Tool room milling machine

DECKEL FP1

Condition: used, Universal Milling Machine DECKEL Type FP 1 Universal milling machine Machine No. 2101 – Year of manufacture: 1979 Manual travel X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Nwodpfjr U St Usx Agmji Rapid traverse: 1200 mm/min Motor power: 1.5 and 1.9 kW, pole-changeable Electrical connection: 380 Volt, 50 Hz - Stepless feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at the vertical milling head: 60 mm - Vertical milling head can be swiveled and extended horizontally by 100 mm - Fixed angle table 600 x 210 mm - Coolant system integrated in the machine base - Standalone control cabinet - Original chip tray for mounting on the machine base - Electrical schematic available Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg Good condition

Condition: used, Univ. universal tool milling machine DECKEL, type FP 1 Machine no. 52185, year of manufacture 1968 Nwsdpfx Aedzqb Ssgmoi Travel distances: X: 300 mm, Y: 150 mm, Z: 340 mm Table size: 600 x 250 mm Spindle mount: SK 40 - S20 x 2 Spindle speed: 40-2000 rpm, 16 steps Motor power: 1.0 and 1.4 kW, pole-shifting Power connection: 380 volts, 50 Hz - Feed in the X and Z axes - Two motor speeds and 8 gear stages - Quill travel on the vertical milling head: 60 mm - Fixed tilting table - Coolant system in the machine base - Adjacent control cabinet - Counter holder with counter bearing for horizontal milling, SK 40 Space requirement L x W x H: 1200 x 1100 x 1600 mm Weight: approx. 1000 kg Very good condition

Condition: used, Univ. universal milling machine DECKEL, Type FP 1 Machine No. 28317, Year of manufacture approx. 1960 Travel distances: X: 245 mm, Y: 150 mm, Z: 340 mm Table size: 600 x 210 mm Spindle mount, horizontal: MK 4 - S20 x 2 Spindle speed, vertical: 95-1900 rpm, 12 steps Spindle speed, horizontal: 60-1200 rpm, 12 steps Motor power: 0.8 and 1.1 kW, pole-changing Power connection: 380 Volt, 50 Hz - Spindle speed controlled via 2 motor speeds and 6 gear stages - Feed in the X and Z axes - Coolant system with mechanical pump in the machine base - Quill travel on the vertical milling head: 60 mm Njdpfxeiy Ekvs Agmjwi - Vertical milling head swivels +/- 90° - Metal substructure made of angle iron with machine feet Space requirement L x W x H: 1100 x 900 x 1650 mm Weight: 650 kg Good condition

Condition: used, Univ. universal tool milling machine DECKEL, Type FP 1 Machine No. 51265, Year of manufacture approx. 1967 Travel distances X: 300 mm, Y: 150 mm, Z: 340 mm Table size 600 x 200 mm Spindle mounting SK 40 - S20 x 2 Spindle speed 40-2000 rpm, 16 speeds Njdeghtvaepfx Agmjwi Motor power 1.0 and 1.6 kW, pole-changing Mains connection 380 volts, 50 Hz - Feed in the X and Z axes - Spindle speed via 2 motor speeds and 8 gear stages - Quill movement on the vertical milling head 60 mm - Swivel, rotary, and tilting angle table - Coolant pump in the machine base - Adjacent control cabinet Space required L x W x H 1100 x 1100 x 1600 mm Weight 690 kg Good condition

Condition: used, Keyway milling head, head for DECKEL milling machine, type FP 1 Factory number: 21948 Dovetail width: approx. 74 - 88 mm Dovetail height: approx. 14.5 mm Dovetail length: 285 mm Distance from the front edge of the dovetail to the center of the gear: approx. 200 mm Stroke size: max. 80 mm Stroke rate: max. 475 double strokes/min. Tool holder: 4-sided, 16 x 16 mm with clamping plate - Stroke size adjustable via eccentric adjustment - Drive from the machine gearbox, within the dovetail guide (as with the normal vertical head) - This keyway milling head is inserted into the dovetail guide in place of the normal vertical milling head (Mounting in place of the vertical milling head) - Drive gear in the keyway milling head, 39 teeth, gear width 15 mm, presumably 15° pressure angle - Keyway milling head can be rotated 360° on the flange plate, degree scale +/- 35° - Small breakout point on the housing Weight: 28.5 kg Nedpfx Ajznn Hrogmewi DECKEL FP1 has a pressure angle of 15° on the drive wheel. DECKEL FP2 + FP3 have a pressure angle of 20° on the drive wheel.

Condition: used, Counter bearing and adapter for milling machine for horizontal milling Counter bearing and adapter (counterholder) for DECKEL milling machine (Bearing block with dovetail mounting adapter DECKEL FP1 + FP2) Type 9570 Dovetail width, narrow: approx. 72 mm Dovetail width, wide: approx. 88 mm Dovetail height: approx. 15 mm Length (bearing block): 133 mm Width (bearing block): 50 mm Total height (bearing block): 105 mm Bearing bore: Ø 17 mm (with bronze bearing bushing) Distance from bore axis to dovetail mounting face: approx. 82.5 mm (center height) Nodpfxexcbl Ds Agmswi - Adapter fits dovetail and mounting surface, raises center height by 22.5 mm to 105 mm Total length (dovetail rail): 635 mm Weight: 3.8 kg Very good condition

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Universal Milling Machine Machine No. 2101 - Year of manufacture: 1979 Travel (manual) X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.4 / 1.8 kW, pole-changeable Power supply: 380 Volt, 50 Hz - Stepless feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gearbox stages - Quill stroke at the vertical milling head: 60 mm - Vertical milling head tiltable and horizontally extendable by 100 mm - Fixed angle table 600 x 210 mm - Coolant system in the machine base - Separate control cabinet - Original chip tray mountable on machine base - Wiring diagram available Space required (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg In very good condition Nwedpfx Agsr D T U Domji

Condition: used, Univ. universal milling machine DECKEL, Type FP 1 Machine No. 33064, Year of manufacture approx. 1960, overhauled in 2012 Travel distances: X: 300 mm, Y: 150 mm, Z: 330 mm Table size: 600 x 210 mm Spindle mount: MK 4 - S20 x 2 Spindle speed, vertical: 95-1900 rpm, 12 steps Spindle speed, horizontal: 60-1200 rpm, 12 steps Motor power: 1.1 and 1.4 kW Power connection: 380 Volts, 50 Hz - Feed in the X and Y axes - Quill movement on the vertical milling head - Fixed angle table - Coolant system with mechanical pump in the machine base - Adjacent control cabinet with cable plug connection Space required L x W x H: 1100 x 900 x 1600 mm Weight: approx. 900 kg Good condition Nwedjdzp T Eepfx Agmsi Machine was overhauled in 2012.

Condition: excellent (used), functionality: fully functional, Universal milling machine Deckel FP1 with 3-axis digital display K&C, stepless feed, light gray color, CE compliant, in excellent condition. Technical data: Nwodpozl Uz Dofx Agmoi >> Year of manufacture 1980, machine number 2101-1423 >> Fixed angular table >> Speed: 40 - 2000 rpm >> Stepless feed on 2 axes >> Drive power: 1.5 / 1.9 kW >> Spindle brake >> Rapid traverse >> Travel distances X/Y/Z: 300/160/340 mm >> Vertical milling head on spindle support, adjustable by 100 mm >> Vertical and horizontal quill - SK40 >> Clamping system M16 >> Weight approx. 700 kg Accessories and equipment: >> 3-axis digital display K&C, newly installed with manufacturer's warranty and operating manual. Display unit: Setting reference points, zero points, entering coordinates, switching between mm/inch, absolute or incremental coordinates, circular functions, hole patterns, radius milling functions, etc. >> Coolant system >> Machine lamp >> Operating manual, parts list >> Tool holders, vise, backstop About the machine: Offered is a universal milling machine Deckel FP1, CE compliant, in very good condition. The machine has very little backlash and all spindles move easily. The bellows are all new. In this newer FP1 model, the feed is steplessly adjustable on two axes, and the machine also has a rapid traverse function. An oil change has been carried out. Mechanically and electrically inspected. Thanks to the new digital display from K&C, working with the machine is easier and even more precise. Take advantage of the opportunity to inspect and test this machine on-site while it is powered on.

Condition: excellent (used), functionality: fully functional, Universal milling machine Deckel FP1 with 3-axis active digital display TNC 113 Heidenhain and continuously variable feed, in very good condition, CE compliant. Technical data: >> Year of manufacture: 1987, Machine No. 2102-3562 >> Fixed angular table >> Speed: 40 - 2000 rpm >> Continuously variable feed in 3 axes >> Rapid traverse in 3 axes >> Drive power: 1.5 / 1.9 kW >> Spindle brake >> Travel ranges X/Y/Z: 300/160/340 mm >> Vertical milling head on spindle support, adjustable by 100 mm >> Vertical and horizontal quill - SK40 >> Clamping system M16 >> Weight approx. 800 kg Nwsdpfxszl Eifj Agmji Accessories and equipment: >> 3-axis digital display Heidenhain TNC113 >> Coolant system >> Machine lamp >> Operating manual, spare parts list >> Tool holders, vise, counter holder About the machine: Offered is a universal milling machine Deckel FP1 in very good condition and CE compliant. The machine has very little backlash and all spindles can be moved easily. Even at maximum speeds, the milling machine runs very smoothly. In this newer FP1 model, the feed is continuously adjustable in three axes, and the machine also has rapid traverse in these axes. A major advantage is the active 3-axis digital display. With this Heidenhain positioning control, you can enter dimensions that the machine will automatically approach. The FP1 was located in a training workshop, where it was only used occasionally. An oil change has been carried out. Mechanically and electrically tested. The digital display from Heidenhain makes working easier and even more precise. Take advantage of the opportunity to inspect and test this machine on-site while it is powered up.
