CNC turning and milling center

Traub TNC65

Condition: used, Year of construction: 1996, max. bar material dia. 65 mm max. swing diameter 175 mm max. bar length 3.000 mm control System TX 8F travel -x axis 140 mm travel -z axis 520 mm CNC lathe | TRAUB - TNC 42/65 DG equipped with bar loader. Iedpfx Ahsxbtq Nowetc The machine is in a well-maintained condition. The machine videos from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TNC65 | TNC-65 |TNC 42-65 DG | TNC 42/65DG

Condition: used, Year of construction: 2003, max. bar material dia. 65 mm max. bar length 3.000 mm control System TX 8H Itedpexbtp Eofx Ahwsc CNC lathe | TRAUB - TNC 42/65 equipped with bar loader . The machine is in a well-maintained condition. The machine videos from the production plant will be shared on request. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TNC65 | TNC-65 |TNC 42-65 | TNC 42/65

Year of construction: 1996, condition: ready for operation (used), Turning length: 450mm, spindle clearance: 65mm, speed: 4000rpm, main spindle/counter spindle power: 18.5kW/11kW, tool positions: 10, driven tools: 10, hydraulic capacity: 150l, hydraulic pressure: 60bar, connected load: 39kW. Rapid traverse X1/X2: 15m/min, feed force: 5000N, feed path: 140mm. Rapid traverse Z1/Z2: 30m/min, feed force: 8000N, feed path: 450mm. Rapid traverse Y1: 6m/min, feed force: 8000N, feed path: +/-35mm. Machine dimensions X/Y/Z: approx. 4150mm/2000mm/1800mm, weight: approx. 4750kg, control: Traub System TX 8F, operating hours: 78825h. Documentation available. On-site inspection is possible. Isdpfx Aov Scrhjhwstc

Year of construction: 2015, condition: ready for operation (used), A CNC double-spindle lathe Traub overhauled in 2025 is available. Turning length: 450mm, spindle clearance: 65mm, speed: 4000rpm, main spindle/counter spindle power: 18.5kW/11kW, tool positions: 10, driven tools: 10, hydraulic capacity: 150l, hydraulic pressure: 60bar, connected load: 39kW. Rapid traverse X1/X2: 15m/min, feed force: 5000N, feed path: 140mm. Rapid traverse Z1/Z2: 30m/min, feed force: 8000N, feed path: 450mm. Rapid traverse Y1: 6m/min, feed force: 8000N, feed path: +/-35mm. Machine dimensions X/Y/Z: approx. 4150mm/2000mm/1800mm, weight: approx. 4750kg, control: Traub System TX 8F, operating hours: 12938h. Including chip conveyor and bar loader LNS Quick Load. Documentation available. On-site inspection is possible. Itjdpfx Ahjv Scrbowjc

Condition: good (used), Year of construction: 1996, CNC turning center TRAUB Type:TNC65 DG Year 1996 Control TRAUB TX8F Itsdpfxou Eug Ij Ahwoc With lots of accessories.

Condition: used, Year of construction: 1995, Traub Type TNC 42/65 DG CNC Lathe with Traub System TX8F Control,Twin Spindle with Collet Chucks, (2) x 10 Station Turrets, Swarf Conveyor. S/No. 251 (1995). Country of Origin: Germany Location: These lots are located in Leamington Spa, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described. Ijdsyfgmmspfx Ahwjtc

Condition: good (used), Year of construction: 2001, Ref. -No.: 10551 Manufacturer: TRAUB Type: TNC 42/65 Year of construction: 2001 Type of control: CNC Control: TRAUB TX Storage location: Halberstadt Country of origin: Germany Machine-No.: 93XXXXX Turning Speeds: 8000 RPM X stroke: 450 mm Turning Length: 450 mm Spindle Speeds: 4000 RPM Clamping Diameter: 42 / 65 mm Spindle Diameter In Front Bearing: 110 mm Tool Taper: 14 Max. Torque: 170 / 230 Nm Rapid Travel Speed X-Axis: 15 m / min Rapid Travel Speed Y-Axis: 6 m / min Rapid Travel Speed Z-Axis: 30 m / min Dimensions Of The Machine (Lxwxh): 4354 x 2076 x 1917 m Chisel slide cross section turning and milling support: 16 x16 ( 20 x20 ) mm Pressure: 70 bar hydraulic tank: 70 L. Total Power Requirement: 39 kVA Weight Of The Machine Ca.: 5,2 t Feed force X-axis at 100% duty cycle: 5000 N Feed path X-axis: 140 mm Iodjx Sw Icopfx Ahwetc Z-axis feed path: 450 mm Y-axis feed path: 35 mm Ball screw Z-axis (Ø x pitch): 32 x 10 mm Ball screw X-axis (Ø x pitch): 32 x 5 mm Ball screw Y-axis (Ø x pitch): 25 x 5 mm Further information: - Revolver 1 Number of branches 10 - Revolver 2 Number of branches 14 - Hecowpkfie Htlx Tfefh - Powered tools Yes

Condition: ready for operation (used), Year of construction: 1996, operating hours: 38,433 h, functionality: fully functional, machine/vehicle number: 489, bar diameter (max.): 65 mm, controller model: TRAUB TX8F, bar length: 3,000 mm, number of axes: 7, Equipment: bar feeder, chip conveyor, CNC automatic lathe with seven axes as well as main and counter spindle! Isdpfsw Uiktsx Ahwstc TECHNICAL DETAILS Axes and spindles Number of axes: 7 Main spindle: present Counter spindle: present Number of turrets: 2 C-axes: 2 Y-axis: 1 Control: TRAUB TX8F MACHINE DETAILS Operating hours: 38,433 hours EQUIPMENT Bar loading magazine Stamag DN61 (bar diameter 65 mm, bar length 3 m) Coolant system Parts discharge Chip conveyor Air filter

Condition: reconditioned (used), Year of construction: 2005, functionality: fully functional, Traub CNC lathe TNC65DGY, TX8I, year 2005, serial no. 1130 Description Y-axis on S1, V-axis, 2x C-axis, 2x rotary tool drive, 2 VDI30 turrets, Hainbuch BZI65 on main and counter spindle, parts gripper, Iemca Master 880MP-E loading magazine, Condition Very well maintained, good condition, serviced. Itedpfxowi I Eys Ahwoc Machine geometry has been checked and corrected/adjusted. Machine can be viewed under power – video available. 6-month warranty on main components as follows: Spindle bearings, ball screws, linear guides, clamping cylinders. The warranty expressly applies only to spare parts, not to downtime, labor, or travel time. The warranty expressly does not apply to parts other than those listed above, e.g., wear parts, electrical, electronic, hydraulic, etc.

Condition: good (used), Year of construction: 2001, functionality: fully functional, Traub CNC Lathe Isdpswi Izhofx Ahwetc TNC65DGY, TX8H, 2001 • 2x 10-station turrets with VDI30 rotating tool drive • C-axis on main/counter spindle • Y-axis on turret 1 • Hainbuch BZI65 on main/counter spindle Hollow clamping cylinder • Chip conveyor, coolant tank • Spare parts list, circuit diagram, ATC optics Very good condition. Can be viewed under power. The machine's geometry has been checked and corrected/adjusted.
