Coordinate grinding machine

HAUSER 3S 3 SM

Condition: new, 1 brand-new universal milling head "HURON" system Make: EMENA Model: V 0, ISO 40, normal Technical data: Mounting ISO 40 Projection 270 mm Rated drive power 5 HP Max. speed 1800 rpm Weight approx. 32 kg Design: Standard, with adapter plate / mounting flange finished on the head side, unmachined on the machine side, for retrofitting to conventional, NC or CNC milling machines or drilling machines of any kind, "HURON" system Option: - Raised version Delivery time: approx. 3 months, after receipt of order and payment Illustrations are similar! Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund-Wambel Kedpfebpmv Sjx Af Sofa

Condition: ready for operation (used), Distance between centers: 4000 mm Center height: – over bed 650 mm – in bridge area: 800 mm Swing diameter: – over bed 1200 mm – over cross slide 1000 mm – in bridge area 1600 mm Platform: 1200 mm Bore diameter: 140 mm Speed: 2–800 rpm Bed: – bed width 650 mm – longitudinal slide length 820 mm – total cross slide travel: 600 mm – upper slide travel: 300 mm GIVI 3-axis digital readout Electric motor 28.5 kW Dimensions: 6325 x 1400 mm Ksdpfjxq E D Tsx Af Sefa

Condition: ready for operation (used), machine/vehicle number: 5722, table mounting size: 190 x 710 mm table movement x: 390/360 mm table movement y: 150 mm table movement z: 280 mm spindle taper: SK 40 Kfodpfx Afoflrg Tj Sja spindle turning speed range: 100 - 3100 rpm carriages longitudinal: 0 - 600 mm/min electrical connection: 380 V, ca. 1,5 kW space needed: 1400 x 1200 x 1500 mm weight: ca. 680 kg

Condition: used, Technical details: swing diameter: 200 mm centre distance: 450 mm cross travel: 245 mm longitudinal feed: 830 mm table speed: 0,05-4,5 stufenlos m/min revolution per minute: Schleifspindel 1780, 2050 U/min revolution per minute: Werkstückspindel 50-500 U/min dimensions of grinding wheel: 350x32x127 mm Table dimensions: 2200x280 mm table swivelling to both sides: 9°vor+10°zurück Grad Kedeu Ng Dgepfx Af Sofa total power requirement: 6,0 kW weight of the machine ca.: 2,2 t dimensions of machine: 2,2x2,05x1,6 m Universal Center Grinding Machine without internal grinding device! - for precision grinding of outer, inner such as cone surfaces - feed of grinding headstock via hydr. or manual possible - table feed hydraulic stepless - grinding spindle swivelable with 60 degrees - workpiece headstock 90 degress swiveable with tapper MK4 - tailstock tapper MK 3 equipment: - dressing device/extruder - coolant tank incl. pump and supply i.D. *

Condition: good (used), Coordinate grinding machine Jig grinding machine Brand: Henri Hauser SA. Model: 3.S.M.O. Serial No.: 76 No.: 218···600 FAGOR 2-axis height display. Machine Type: Jig Grinding Machine Control Type: Conventional X-axis travel: 400 mm Y-axis travel: 250 mm Workpiece height: 500 mm Grinding diameter: 220 mm Table top: 600 x 320mm Neckline: 310mm Angle Range: 12° Grinding carriage adjustment - vertical: 110 mm Lifting speeds: 0 - 6 m/min. Kfsdpektkmvjfx Af Soa Grinding spindle speed: max. 50,000rpm Peripheral speed: max. 35m/sec Maximum weight of the piece on the table: 80 kg.

Condition: ready for operation (used), Manufacturer MODUL Model ZFTKK 500/2 W Condition Used Tilting of hob spindle 0....8 gradi Hob spindle speed 45-224 giri/min Max workable diameter 540 mm Maximum module 16 Max tooth range 78 mm Range no. teeth 6....100 Kfedev Rpq Ijpfx Af Sea Machine weight 12000 Kg *Roughing and finishing machine*

Condition: good (used), Year of construction: 2001, Table work area : 850×400 mm Table travel distance : 950×440 mm Distance table top to wheel bottom : 47.5 – 547.5 mm Kjdjwuglvspfx Af Sefa Standard chuck size : 800×400×105 mm Max workpiece weight : 700 kg (230 kg sur plateau magnétique) T-Slots (W×No.) : 17×3 Longitudinal feedrate : 3 – 25 mm/min Crosswise feedrate : 1 – 1000 mm/min Vertical feedrate : 1 – 1000 mm/min Min input increment (vertical) : 0.0002 mm Grinding wheel O.D.×W×I.D. : 355×38×127 mm Grinding wheel speed : 1500/1800 r.p.m. Wheel spindle drive motor : 3.7 / 4 kW Vertical feed motor : 0.3 kW Cross feed motor : 0.3 kW Hydraulic pump motor : 2.2 / 4 kW Air-cooled oil cooler motor : 90 / 105 W Floor space (L×W×H) : 3310×2228×2713 mm Machine weight : 4000 kg Specifications are subject to change at any time without prior notice. No liability shall be assumed for errors or omissions.

Condition: used, Year of construction: 1990, x-travel 400 mm y-travel 250 mm Kfsdpfx Afjt Hxcno Sea workpiece height mm Control CNC 314 ELESTA total power requirement 15 kW weight of the machine ca. 5500 kg dimensions of the machine ca. m H A U S E R (Switzerland) CNC - Controlled High Precision Jig Grinding Machine Model S 3 – CNC 314 Year approx.. 1990 S/N 32086 _____ Table size, approx. 600 x 380 mm Max. load on table, approx. 300 kg Table travel, longitudinal, max. (X Axis) 400 mm Table travel, cross, max. (Y Axis) 250 mm Vertical adjustment of grinding head max. (W Axis) 450 mm Stroke of grinding spindle, max. (Z Axis) 120 mm Table Longitudinal and cross feeds (X/Y-Axis) 0 – 1.500 mm/min Speed of grinding head stroke 15 – 12.000 mm/min Vertical distance between table and grinding spindle, max. 0 – 485 mm Distance between grinding spindle and column 350 mm Conical grinding, up to max. 16 ° Grinding Ø bore approx. 230 mm Planetary speeds (C-Axis) 5 – 250 rpm U Axis, radial infeed 6 mm Total electrical load, approx. 15 kW - 400 V - 50 Hz Weight/Total weight approx. 4.000/5.500 kg Accessories / Special Features: • CNC Continuous Path Control, Model CNC 314, (ELESTA-POLESTA II) with new monitor,for 4 axes (XYC+U) in 2 1/2 dimension (XY+C) Interpolation with a free and easy programming for Linear and circle interpolation. Direct Input of data on keyboard, also loading data on RS 232 connection. There is also a handwheel control device for setting – up purposes. Manual feed correction during the working cycle possible. • Digital Read-out for the Z-Axis, Z-Axis as high speed stroke, also good for blind holes. • W Axis for vertical positioning of grinding head slide, • U Axis for the infeed cycles during bore grinding, grinds different bore-Ø automatically. • C Axis Feed for the of the Planetary Head, grinds radii and contours • 2 grinding motors HAUSER approx.. 22.500 to 60.000 rpm, with some collets and arbors • Built-on Acoustic Grinding Contact Display Device Model KSV 5. • Separate coolant unit with band filter. * Built-on fire extinguishing system. • Separate switch cabinet and control unit, Separate hydraulic unit with oilchiller, • Central lubrication, service tools, collets and grinding arbors/tools. Condition : Very good - Machine can be inspected under power commissioned by a Specialist. Delivery : Ex stock - as inspected under power. Payment : Net, after conclusion of contract

Condition: ready for operation (used), Year of construction: 1988, SARATOV 5C280P Spiral Bevel Gear Generator - 2 machines Max gear diameter: 800 mm Max module: 16 Max gear ring width: 125 mm Number of teeth: 5-150 Spindle speed range: 20-125 rpm Main motor power: 7.5 kW Overall dimensions (LxWxH): 3170x2180x2200 mm Weight: 15 t SARATOV 5C276 Straight Bevel Gear Generators Module (mm): 10 Max. gear wheel diameter: 500 mm Max. bevel gear cone distance: 250 mm Max. gear ring width: 80 mm Ksdpfx Aoum Ez Rjf Sofa Min. angle of dividing cone (pitch): 5 degrees Number of gear teeth: 10 – 150 Distance between spindle and machine center: max. (stock angle 5°): 375 mm; min. (stock angle 90°): 75 mm Stroke: 100 mm Slider double stroke: 48 – 400 spm Motor capacity: 4.0 kW Machine weight: 8750 kg

Condition: used, Year of construction: 1987, x-travel 400 mm y-travel 250 mm workpiece height 485 mm Control ELESTA CNC 314 total power requirement 10 kW weight of the machine ca. 4000 kg Kfjdpfx Aot Hw Txsf Sja dimensions of the machine ca. m H A U S E R CNC - Controlled Vertical Precision Coordinate Grinding Machine Model S 3 – CNC 314 Year 1987 / 1998 partially reconditioned by Swiss-HTT # 0463 _____ Table size, approx. 600 x 380 mm Max. load on table, approx. 300 kg Table travel, longitudinal, max. (X Axis) 400 mm Table travel, cross, max. (Y Axis) 250 mm Vertical adjustment of grinding head max. (W Axis) 450 mm Stroke of grinding spindle, max. (Z Axis) 120 mm Table Longitudinal and cross feeds (X/Y-Axis) 0 – 1.500 mm/min Speed of grinding head stroke 15 – 7.500 mm/min Vertical distance between table and grinding spindle, max. 0 – 485 mm Distance between grinding spindle and column 350 mm Conical grinding, up to max. 16 ° Grinding Ø bore approx. 230 mm 18 Spindle speeds, depending on spindle motor 4,500 – 80,000 rpm Planetary speeds (C-Axis) 5 – 250 rpm U Axis, radial infeed 6 mm Total electrical load, approx. 10 kW - 380 V - 50 Hz Weight, approx. 4.000 kg Accessories / Special Features: * CNC Continuous Path Control, Model CNC 314, (ELESTA-POLESTA II) with monitor,for 4 axes (XYC+U) in 2 1/2 dimension (XYC) Interpolation with a free programming,the U-Axis is not interpolating it is just an infeed axis. There is also a handwheel controldevice for setting – up purposes. Digital Read-out for the Z-Axis W Axis for vertical positioning of grinding head, Z Axis as high speed stroke axis, also for blind-hole grinding and surface grinding. U Axis for the infeed cycles during bore grinding. C Axis Feed for the of the Planetary Head. * Alltogether 2 grinding turbines 22.500 to 80.000 rpm, with some collets * Built-on Acoustic Grinding Contact Display Device Model KSV 5. * Separate coolant unit with band filter. * Built-on fire extinguishing system. Separate switch and control cabinet. Covered working area. Separate hydraulic unit * Central lubrication, service tools. Condition : Very good - Machine can be inspected under power. Delivery : Ex stock - as inspected under power. Payment : Net, after conclusion of contract
