Used Ima Packaging Machine for sale (144)

Condition: used, functionality: fully functional, Reportedly very little used IMA model TR 135 medium speed blister packaging machine. - Manufacturer: IMA - Model: TR 135 - Forming capacity: max 90 cycles/min - Cutting capacity: max 230 cycles/min Isdpfx Aijy Slchedjif - Control system: Color touch screen - Feeding system: Pre-feeder hopper with capacity 45 litre + bowl with vibrator - Power supply: 400 V, 50 Hz (max power 12 kW, average power 7 kW) - Air supply: 700 Nl/min, 6 - 8.5 bar - Cooling device: Chiller Euro cold ACW-LP 16T Blisters: - Blister: PVC/ALU blisters. - Size range: Width 30 - 88 mm x Lenght 60 - 135 mm x Thickness 3 - 12 mm - Available parts: Possible to supply with IMA A83 horizontal cartoning machine

Condition: used, Year of construction: 2012, - Machining area: 5300x1400 mm - Main spindle replaced 3 years ago - 18-position tool changer Technical data Machining area - In the X direction: 5300 mm - In the Y direction with main spindle + WZ-0: 20 mm: 1400 mm - In the Y direction with drilling unit: (all vertical drills) 890 mm - Single-position machining: X = 2 x 2550 mm - Free space in the center: X = 200 mm - Alternating field machining: X = 2 x 2250 mm - Free space in the center: 800 mm 1 automatic tool/adapter changer magazine - Arrangement: mounted on the support, moving in the X direction - Disc changer with 18 magazine positions Guidance system - All axes are equipped with pre-tensioned, surface-hardened precision roller guides. Central lubrication - Manual central lubrication for all main axis linear guides and Z ball screw. 1 vacuum pump, 90 m3/h Console table consisting of: - 2 work piece stops fixed on the right and 2 on the left in the X direction, for movement in the Y direction - 10 adjustable support arms in the X direction, each with a rear stop - All stops are controlled by the program - The suction plates are fixed via the patented 2-circuit clamping system, eliminating the need for hoses. - 8 smooth support rails, automatically retractable - 2 push buttons for the workpiece clamping/releasing function Additional 2nd vacuum pump, 90 m3/h 1 additional central stop row, for centering workpieces Chip conveyor 1 main spindle - Drive power: 10.0 kW in S-6 operation - 7.5 kW in S-1 operation - Tool holder: HSK F63, taper diameter = 38 mm, similar to DIN 69893 - Speed range: infinitely variable RPM, programmable 1 centrally integrated CNC axis, rotating 360 degrees - for all adapter units, with torque support on the main spindle and pneumatic interface 1 vertical drilling unit l14 with 6 spindles, horizontal and attachment unit for a dado cutter - Horizontal drilling units with 2 outputs each Attachment unit for a dado cutter - Swivel range: 0 or 90° Control system ICOS CNC Modern, powerful PC-based control system with: - User-friendly interface with Windows standards - Trajectory control of all servo axes - Job list / order processing - IMA backup and recovery system on two hard drives - Uninterruptible power supply (UPS) IMAWOP software package - for dialog-oriented creation of CNC machining programs Iijdpezuw Rtjfx Aidjf - - 3D view and basic simulation of the programmed workpiece, the suction cups and consoles including tool and adapter display.

Condition: used, Year of construction: 2000, machine/vehicle number: 13304, type of input current: three-phase, workpiece height (max.): 45 mm, workpiece width (max.): 1,300 mm, workpiece length (max.): 2,250 mm, edge thickness (max.): 3 mm, actuation type: electric, total length: 10,000 mm, total width: 8,500 mm, Equipment: CE marking, documentation/manual, We offer a two-sided edge banding machine, IMA COMBIMA I K/II/R75/760/V/R3, manufactured in 2000, renowned for its reliability and efficiency in professional edge processing. This model handles workpieces with a thickness of 10 to 45 mm and a width of 270 to 1300 mm, offering versatility in working with various materials. The feed rate ranges from 6 to 30 m/min, enabling efficient production while maintaining high quality. The machine handles edge banding with a thickness of 0.7–3 mm and workpieces with a length of 270 to 2250 mm, making it an ideal solution for demanding industrial applications. This is a robust option for companies seeking proven machines in good working condition. Iiedpfx Aiozgb A Dodef The machine features a new Beckhoff control system. It is possible to purchase the entire line, including a roller conveyor equipped with a conical rotating table and a two-chamber automatic loading station.

Condition: used, Machining area: - in the X direction without gluing 6000 mm - in the X direction with gluing 5000 mm - in the Y direction 1200 mm - in the Y direction with main spindle + center distance 20 mm 1300 mm max. workpiece height above - top edge of suction plate Z1 100 mm - max. workpiece thickness Z2, dependent on equipment/application Work table height: approx. 950 mm 1 main spindle with pneumatic feed stroke - drive power: 12 kW in S-1 operation - tool holder: HSK F63, taper diameter = 38 mm - tool change: automatic - change force: 11000 N - tool weight: max. 6 kg - direction of rotation: clockwise/counterclockwise, programmable - speed range: continuously variable 1500 - 24000 rpm, programmable - drive: frequency-controlled three-phase motor - spindle lubrication: single grease lubrication - spindle cooling: water cooling 1 CNC axis rotating 360 degrees Ijdpfx Aiszupibedsif 1 vertical drilling unit S21 Machine table consists of: - 6 support arms adjustable in the X direction, each with a rear and center stop, all stops controlled by the program - 6 sets of suction plates consisting of a total of - 6 suction plates 114 x 159 x 100 mm - 6 suction plates 125 x 75 x 100 mm - The support arms and suction plates can be individually positioned according to the corresponding workpiece size. Changeover area: - without pendulum machining, without gluing: X = 2 x 2900 mm - free space in the middle: X = 200 mm - without pendulum machining, with gluing: X = 2 x 2150 mm - free space in the middle: X = 700 mm - with pendulum machining, without gluing: X = 2 x 2400 mm - free space in the middle: X = 1200 mm - with pendulum machining, with gluing: X = 2 x 1700 mm - free space in the middle: X = 1600 mm Feed drive system Rapid traverse rates: - X-axis 100 m/min - Z-axis 25 m/min Air pressure: 6 bar Tool changer magazine with 18 positions Tool coding: position-coded Tool weight: max. 6 kg Tool length: max. 150 mm Tool diameter: max. 100 mm when fully loaded max. 150 mm with free adjacent positions or nesting Central connection for extraction Mains voltage: 3/N/PE, 400/230 V, 50 Hz 1 vacuum pump 100 m3/h

Condition: used, Year of construction: 2010, - Application of release agent, top/bottom - Joint milling unit - Gluing unit - Trimming unit - Copy milling unit SKF-L - Profile trimming blade unit - Spray cleaning agent - Self-adjusting trimming blade unit - Buffing unit Single-sided edge banding machine Manufacturer: IMA Type: Advantage 310 Year of construction: 2010 Technical data Workpiece - Workpiece length: min. 150 mm - Workpiece width: min. 65* / 150 mm *at a max. workpiece thickness of 25 mm - Workpiece thickness: min. 8 mm, 12 mm with profile trimming blades max. 40 mm (with MFA 08.346), 60 mm (with SKF) - Smallest workpiece: 65 x 300 / 150 x 150 x 19 mm - Machining allowance per workpiece edge: 0 - 5 mm (observe max. chip cross-section) - Workpiece shape: right-angled - Material: chipboard, MDF - Surface material: direct coating (melamine resin paper), paper, film, veneer Edge material - Roll material without film: Paper edges & plastic edges: 0.3 - 3.0 mm Veneer edges: 0.5 - 3.0 mm - max. edge cross-section: 150 - 180 mm² - Cut edge strips: Strips: 3.0 - 8.0 mm - max. strip cross-section: 520 mm² - Edge height: min. 12 mm, max. 65 mm - max. upper edge overhang: 2 mm - Edge profiles Paper edge: approx. 0.4 mm, chamfer 15 Plastic edge up to 3.0 mm, radius depending on the tool Strip up to 8 mm flush milling (with interchangeable motor on MFA) Machine - Constant workpiece projection from the chain track: 35 mm + edge thickness - max. trimming cross-section 520 mm² - Throughput width: min. 65 mm (with projection of 35 mm) - min. workpiece length in feed direction: 150 mm - Overall height (top edge of chain track): 940 mm - Unit side: on the left in feed direction - Pneumatic connection: approx. 7 - 8 bar Application of release agent, top/bottom Joint milling unit 08.379 and blowing nozzle - with 2 motors, each 4 kW, 9000 RPM, 150 Hz Gluing unit 283.1513 with oil bath gearbox - Adhesive output 0.8 l, 60 mm high, with quick-lock system - can be used for hot melt adhesive or PU adhesive - with single roll / strip magazine, roll diameter 800 mm - with 3 main pressure rollers and 3 counter pressure rollers Trimming unit 08.415 - pneumatically swiveling to 0 or 8 degrees - with 2 motors 660 kW, 400 V, 200 Hz, 12000 RPM - 2 HM trimming saw blades 160 x 3.5 x 22, Z=36 Copy milling unit SKF-L Ijdpfjzuyp Eox Aideif - with 2 motors 180 W, 400 V, 200 Hz, 12000 RPM - and 2 motors 400 W, 400 V, 200 Hz, 12000 RPM - 1 set of DP profile milling cutter I 80x12xHSK25-R, Z = 4, with HSK25 shank - Profile length in the feed direction: max. approx. 50 mm - Workpiece thickness: max. 60 mm - Working speed: max. approx. 20 m/min - Distance between 2 workpieces: min. approx. 400 mm - min. workpiece projection = 35 mm + profile depth Profile trimming blade unit 08.519 - For finishing a top and bottom milled quarter-circle profile Spray cleaning agent Self-adjusting trimming blade unit 08.521 - for removing hot melt adhesive residue from the edge area of the top and bottom of the workpiece Buffing unit 08.617-2 - with an upper and lower motor: 180 W, 50 Hz, 1400 RPM - 2 polishing pads 50 x 160 x 19 mm

Condition: used, Year of construction: 1996, - Double-sided IMA COMBIMA for longitudinal machining - Swiveling device - Double-sided IMA COMBIMA for transverse machining 1 used edge processing line IMA COMBIMA / K/ II/ R75 / 1075 / V / R3 Ijdpfxezuypxj Aidjif Year of manufacture: 1996 Consisting of: - Double-sided IMA COMBIMA for longitudinal machining: Double edging unit 2 x milling units Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Cutting unit Flush trimming 2 x fine milling units Profile trimming blade Surface trimming blade Buffing unit Smoothing unit - Swiveling device from longitudinal to transverse - Double-sided IMA COMBIMA for transverse machining Protective milling Double edging Grooving milling unit Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Capping at the top pressure (retrofit to current model) Flush trimming Fine milling 2 x MFA milling units Grooving milling unit Profile trimming blade Surface trimming blade Copy buffing (4 motors) Buffing (2 motors) Smoothing unit Note: The technical data and descriptions are a transcript of the order confirmation at the time. Data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2005, - Automatic infeed table - KFA unit - Return system Ijdpozuyplsfx Aidoif Used single-sided edge banding machine Manufacturer: IMA Type: Combima Systems / I/R751220/R3 1 single-sided combination machine for trimming, edge gluing and edge finishing of panel-shaped workpieces made of wood and/or wood-based materials. - Automatic infeed table - KFA unit - Return system Technical data "Workpiece": Workpiece length - min.: 238 mm - max.: 2350 mm Workpiece width - min.: 142 mm - max.: 800 mm Workpiece thickness: - min.: 8 - 40 mm Technical data "Strip" (only for longitudinal processing): Roll material: - Paper edge bands & plastic edge bands: 0.3 - 3.0 mm - Veneer edge bands: 0.5 - 3.0 mm Edge height: - min.: 14 mm - max.: 45 mm Technical data "Machine": Variable workpiece overhang from the chain conveyor (including edge with edge thickness 0.3-3 mm): - min.: 40 mm - max.: 80 mm - PC control ICOS open - Feed speed v=5-25 m/min, frequency-controlled drive - Inclined roller table as infeed section NC infeed system for front and carcass parts - for length and width-independent automatic workpiece feed in single-sided edge processing machines. Only for the production of strip material in the 2nd pass - An additional stop rail, adjustable via NC axis. Double milling unit 08.376: - Controllable - Motor 1 operating in the same direction and motor 2 operating in the opposite direction - Reserve space on the unit carrier for a double trimming unit with electrical pre-installation for 2 x 6.6 kW. - Heater 300 lg, 2x1.5 kW, for preheating the workpiece edge. - Gluing unit 04.1570 system for straight edges and adhesive application to the workpiece. The edge thickness depends on the magazine used and is max. 3 mm. - Adhesive application for workpiece thickness max. 50 mm - 2 pre-melting tanks for PU adhesive - 12-position edge magazine for roll material 0.3-3 mm thick. (8 slots up to 3 mm, 4 slots up to 1.3 mm) Vertical roll holder for 12 rolls: - max. roll diameter 850 mm - max. edge height 45 mm - Trimming unit 08.42, for 2 motors mounted on the upper pressure bar - Pre-milling and milling unit with height sensor - with 1 motor 1000 W - Multi-profile / chamfer unit, with 2 motors 1000 W - Contour milling unit KFA 30 - Multi-profile drawing blade unit - Flat drawing blade 08.517 - Copy edging unit 08.604 - Edging unit 08.617-2 - Double milling stand 75.184, 1050 mm high, both stand sides can be used - Milling / profile milling / grooving unit 75.34 with 1 motor, without tool, 100 Hz, 6000 rpm - Milling / profile milling / grooving unit 75.34 with 1 motor, without tool, 100 Hz, 600 rpm - Motor spindle for the use of the Hydro-Format tool system - Return system, manufacturer Meinert Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 1996, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, number of slots in tool magazine: 5, total height: 3,100 mm, overall weight: 7,500 kg, table length: 4,000 mm, table width: 1,200 mm, spindle motor power: 7,500 W, spindle speed (max.): 18,000 rpm, This 3-axis IMA BIMA 610 V CNC Wood Machining Centre was manufactured in 1996. It features a working area of 4000 mm in the X-axis and 1200 mm in the Y-axis, with a maximum drilling diameter of 45 mm. The machine is equipped with 5 drilling spindles in the X direction and 11 in the Y direction. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 610 V machine we have for sale. Contact us for further details. • CNC Control: NUM CNC Control • Drive System: Siemens SIMODRIVE 611 • Maximum Workpiece Length: 4000 mm • Minimum Workpiece Length: 150 mm • Maximum Workpiece Width: 1650 mm • Minimum Workpiece Thickness: 10 mm • Maximum Workpiece Thickness: 65 mm • Drilling Spindles (X): 5 • Drilling Spindles (Y): 11 • Maximum Drilling Diameter: 45 mm • Main Spindle Power: 7.5 kW • Main Spindle Motor: Water-cooled • Tool Holder: HSK F63 DIN 69893 • Feed Drive Motor Power: 4 kW • Feed Speed: 1,500–18,000 mm/min • Maximum Tool Weight: 5 kg • Maximum Tool Clamping Force: 10,000 N • Operating Voltage: 400 V ±5% • Supply Voltage: 3/N/PE, 400 V, 50 Hz • Frequency: 50 Hz • Total Connected Load: 33 kVA • Rated Power: 41 kW • Rated Current: 62 A • Connection Cross Section: 16 mm² • Control Voltage: 24 V • Control Current: 52 A • Compressed Air Pressure: 6–10 bar • Air Connection: 1/2" • Required Air Consumption: 28 m³/h • Dust Extraction Connection: Ø100–300 mm • Air Flow Ø100: 14 m³/min • Air Flow Ø140: 28 m³/min • Air Flow Ø160: 36 m³/min • Air Flow Ø180: 46 m³/min Iisdpezug Alefx Aidsf • Air Flow Ø200: 56 m³/min • Air Flow Ø280: 105 m³/min • Air Flow Ø300: 127 m³/min • Number of Dust Extraction Ports: 1 • Machine Condition: Disassembled but fully functional Optional Equipment, not included: • Vacuum block suction cups (aluminum) and sliding console • Two milling spindles for synchronous milling with integrated tool changers • Safety fence with associated safety mats • Control cabinet and operating unit • Waste conveyor belt for milled sections

Condition: good (used), Year of construction: 2012, functionality: fully functional, Equipment: documentation/manual, IMA BIMA 300 CNC Machining Center For sale is an IMA BIMA 300, a 4-axis CNC machining center with a cantilever table. Key data: Machining area: X-axis: approx. 5300 mm [IMA BIMA 300 | PDF] Y-axis: up to approx. 1400 mm (depending on the tool) [IMA BIMA 300 | PDF] Max. workpiece height or clamping height: approx. 125 mm [IMA BIMA 300 | PDF] Machine weight: approx. 6500 kg [IMA BIMA 300 | PDF] Machine structure and drive: Steel construction with a movable support in the X, Y, and Z axes [IMA BIMA 300 | PDF] Servo-driven axes with rack and pinion drive (X) and ball screws (Y/Z) [IMA BIMA 300 | PDF] Travel speeds: X: up to 100 m/min Y: up to 60 m/min Z: up to 30 m/min [IMA BIMA 300 | PDF] Main spindle: Power: 7.5 kW (S1) / 10 kW (S6) [IMA BIMA 300 | PDF] Tool holder: HSK F63 [IMA BIMA 300 | PDF] Speed range: up to 24,000 rpm [IMA BIMA 300 | PDF] Clockwise/counterclockwise rotation programmable [IMA BIMA 300 | PDF] Iisdpfx Aeza Dm Hjidof Tool and machining units: Tool changer (disc-type tool changer) with approx. 18 magazine positions [IMA BIMA 300 | PDF] CNC-controlled C-axis (360° rotatable) [IMA BIMA 300 | PDF] Drilling unit: Vertical and horizontal drilling spindles Integrated dado saw [IMA BIMA 300 | PDF] Mounting for various adapter units [IMA BIMA 300 | PDF] Table system / clamping technology: Cantilever table with: 10 adjustable support arms several suction plates (vacuum clamping system) [IMA BIMA 300 | PDF] Two vacuum circuits, positionable depending on the workpiece [IMA BIMA 300 | PDF] Second vacuum pump available (90 m³/h) [IMA BIMA 300 | PDF] Control and software: ICOS CNC control system [IMA BIMA 300 | PDF] Programming via IMAWOP (dialog-oriented, graphical interface) [IMA BIMA 300 | PDF] PC-based control with network connection [IMA BIMA 300 | PDF] Additional equipment: Chip conveyor [IMA BIMA 300 | PDF] Central lubrication of the linear guides [IMA BIMA 300 | PDF] Dust extraction connection (Ø 250 mm, approx. 4950 m³/h) [IMA BIMA 300 | PDF] Safety equipment according to CE with safety guards and floor mats [IMA BIMA 300 | PDF] Documentation and spare parts catalog available [IMA BIMA 300 | PDF] Electrical data: Power connection: 400/230 V, 50 Hz, 3N/PE [IMA BIMA 300 | PDF] Further details regarding the equipment and condition can be provided upon request.

Condition: used, Year of construction: 2005, Single-sided edge banding machine Manufacturer: IMA Type: Novimat Systems/I/R75/1000 Year of manufacture: 2005 Technical data PC control - ICOS OPEN control system Feed rate 5-25 m/min, frequency-controlled Fence with electronic positioning control Adhesive application above and below Trimming unit with 2 motors, each 4.5 kW, 9,000 rpm, controllable. Iedpfx Aezuyhnsidoif - Horizontally adjustable via axis Heating element approx. 300 mm long, 2x 1.5 kW Gluing unit - Adhesive application with pneumatic quick-lock system. - Automatic PU melting system Quickmelt for 2 kg cartridges - 32-position edge magazine (8 slots up to 3 mm / 24 slots up to 1.3 mm) Vertical roller holder for 32 rollers, max. diameter 850 mm Cutting unit on the upper pressure roller with 2 motors, each 200 W, 400 V, 12000 rpm. - Horizontal pneumatic swiveling 0-25 - With controllable side contact, for 3 edge thicknesses Trimming unit with 2 motors, each 1000 W, 400 V, 200 Hz, 12000 rpm. - Operating in counter-rotation. Multi-processing unit 08.348 - For chamfering or radius trimming of the upper and lower longitudinal edges, as well as for copying the front and rear workpiece edges. - Program-controlled adjustment for up to 4 profiles - 2 motors, each 660 W, 400 V, 200 Hz, 12000 rpm. Spray nozzles above and below for applying cleaning agents Multi-profile scraper unit - With stepper motor axes for horizontal and vertical positioning. - For 4 profiles. Straight scraper unit - With electro-pneumatic retraction device Copying edge smoothing unit - With 4 smoothing motors, each 250 W - Smoothing unit with 2 lower and 2 upper motors, each 180 W, 50 Hz, 1400 rpm. Smoothing unit - For smoothing and eliminating the white haze on the trimmed PVC/ABS edges - With an upper and lower smoothing zone With workpiece return system LGIMATECH ZHR 05/L/145 - Air cushion table, inclined, 2 return belts with brushing devices from below. Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, This 3-axis IMA BIMA 410 CNC Wood Machining Centre was manufactured in 2000. It features a working area of 3000 mm in X and 1200 mm in Y, with a maximum clamping height of 100 mm. The machine is equipped with an automatic central lubrication system and AC servo motors for precise operation. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 410 machine we have for sale. Contact us for further details. • Working area X: 3000 mm • Working area Y: 1200 mm • Max. clamping height Z1: 100 mm • Max. workpiece thickness Z2: depending on equipment/application • Table height: approx. 1000 mm • Pendulum operation X: 2 × 1400 mm • Free space center X: 200 mm • Pendulum operation alternative X: 2 × 900 mm • Free space center alternative X: 1200 mm • Machine weight: approx. 6000 kg • Guide system: precision linear guides hardened approx. 62 HRC • Central lubrication: automatic for all main axes and ball screw • Drive system: AC servo motors with encoder • X/Y drive: rack and pinion • Z drive: ball screw • Feed rate: 40 m/min • Rapid traverse X/Y: 80 m/min • Rapid traverse Z: 25 m/min • Acceleration: 3 m/s² • Extraction connection main spindle: 300 mm • Extraction connection drilling spindles: 120 mm • Air speed: approx. 28 m/s • Air volume: approx. 7080 m³/h • Vacuum pump capacity: 100 m³/h • Compressed air connection: 1/2" • Air pressure: 6 bar • Control voltage: 24 V DC Isdpfxozug Afe Aidsif • Connected load: approx. 24 kVA • Power supply: 3/N/PE 400/230 V 50 Hz • Frequency converter: 0–480 Hz • Ambient temperature: +15 to +35 °C • Control system: IMATRONIC NT 231 • Interpolation: linear all axes, circular 2.5D • Resolution: 0.001 mm • Spindle: HSK F63 • Tool clamping force: 11000 N • Max tool weight: 6 kg • Speed range: 1500–18000 rpm • Spindle power: 7.5 kW • Cooling: water cooled • CNC axis: 360° rotating • Tool magazine type: plate changer • Tool positions: 18 • Max tool length: 150 mm • Max tool diameter: 100 mm (150 mm with free сосед positions) • Max load: 60 kg • Saw unit motor: 1.5 kW • Saw speed: 5600 rpm • Saw blade diameter: max. 150 mm • Drilling unit: 14 spindles • Spindle stroke: 70 mm • Drive: 2.2 kW • Speed: 3150 rpm • Drill diameter max: 20 mm • Adapter head spindles: 4 • Speed max: 6000 rpm • Drill diameter max: 12 mm Table equipment: • 6 adjustable support arms • 12 suction cups 114 × 159 × 100 mm • 6 suction cups 125 × 75 × 100 mm • Vacuum system: 2-circuit clamping system • Electrical cabinet size: 2000 × 1800 × 600 mm DEFECT: • The main spindle no longer releases the interchangeable drill head

Condition: used, Year of construction: 2005, Edge banding machine Manufacturer: IMA Type: Advantage 600 Year of manufacture: 2005 Iijdpfx Aezuyirsidjf Technical data - Joint milling - Gluing unit for thin and thick edges - Imprint zone - 2x edge trimmers - Flush trimming - Multi-function trimming unit (MFA) - Profile trimming blade - Surface trimming blade - Buffing - Return system at the upper pressure roller Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, Year of construction: 2003, Single-sided edge trimming and gluing machine Manufacturer: IMA Type: AVM/K/I/G80/822/S3R3L20 Year of manufacture: 2003 For milling, edge gluing, and finishing for a standard groove - only for pre-shaped/pre-grooved doors and square-edged doors Left-hand machine (fixed stop on the left). Complete processing in 3 passes 1st pass: Processing of the top surface of the door (transverse processing) Iijdpfx Aiozuykvedof 2nd pass: Door long edge 3rd pass: Door long edge During the 2nd and 3rd passes, the protruding transverse edge from the 1st pass is milled off by using a co-rotating/counter-rotating milling process. Double groove gluing is only possible through modifications to the machine and subsequent manual finishing of the edge. Max. door thickness: - Straight edge: approx. 70 mm - Groove gluing: approx. 60 mm Stable machine frame as a support for aggregates and housing for electrical installation. Drive for feed speeds of approx. 5-25 m/min., mechanically infinitely adjustable. (not to be confused with processing speed) Continuous, plastic-coated strip-type conveyor chain, approx. 80 mm wide, with automatic central lubrication. Manually height-adjustable top pressure with a V-belt 80 mm wide and spring-loaded, ball-bearing guide rollers. Machine length approx. 10,900 mm Infeed table at the machine inlet. 1 horizontal, manually adjustable, unheated stop bar 1 joiner milling unit controllable, not swiveling, without sensing with 2 motors, each 3 kW Gluing unit for optional operation of straight edge or softforming gluing, by changing the glue application. Edge material: - Strips: up to 1.3 mm - Roll material: 0.4-3 mm - Solid wood strips: 6 mm Strip length max.: 2550 mm Strip height: 14-80 mm (depending on glue application) with: - Side adjustment by hand for the pneumatically controlled glue application. - Height adjustment by hand -15mm downwards and up to +10mm upwards. 1 bell for the main pressure roller, manually adjustable 1 glue application 0.8L, max. edge height 70mm, straight edge with pneumatic quick-release, Chem-Coat coated, electronic temperature control 1 hot melt glue application 0.8L with quick-release, up to max. 80 mm high edge material, soft edge, Chem-Coat coated, with temperature control and control unit for the strip coating 1 automatic Quickmelt hot melt glue feeder with a heating power of 5.0 kW 1 2-fold magazine only for edge material up to 3.0 mm thick, can be manually attached to the single-roll magazine 1 groove forming pressing unit for pressing the edge material into the groove with: - an activation unit 15 kW for re-activating the edge material for groove forming - a pneumatically controlled forming shoe for the underlapping edge - a pneumatically controlled forming shoe for the entire groove - additional post-pressing rollers for the edge areas in the groove - an electro-pneumatic lateral retraction device for the entire pressing unit 1 horizontal adjustment with mechanical digital display 1 trimming unit for 2 motors mounted on the top pressure for trimming the front and rear edge/strip overhang, for trimming cuts flush or with a bevel. 1 milling unit for 2 motors with height sensing, side sensing, for pre-milling from below and above with 2 motors 1kW, 400V, 200Hz, 12,000 RPM, 30° swiveling 1 milling unit for 2 motors with height sensing, side sensing, for fine milling from below and above with 2 motors 660W, 400V, 200Hz, 12,000 RPM, 30° swiveling Note: The technical data and descriptions are copies of the original order

Condition: excellent (used), Year of construction: 2014, machine/vehicle number: 24406, functionality: fully functional, operating hours: 900 h, input voltage: 400 V, input frequency: 50 Hz, ⚙️ IMA BIMA CUT 145/330 – Technical Specifications (Main) 🔹 Working range (axis travel) • X axis: approx. 3300 mm • Y axis: approx. 1450 mm • Number of axes: 3 (typically X, Y, Z) 🔹 Spindle • Spindle power: approx. 18 kW • Applications: milling, drilling, and board nesting 🔹 Tool changer • Automatic tool changer (ATC): up to 18 positions 🔹 Material clamping system • Vacuum table with beams and suction cups Isdpeykn Dwefx Aidjif 🔹 Saw unit • Saw projection: approx. 145 mm • Cutting length: approx. 330 mm ⸻ 🛠️ Typical features and equipment • 5-sided drilling (top + X+/X−/Y+/Y− sides) • Saw unit for cutting and grooving • Optional horizontal milling aggregate (HBO) • Automatic loading and unloading table (depending on configuration) • Nesting system (panel optimization with simultaneous machining) • Automatic lubrication • Waste and chips conveyor (belt) ⸻ 📌 General information • Manufacturer: IMA Schelling (Germany) • Year of manufacture commonly found in offers: approx. 2010–2016 (often 2014) • Applications: furniture production, MDF panels, HPL, solid wood, nesting

Condition: good (used), Year of construction: 2008, machine/vehicle number: 22410, functionality: fully functional, power: 17 kW (23.11 HP), input voltage: 400 V, input current: 29 A, input frequency: 50 Hz, number of axes: 4, THE MACHINE IS CURRENTLY READY FOR SHIPMENT ON A TRUCK TRAILER. WE CAN ARRANGE DELIVERY FOR €2.00/KM. THE BUYER IS RESPONSIBLE FOR ORGANIZING AND PERFORMING THE UNLOADING. IMA BIMA 300 CNC Machining Center Offered is a fully functional IMA BIMA 300, 4-axis CNC machining center in a console table design. Basic data (no guarantee of accuracy and completeness): Machining area: X-axis: approx. 5000 mm Y-axis: up to approx. 1400 mm Max. workpiece height or clamping height: approx. 125 mm Machine weight: approx. 6000 kg Main spindle: Power: 7.5 kW (S1) / 10 kW (S6) Tool holder: HSK F63 Speed range: up to 24,000 rpm Programmable clockwise/counterclockwise rotation Tool and machining units: Tool changer (disc changer) with approx. 18 magazine slots CNC-controlled C-axis (360° rotatable) Drilling unit: Vertical and horizontal drilling spindles Integrated nut saw Mount for various adapter units Table system / Clamping technology: Console table with approx. 6 adjustable support arms and several suction plates (vacuum clamping system) Two vacuum circuits, positionable depending on the workpiece External vacuum pump from Becker available (see images) Control and software: ICOS CNC control Programming via IMAWOP (dialog-oriented, graphical interface) PC-based control with network connection Additional equipment: Central lubrication of the linear guides Extraction connection (Ø 250 mm, approx. 4950 m³/h) Safety equipment according to CE with protective grilles and safety mats (some mats may have intermittent contact) Isdpfxszq U Rio Aidoif Documentation and spare parts catalog incomplete Electrical data: Mains connection: 400/230 V, 50 Hz, 3N/PE We are available at any time to answer questions or arrange a viewing appointment.

Year of construction: 2005, condition: ready for operation (used), A single-sided IMA edge processing machine for sizing, edge bonding and post-processing of wood panels is available. Min. workpiece dimensions X/Y/Z: 150mm/130mm/16mm, max. workpiece dimensions X/Y/Z: 2350mm/800mm/40mm, max. workpiece weight: 50kg, workpiece angle: 90°, material: particleboard/MDF, working height: 960mm. This is a complete system with conveying and peripheral units. Documentation available. An on-site inspection is possible. Iiedpfezidi Sox Aidsf

Condition: excellent (used), Year of construction: 2001, machine/vehicle number: 24205, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 4,800 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 100 mm, workpiece length (max.): 4,800 mm, workpiece width (max.): 1,800 mm, number of slots in tool magazine: 18, overall weight: 16,000 kg, spindle motor power: 12,000 W, number of spindles: 1, workpiece diameter (max.): 1,800 mm, Equipment: chip conveyor, documentation/manual, Exceptional machine and exceptional quality output. Machine was serviced by IMA technicians and original spare parts where used. Optic fiber and most of the compressed air pipes have been replaced with new ones. The automatic positioning of the vacuum cups is speeding the setup time. ImaWoop version 6.0 with Quicktool is making the operator life easier. Iijdpfx Aistt Rpwedjf You are always welcome to see the machine working. Anytime, a live visualisation of the machine through video link is available. CNC-portal processing centre make: IMA type: BIMA P 480 V, 180/480 Year of production: 2001 Short description Machine able to do a lot of complex tasks (milling, drilling, cutting, edgebanding, various angle cutting) - alternate processing - X = 2 x 2.400, Y = 1.800 mm - main spindle 12 kW - 18-fold tool changer - gluing unit with 6-fold coil-magazine Description working area with standard units Y = 1.800 mm changing table area with alternate processing: X = 2 x 2.400 mm /milling- and boring processing X = 2 x 2.100 mm /gluing processing CNC-line control IMATRONIC NT 231 Software Imawoop 6.0 automatic positioning of the vacuum cups Automatic lubrication Conveyor for waste and chips (belt) main spindle 12 kW with integrated C-axis 360 degrees autom. tool / adapter units changer 18-fold 1 edge gluing unit VT100 with glue application device edge thickness: 0,4 – 3 mm for 4-sided edgebanding and all around edgebanding with butt joint 6-fold coil magazine 1 end-trimming unit 0,8 kW adapter units included - saw, 90 degrees fixed - horizontal drilling unit with 4 ways - ABS edge milling unit - ABS edge radius scraper and horizontal scraper unit other adapters and tools available for extra cost Chip removal transport belt Air conditioned included in the electric cabinet

Condition: used, Year of construction: 2001, - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Used CNC machining center Iedjzux Uaepfx Aideif Manufacturer: IMA Type: BIMA P 480 V, 180/480 Year of manufacture: 2001 Alternative processing: - X = 2 x 2,400 - Y = 1,800 mm - Main spindle 12 kW - 18-position tool changer - Gluing unit with 6-position coil magazine Working area: For standard machines, Y = 1,800 mm Changing table area for alternating machining: X = 2 x 2,400 mm / Milling and drilling X = 2 x 2,100 mm / Gluing CNC line control IMATRONIC NT 231 Automatic adjustment table with clamping plates Main spindle 12 kW With integrated C-axis, 360 degrees Automatic tool/adapter unit changer, 18-position 1 edge banding unit VT100 With glue application device Edge thickness: 0.4 - 3 mm For 4-sided edge banding and all-round edge banding with butt joint 6-position roller magazine 1 trimming unit 0.8 kW Including adapter unit - Saw, fixed at 90 degrees - Horizontal milling unit (corner release) - Chamfer milling unit - Straight milling unit - Profile drawing blade Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: reconditioned (used), Year of construction: 2000, functionality: fully functional, Equipment: CE marking, IMA BIMA 410 V CNC WORKING CENTRE FOR BORING + ROUTING + EDGE BANDING • Industrial machine with heavy-duty structure • Working area: X:4000 mm Y:1200 mm Z: 100 mm • Travel speed: X:100 m/min Y:80 m/min Z: 25 m/min • 2 Working areas • 8 movable work tables to support the panels. SCHMALZ system • 23 SCHMALZ suction cups with vacuum system for the locking of the working piece • 4 loading device through pneumatic bars assembled on the work tables that lift the pieces • 1 SIEMENS vacuum pump ROUTING UNIT: • 10 HP. Refrigerated router head • Automatic change of the tool • Tool holders: HSK F-63 • C AXIS that allows to turn and 360° angle drive heads with rotation regulation in automatic by numerical control • 0 to 20.000 rpm • Tool magazine 12 positions MULTI-BORING UNIT: • 7 independent spindles for vertical boring in X direction • 5 independent spindles for vertical boring in Y direction • High revolution speed: 9.000 rpm Iisdpfx Ajzc E A Ieidof EDGE BANDING UNIT: • Automatic device to apply the edge into straight profiles of shaped panels • Applicable banding material in coils: thin edge and PVC up to 3 mm • Independent unit to edge band shaped panels. It's installed on the main frame of the machine - hot-melt glue pot and premelter - spreading roller to regulate the quantity of apllied glue - edge pression roller • Lamp zone to pre-heat the side of the panel • Multiple magazine for edge coils with 2 positions, to automatically change the edge type • Top and bottom edge trimming head-unit • Top and bottom edge scraping head-unit CONTROL OF THE MACHINE: • IMATRONIC • Software IMAWOP • Command board installed on a separated electrical cabinet to control the machine PROTECTION ENCLOSURE OF THE WORKING UNITS PROTECTION FENCES SECURITY CARPETS SECURITY NORME CE MARK

Condition: excellent (used), Year of construction: 2008, Used CNC machining center Manufacturer: IMA Model: BIMA 300 125/430 Year of manufacture: 2008 4-axis CNC machining center with console table 8 supports in X, manually adjustable, 3 vacuum cups per console, vacuum pump 90 m³/h vacuum connection for templates LED display for vacuum cup position indication Working area X: 200 – 4300 mm Working area Y: 0 – 1400 mm (milling/drilling), Working area Z: 12 – 125 mm (clearance 150 mm) Additional central stop row 14 vertical drilling spindles + 6 horizontal horizontal drilling and grooving saw unit, swiveling 90° Milling spindle 7.5 kW up to 18,000 rpm with C-axis 360° interpolation, liquid circulation cooling – 18-position tool changer mounted on the Y-support Edge banding unit VT 100, four-sided/all-around – rotation range 740 degrees with 2-position roller magazine, automatic granule feed Adapter units: – fixed saw 90° – 4-spindle angle head Control ICOS open 231 with 17″ TFT UPS ImaWop 10.0 incl. MDE and production list software Safety fence on right side and foot mats at front; Rear: requires wall installation or separate safeguarding Iisdpfx Asy Nzw Njidsf

Condition: ready for operation (used), Year of construction: 2005, Carton width range: 28mm-92mm, carton height range: 14mm-60mm, carton length range: 55mm-190mm, max. total cross-section (width + height): 140mm, packaging capacity: 120 cartons/min, machine dimensions X/Y/Z: approx. 2550mm/1250mm/1800mm, weight: approx. 1200kg. Documentation available. On-site inspection is possible. Iodjv Suhbepfx Aidjif

Condition: used, Year of construction: 2008, - Machining area 4300 x 1250 mm - 8 pcs. workpiece supports - Main spindle 7.5 Kw / 11kw - Vertical drilling unit - Horizontal drilling unit - Dado cutter - Tool changer for 18 positions CNC machining center Manufacturer: IMA Type: Bima 300 Year of manufacture: 2008 Technical data - Machining area 4300 x 1250 mm Iodpozux Tiefx Aidoif - 8 pcs. workpiece supports - 1x Main spindle 7.5 Kw / 11kw (S1 / S6) HSK F63 1500 - 18000 rpm - Horizontal drilling unit - Vertical drilling unit - Dado cutter - 2x Vacuum pump, each 90 m³/h - Safety mats - IMA Wop software + office license

Condition: ready for operation (used), Year of construction: 1997, A 1.5-times linked IMA edge processing line with automatic Venjakob workpiece transfer is offered. Max. working width: 2500mm, transfer angle: 90°, distance between the workpiece edges: 6000mm. Control system: Siemens S5. Including peripheral equipment and conveying system. Required installation space: approx. 250-300m², overall dimensions X/Y: approx. 19000mm/13600mm. IMA. Operator PC: renewed in 2018. Inspection possible by appointment. Iedpfxjzh Nh Ro Aidsif

Condition: used, machine/vehicle number: 008269, Position 1: Panel Feeding and Loading IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 2: Panel Turning Device IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 3: Double Sided Squaring/Edgebanding Machines IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Iisdpfox A Hggex Aidsf Position 4: Panel Turning Device IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 5: Panel Stacking and Offloading IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3

Year of construction: 1999, condition: good (used), IMA Compact MFA / F / 5212 edge banding machine Year of manufacture: 1999 Serial number: 06601 Max. edge banding thickness: 12 mm Min. workpiece thickness: 10 mm Max. thickness of edging material roll: 3 mm Feed speed: 12 m/min Adjustment of the joint guide rail: manual Heating time: 10 min Jointing unit: Yes, with 2 milling units Automatic edging roll magazine: Yes Trimming shears up to: 0.2 - 3.0 mm Iiodpfx Aioia Naqsdsf Solid edge magazine: Yes Preheating of the panel by heating radiator Automatic glue application with glue tank and granulate Cutting saw angle adjustment via program Multi-function unit Rounding unit/corner copying, 2 motors Profile trimming blade Flat trimming blade Buffing unit Unit display, mechanical digital display Control type via control panel Operation: selector switch/push buttons Protective hood Weight approx. 2500 kg Dimensions L x W x H: 6500 x 1000 x 1600 mm CE marked Technical specifications subject to change
