Used Homag Edgebander for sale (487)

Condition: used, Year of construction: 2008, Used machine Year of manufacture: 2008 Condition: well-maintained, serviced regularly (last service by Homag in 11/2024) Features and technical specifications: Minimum workpiece thickness: 12 mm Maximum workpiece thickness: 60 mm Minimum workpiece size (L×W): 240 × 55 mm (with 22 mm thickness) / 100 mm (with 60 mm thickness) Minimum edge thickness: 0.3 mm (roll material) / 0.4 mm (strip material) Maximum edge thickness: 3 mm (roll material) / 20 mm (strip material) Feed speed: infinitely variable, 18–25 m/min (frequency-controlled) Type of glue: EVA hot-melt adhesive Glue application (pot / cartridge / nozzle): melting unit with granulate hopper Glue volume / cartridge size: granulate hopper, melting capacity 18–35 kg/h, level-controlled Heat-up time: approx. 8–10 min Edge magazine (slots): 2 rolls (automatic roll change) Automatic edge change: yes (automatic via PC22, can be switched manually) Pre-milling: 2 × 1.5 kW, 200 Hz, 12,000 rpm, pneumatically adjustable Pressure zone: 1 pre-press roller Ø 150 mm + 6 post-press rollers Ø 70 mm, automatic adjustment End trimming: HL84 trimming unit, 2 × 0.8 kW, pneumatically adjustable (bevel / straight) Flush milling: via pre-milling unit, pneumatically adjustable Radius milling: FK13 contour routing unit, automatic 8-position tool changer (R = 2 mm) Bevel/profile milling: yes, via FK13, pneumatically adjustable Scraper: integrated in multi-finishing unit MN21 Polishing: buffing unit in finishing module FA11 Jointing unit: jointing milling unit KAL310/A20/S2, 2 × 3 kW Workpiece pre-heating: available Release agent spraying device: top / bottom, type 2929 (F.01) Extraction ports: multiple Ø 100 mm (individual extraction per unit) Control: power control PC22 (industrial PC, woodCommander on Win XP embedded) Operating voltage: 400 V, 50 / 60 Hz CE / Standards: CE-compliant according to EU Directive 98/37/EC Dimensions / required space: approx. 8,000 × 1,400 × 1,600 mm Weight: approx. 3,000 kg The return conveyor system visible in the pictures is not included in the scope of supply! Availability: short-term Location: 63934 Röllbach Dodewx Aaqopfx Af Docc

Condition: excellent (used), Double-side Sizing & Edge Banding - Independent Machine (1st &/or 2nd in a line) Dcsdpfx Aott Iudsf Dsc Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Edges thickness in stips / lippings (min/max) mm 0,4 - 12 Panels thickness (min/max) mm 8 - 100 Working width (min/max) mm 240 - 3000 Numerical Control Power Control PC22 (Windows XP) Software woodCommander Adjustable feeding speed (m/min) 10 - 40 Safety and sound-proof enclosures/cabins Distance (center-axes) of the Disappearing Dogs (mm) 400 SIZING PART (for each side): Pre-Milling unit (2 x Kw 6,6) Free place LEFT SIDE only: 2 x Milling grooving rotating unit (2 x KW 6,6) EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) E34 Pressing rollers (revolver) both for straight and shaped edges (softforming) GL sextuple Edge coils supporting unit (No. of reels) 1 Snipping (end-cutting) Unit WK14 (2 x 0,8 KW) 25 m/min (0°-30°) Fine Trimming Unit (2 x 0,55 KW) 0°-30° Corner-rounding unit FF12 (4 motors) WD70 20 m/min Profile edge scraping unit PN20 Finish processing unit (Glue scraper + Buffing unit) FA 11

Year of construction: 2005, condition: ready for operation (used), functionality: fully functional, working width: 2,400 mm, working height: 32 mm, working length: 800 mm, TECHNICAL DETAILS Working width X-axis: 267 - 2,400 mm Working length Y-axis: 120 - 800 mm Working height Z-axis: 16 - 32 mm 2 upper drilling heads + independent Y-axis grooving consisting of: Left head with 15 vertical spindles in X and Y-axis + one blade for grooving Right head with 15 vertical spindles in X and Y-axis + one automatic hinge installation unit 2 independent lower vertical drilling heads in Y-axis each with 5 + 5 independent spindles Dsdpfxoydn A Tj Af Decc MACHINE DETAILS Control: Numerical control with WoodWop software EQUIPMENT Automatic loading system with motorized roller conveyor Tank with vibrator for hinge storage and automatic feeding Unloading system with automatic roller conveyor

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 0-201-09-5124, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,650 mm, controller model: Homatic PC 85 Power Control, TECHNICAL DETAILS X-axis working range: 6,000 mm Y-axis working range: 1,650 mm – up to 1,750 mm for milling Max. travel height during edge banding: 60 mm Max. applicable edge height: 65 mm Minimum internal radius: 30 mm Automatic tool changer: 18 positions Drilling head: 27 spindles (4 kW) Max. unit saw blade diameter: 200 mm MACHINE DETAILS Control system: Homatic PC 85 Power Control Software: WoodWop Electrospindle C Vector: 11 kW, HSK F63 Edge specification: Rolls, PVC / ABS 0.4 - 3 mm EQUIPMENT 10 adjustable support rails for vacuum cups Loading and unloading aid with 8 pneumatic rods Vacuum cup positioning with laser system Edge banding unit with 360° rotation, glue pot, and preheater for granular EVA glue Rubber-coated pressure roller + Rubber-coated pressure roller Preheating lamp Edge trimmer and edge scraper Edge holder magazine Front and side safety system with carpets Dcjdpfxsydl Nwj Af Doc Protective cage around access area Chip extraction with motorized conveyor belt Air conditioning for machine control cabinet Automatic lubrication system Vacuum pump

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 0-200-03-8334, feed rate X-axis: 24 m/min, workpiece height (max.): 60 mm, controller model: Power Control Pc 22, TECHNICAL DETAILS Panel height: 60 mm Solid wood: 20 mm PVC / ABS: 3 mm Feed speed: 24 m/min MACHINE DETAILS Control system: Power Control PC 22 Supply voltage: 480 V Frequency: 60 Hz Phases: 3~ + N Operating current: 51 A Fusing: 63 A Phase circuit: 3~ Control voltage: 24 V EQUIPMENT Electronically adjustable working height via CNC Powered, rubberized conveyor belt with increased pressure Panel support guide Lateral roller conveyor with idler rollers for panel support Sanding unit Infrared lamps for panel edge preheating Six-position coil holder magazine with automatic edge change via CNC EVA hot-melt gluing unit with premelter and glue pot Edge pressing unit for straight profiles with electronically adjustable pressure rollers via CNC End trimming unit with two motors and automatic tilt adjustment Dsdpfxoydiyms Af Docc Overlapping cut-off / milling unit with two motors Glue / milling unit with two tiltable motors, electronically adjustable via CNC Multifunctional 4-motor corner rounding unit (smoothing + rounding) with CNC control, automatic adaptation Provision for integrating an additional working station Edge scraping unit Oscillating brush unit

Condition: not inspected (used), Year of construction: 2009, operating hours: 29,000 h, functionality: unexamined, feed rate X-axis: 25 m/min, total length: 7,755 mm, workpiece height (max.): 40 mm, working height: 950 mm, controller model: PowerControl PC22, TECHNICAL DETAILS Feed rate: 18 - 25 m/min Maximum feed rate with FK11: 20 m/min Working height: 950 mm Minimum workpiece width (for workpiece thickness 12-22 mm): 60 mm (depending on workpiece length) Minimum workpiece width (for workpiece thickness 23-40 mm): 105 mm (depending on workpiece length) Workpiece protrusion: 30 mm Workpiece thickness: 12 - 40 mm Edging material (coil): 0.3 - 3 mm Maximum edge cross-section (PVC): 135 mm² Maximum edge cross-section (veneer): 100 mm² Maximum coil diameter: 830 mm Edging material (strips): 0.4 - 20 mm Maximum edge cross-section (strips): 900 mm² MACHINE DETAILS Control system: PowerControl PC22 Pneumatic connection: 7 - 8 bar Total length: 7,755 mm Operating hours: approx. 29,000 h EQUIPMENT Workpiece support with scissor-design and roller support, extendable to 1000 mm Automatic infeed guide adjustment Fixed stops on left side Pneumatically controlled infeed lock Top pressure via driven composite V-belt Electrical height adjustment Workpiece transport unit via transport chain with rubber coating Separating agent spray unit, top/bottom Joint trimming unit 2 x 3 kW Gluing unit A20 with 2 rollers, comprising workpiece preheating, Quickmelt application unit with quick-clamping system, 2-roller magazine, pressure zone C (automatically adjustable with 1 pre-press roller and 6 post-press rollers) Trimming unit HL84 0.8 kW, with automatic chamfer/straight adjustment and pneumatic flush/excess trimming adjustment Pre-milling unit 1.5 kW, pneumatic adjustment between flush and excess milling Contour milling unit FK11 with automatic adjustment from chamfer to radius milling Profile scraper PN10 (with pneumatic side retraction) Finishing unit (with pneumatic side retraction), consisting of glue joint scraper and buffing unit Remote control Workpiece guide for FK device Dcodpfoyc S Hasx Af Doc Note: Container loading and seaworthy packaging by the seller is not possible.

Condition: not inspected (used), Year of construction: 2008, operating hours: 33,000 h, functionality: unexamined, feed rate X-axis: 25 m/min, workpiece height (max.): 60 mm, working height: 950 mm, controller model: Power Control PC22, TECHNICAL DETAILS Feed rate: 18 - 25 m/min Working height: 950 mm Minimum working width at workpiece thickness of 22 mm: 55 mm Minimum working width at workpiece thickness of 60 mm: 100 mm Dcjdpfjyc Sr Aex Af Doc Workpiece overhang: 30 mm Workpiece thickness: 8 (12) - 60 mm Edging material, strip max.: 0.4 - 20 mm Edge cross-section, strip max.: 900 mm² Edging material, coil: 0.3 - 3 mm Max. edge cross-section for PVC: 135 mm² Max. edge cross-section for veneer: 100 mm² Max. roll diameter: 830 mm MACHINE DETAILS Control system: Power Control PC22 Pneumatic connection: 7 - 8 bar Operating hours: approx. 33,000 h EQUIPMENT Continuous machine frame for mounting processing units Workpiece support with roller rail, extendable approx. 800 mm Glue roller drive on feed stop Glue pot lift-off at feed stop Glue pot clamping, workpiece actuated Infeed fence automatically adjustable Infeed lock pneumatically controlled Infeed device with 2 rollers Infeed extension 500 mm Automatic pressure zone adjustment Sliding carriage Pre-installed for Boomerang ZHR05 return system Workpiece support in extended scissor design Operating data collection Electric height adjustment Fixed stop on left side Workpiece transport system Top pressure Separating agent spray unit Jointing cutter unit, 2 x 3 kW Gluing station A20 Basic for coil material up to 3 mm and strip material up to 20 mm, with melting unit with granulate tank and quick-change system Cross-cutting unit, 2 x 0.8 kW, with pneumatic adjustment Slip agent spray unit Pre-milling unit 1.5 kW, pneumatically adjustable Profile trimming unit FK13, 2 x 0.4 kW Universal milling unit 4 kW, controlled, with stepless axis Multi-finishing unit MN21 automatic Finishing unit FA11, with finishing station, cleaning agent application, and buffing unit, pneumatically adjustable Noise protection Spare position for additional processing units Note: The machine is sold without consumable tools. Container loading and seaworthy packaging by the seller is not possible.

Condition: used, machine/vehicle number: 008294, Position 1: Single Edgebanders HOMAG + LIGMATECH-KAL 210 + ZHR 01 Position 2: Panel Return Systems HOMAG + LIGMATECH-KAL 210 + ZHR 01 Dcjdpfsx A Tf Nsx Af Dsc

Condition: used, machine/vehicle number: 008256, Max width workable: 800 mm Max length workable: 2500 mm Max height workable: 1340 mm Dcedpfxex A Hfve Af Dec Max feed speed: 40 m/min

Condition: used, machine/vehicle number: 008321, X axis working area: 4200 mm Y axis working area: 1350 mm Working Table: Pod and Rail Dcodpox A Tdljfx Af Djc Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 18 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 007328, X axis working area: 3200 mm Djdexmgybepfx Af Decc Y axis working area: 1850 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 3 axes Number of controlled axes: 3 axes Total number of drilling spindles: 31 Total number of tool changer positions: 10

Condition: used, machine/vehicle number: 007329, X axis working area: 3200 mm Y axis working area: 1850 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 3 axes Number of controlled axes: 3 axes Total number of drilling spindles: 31 Dcodpsxn Nfvjfx Af Djc Total number of tool changer positions: 10

Condition: used, machine/vehicle number: 008339, Max. panel width: 3800 mm Max. panel length: 1600 mm Main saw blade projection: 95 mm No of Grippers: 6 Dcedex Nm S Sjpfx Af Djc

Condition: used, machine/vehicle number: 007985, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Dcodjx A Th Depfx Af Dsc Premilling Unit: yes Corner Rounding Unit: yes Operating Units: 7 nr

Condition: used, machine/vehicle number: 007987, Position 1: Single Edgebanders HOMAG-HIGHFLEX 1650 Dodpjx A Thqofx Af Decc Position 2: Panel Return Systems HOMAG-HIGHFLEX 1650

Condition: used, machine/vehicle number: 008395, X axis working area: 3050 mm Y axis working area: 1250 mm Main Electrospindle power: 10 KW Number of controlled axes: 3 axes Total number of drilling spindles: 27 Total number of tool changer positions: 8 Dcedpeygtcqefx Af Doc

Condition: ready for operation (used), Year of construction: 2009, Edgebander manufactured in 2009. This HOMAG PROFI KAR310/11/A20/S2 features a work piece return system BARBARIC. Consider the opportunity to buy this HOMAG PROFI KAR310/11/A20/S2 edgebander. Contact us for further details. • Condition: Used Dodpfsyhqi Dsx Af Decc Additional equipment • BARBARIC workpiece return system

Condition: ready for operation (used), Year of construction: 2006, number of axes: 3, This 3s HOMAG OPTIMAT BAZ 211 VENTURE 20 was manufactured in 2006. It features a reconditioned AC motor with a holding brake and a timing belt for enhanced performance. With approximately 32,572 operating hours, this CNC Wood Machining Centre represents a valuable opportunity for high-quality woodworking capabilities. Consider the opportunity to buy this HOMAG OPTIMAT BAZ 211 VENTURE 20 CNC Wood Machining Centre. Contact us for further details. Dcsdpfx Afeyhqc Re Doc • Operating hours: approx. 32,572 h • Condition: Reconditioned (factory reconditioned) • Replaced/repaired components: • AC motor 8.00 Nm digital with holding brake • Timing belt HTD 800-8M-30 • Adapter OMLAT–Homag spindle

Condition: used, machine/vehicle number: 007134, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, Hot Air Premilling Unit: yes Dcjdpfx Aet Hmtzsf Djc Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 10 nr

Condition: used, machine/vehicle number: 006574, Type of edging: Thin edge, Thick edge, Solid wood, Veneer Gluing System: EVA Hotmelt Premilling Unit: yes Djdpovxxuxofx Af Djcc Corner Rounding Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: used, machine/vehicle number: 007227, Position 1: Single Edgebanders HOMAG + LIGMATECH-KAL 310 + ZHR 05 Position 2: Panel Return Systems HOMAG + LIGMATECH-KAL 310 + ZHR 05 Dsdpewuuc Ajfx Af Djcc

Condition: ready for operation (used), Year of construction: 2003, spindle speed (max.): 18,000 rpm, number of axes: 4, This 4-axis HOMAG PROFI BAZ20/30/16/V/D was manufactured in 2003. It features a Homatic CNC control, WOODWOP CNC programming, an 18-position disk changer, and a main spindle with a 12 kW three-phase motor. Capable of handling workpieces up to 3000 mm in length and 1400 mm in width, it includes a continuous table with adjustable vacuum clamps. Consider the opportunity to buy this HOMAG PROFI BAZ20/30/16/V/D CNC Wood Machining Centre. Contact us for more information. • Control/Software: Homatic CNC control; WOODWOP CNC programming system; Postprocessor • Workpiece capacity: • Length 800–3000 mm; Width 350–1400 mm; Thickness max. 70 mm with edge / 80 mm milling • Frieze width min. 120 mm; Weight max. 150 kg • Table/Clamping: • Continuous table (D-table) • Longitudinal console 1 fixed; Longitudinal console 2 manual Y-width adjustment • 8 vacuum clamps 125 x 50 x 100 mm • Working height lower edge of workpiece 950 mm • Unit for moving vacuum clamps on unit carrier with pneumatic extension console (max. 4 clamps per longitudinal console) • Width adjustment (longitudinal console/D-table): Servo drive, per longitudinal console • Stop bolt for top layer overhang: Lifting/rotating device, max. 20 mm top layer, stroke 110 mm, individually selectable, end-position monitored (for manual door placement) • Main spindle: • Speed 1500–18000 rpm (VFD 15 kW), full rated power from 12000 rpm • Tool diameter max. 180 mm (milling) / 200 mm (grinding); Room extraction for all tools/units • Aggregate interface/C-axis: • Pneumatic and swivel drive interface • C-axis with torque drive and 3-point support • Tool changer: • 18-position disk changer for HSK F63; tool weight 6 kg; tool length max. 200 mm • Configurations: 18 x Ø max. 130 mm; or 9 x Ø max. 180 mm + 9 x Ø max. 70 mm; grinding tools Ø max. 200 mm • Changer raisable for traveling pickup (left side) • Units/aggregates (for tool changer unless noted): • Drilling/milling unit, 4 spindles: ER25 up to Ø16 mm shank, protrusion max. 50 mm, speed max. 13500 rpm, unlimited swivel via C-axis • Lock case milling unit, 2 spindles D=16/20: counter-rotating, 12000 rpm, integrated blow-out, unlimited swivel via C-axis • Swiveling saw/drill unit: manual 0–90°, flange Ø30 mm, TK Ø52 mm, prepared for crosscut saw Ø max. 180 mm, drill chuck with Weldon D=10 mm, speed max. 9000 rpm, C-axis swivel • Milling cutter holder D=30 with chip guide: mandrel length 45/80 mm, chip guide plate controlled via C-axis, changer space Ø 140 mm • Flush milling unit: simultaneous top/bottom, edge radius max. R12 mm, min. outer radius ~R5 mm / inner radius ~R30 mm at 90°, scanning top/bottom/side, unlimited C-axis swivel, speed max. 12000 rpm, workpiece thickness max. 50 mm, min. overhang ~35 mm, with narrow feeler shoes Dodpfx Aex D Ribef Djcc • WPL knife head: run-out angle 5°, Ø 70 mm • Gluing/edgebanding equipment: • Drive spindle/V for gluing units: mounted right side of boom; cross slide with Y anti-reb and Z extension stroke; anti-reb spindle with C-axis and electrical/electronic interface; dedicated Z-axis • Gluing unit 4 sides, 90 mm (for main spindle): straight edges with direct glue application; 1 pre-press roller + 1 pneumatic post-press roller (programmable); inner radius min. R40 at 90°; edge height max. 90 mm; veneer thickness 0.4–1 mm; folding pressure zone on main spindle with hot-melt reactivation • Edge hold-down device, manual adjustment • Magazine/pickup: • Pickup space on X-support for interchangeable special unit (e.g.

Year of construction: 2019, condition: ready for operation (used), spindle speed (max.): 8,000 rpm, This HOMAG Optimat LPP306 was manufactured in 2019. A used planing and profiling machine featuring six working spindles, it handles workpiece widths up to 250 mm and heights up to 160 mm. Equipped with PowerControl and powerTouch LPP300 for enhanced control, it offers feed speeds from 6 to 24 m/min. Spindle speeds are adjustable up to 8,000 rpm, ensuring versatility and efficiency in wood milling applications. Contact us for more information about this machine. • Workpiece width after processing: 10–250 mm • Workpiece height after processing: 10–160 mm • Control: PowerControl with powerTouch LPP300 • Feed table length: 2,500 mm • Feed speed: 6–24 m/minSpindles: • First lower spindle: • Motor power: 7.5 kW (Siemens IE3) • Speed: 6,000 rpm • Spindle diameter: 40 mm • Spindle length: 281 mm • First right spindle: • Motor power: 7.5 kW, speed continuously adjustable (Siemens IE3) Djdpsygvnpsfx Af Decc • Speed range: 4,000–8,000 rpm • Spindle diameter: 40 mm • Spindle length: 176 mm • First left spindle: • Motor power: 7.5 kW, speed continuously adjustable (Siemens IE3) • Speed range: 4,000–8,000 rpm • Spindle diameter: 40 mm • Spindle length: 176 mm • First upper spindle: • Motor power: 7.5 kW, speed continuously adjustable (Siemens IE3) • Speed range: 4,000–8,000 rpm • Spindle diameter: 40 mm • Spindle length: 266 mm • Second upper spindle: • Motor power: 7.5 kW, speed continuously adjustable (Siemens IE3) • Speed range: 4,000–8,000 rpm • Second lower spindle: • Motor power: 7.5 kW, speed infinitely variable (Siemens IE3) • Speed range: 4,000–8,000 rpm • Spindle diameter: 40 mm • Spindle length: 266 mm

Condition: excellent (used), Year of construction: 2020, HOMAG Centateq N-500 BHP 100 / VANTAGE 710 #0-250-71-6275 Year of manufacture: 2020 Table size: 3100 x 2250 mm Stop system front right, front left, rear 2x Vacuum system 580/690 m³/h Tool spindle 10kW, air-cooled Aggregate interface for main spindle, C-axis Tool changer magazine, fixed at the rear Milling unit with tracer ring 2 vacuum pumps Working field dimensions: 3100 mm X-axis 2250 mm Y-axis Dcsdpfsxfkdzox Af Dec 100 mm Z-axis Base machine footprint: 9400 x 6150 mm, weight 7,800 kg The gantry is mounted on a special frame. Installed software: WoodWOP Office Professional 3D CNC simulation Woodnest Basic The machine is currently disassembled and stored in our warehouse. Disassembly was supervised by a HOMAG technician.

Condition: used, machine/vehicle number: 008246, Position 1: Single Edgebanders HOMAG-KAL 310 + ZHR 05 Dcodpfx Asx A Hi Ijf Djc Position 2: Panel Return Systems HOMAG-KAL 310 + ZHR 05
