Tool presetter

WEINIG

Condition: used, Year of construction: 2009, machine/vehicle number: 113680, functionality: limited functionality, working width: 230 mm, spindle diameter: 40 mm, spindle speed (max.): 6,000 rpm, working height: 120 mm, TECHNICAL DETAILS Working width: 20–230 mm Working height: 8–120 mm Infeed table length: 1,950 mm Feed rate: 6–12 m/min Number of spindles: 5 Spindle diameter: 40 mm Spindle speed: 6,000 rpm Max. tool diameter vertical spindle: 232 mm Max. tool diameter horizontal spindle (except for the first spindle): 200 mm Spindle arrangement and power 1. Spindle, bottom: 5.5 kW 2. Spindle, left: 7.5 kW 3. Spindle, right: 7.5 kW 4. Spindle, top: 11 kW 5. Spindle, bottom: 5.5 kW MACHINE DETAILS Connection voltage: 400 V Dedpfozrmptjx Aanokr Connection power: 32 kW Fuse rating: 64 A Dimensions & Weight Dimensions (L x W x H): 4,000 x 1,400 x 1,350 mm Weight: 2,500 kg EQUIPMENT 5-spindle version Four-sided machining Infeed table CE marking Note: The 5th spindle is defective.

Condition: used, Year of construction: 1999, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 6 with NC spindles ----- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included; positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ----- > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Item 3: 1st profiling spindle (climb-cut and conventional-cut capable) ----- > Position: vertical right > Number of tools: 1 pc. Dodpfx Aozdk Hyjanjkr > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 11 kW Item 5: Horizontal profile milling unit (top) ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed: 5,850 rpm > Max. tool cutting circle: 130 mm > Axial adjustment range: 2 positions > Radial adjustment range: 2 positions Item 6: 3. Profiling spindle (hardware groove spindle) ----- > Position: vertical, right > Tool clamping length: 160 mm > Axial adjustment range: 3 positions > Radial adjustment range: 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool cutting circle: 210 mm > Motor power: 3.0 kW Additional features ----- > Network-ready (online capability) > Rebating unit for tear-free rebating > Double-part processing package > Return conveyor system for one-man operation: slat conveyor > Screen-based control system > Angled window processing unit > Electronic angle display for angled windows > Industrial PC, PC control/NEXUS > Excluding machining tools ----- Price of the above-mentioned machine available on request! ----- Optional extra: EUR 6,500.00 Note regarding used tools: We currently have used "Gold" series tools in stock (Stock No. #2790) Window tools (Gold series) for IV78 Wood and IV78 Wood/Aluminum Previously used on a Weinig Unicontrol 10; a jointing cutter is additionally required for use on a Unicontrol 6. Tool set for fixed-stroke or CNC spindle machines (80 mm and 95 mm stroke), (Tool set prepared for IV92 where technically feasible) Wood-aluminum tool set for fix...

Condition: used, Tenoning spindle 1 St. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig PC-Nexus Weinig Unicontrol 11 Window System with Extensive Tooling ----- Optionally available (at additional cost): - Weinig Univar 6 Rebating Machine (Price upon request!) - Götzinger PowerDrill Drilling and Milling Center for Windows and Doors (Price upon request) Manufacturer's Technical Description: ----- Item 1: Weinig Unicontrol 11 Window System ----- Includes existing tooling sets: - IV 67 (Wood and Wood-Aluminum) - IV 77 (Wood and Wood-Aluminum) - IV 90 (Wood) Cross-cut Saw ----- With laser alignment light; motor power: 3 kW; spindle diameter: 40 mm; electronically variable spindle speed with brake: 3,000–6,000 rpm. Max. tool cutting circle: 400 mm Axial adjustment: 150 mm via NC axis Radial adjustment: pneumatic, to 8 positions for top edge rounding Horizontal Bottom Rounding Unit ----- Motor with brake: 1.5 kW; Spindle diameter: 20 mm; Clamping length: 25 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Axial adjustment travel: mechanically coupled with cut-off saw Radial adjustment travel: pneumatically controlled Tenoning and Slotting Spindle ----- With hydraulically clamped outboard bearing Motor power with brake: 15 kW Spindle diameter: 50 mm Spindle speed: 2,800 rpm Dodpoy T R Tujfx Aanskr Max. tool cutting circle: 400 mm Tool clamping length: 640 mm Axial adjustment travel: NC axis Home position below table: 5–10 mm Radial adjustment travel: fixed 1st Profiling Spindle (Climb and Conventional Milling) ----- Motor power with brake: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Min. tool cutting circle: 140 mm; Max. tool cutting circle: 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position below table: 5–10 mm 2 feed rollers opposite the spindle; axial adjustment pneumatically controlled (8 positions) Horizontal Top Profiling Unit ----- Motor power with brake: 3.7 kW Spindle diameter: 40 mm Clamping length: 40 mm Spindle speed: 9,000 rpm Max. tool cutting circle: 130 mm Adjustment: pneumatic, to 8 positions (axial and...) radial 2. Profile Spindle ----- Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6,000 rpm Tool cutting circle: min. 140 mm, max. 232 mm Tool clamping length: 400 mm (with outboard bearing) Axial adjustment travel: 350 mm (NC axis) Radial adjustment travel: NC axis Home position (below table): 5–10 mm Indexed guide fence with muntin support strip 2 feed rollers (opposite the spindle); axially pneumatically controlled (8 positions) Vertical Profile Milling Unit (Right-hand side, at machine end) ----- Motor power (with brake): 3.7 kW Spindle diameter: 40 mm Clamping length: 160 mm Spindle speed: 5,850 rpm Tool cutting circle: min. 112 mm, max. 210 mm Adjustment: Pneumatic (8 positions—axial a...

Condition: excellent (used), CATALOGUE NUMBER 6946 TECHNICAL DATA - Max. working width: 210mm - Max. working thickness: 120mm - Number of spindles: 2 pcs - Spindle diameter: 50mm From above: - 3 infeed feed rollers, rubber, smooth, including 2 double rollers - 2 outfeed feed rollers, rubber, including 1 double roller - Cutterheads on supports - Cutterhead up/down adjustment - Electric adjustment of top cutterhead height - Electric setting of planing thickness - Spindles equipped with brake - Main motor: 2×5.5kW - Stepless feed speed adjustment - Feed motor: 3kW - Feed via Kardana shafts - Extraction nozzle diameter: 2x160mm - Dimensions (L/W/H): 2350x1780x1950mm - Weight: 1882kg – Made in Germany – Jointers for sharpening knives on the cutterhead – 2 Hydro cutterheads included – Not repainted Dksdpfszr I Rlex Aansr – Very good condition, used planer Net price: 33,900 PLN Net price: 8,070 EUR Net price calculated at 4.2 PLN/EUR (price may change with significant exchange rate fluctuations)

Condition: used, Year of construction: 1986, total width: 6,030 mm, total height: 1,500 mm, Colour: Green Dimensions (LxBxH): 175 x 603 x 150 cm Four-sided planer Weinig Profimat 22N Serial number: 226 - 742 400v, 40Amp. Max working width 220mm Max working height 120mm Input table length 1950mm Throughput speed 4-20 m/min Spindle diameter 40mm Speed spindles 6000 U/min 1st spindle, bottom: kW 2nd & 3rd spindle, left & right: kW 4th spindle, top: kW Dkedpfownhh Ssx Aaner Dimensions; 3400x1500x1400mm, Own weight 1600 kg - Year: 1986 - Documentation available: No - CE certificate present: No - Serial number: 226 - 742 - Number of spindles [pcs.]: 4 - └ Spindle 1: - - Spindle type: Bottom - - Spindle diameter [mm]: 40 - - Max. planing block diameter [mm]: 140 - └ Spindle 2: - - Spindle type: Right - - Spindle diameter [mm]: 40 - - Max. planing block diameter [mm]: 120 - - Tool present: Yes - └ Spindle 3: - - Spindle type: Left - - Spindle diameter [mm]: 40 - - Max. planing block diameter [mm]: 120 - - Tool present: Yes - └ Spindle 4: - - Spindle type: Top - - Spindle diameter [mm]: 40 - - Max. planing block diameter [mm]: 120 - - Tool present: Yes - Min. planing width [mm]: 50 - Max. planing width [mm]: 230 - Max. planing height [mm]: 120 - Feed table length [mm]: 1970 - Feed roller diameter [mm]: 140 - Tool type: Standard - Conveyor drive: Cardan drive - Diameter extraction nozzle [mm]: 135 - Voltage [V]: 400 - Current consumption [A]: 40 - Fuse [A]: 50 - Transport dimensions: 1750mm x 6032mm x 1500mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: ready for operation (used), Year of construction: 2018, Optimizing Cross-Cut Saw manufactured in 2018. This WEINIG DIMTER Opticut S90 features a saw blade diameter of 500 mm and a maximum cutting height of 120 mm. It accommodates input lengths from 400 to 6,300 mm and widths from 20 to 300 mm. If you are looking to get high-quality cutting capabilities, consider the WEINIG DIMTER Opticut S90 machine we have for sale. Contact us for further details. Dksdpfx Aaoylmmmoner • Saw blade • Diameter: 500 mm • Bore: 30 mm • Adjustable saw blade speed: 40–100% via frequency converter • Workpiece capacity • Input length (min/max): 400–6,300 mm • Width (min/max): 20–300 mm • Thickness (min/max): 10–120 mm • Maximum cutting height: 120 mm • Minimum cross-section: 20 x 10 mm • Maximum cross-section 1: 215 x 120 mm • Maximum cross-section 2: 300 x 40 mm • Permissible timber curvature: max 2 mm/m or 8 mm over entire length • Table inclination: 10° • Motion and accuracy • Positioning speed (reverse stroke): max approx. 180 m/min • Positioning speed (forward stroke): max approx. 60 m/min • Positioning accuracy: +/- 0.1 mm • Motors and power • Pusher motor power: 5.1 kW • Saw motor power: 7.5 kW • Total electrical load: approx. 15 kW • Control and interface • Control unit: OptiCom Pro with 18.5" touch screen • Screen resolution: 1366 x 768 pixels • Protection class (front): IP65 • Interface: USB port and Ethernet network connection • Data format: CSV (ASCII) for import/export • Utilities and environment • Voltage: 400 V / 50 Hz • Operating pressure: 6–8 bar (min.) • Air consumption: approx. 250 NL/min • Extraction connection: diameter 125 mm • Required extraction performance: speed approx. 30 m/s; volume approx. 1,300 m³/h • Noise level (idling): ≤ 85 dBA

Condition: used, Raimann KR 450 multi-blade saw Track width: 450 mm Dksdpfx Aaezr Epfjner Cutting height: 120 mm Material discharge chute with side discharge

Condition: used, total length: 2,300 mm, total width: 1,600 mm, total height: 1,450 mm, Colour: Blue Weight: 2.000 kg - Documentation available: No - CE certificate present: No - Serial number: 19031 - Main motor power [kW]: 15.0 - Arbor hole saw blade diameter [mm]: 40 - Min. saw blade diameter [mm]: 120 - Max. distance between saw blades [mm]: 2450 - Max. cutting width [mm]: 2450 - Max. cutting height [mm]: 75 - Table length [mm]: 1700 - Table width [mm]: 1000 - Conveyor motor power [kW]: 2.2 - Conveyor width [mm]: 2450 Djdpezrza Hofx Aanekr - Voltage [V]: 380 - Fuse [A]: 63 - Power [kW]: 18.0 - Transport dimensions: 2300mm x 1600mm x 1450mm (l x w x h) - Transport weight [kg]: 2000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 1998, total height: 1,500 mm, total length: 1,200 mm, total width: 110 mm, Colour: Cream Dodpfozry Ivex Aanskr Empty weight: 750 kg Price: On request - Year: 1998 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 84915 - Control: Conventional - Transport dimensions: 1200mm x 110mm x 1500mm (l x w x h) - Transport weight [kg]: 750kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Grinding disc for the Weinig Rondamat or similar sharpening machines Technical data: - Manufacturer’s No.: 930 Condition: As new Dedpfezry A Hsx Aanjkr - Grit size: D 151 - Diameter: 200 mm
