Turn-Mill Centre

Mazak INTEGREX 200 SY

Condition: used, Year of construction: 2000, Turning length 1000 mm Max. swing 640 mm dia. Max. turning 540 mm dia. Spindle bore 51 mm Max. Spindle speeds 4000 rpm (same for subspindle) Max. spindle speeds on milling spindle 6000 rpm No. of stations in tool changer 40 pcs. Control: PC Fusion 640 MT Fedpfx Aop Ui N Hjc Hepp Equipped with: Gantry loader 10 pcs. tool holders

Condition: excellent (used), functionality: fully functional, turning length: 530 mm, turning diameter over cross slide: 620 mm, turning diameter: 260 mm, spindle motor power: 15,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 3,500 rpm, spindle bore: 80 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 590 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, Mori Seiki SL-25Y/500 CNC LATHE With 1.5m LNS bar feeder Control: Mori Seiki MF-T6 Tool holders: (2) Radial live tolls (2) Axial live tools (4) inside tool holders (4) outside tool holders Swing over bed: 815 mm (32.1″) Swing over cross slide: 620 mm (24.4″) Distance between centers: 620 mm (24.4″) Fpjdpfx Aew Ett Ijc Hsp Max. turning diameter: 260 mm (10.2″) Max. turning length: 530 mm (20.9″) X-axis travel: 195 mm +130 +65 (7.7″ + 5.1″ + 2.6″) Z-axis travel: 590 mm (23.2″) Y-axis travel: 100 mm ±50 (3.9″ ± 2.0″) Spindle speed range: 35 – 3,500 RPM Spindle nose: JIS A-8 Through spindle hole diameter: 80 mm (3.1″) Spindle bearing inner diameter: 130 mm (5.1″) Number of tool stations: 12 Shank height for square tool: 25 mm (1.0″) Shank diameter for boring bar: 50 mm (2.0″) Turret indexing time: 0.25 sec Rotary tool spindle speed: 100 – 2,000 RPM Rotary tool cutting capability: End mill max Ø20 mm, Face mill max Ø50 mm, Tap max M12 Rapid traverse rate:   X-axis: 12,000 mm/min (472.4 IPM)   Z-axis: 15,000 mm/min (590.6 IPM)   Y-axis: 10,000 mm/min (393.7 IPM) Feed per revolution:   X-axis: 0.001 – 342 mm/rev   Z-axis: 0.001 – 342 mm/rev   Y-axis: 0.001 – 500 mm/rev Jog feedrate: 6,000 mm/min (236.2 IPM) Tailstock travel: 403 mm (15.9″) Tailstock spindle diameter: 110 mm (4.3″) Tailstock spindle travel: 100 mm (3.9″) Tailstock taper: MT-5 (Live center) Spindle motor power (30 min/cont): 15/11 kW (20/15 HP) Rotary tool spindle motor: 3.7/2.2 kW (5/3 HP) Electrical power supply: 44 kVA Coolant tank capacity: 100 liters (26.4 gal) Machine height: 2,060 mm (81.1″) Floor space: 3,183 × 1,799 mm (125.3″ × 70.8″) Machine weight: 5,400 kg (11,900 lbs)

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 157626, Manufacturer: Mazak Model: Integrex 200-2SY Controller: Mazatrol PC Fusion CNC 640 Fedpfx Acsvlxf De Hspp Robot NOT included Max. Machining diameter: 540 mm Max. Machining length: 1018 mm Spindlebore: 51 mm Spindlepower: 22 kW 5000 rpm Travel: X = 530 mm Z = 1065 mm Machine weight: 7800 kg. Machine dimensions: L=5200 x W=2500 x H=2750 mm

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, turning diameter over cross slide: 1,800 mm, turning diameter: 2,000 mm, turning length: 8,000 mm, total length: 12,000 mm, overall weight: 29,500 kg, Machine can be inspected under power Fpsdpewv S D Hjfx Ac Hsp

Condition: excellent (used), Year of construction: 2014, operating hours: 2,315 h, functionality: fully functional, turning length: 500 mm, turning diameter over cross slide: 400 mm, turning diameter: 320 mm, spindle motor power: 15,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 50,000 rpm, spindle bore: 75 mm, travel distance Z-axis: 580 mm, rapid traverse X-axis: 33 m/min, rapid traverse Z-axis: 33 m/min, total height: 1,700 mm, total length: 2,630 mm, chuck outer diameter: 210 mm, total width: 1,700 mm, bar diameter (max.): 66 mm, quill stroke: 500 mm, swing diameter over cross slide: 660 mm, spindle nose: 6, overall weight: 4,500 kg, MAZAK QUICK TURN 200 Smart Operating hours: Automatic cycle: 2,330 hours Condition: Very good condition, regularly serviced and meticulously maintained! Capacity & Working Area Max. swing diameter: D 660 mm Max. turning diameter: D 350 mm Max. bar capacity: D 66 mm Max. machining length: 520 mm Main Spindle Max. spindle speed: 5,000 rpm Spindle nose: JIS A2-6 Rated power (40% duty cycle): 15 kW Max. torque: 233 Nm Turret Number of tool stations: 12 Tool cross-section: 25 mm (external), 40 mm (internal) Feed Axes Rapid traverse (X / Z): 30 / 33 m/min Travel (X / Z): 180 mm / 550 mm Tailstock Mount: MT NC axis, pressure via M-codes Dimensions & Weight Machine dimensions (L x W x H): 2,630 x 1,710 x 1,700 mm Weight: 4,500 kg (without chip conveyor and coolant) Chuck: Kitagawa BB208 with through-hole Chip Management Mayfran hinged belt chip conveyor Coolant pump 8 bar & chip flushing Fjdpfewzkzzsx Ac Hspp General Specification: - SD MEMORY I/F (1 port) + USB MEMORY I/F (1 port) - Mazak standard colour - NC-controlled tailstock - Tailstock pressure adjustment - Tailstock with fixed live center mount - Operator door with interlock switch - Double foot switch - Fully enclosed work area - Work area lighting - Safety features compliant with global standards - Complete coolant system - Chuck condition monitoring - Automatic Tool Eye - 10.4" color screen - EIA/ISO package - LAN interface - Standard tool set

Condition: used, functionality: fully functional, turning diameter over cross slide: 1,100 mm, spindle bore: 220 mm, turning diameter: 1,500 mm, turning length: 7,000 mm, Tacchi FTC Lathe with 7,000 mm between centers Description Manufacturer: Tacchi Model: FTC Capacities: Distance between centers: 7,000 mm Swing over bed: 1,500 mm Swing over cross slide: 1,100 mm Swing over gap: 1,850 mm Spindle bore diameter: 220 mm Speeds: 8 speeds from 24 to 485 rpm Rapid feeds: Rapid traverse on both carriage axes Fjdpfjwulimsx Ac Hepp Equipment: 3 fixed steadies and 1 movable steady 4-jaw chuck Ø 1,000 mm mounted on the lathe Additional heavy-duty 4-jaw chuck Ø 1,200 mm General condition: Lathe in good condition

Condition: used, Year of construction: 2001, functionality: fully functional, Japanese-built 4-axis CNC lathe for secondary machining, featuring C axis, Y axis, and driven tools. Installed in 2002 and compliant with CE standards, with the following main specifications: Turning diameter: 755 mm Workable diameter: 390 mm Workable length: 655 mm 12-position driven turret Y axis travel: +/- 60 mm C axis Spindle nose: A2-8 Kitagawa B-210, 250 mm Fsdpsxf Iygofx Ac Hspp Spindle speed: 3,500 rpm Spindle motor: 18.5 kW Driven tool motors: 5.5 kW Driven tool speed: 4,000 rpm Bar capacity: 73 mm Tailstock: MT5 Rapid traverse speed: 18 and 24 m/min on X and Z axes Weight: 5,800 kg Complete with: - Hydraulic programmable tailstock - Box ways - Chip conveyor - Headstock oil cooling - Dual foot pedal for main chuck and tailstock open/close - Set of fixed tool holders - Set of driven tool holders - Complete manual set - CE certificate

Condition: ready for operation (used), controller model: Num 1040, swing diameter over cross slide: 7,500 mm, Robuuste draaibank met 4 geharde lineaire geleidingen Maximaal werkstukgewicht: 60 ton Hydraulisch contrapunt = automatische compensatie Dwarsslede voorzien van twee CNC gestuurde gereedschapshouders Siemens aandrijvingen en motoren Heidenhain-linialen en encoders Super Lathe-principe/licentie van Binns Machinery (VS). De ultieme prestatie voor zware draaibanken, bedoeld voor staalfabrieken, walsgieterijen en smederijen, voor de productie van producten zoals turbinerotoren, grote assen en staafproductie. Meest opvallende verschillen met een normale draaibank: veel breder bed = zeer hoge stijfheid = geen trillingen meer zwaar en omvangrijk vervoer ook voor stijfheidsdoeleinden zware werkstukken kunnen tussen de centers worden geplaatst het totale gewicht van de roldraaibank is erg hoog Swing over bed: 2000 mm Swing over cross-slide: 1700 mm Power on the spindle: 110 kW Fpjdpfx Ajwaivbsc Hep Number of speeds: 0,7 > 70 rpm

Condition: ready for operation (used), controller model: CNC, empty load weight: 70,000 kg, total length: 10,000 mm, total width: 3,230 mm, total height: 1,900 mm, swing diameter over cross slide: 6,000 mm, Geharde draaibank met 4 geharde lineaire geleidingen Gewicht van het werkstuk tussen de centers: 20 ton Siemens aandrijvingen en motoren Heidenhain-linialen en encoders Super Lathe-principe/licentie van Binns Machinery (VS). De ultieme prestaties voor zware draaibanken, bedoeld voor staalfabrieken, walsgieterijen en smederijen voor de productie van producten zoals turbinerotoren, grote assen en staafproductie. Meest opvallende verschillen met een normale draaibank: veel breder bed = zeer hoge stijfheid = geen trillingen meer zwaar en omvangrijk vervoer ook voor stijfheidsdoeleinden zware werkstukken kunnen tussen de centers worden geplaatst het totale gewicht van de rollenbank is erg hoog Swing over bed: 1200 mm Fpsdpfx Aswaivhsc Hop Swing over cross-slide: 850 mm Power on the spindle: 165 kW Number of speeds: 3 > 320 rpm

Condition: used, Technical details: turning diameter over bed: 1040 mm turning diameter over support: 720 mm centre distance: 5400 mm center height over bed: 540 mm control: Siemens 828D CNC mit shop turn turning dia. in gap: 1300 mm length of gap: 640 mm spindle bore: 152 mm revolution per minute: 3,5...1000/ 4 steps U/min feed:: x-Achse: 37,24 (m/min) m/min feed:: z-Achse: 21,91 (m/min) m/min force of feed longitudinal: x-Achse: 6,44 (KN) N feed force Z - max.: 17,2 (KN) N tailstock taper MT: MK 6 tailstock quill stroke: 300 mm total power requirement: ca. 30 kW weight of the machine ca.: 14,1 t space requirement approx.:: L:7,7xB:1,7xH:2,0 m CNC Lathe with shop turn Geometric overhaul is in procedure. Equipment: - headstock Morse 6, travel of spindle sleeve 300mm - thread cutting possible (metric thread, inch threads, module threads) - multi quick steel holder swiveable 360° - 3-jaw lathe chuck Ø=630mm - chuck protection - 2 steady rests (Lynettes) (1x fixed + 1x fixed open) - 4 pcs tips for tailstocks - 5 x multi quick change steel holder for chisel - 1 x drill chuck 16mm + 2x drills with MK-cone sleeves 68,5mm & 24,75mm - 1 lot self constructed clamping means Fpodpfxeu Ix Rps Ac Hsp Accessories: - face chuck Ø=800mm (adaptation necessary) - CNC turning with shop turn - your benefits at first glance: - flexible programing via graphic interactive (without DIN/ISO knowledge) or text programming with contour definition and cycle support - user friendly operation through practical set up -and measuring operations, clearly arranged tool managment and 3D-Simulation - increase of productivity via supporting PC-Software for work preparation without machine assignment *
