Surface grinder

Jung JF-520

Condition: like new (used), Year of construction: 2016, Jung Supromatic JF 520 Jung Supromatic JF 520 Surface Grinding Machine, year of manufacture 2016, very good general overhauled original condition. The machine comes from the technical center of a renowned German mechanical engineering company. Technical Data: Year of manufacture: 2000 Technical Data: Clamping area (L x W in mm): 600 x 200 Grindable area (L x W in mm): Dcedpfx Aoy Naw Iobbeg 600 x 250 Max. magnet size mm: 500 x 200 Max. grinding wheel dimensions mm: 225 (250) x 25 x 51 Distance table/spindle center mm: Max. 400 Table longitudinal feed traverse m/min: 1 – 20 Creep feed mm/min: 0 – 500 Grinding spindle drive speed RPM: 800 – 4200 Power kW (with creep feed): 1.6 – 2.2 Machine weight approx.: 2.0 t Accessories and Equipment: Magnet Coolant system Machine feet Grinding wheel About the machine: We are offering a Jung Supromatic JF 520 surface grinding machine, year of manufacture 2016, in very good condition. The machine is, of course, fully operational and has completed approx. 50 operating hours since overhaul. All slides move very smoothly and evenly. Even at high speeds, the Jung runs very quietly. This newer generation of surface grinding machines is very user-friendly and can achieve surfaces with a low Rz value. Take the opportunity to inspect this machine under power on site and see for yourself its condition. Scope of overhaul: Mechanical scope: Mechanical basic overhaul Hydraulics Feed Lubrication Cross and vertical adjustment Grinding spindle Dresser Painting to new-machinery quality Geometric scope: Guideway grinding at the manufacturer’s facility (optional) Scraping of the guideways Column pull, measurement, possible re-scraping/grinding, adjusting with pressure stones, check and pattern guideways Setting of cross-grinding on spindle head Aligning the dresser Regrinding the table and magnet Machine acceptance to manufacturer's inspection checklist Electrical scope: Renewal of complete electrics, all limit switches and buttons Conversion of X-axis from cam switch to contactless limit switches New control cabinet RSF position display (2- or 3-axis readout) Holding force regulation for 24V or EP-magnetic chuck Control system modernization New auxiliary control cabinet (control panel top right) Thyristor control for grinding spindle drive Manual cylindrical dressing with head or side dresser (for Diaform operation)

Condition: good (used), 1 used surface grinding machine Manufacturer: Jung Model: HF 50 Technical specifications: - Z-axis travel: 400mm - X-axis travel: 500mm Dcodexgbb Tepfx Abbjg - Y-axis travel: 200mm - Table length: 720mm - Maximum spindle speed: 4000rpm - Table width: 200mm - Minimum spindle speed: 1000rpm - Transport dimensions: 2300mm x 1500mm x 1700mm (L x W x H) - Transport weight: 2000kg Equipped with: - Digital readout - Diaform device

Condition: good (used), Year of construction: 1983, operating hours: 15,870 h, functionality: fully functional, grinding length: 600 mm, grinding width: 200 mm, table load: 100 kg, overall weight: 2,000 kg, distance stand to spindle center: 500 mm, input voltage: 400 V, Surface grinding machine Jung JF520 Dsdpfx Aeyxcm Robbocg Year of manufacture: 1983 Operating hours: 15,870 h Grinding area: 600x200 mm Distance table to grinding spindle center: 500 mm Max. table load: 100 kg Automatic table cross feed Automatic grinding head height adjustment Rapid traverse Central lubrication Required floor space: 3,100x1,700 mm Weight approx. 2,000 kg - complete documentation - extensive accessories: grinding wheels dresser angle table balancing scale

Condition: reconditioned (used), Year of construction: 1978, functionality: fully functional, machine/vehicle number: 1025, Surface Grinding Machine Jung JF 520 DS No. 1025 with 1 Year Full Warranty - Geometrically overhauled; accuracy according to Jung standard less than 0.003mm - Electrical system tested, fully functional, relevant components replaced - Mechanics overhauled - All wear parts replaced - Color: reseda green; paint condition ok Equipment: Electro-permanent magnet 500x200mm including retrofitted Wagner control unit 756 2-axis digital readout for Y and Z axes Automatic feed for Y and Z axes Spark-out: 0 to infinite Dcjdpfx Asy D I Idebbog Y-axis with zero shutoff via stepper motor Roughing-finishing feed adjustment Manual hand dresser Infinitely variable spindle speed V-constant through wheel wear compensation Paper band filter unit, used, fully functional Max. grinding area: 600x250mm Max. load incl. magnet: 100kg Total weight: 2.5t

Condition: used, Year of construction: 1977, functionality: fully functional, machine/vehicle number: 7570, 1 used: JUNG Surface and Profile Grinding Machine • Model: HF 50-R(D) • Machine No.: 7570 • Year of manufacture: approx. 1977, overhauled 06-1998 • Grinding area: 500 x 200 mm • Grinding wheel: max. 250 x 25 x 51 mm EQUIPMENT: Electro-magnetic chuck 450 x 180 mm 1 straight dresser mounted on the side of the spindle head 1 grinding wheel holder with wheel 1 universal paper band filter 1 frequency converter for speed control Leveling feet Dcsdpfx Aow R Tqpobbeg

Condition: used, Year of construction: 1980, grinding length 500 mm grinding width 200 mm workpiece height 290 mm Machine from the German Federal Institute of Physics and Metrology - geometrically revised - electrics tested, fully functional, relevant parts replaced - all wear parts replaced - colour light grey, colour condition good Equipment: - electro magnet 500x200mm - grinding spindle overhauled 2-axis display for Y and Z axes Automatic delivery for Y and Z axes Y-axis with zero shutdown Manual hand dresser Stepless speed for grinding wheel V-constant via disc wear Paper band filter system, used Max. height with 250 disc diameter 290mm max. grinding area 600x250mm max. load incl. magnet 100kg Warranty: 1 year on geometry and electronics, Germany-wide Delivery: ex works Dcjdpfx Abewb Hygobjg Shipping time: immediately Payment: before pickup Acceptance at our premises Shipping according to your specifications

Condition: good (used), Year of construction: 1980, operating hours: 15,393 h, functionality: fully functional, grinding length: 600 mm, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. Dcedpfx Aoxru H Tebbjg No private sales.

Year of construction: 2015, condition: used, workpiece diameter 300 mm workpiece weight 999 kg workpiece height 145 mm Features: -Digital display vertical axis -Automatic feed -Programmable automatic end stop -Grinding spindle drive with infinitely variable electronic speed control -Infinitely variable cross feed and table rotation -24V magnetic clamping plate 300 mm -Various occupational safety devices, e.g. protective cover monitoring, operating status display via traffic light -Lubricating oil level monitoring -The machine was completely overhauled in 2015, at which time the entire electrical system was replaced with PLC control and 24V control voltage -Paper belt filter system specially designed for this machine The following work has now been carried out: -Replacement of bellows and belts -New bearings for grinding spindle -Grinding carriage bed and rotary table bed scraped by hand Dcjdexflcljpfx Abbsg to restore better and more precise running characteristics -Grinding carriage and cross table lifted from machine body and all tracks cleaned, lubrication checked -Various wear parts, such as rubber caps and switching elements, replaced -Detailed functional check -Modernisation of feed arm -Paint touch-up work, machine colour: light grey RAL 7035 and RAL 7012

Condition: refurbished (used), Year of construction: 2025, grinding length: 600 mm, grinding width: 250 mm, grinding wheel diameter: 250 mm, JUNG JF520 / JF525 SPM-X rebuilt mechanicaly, geometricaly und elektricaly rebuilt according JUNG acceptance protocoll for new machines - retrofit with new 12“-SIEMENS-Touch-OP control Dsdpfsbwl Uhjx Abbecg - new electrical cabinet with magnetic control for chuck - plain text error codes - electro mechanical vertikal feed - dresser compensation - automatic lubrication unit - all numeric values (verical feed) und on/off functions e.g. hydraulic and und coolant unit over touch panel - all analog functions e.g. rpm, magnetic force and feed of Z-axis fpr direct access of the worker over switches on the control panel - 12 month warranty max. grinding range: 600 x 250 mm delivery time approx. 12 weeks

Condition: reconditioned (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 3806, grinding length: 600 mm, grinding width: 250 mm, grinding wheel diameter: 250 mm, grinding spindle speed: 3,000 rpm, power: 3.5 kW (4.76 HP), Equipment: rotational speed infinitely variable, JUNG JF520 SPM – workshop overhauled Mechanically / geometrically and electrically completely overhauled in 2007 Mechanically and geometrically partially overhauled in 2025 and fully functional Wear parts replaced Geometry overhauled according to JUNG new machine protocol Dodpfewz Hf Njx Abbecg - Grinding area: 600 x 250 mm - Stepper motor feed - 3-axis RSF digital readout - Dressing dimension compensation - Magnetic force control - Automatic central lubrication - Used magnetic chuck - Used paper band filter 6 weeks parts warranty Delivery time: short notice We are happy to take your used JUNG grinding machine in part exchange.

Condition: used, Year of construction: 2001, grinding length 600 mm grinding width 400 mm workpiece height 375 mm digital readout 2 Achsen HEIDENHAIN table-size 650 x 350 mm max. table load 400 kg magnetic clamping plate 600 x 350 mm dist. center of grinding spindle - table 525 mm table travel longitudinal 650 mm table travel cross 350 mm table feed 2 - 28 m/min grinding wheel size 300 x 30 x 76,2 mm dressing device Kopfabrichter voltage 400 V total power requirement 11,0 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 2,20 x 1,70 x 2,25 m band filter unit 1,00 x 0,75 x 0,80 m electric cabinet 0,90 x 0,40 x 2,25 m - Serial-No.: 18090201 - Automatic vertical feed - Electric handwheel Dcjdpfxoy Ehw Is Abbsg - HEIDENHAIN digital display, 2 axes - Head dresser - Coolant device - Belt filter system

Year of construction: 1989, condition: ready for operation (used), Table dimensions X/Y: 600mm/200mm, grinding dimensions X/Y: 600mm/250mm, magnet dimensions X/Y: 600mm/200mm, grinding wheel diameter: 225mm, grinding wheel width: 25mm, grinding wheel bore: 51mm, spindle center-to-table distance: 350mm (+/-50mm), table feed: 20m/min, creep speed: 0mm/500mm/min, speed: 4200rpm, machine dimensions X/Y/Z: approx. 2700mm/2100mm/2100mm, weight: approx. 2500kg. On-site inspection is possible. Dcsdpfxsv Exrwj Abbjg

Condition: good (used), Year of construction: 1987, functionality: fully functional, Jung JF 520 MS 1987 magnet 175 x 450 mm max. grinding range 600 x 220 mm variable magnetic force variable speed creep feed grinding Dodpjydd S Djfx Abbjcg automatic feed for plunge and surface grinding diaform 4x grinding flange with wheel documentation machine powered for inspection.

Condition: used, Year of construction: 2010, functionality: fully functional, machine/vehicle number: M60I/9035, Offer Number: M60I/9035 Dcedpfew N Dmxsx Abbjg Machinetype: surface grinding machine Make: STÖCKEL Type: FX60/30 SPS Constr. year: 2010 table size: 600 x 250m Location: Germany

Condition: new, We can deliver all spare parts for JUNG JF- und HF-series. z.B. grinding flanges, switches, bellows, refurbished grinding and transvers spindles, hydraulic pistons etc. Also equipment like magnetic chucks (new oder refurbished), dressers, filtrtion units, lubrication pumps etc. Also used parts which are discontinued by the manufacturer. Please inquire wih the exact part name. Dsdogbt U Nspfx Abbecg
