Used Ima Edgebander for sale (143)

Year of construction: 1999, condition: good (used), IMA Compact MFA / F / 5212 edge banding machine Year of manufacture: 1999 Serial number: 06601 Rsdpfx Acoia Naqezew Max. edge banding thickness: 12 mm Min. workpiece thickness: 10 mm Max. thickness of edging material roll: 3 mm Feed speed: 12 m/min Adjustment of the joint guide rail: manual Heating time: 10 min Jointing unit: Yes, with 2 milling units Automatic edging roll magazine: Yes Trimming shears up to: 0.2 - 3.0 mm Solid edge magazine: Yes Preheating of the panel by heating radiator Automatic glue application with glue tank and granulate Cutting saw angle adjustment via program Multi-function unit Rounding unit/corner copying, 2 motors Profile trimming blade Flat trimming blade Buffing unit Unit display, mechanical digital display Control type via control panel Operation: selector switch/push buttons Protective hood Weight approx. 2500 kg Dimensions L x W x H: 6500 x 1000 x 1600 mm CE marked Technical specifications subject to change

Condition: excellent (used), Year of construction: 2007, Filling and Packaging Line for 50 ml Vials 1. Vial Loading Machine: Rotary Table, SSS Conveying Technology, year of construction 2007 Empty or already filled and sealed 50 ml vials are manually placed onto a rotary table. From there, they are individually transferred onto the conveyor belt and continue down the line. 2. Labelling with Print and Camera Inspection Machine: Pago System 520, year of construction 2007 Printing system: Domino 320i thermal transfer printer Camera system: Cognex (integrated into Pago) The vials are labelled with self-adhesive labels. During the labelling process, batch number, expiry date etc. are printed directly onto the label via thermal transfer (Domino). At the same time, a camera-based inspection (Cognex) checks the printed data. Inspection results are displayed on an integrated screen. The print and camera systems are fully integrated into the Pago labelling machine. 3. Change of Vial Orientation (vertical to horizontal) Machine: FlexLink Conveyor XH, SSS Conveying Technology, year of construction 2016 Labelled vials are repositioned horizontally by a bottle turner to prepare them for insertion into the cartoner. 4. Cartoning with Leaflet Feeding Rjdpfjxb Uptox Aczjw Machine: MK-120, Harro Höfliger, year of construction 2007 Pre-formed folding cartons are erected automatically in the cartoner. At the same time, a leaflet is folded and provided via a GUK folding machine. One 50 ml vial and one leaflet are automatically inserted into each folding carton. In the configuration shown here, the carton bottom is glued with hotmelt and the top is closed with a tuck-in flap. Optionally, it can be converted (using existing format parts) to double tuck-in flaps without gluing. 5. Serialization and Camera Inspection Machine: Laetus PrintSpect TTS MV-70, year of construction 2015 After the cartoner, the folding cartons are printed with serial numbers and variable data (thermal transfer) and fully inspected by a Laetus camera system. This station was added in 2015. The Harro Höfliger MK-120 also features an integrated Wölke print system, which is not used here. 6. Tamper-Evident Labelling Machine: Pago System, year of construction 2007 The serialized folding cartons are sealed on the flap sides with tamper-evident labels. To do this, the cartons are precisely aligned and guided via a side belt. 7. Case Packing Machine: IMA CP18BA Case Packer, year of construction 2007 The finished individual packages are pneumatically pushed into shipping cartons (cases). The case packer seals the shipping cartons with hotmelt. 8. Final Labelling of Shipping Cartons Machine: Laetus VL4 C2 ICMV Cabinet + Pago labeller, year of construction 2015 The finished shipping cartons are labelled using thermal transfer printing. No camera inspection takes place at this station. This unit is exclusively for labelling shipping cartons (no serialization or aggregation). 9. Check Weighing (optional) A manual checkweigher is also available, but not included in the scope of supply and was only used for internal final checks. System available from Jan. 2026. Further information to follow.

Condition: used, • Dimensions (mm): 80 x 60 • Rubber plate • Mounting bracket Rodpfobxp Eaox Aczow

Condition: used, Milling and chamfering unit Manufacturer: IMA Rodobxp Nuopfx Aczsw - for double-sided edge banding machine (1 unit on the left side / 1 unit on the right side)

Condition: used, 2 units available. Rodsd Tmabopfx Aczew Please refer to the attached photos for more information.

Condition: good (used), functionality: fully functional, overall weight: 48 kg, FISCHER IMA Main Spindle FEZPS 100×88.3 HSK F63 Motor Spindle Electrospindle with C Axis No. 123866 | Art. No. 123866 – IMA CNC (spindle motor, main spindle, c axis) Art. No.: 123866 Manufacturer: E. Fischer AG Machine focus: IMA CNC Marking on spindle: FEZPS 100×88.3 HSK F63 Serial range on spindle: 123866 Serial No.: as per nameplate Manufacture date: 15.07.2004 Technical description Offered here is an original FISCHER main spindle, model FEZPS 100×88.3 with HSK F63 tool interface, for IMA CNC machining centers. The FEZPS 100×88.3 HSK F63 designation is the critical identifier for this spindle and is decisive for compatibility verification. Additionally, this spindle is equipped with an integrated C axis (W axis) and a mounted permanent magnet motor. Connections and configuration The spindle features multiple connections in the upper terminal box: • Main power connector for motor supply • Separate circular connectors for C axis and encoder signals • Coolant connections at the spindle base marked WATER IN and WATER OUT • Connection for Protecting Air Flow for compressed air sealing The arrangement, design, and pin configuration of these connectors are machine and type-specific and must be compared with your original spindle before purchase. Technical data as per nameplate Type: mW 13.5/10 4 No.: 964207 Class No.: B Rjdpfx Acjychd Ujzew Rated voltage: 28 to 380 V Frequency: 25 to 400 Hz Rated current: 2.6 to 2.8 A Rated power: 0.55 to 1.2 kW Rated speed: 680 to 11,900 rpm Protection rating: IP55 Number of poles: 4 Efficiency: 81.1 % Model: FEZPS 100×88.3 Weight Approx. 45 kg Dimensions Approx. L × W × H = 420 × 220 × 650 mm Technical application Deployed as main spindle in IMA CNC machining centers with C axis for precise milling, drilling, and positioning operations. Important note on compatibility The compatibility of this spindle must be confirmed absolutely based on the designation FEZPS 100×88.3 HSK F63, article number 123866, nameplate data, and arrangement of the connections in the upper terminal box. The housing number is for internal reference only and is not sufficient for reliable identification. Condition Used, tested and functional Signs of use as per photos

Condition: good (used), Electrospindle Main spindle OMLAT IMA 12 KW The price includes the C-axis shown. If you only require the main spindle, we will of course grant a discount. 1st tool holder: Type: HSK F63, similar to DIN 69893 Taper diameter: 38 mm 2. tool retraction: Automatically controlled Pull-in force: 11000 N 3. tool weight: Rodorhzlnspfx Aczow Maximum weight: 6 kg 4. direction of rotation: Right/left rotation, programmable 5. speed range: Infinitely adjustable from 1500 to 22000 revolutions per minute Programmable for individual requirements 6. drive: Frequency-controlled three-phase motor 7. drive power: 12 KW in S-1 operation 8. spindle lubrication: One-time factory grease lubrication for efficient maintenance 9. spindle cooling: Water cooling to maintain optimum operating temperatures 10. constant performance: Range from 12,000 to 22,000 revolutions per minute Spindle condition: Used but tested The main spindle was removed from a running system and carefully checked. As an alternative to new spindles, which are often not available, it guarantees immediate use and optimum reliability. This used spindle offers a cost-effective solution without compromising on performance.

Condition: used, Year of construction: 2006, IMA Novimat edge banding machine: Manufacturer: IMA Type: Novimat Concept/I/G/80/650/R3 Year of construction: 2006 Machine no.: 08113 Rated power: 41 kW Workpiece feed: Sliding chain Stop fence: Adjustable stop fence 700.080 Slide-in table: 63.152 Milling unit: 08.378 Glue level monitoring: Available Glue application unit: 04.0832 Gluing unit: 04.1570 PU premelter: 283.203 HK tool holder: For high-speed motors Snipping unit: 08.42 Trimming unit: 08.0555 Multiple processing unit: 08.348 Multiple profile scraper unit: 08.516 Flat scraper: 08.517 Copy corner buffing unit: 08.604 Buffing unit: 08.617-4 Safety devices: Light barriers, temperature controller, control terminal Additional equipment: Roller conveyor table in front Total machine length: Approx. 11 /16 m Suction device: Included Accessories: Edge magazines: 2 sliding magazines for gluing edges, each for 12 rolls, mobile Plasma edge heating (PLASMATREAT Düstec): 2 plasma devices Switch cabinet Panel return system (manufacturer: VENJAKOB): Components: Rodpfernkw Dsx Aczew 7 belt conveyor tables, belt width approx. 100 cm, different table lengths Round belt conveyor table Switch cabinet system 2 angular transfer tables Peripheral stations for edge processing line: Consisting of: Interface system Barcode scanning system

Condition: good (used), IMA BENZ drilling unit 10 +11 spindles with additional milling cutter and horizontal drilling head 2 x 3 spindles for IMA 310 410 610 If you are looking for a different drilling gear from Homag or IMA, please contact us or have a look at the website in our store. IMA BENZ drilling unit is a versatile and powerful tool, especially for the IMA 310, 410 and 610 machines. It is a 10 + 11 spindle drilling unit with an additional milling cutter and a horizontal drilling head with 2 x 4 spindles. Here are some technical details: Unit no.: 4-08300 and 4-07753 Drawing no.: 000W00004824 and 000M11100819 Motor speed: 1max = 4800 min-¹ Spindle speed: 8100 min-¹ and 8400 min-¹ Drive power: 4 kW Gear ratio: i = 1:1.69 and 1:1.75 Milling spindle: For holding milling tools The unit is used but in a functional condition and offers high productivity thanks to the ability to drill several holes simultaneously, which significantly reduces machining time. Rjdpfxeudluds Aczew

Condition: reconditioned (used), functionality: fully functional, IMA Adapter Unit with Interchangeable Flush Trimming Head and Flat Scraper Blade The IMA adapter unit is a refurbished interchangeable unit designed for flush trimming operations and equipped with a flat scraper blade. Featuring the article number 10 237 069 and an HSK 63 F clamping system, this unit is ideal for precise and secure machining tasks. The unit’s rotation is synchronized with the drive rotation, and it includes a 57 mm opening. Specifically designed for use with IMA machines, it supports tools with chamfer milling cutters. Included in the package is a flat scraper blade. The bolt dimensions are 16/18.1 mm. The unit can reach a maximum speed of 9000 revolutions per minute and has a maximum probing depth of 1.5 mm. Following a comprehensive refurbishment, which includes inspection, replacement of bearings, and new pneumatic hoses, the unit offers maximum safety, precision, and a nearly new condition. Used adapter units are taken from operational systems and are fully functional. Any age-related wear or significant precision limitations are clearly noted. Technical Description • Product: IMA Adapter Unit with Interchangeable Flush Trimming Head and Flat Scraper Blade • Article Number: 10 237 069 • Clamping System: HSK 63 F • Condition: Refurbished • Rotation: Synchronized with drive rotation • Opening: 57 mm • Support Bolt: For IMA machines • Tools: Compatible with chamfer milling cutters • Flat Scraper Blade: Included • Bolt Dimensions: 16/18.1 mm • Maximum Speed: 9000 RPM • Maximum Probing Depth: 1.5 mm • Special Features: Rjdpfeudl Idsx Aczjw • Inspected and fully re-bearings for maximum safety and precision • Pneumatic hoses replaced • Nearly new condition Note: Used adapter units are fully functional, extracted from operational systems. Explicit notice is provided for excessive wear or significant precision reductions due to aging.

Condition: good (used), Year of construction: 2014, An IMA feeding system is for sale. Redpfxsqwn E He Aczsw Machine is available immediately. Year 2014

Condition: reconditioned (used), Connected load 380V 5.5kW Roller diameter 900 mm Machine height 2950 mm Machine table 1310 x 1020 mm Stop Rsdex Ezqbopfx Aczsw

Condition: ready for operation (used), Year of construction: 2005, Carton width range: 28mm-92mm, carton height range: 14mm-60mm, carton length range: 55mm-190mm, max. total cross-section (width + height): 140mm, packaging capacity: 120 cartons/min, machine dimensions X/Y/Z: approx. 2550mm/1250mm/1800mm, weight: approx. 1200kg. Documentation available. On-site inspection is possible. Redsv Suhbspfx Aczew

Year of construction: 1955, condition: used, used manufactured by IMA type B55 built in 1955 Masch.-No. 0/650 pressing cylinder pneumatic 4 table 2900x1300 mm working height 750 mm Rodpfxevwf Sze Aczsw max. material thickness ca. 200 mm located in 97447 Gerolzhofen, free on truck, unpacked sale in current condition as seen without guarantee and warranty

Condition: used, Imatronic Numerical Control with ImaWop 8.0 Software (software updated in 2020) Working range on X axis mm 7000 Working range on Y axis mm 1400 Full table with support panel for positioning the suction cups Suction cups can be manually positioned on the work surface using a laser indicator No. 2 vertical electrospindles with C axis with automatic tool change Automatic tool changer with 18 positions on the back of the machine Drilling head with 21 spindles arranged as follows: * N° 11 verticals on X axis * N° 10 verticals in Y axis Edgebanding unit with glue pot and pre-melter for EVA glue (glue pot new in 2023) Nordson pre-melter for PUR bonding on Folding panels No. 1 blade aggregate (end cutter) No. 1 trimming aggregate No. 1 cross-shaped aggregate with 4 horizontal drilling lines No. 1 blower aggregate 2-position edge storage unit Front protection and safety system with carpets Full protection cabin (not original IMA) TECHNICAL DETAILS TO BE CHECKED Rodpew El Nhsfx Aczsw

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, operating hours: 80,859 h, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,630 mm, TECHNICAL DETAILS X-axis travel without edge banding: 6,000 mm X-axis travel with edge banding: 5,000 mm Y-axis travel: 1,300 mm Y-axis travel with main spindle + tool diameter 20 mm: 1,630 mm Rjdpfxsx Af Ivs Aczjw Y-axis travel with edge banding: 1,450 mm Clamping table: Dyna Poin BIMA 410 V Number of positions: 4 Edge banding unit: available Operating hours: 80,859 h

Condition: used, Year of construction: 2001, functionality: fully functional, Electronically controlled CNC processing center featuring: • Standard table • Safety mats • 1 vacuum pump, 100 m³/h • IMATRONIC-NT • Lateral safety grid, right-hand side Redpfx Acswyvfcszjw • With door and left-hand front • Portable workstation for the assembly of fixing dowels and bolts Technical data: • Processing area with standard units X/Y: 6000/1200 mm • Max. clamping height from upper edge of vacuum clamping plate (Z1): 100 mm • Max. panel thickness (Z2): depending on application • Working table height approx.: 1000 mm • Alternative field area without cycle operation (X): 2 x 2650 mm Free space in the center (X): 700 mm • With cycle operation (X): 2 x 2250 mm Free space in the center (X): 1500 mm • Central lubrication • Power supply: 3/N/PE, 400/230 V • IMAwinCAD for BIMA machines including edgebanding • IMAWOP • Main spindle HSK F63, cone diameter 38 mm, 12 kW, water-cooled • 1 boring saw unit • 1 grooving saw unit • Edge gluing unit VT 61

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: L3B031, IMA MISTRAL Y 16 Bottle/Can Air Rinsing Machine – Used, Immediately Available Machine Data: Model: IMA MISTRAL Y 16 Type: Automatic Bottle/Can Air Rinsing and Extraction Machine Serial No.: L3B031 Year of Manufacture: 2011/2012 Manufacturer: IMA S.p.A. / IMA Swiftpack (Italy) Electrical Specifications: 220/380 V, 3 phases, 50 Hz Space Requirements: approx. 400 × 140 × 220 cm Description & Features: This rotary air rinsing machine is designed for pharmaceutical and medical applications, suitable for GMP-compliant internal cleaning of stable, round glass or plastic bottles using sterile compressed air. • Fully automatic bottle cleaning and extraction • Processes up to 200 containers per minute • Includes format parts for plastic bottles Ø 44 mm × height 95 mm • Additional formats included: Ø 40 × 55 mm, Ø 60 × 130 mm • Operation: Bottles are single-lane fed via conveyor and screw separator, transferred into a carousel, gripped by tongs, rotated 180°, and cleaned with nozzles (blowing) and extraction heads (suction). Bottles are then transferred to the conveyor for downstream processing. • Suitable for bottles and cans made of plastic and glass • High level of automation, GMP-compliant design Rodpew Sfa Esfx Aczjw Documentation & Manuals: • Operating manuals (German, English, Italian) • Electrical circuit diagrams • Layout drawings / guards layout • Spare parts catalog • Blowing diagram / electrical diagram • FAT and SAT documentation • Machine and operator manual in German Scope of Supply: • Complete machine • Spare parts as per catalog • All original documentation (PDFs and printed documents) • Size parts for various bottle sizes Condition: • Used, from pharmaceutical production • Immediately ready for operation after installation • Available immediately Location: Çorlu, Turkey Price: On request
