank Chip conveyor Coolant and filter system

Condition: reconditioned (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: U300625501192, travel distance X-axis: 800 mm, travel distance Y-axis: 950 mm, travel distance Z-axis: 1,020 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece diameter (max.): 900 mm, workpiece weight (max.): 800 kg, table load: 800 kg, rotary table diameter: 770 mm, rotational speed (min.): 50 rpm, spindle speed (max.): 16,000 rpm, number of spindles: 1, number of slots in tool magazine: 208, tool length: 465 mm, tool weight: 8 g, input voltage: 400 V, input frequency: 50 Hz, warranty duration: 3 months, Equipment: documentation/manual, rotational speed infinitely variable, Base machine G550 AB, Generation 0 Travel in X: 800 mm Travel in Y: 950 mm Travel in Z: 1020 mm Power supply: 400 V, 50 Hz, TN-S Dust extraction port for connection to a work area extraction system Kedpfxjzmabfo Aicodr Swiveling table (A' axis) Rotary table (B' axis), pallet clamping system GROB Machine control: HEIDENHAIN iTNC 530 Optimization of the machine kinematics with KinematicOpt GROB standard interface to the loading system V1.4 Swiveling table (A' axis) Rotary table with pallet clamping system GROB (B' axis) Motor spindle HSK-A 63, 16,000 min-1, 159/206 Nm, 25/32 kW GROB spindle diagnostics GSD Simple disc magazine HSK-A 63 with 50 tool positions Tool additional magazine TM167 HSK-A 63 with 167 tool positions Tool cleaning device Electromechanical tool length measuring device Palette 630 x 630 mm, grid hole pattern, without gripper claws Scraper belt chip conveyor, discharge height 1,100 mm Coolant high-pressure system (5-38 bar, internal coolant) Coolant low-pressure system Compressed air supply through the spindle center External compressed air supply via a flexibly adjustable hose Switchable coolant pressure booster for the nozzles in the motor spindle Oil skimmer for coolant maintenance Flushing device for the floor of the work area Blow-out gun in the work area Flushing gun in the work area Flushing device (Z-axis) Workpiece clamping system in the work area - KP1: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP2: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP3: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) - KP4: Hydraulic oil, manual pressure reduction, 30-200 bar (H1) Machine status indicator, three-color Infrared measuring probe m&h IR25.41 Remote machine diagnostics with access control switch Warranty for 3 months

Condition: used, Year of construction: 2011, Technical details: x-travel: 800 mm y-travel: 950 mm z-travel: 1020 mm weight of the machine ca.: 17 t dimensions of the machine ca.: 6 x 3 x 3,2 m Diameter of the table: 770 mm max. table load: 800 kg tool taper: HSK-A63 max. tool length: 465 mm no. of tools in magazin: 60 spindle turning speed range: 12.000 U/min feed power: 8 kN kp power capacity: 25/35 kW Kjdpot Rmd Iefx Aicjdr 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle *

Condition: used, Year of construction: 2016, x-travel 800 mm y-travel 1020 mm z-travel 1020 mm Control SIN840D sl B - axis 360 x 0,001 ° A - axis -185 / +45 x 0,001 ° feed x-axis 1 - 65.000 mm/min feed y- axis 1 - 50.000 mm/min Feed z- axis 1 - 80.000 mm / min. rapid traverse X/Y/Z 60 / 50 / 80 m/min spindle turning speed - stepless 1 - 16.000 U/min power capacity at 100 % load 25,00 kW power capacity at 40 % load 32,00 KW max. torque at 40% / 100% load 206 / 159 Nm spindle diameter in front bearing 70 mm tool taper HSK-A63 tool magazin: 272 tool length - max. 400 / 465 mm tool diameter 68 mm tool diameter with 2 vacant positions 160 mm Kdodpfezrpnfox Aicor tool total weight 8,00 kg Chip to chip time 4,2 sec. size of pallet 630x630 mm workpiece weight 700 kg interference diameter 900 mm total power requirement 50,00 kW weight of the machine ca. 32,00 t dimensions of the machine ca. 10,00 x 6,00 x H3,50 m 5-axis machining center with SIEMENS Sinumerik 840D SL control, integrated KNOLL coolant, coolant through the spindle, chip conveyor, RENISHAW measuring probe, BLUM-Laser, GROB Spindle-diagnosis (GSD) Additional Tool-Magazine TM218, Pallett-Storage PSS630-R13-12

Condition: used, Year of construction: 2017, Milling machines Travel distance X: 800 mm Travel distance Y :950 mm Travel distance Z: 1020 mm HSC-machines Number of axis: 5 milling machine / machining center Control: Siemens Sinumerik spindle chuck: HSK 100 spindle revolutions: 6000 rpm Speed range to: 6000 U/min table size X: 770 mm table size Y: 770 mm max. workpiece weight: 800 kg tool changer: 60 - time input Power : 32 kW Torque: 340 Nm Rapid traverse: 40 m/min feed rate: 40 mm/min spindle cooling chip conveyor control Siemens 5-axis CNC universal machining center Designed for high-precision milling of various materials Extremely rigid construction for heavy-duty cutting Equipped with Siemens Sinumerik control Kdsdpfx Aieyzw Sajcor HSK100 spindle, ideal for hard metal machining High process reliability and efficiency Suitable for automotive, mechanical engineering and mold making industries

Condition: used, Technical details: x-travel: 800 mm y-travel: 950 mm z-travel: 1020 mm control: Sinumerik 840D sl MDynamics Operate turning speeds: 9.000 1/min Spindle power: 65/54 kW max. torque on the spindle: 575/470 Nm tool taper: HSK-A 100 tool change unit: 60 Pos. Pallet changer 2x: 630 x 630 mm Kdedpozu Skuofx Aicsr table load capacity: 700 kg weight of the machine ca.: 23 t dimensions of the machine ca.: 3,8 x 6,15 x 3,2 m We offer 3pcs of 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don’t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle (10-80bar), one channel with proportional valve for pressures 10-200 bar, electromech. tool-length measuring device GROB, BLUM laser for tool measuring, tool coding, chip conveyor, 3D touch probe M&H, el. handwheel Siemens HT8 coolant gun, coolant shower, air gun, oilskimmer, automatic door Remote diagnosis KOMET Komtronic U-axis system with two heads: 1. UAS 160-HSK100-E-Z50-1 with 50 mm travel 2. Special UAS 160-HSK100-E-Z-32-1 with 32 mm travel. or *
