IMA HSK Aggregate 4 Outputs

IMA

Condition: used, Year of construction: 2008, power: 41 kW (55.74 HP), edge thickness (max.): 3 mm, controller model: ICOS OPEN, The machine has the following configuration: Pre-milling unit Manufacturer model: R3 L20 Engagement control: Automatic, time-controlled Motor power: 4 kW Speed: 9,000 rpm Edge processing Number of edge processing units: 10 Crosscut saw unit Manufacturer model: 8.42/39/B Number of motors: 2 Motor power: 0.6 kW Speed: 12,000 rpm Flush trimming and rounding unit Manufacturer model: 08.055 Number of motors: 0.6 (?) Motor power: 1 kW Speed: 12,000 rpm Corner rounding unit Manufacturer model: 08.342 Number of motors: 2 Motor power: 0.66 kW Speed: 12,000 rpm Scraper blade unit Manufacturer model: 08.50 Belt sanding unit 1 Manufacturer model: 08.62 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 2 Manufacturer model: 08.062 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 3 Manufacturer model: 08 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 4 Manufacturer model: 08.617-2 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 5 Manufacturer model: 08 Processing unit 10 Manufacturer model: 08.190 Motor power: 4.5 kW Speed: 9,000 rpm TECHNICAL DETAILS Workpiece dimensions Max. panel height: 60 mm Min. panel length: 130 mm Min. panel width: 65 mm Edge material Min. edge thickness: 0.4 mm Max. edge thickness: 3 mm Feed Max. feed rate: 30 m/min Pressure: Rubber belt Number of panel sizing/milling units: 1 MACHINE DETAILS Control system: ICOS OPEN Total connected power: 41 kW EQUIPMENT Number of panel sizing/milling units: 1 Lamps for preheating the panel side Fsdpfozmtkajx Ahaegf Edge roller magazine with 2 positions PUR pre-melting unit Pressure roller set with 5 pressure rollers Spraying unit The machine is sold and delivered in its actual and legal condition ("as is, where is") based on photo documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at its destination. External reference: 5657

Year of construction: 1994, condition: used, Manufacturer: IMA Model: K150/C Year: 1994 Type: Automatic cartoning machine with tuck-in closure Power: 3.5 kW Manufacturer's data capacity: 120 strokes/min Mechanical speed achieved in our workshops without products: 70 strokes/min Formats - A mini : 20mm - A maxi : 85mm - B mini : 12mm - B maxi : 60mm - C mini : 50mm - C maxi : 170mm Carton feeding: suction cup picking Product feed belt: cell chain Automatic inspection and rejection of non-compliant cartons Compressed air consumption: 183.5 Nl/min Dimensions depending on layout: diagram available in the photo gallery Weight: 1,400 kg Fedox R D A Repfx Ahaogf Documentation and video in operation available

Condition: ready for operation (used), Year of construction: 2003, Edgebander manufactured in 2003. This IMA AVM/K/I/G80/822/S3R3L20 is designed for milling, edge banding, and postproduction for rebate doors. It features a heavy machine base, a drive for feed speed of approximately 5-25 m/min, and a glue application unit for various edge materials. If you are looking to get high-quality edge banding capabilities, consider the IMA AVM/K/I/G80/822/S3R3L20 machine we have for sale. Contact us for further details regarding this machine. • Spindle motor power: • 1 pre-milling unit with 2 motors, each 3 kW • 1 milling unit with 2 motors, 1 kW • 1 milling unit with 2 motors, 660 W • Spindle speed range: 12.000 rpm • Heating capacity: 5,0 kW • Used single-sided rebate and edge-banding machine • Year of manufacture: 2003 • For milling, edge banding and postproduction for a rebate - only on formated / pre-rabbet doors and unrebate doors • Left machine (fix stop on the left side) • Total processing in 3 throughfeeds: • • throughfeed: door top side (cross processing) • • throughfeed: door long side • • throughfeed: door long side • During 2. and 3. throughfeed the edge projection from 1. throughfeed is beeing milled by normal-reverse milling • The double rebate glueing is only possible by readjustment of the machine and manual postprocessing of the edge • Max. door thickness: • Vertical edge: approx. 70 mm • Rebate glueing: approx. 60 mm • Heavy machine base as carrier for units Fgodpfx Aozrhbdshajf • Drive for feed speed of approx. 5-25 m/min., mechanical stepless adjustable • Transport chain with plastic plates, approx. 80 mm wide, with automatic central lubrication • Manually height-adjustable top pressure with v-belt 80 mm wide • Infeed table • 1 horizontal manually adjustable unheated infeed fence • 1 pre-milling unit controllable, not swivable, not tracing • Glueing unit for optional use of straight edges or softforming, by change of glue application device • Edge material: • Strips: up to 1,3 mm • Coil material: 0,4-3 mm • Solid wood strips: 6 mm • Strip length max.: 2550 mm • Strip height: 14-80 mm (depending on glue application) • Manual side adjustment for pneumatic moveable glue application • Manual height adjustment from -15 mm up to +10 mm • 1 glue application 0,8 L, max. edge height 70 mm, straight edge with pneumatic quick lock, Chem-Coat, electronic temperature control • 1 hot melt glue application 0,8 L with quick-lock, edge height max. 80 mm, soft edge, Chem-Coat, with temperature control and control unit for strips • 1 automatic Quickmelt hot melt glue application • 1 2-fold magazine for edge material up to 3,0 mm thickness, manually mountable on the single coil magazine • 1 rebate shape pressure zone for pressing of edge material to a rebate with: • an activation unit 15 kW for reactivation of the edge material for rebate-shaping • a pneumatic controlled shaping tool for the bottom fold edge • a pneumatic controlled shaping tool for the complete rebate • additional pressure rollers for the edge areas with rebate • an electropneumatic side-moving device for the complete pressure zone • 1 horizontal adjustment with mechanical digital readout • 1 trimming unit for 2 motors mounted on top pressure for trimming of the front and rear edge/strip projection for trimming flush or with chamfer • 1 milling unit for 2 motors with height tracing, side tracing, for flush milling from bottom and top, 30° swivable

Condition: used, Year of construction: 1994, Storage location: Nattheim Fgsdpfx Ahewmm Nreasf

Condition: excellent (used), Year of construction: 2001, machine/vehicle number: 24205, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 4,800 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 100 mm, workpiece length (max.): 4,800 mm, workpiece width (max.): 1,800 mm, number of slots in tool magazine: 18, overall weight: 16,000 kg, spindle motor power: 12,000 W, number of spindles: 1, workpiece diameter (max.): 1,800 mm, Equipment: chip conveyor, documentation/manual, Exceptional machine and exceptional quality output. Machine was serviced by IMA technicians and original spare parts where used. Optic fiber and most of the compressed air pipes have been replaced with new ones. The automatic positioning of the vacuum cups is speeding the setup time. ImaWoop version 6.0 with Quicktool is making the operator life easier. You are always welcome to see the machine working. Anytime, a live visualisation of the machine through video link is available. CNC-portal processing centre make: IMA type: BIMA P 480 V, 180/480 Year of production: 2001 Short description Machine able to do a lot of complex tasks (milling, drilling, cutting, edgebanding, various angle cutting) - alternate processing Fedpfjtt Rpwsx Ahaegf - X = 2 x 2.400, Y = 1.800 mm - main spindle 12 kW - 18-fold tool changer - gluing unit with 6-fold coil-magazine Description working area with standard units Y = 1.800 mm changing table area with alternate processing: X = 2 x 2.400 mm /milling- and boring processing X = 2 x 2.100 mm /gluing processing CNC-line control IMATRONIC NT 231 Software Imawoop 6.0 automatic positioning of the vacuum cups Automatic lubrication Conveyor for waste and chips (belt) main spindle 12 kW with integrated C-axis 360 degrees autom. tool / adapter units changer 18-fold 1 edge gluing unit VT100 with glue application device edge thickness: 0,4 – 3 mm for 4-sided edgebanding and all around edgebanding with butt joint 6-fold coil magazine 1 end-trimming unit 0,8 kW adapter units included - saw, 90 degrees fixed - horizontal drilling unit with 4 ways - ABS edge milling unit - ABS edge radius scraper and horizontal scraper unit other adapters and tools available for extra cost Chip removal transport belt Air conditioned included in the electric cabinet

Condition: used, Imatronic Numerical Control with ImaWop 8.0 Software (software updated in 2020) Working range on X axis mm 7000 Working range on Y axis mm 1400 Full table with support panel for positioning the suction cups Suction cups can be manually positioned on the work surface using a laser indicator No. 2 vertical electrospindles with C axis with automatic tool change Automatic tool changer with 18 positions on the back of the machine Drilling head with 21 spindles arranged as follows: * N° 11 verticals on X axis * N° 10 verticals in Y axis Edgebanding unit with glue pot and pre-melter for EVA glue (glue pot new in 2023) Nordson pre-melter for PUR bonding on Folding panels No. 1 blade aggregate (end cutter) No. 1 trimming aggregate No. 1 cross-shaped aggregate with 4 horizontal drilling lines No. 1 blower aggregate 2-position edge storage unit Front protection and safety system with carpets Full protection cabin (not original IMA) TECHNICAL DETAILS TO BE CHECKED Fgjdsw El Nhjpfx Ahaef

Condition: good (used), Year of construction: 2008, machine/vehicle number: 22410, functionality: fully functional, power: 17 kW (23.11 HP), input voltage: 400 V, input current: 29 A, input frequency: 50 Hz, number of axes: 4, THE MACHINE IS CURRENTLY READY FOR SHIPMENT ON A TRUCK TRAILER. WE CAN ARRANGE DELIVERY FOR €2.00/KM. THE BUYER IS RESPONSIBLE FOR ORGANIZING AND PERFORMING THE UNLOADING. IMA BIMA 300 CNC Machining Center Offered is a fully functional IMA BIMA 300, 4-axis CNC machining center in a console table design. Basic data (no guarantee of accuracy and completeness): Fodpezq U Riofx Ahaogf Machining area: X-axis: approx. 5000 mm Y-axis: up to approx. 1400 mm Max. workpiece height or clamping height: approx. 125 mm Machine weight: approx. 6000 kg Main spindle: Power: 7.5 kW (S1) / 10 kW (S6) Tool holder: HSK F63 Speed range: up to 24,000 rpm Programmable clockwise/counterclockwise rotation Tool and machining units: Tool changer (disc changer) with approx. 18 magazine slots CNC-controlled C-axis (360° rotatable) Drilling unit: Vertical and horizontal drilling spindles Integrated nut saw Mount for various adapter units Table system / Clamping technology: Console table with approx. 6 adjustable support arms and several suction plates (vacuum clamping system) Two vacuum circuits, positionable depending on the workpiece External vacuum pump from Becker available (see images) Control and software: ICOS CNC control Programming via IMAWOP (dialog-oriented, graphical interface) PC-based control with network connection Additional equipment: Central lubrication of the linear guides Extraction connection (Ø 250 mm, approx. 4950 m³/h) Safety equipment according to CE with protective grilles and safety mats (some mats may have intermittent contact) Documentation and spare parts catalog incomplete Electrical data: Mains connection: 400/230 V, 50 Hz, 3N/PE We are available at any time to answer questions or arrange a viewing appointment.

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, This 3-axis IMA BIMA 410 CNC Wood Machining Centre was manufactured in 2000. It features a working area of 3000 mm in X and 1200 mm in Y, with a maximum clamping height of 100 mm. The machine is equipped with an automatic central lubrication system and AC servo motors for precise operation. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 410 machine we have for sale. Contact us for further details. • Working area X: 3000 mm • Working area Y: 1200 mm • Max. clamping height Z1: 100 mm • Max. workpiece thickness Z2: depending on equipment/application • Table height: approx. 1000 mm • Pendulum operation X: 2 × 1400 mm • Free space center X: 200 mm • Pendulum operation alternative X: 2 × 900 mm • Free space center alternative X: 1200 mm • Machine weight: approx. 6000 kg • Guide system: precision linear guides hardened approx. 62 HRC • Central lubrication: automatic for all main axes and ball screw • Drive system: AC servo motors with encoder • X/Y drive: rack and pinion • Z drive: ball screw • Feed rate: 40 m/min • Rapid traverse X/Y: 80 m/min • Rapid traverse Z: 25 m/min • Acceleration: 3 m/s² • Extraction connection main spindle: 300 mm • Extraction connection drilling spindles: 120 mm • Air speed: approx. 28 m/s • Air volume: approx. 7080 m³/h • Vacuum pump capacity: 100 m³/h • Compressed air connection: 1/2" • Air pressure: 6 bar • Control voltage: 24 V DC • Connected load: approx. 24 kVA • Power supply: 3/N/PE 400/230 V 50 Hz • Frequency converter: 0–480 Hz • Ambient temperature: +15 to +35 °C • Control system: IMATRONIC NT 231 • Interpolation: linear all axes, circular 2.5D • Resolution: 0.001 mm • Spindle: HSK F63 • Tool clamping force: 11000 N Fgodoy Aw N Ujpfx Ahajf • Max tool weight: 6 kg • Speed range: 1500–18000 rpm • Spindle power: 7.5 kW • Cooling: water cooled • CNC axis: 360° rotating • Tool magazine type: plate changer • Tool positions: 18 • Max tool length: 150 mm • Max tool diameter: 100 mm (150 mm with free сосед positions) • Max load: 60 kg • Saw unit motor: 1.5 kW • Saw speed: 5600 rpm • Saw blade diameter: max. 150 mm • Drilling unit: 14 spindles • Spindle stroke: 70 mm • Drive: 2.2 kW • Speed: 3150 rpm • Drill diameter max: 20 mm • Adapter head spindles: 4 • Speed max: 6000 rpm • Drill diameter max: 12 mm Table equipment: • 6 adjustable support arms • 12 suction cups 114 × 159 × 100 mm • 6 suction cups 125 × 75 × 100 mm • Vacuum system: 2-circuit clamping system • Electrical cabinet size: 2000 × 1800 × 600 mm DEFECT: • The main spindle no longer releases the interchangeable drill head

Condition: used, machine/vehicle number: 008660, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Fgodpfozmmt Uox Ahajf Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 30 m/min Maximum panel thickness: 60 mm Operating Units: 9 nr

Condition: used, machine/vehicle number: 008662, Position 1: Single Edgebanders IMA-NOVIMAT CONTOUR I/G80/790/R3 Fgsdpfx Aezmmtnohasf Position 2: Panel Return Systems IMA-NOVIMAT CONTOUR I/G80/790/R3
