Center Lathe

Meuser DLZ 400x1000

Condition: new, Year of construction: 2025, 0330 mm 210 mm 1000 mm Fsdowp Tq Ujpfx Afuopd 167 mm 40 mm 2,2 kW

Condition: new, Center length ----- 1000 mm Center height ----- 230 mm Turning diameter ----- 460 mm Passage of main spindle ----- 58 mm Bed width ----- 300 mm Spindle speed ----- 25-2000 rpm Motor ----- 5.5 KW Weight ----- 1750 kg INCLUDING * 3-axis digital readout brand SINO * Quick-change chisel holder type Multifix TOOB2 with 4 attachments Fpjdjk Iug Tjpfx Afujd * Self-centering 3 chuck 250 mm * Independent 4 chuck 320 mm * chuck 350 mm * Fixed and moving grips * LED work light and cooling system * Electric brake (CE) * Foot brake * Box with various tools

Condition: good (used), Year of construction: 2010, Conventional lathe, center high 254 mm, between centers 1000 mm, bore Ø 80 mm, 12 speed 30 - 2200 rpm, motor 5,5 kw, camlock 6'', dimensions 230x115x165 cm, weight ca. 1750 kgs; equipement: DRO on 2 axis, coolant device, 3-jaws chuck Ø 250 mm, rotating pin, tool post MULTIFIX C with toolholders, steady and following rest Fpjdetv Iy Eepfx Afuod

Condition: new, Year of construction: 2025, 0350 mm Fpodpfoxxb Azsx Afued 196 mm 0650 mm 170 mm 42 mm 7,5 kW

Condition: new, Year of construction: 2025, turning diameter over cross slide: 270 mm, spindle bore: 58 mm, turning diameter: 460 mm, center height: 230 mm, center width: 1,060 mm, quill stroke: 130 mm, quill diameter: 60 mm, total length: 2,280 mm, total width: 1,150 mm, total height: 1,650 mm, Turning diameter in gap: 690 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 25 rpm, overall weight: 1,910 kg, quill mount: MK 4, metric thread pitch (max.): 14 mm, tailstock quill diameter: 60 mm, Optimum TH 4610D center lathe with DPA 31 Plus digital position indicator and quick-change tool post Hardened and ground Z-axis guideway Guaranteed spindle nose concentricity ≤ 0.015 mm Shafts, gears, and main spindle run in an oil bath Lead screw cover Precisely machined slide All guideways adjustable via V-ledges Mechanical longitudinal feed shutoff of the bed slide with four adjustable eccentrics Right/left rotation on the bed slide can be switched via a switch spindle Central lubrication in the bed slide Top slide adjustment range ± 90° Smooth-running, hardened, and ground gears mounted on two adjustable precision tapered roller bearings Switch with life cycle calculation, tested according to EN ISO 13849 Large chip guard with integrated LED Machine lamp Handwheels with adjustable fine scales of 0.04 / 0.02 mm Safety handwheels with disengagement function according to EN23125 on the X and Z axes Quick-action feed gears in a closed design, gears and shafts hardened and ground, running in an oil bath on precision bearings Adjustable thread dial scale Tailstock for taper turning adjustable ± 10 mm Tailstock sleeve and handwheel with adjustable fine scale of 0.025 mm Quick, easy, and tool-free adjustment of the tailstock using a clamping lever Cable routing via energy chain Heavily ribbed prismatic bed, induction-hardened and precision-ground from gray cast iron Coolant system with separate coolant tank with level indicator and oil separator; Easy and complete emptying and cleaning according to DIN standards Emergency stop device with foot operation Scope of delivery: Fixed steady rest, opening Ø 25 - Ø 178 mm Revolving steady rest, opening Ø 19 - Ø 114 mm LED machine light Adapter MK6-MK4 Non-revolving center MK4 Non-revolving, but temperature-resistant center MK4 Quick-change tool holder SWH 5-B Tool holder 25 x 120 Type D for 20 mm square chisel Thread gauge Set of interchangeable gears Gears for thread gauge (metric) Initial machine filling with high-quality oil Operating tools Options available upon request; we will be happy to advise you: - Three-jaw chuck / four-jaw chuck - Steel reamer / turning tool - Mounting elements - Commissioning Do you need a different machine? Please contact us! Fodpfjwaaf Hjx Afujpd
