CNC Lathe

INDEX G200 YB Ratioline

Condition: new, number 65 Positionen 28 mm condition neu weight 49 kg Basic-Set 3: 69 pieces, 28mm system, consisting of: Forceps: 10 x 280604 Bolt: 18 x 280511 Stop: 10 x 280420.N Angle: 6 x 280110.G Angle: 4 x 280162.N Threaded bolt 8 x 280543 Knodpfx Aeupw Stjf Sof Stop 8 x 160415 Stop 3 x 284050 Accessory set. 1 x 163999 Price plus packaging and transport.

Year of construction: 2003, condition: used, pressure 100 t stroke 10-130 mm no. of strokes 30-90 Hub/min throat 330 mm ram - range of adjustment 100 mm table surface area 950x660 mm ram surface 540x440 mm Knodpjra Rr Eefx Af Sof hole in the table Ø 230 mm table height 1000 mm tool hole in ram Ø 50 mm total power requirement 7,5 kW weight of the machine ca. 7 t

Year of construction: 2008, condition: excellent (used), SMG HZPU 8000-3000/2100-S1 Hydraulic Drawing Press Brand SMG Type HZPU 8000-3000/2100-S1 Year 1995 Description Hydraulic Drawing Press H frame hydraulic press Pressing force 800 ton Kodpjn Awd Rjfx Af Sjnf Clamping area Approx. 3,000 x 2,100 mm Installation height Max. 1,400 mm

Condition: used, Year of construction: 1996, pressure 80 t throat 320 mm stroke 6 - 118 mm no. of strokes 30 - 80 Hub/min ram adjustment 70 mm table surface area 830 x 610 mm ram surface 650 x 400 mm column daylight (nach hinten) 630 mm total power requirement kW weight of the machine ca. 8,1 t dimensions of the machine ca. B 1,2 x T 1,9 x H 3,3 m Furnishing: - with gear transmission - fixed table - automatic stroke adjustment - automatic ram adjustment - hydr. Overload - Ejector - Grease central lubrication - Cover plate for drainage hole Knodpfstycdkjx Af Sjf - Continuous speed control using a frequency converter - Machine is technically checked in our company and receives a new control cabinet with safety controls and touchscreen - current UVV test with braking time measurement

Condition: good (used), Year of construction: 1977, functionality: fully functional, throat depth: 440 mm, ram adjustment: 110 mm, total height: 18,200 mm, table width: 800 mm, table length: 1,100 mm, total width: 24,000 mm, total length: 37,200 mm, overall weight: 12,600 kg, pressing force: 200 t, distance table to ram: 400 mm, power: 15 kW (20.39 HP), ram stroke: 40-180 mm Kjdpfx Afstu Hvws Senf incl. Helmerding feed, 400 mm x 4 mm Strokes: 40 + 60 1/min Distance table/ram - adjustment top/stroke bottom: 400 mm Table opening: 450 mm diameter

Condition: good (used), Year of construction: 1998, Press Force 315.00 t Stroke 500 mm Throat 425 mm Installation Height (Upward Stroke) 1,000 mm Table Surface 1,200 x 815 mm Table Height above Floor 800 mm Ram Surface 1,100 x 700 mm Speed Down 48 mm/s Speed Up 330 mm/s Working Speed 19 mm/s Oil Volume 1,600 l Power Requirement 82.0 kW Weight 23.00 t Knedjv Rwu Uopfx Af Sef Dimensions (WxDxH) 2.4 x 2.8 x 4.0 m For Permitted for manual loading according to the CE standard with oil-hydraulic drive, controllable depending on pressure/time and travel, light-guard at the front (Sick), two-hand operation permitted for manual loading according to the CE standard with oil-hydraulic drive, controllable depending on pressure/time and travel, light-guard at the front (Sick), two-hand operation

Year of construction: 1990, condition: excellent (used), Manufacturer: Arthur Klink Year of manufacture: 1990 Model: RISZ 16 x 1250 x 400 / HG Technical data: Vertical internal broaching machine in technically very good condition tractive force: 16.000kg clearing speed: up to 27,5 m/min infinitely variable return speed: up to 34 m/min infinitely variable Knodpfelpadyjx Af Sof maximum stroke: 1250mm broaching units: 4 pieces accessories: - automatic tool changer - automatic part feeding (part specific) - hydraulic tool clamping device (part specific) Remark: High performance production broaching machine for high volume production with high cutting speed!

Condition: used, Year of construction: 1985, Pressure 080 t throat 345 mm stroke 20 - 160 mm no. of strokes 65 /min distance table/ram, max. stroke up, adjustment up 495 mm Knjdpfxsvuug No Af Sjf table surface area 920 x 610 mm table height over floor 800 mm Hole in the table 280 mm passage to the back 670 mm ram surface 650 x 400 mm ram adjustment 50 mm power capacity 10,0 kW weight 7,7 t Dimensions (WxDxH) 1,5 x 2,2 x 3,15 m permitted for manual put-in according to the German Safety Regulations (UVV) with motor, pneumatic clutch, hydraulic overload protection in ram, manual stroke adjustment, motoric ram adjustment, motoric centralized lubrication, two-hand operation Press is at the moment being overhauled electrically and mechanically - video is from before starting the overhaul WITH mechanical partly overhaul, WITH new electrical control Pilz

Condition: used, Year of construction: 1980, Pressure capacity 1,250 kN Adjustable stroke 20 - 140 mm Kodpfx Aform Ntpo Senf Stroke rate 70 1/min. Further data and pictures on request the press is currently not functional and must be mechanically and electrically overhauled

Condition: used, Year of construction: 1993, pressure:160 t throat:360 mm stroke:300 mm table-size:1500 x 700 mm dimension of ram:1200 x 560 mm return capacity:40 t stroke speed:400 m/min stroke speed - under load:16 - 42 Hub/min stroke speed -return:350 mm/min die-cushion pressure:630 kN die cushion stroke:100 mm Knedpfsh Ra R Isx Af Sef total power requirement:42 kW weight of the machine ca.:19,5 t pressure of ejector:50 kN ejector stroke:50 mm
