Used surface grinding horiz. 700-999mm grind. length for sale (48)

Condition: used, Year of construction: 1998, grinding length 800 mm grinding width 500 mm workpiece height 425 mm total power requirement 15 kW weight of the machine ca. 4,5 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical : GEIBEL & HOTZ CNC Cycle Controlled Precision Surface Grinding Machine Dsdpfx Ajt Hxamobrecb model FS 850 GT SL year 1998 Serial no 1012580698 _____ Grinding length max. (table movement 900 mm) 800 mm Grinding width max. (cross movement 500 mm) 500 mm Mounting height under new grinding wheel 425 mm size of magnetic plate 800 x 500 mm Max. table load 1.100 kg Table speed 2 – 28 m/min Cross feed intermittend 3 – 60 mm/stroke Cross-/Vertical quick feed 4.000 mm/min Grinding wheel measurements 400 x 100 x 127 mm Grinding spindle-drive approx. 9 kW Total electrical load approx. 22 kW - 400 V - 50 Hz Weight approx. 4.500 kg Accessories / Special Features: • Dialog-guided GEIBEL & HOTZ automatic CNC cycle control model SL for 3 axes. Graphically supported data input in absolute dimensions or via teach-in procedures for preprogrammed grinding and dressing cycles. SIEMENS LCD display with softkeys for setting all parameters and easy monitoring axis movements and work progress. • Electronic handwheel for 3 axes X, Y, and Z, feed rate switchable from 0.01 / 0.1 / 1 mm/rev. • table movement is effected by a rolling ring thread drive (GT), which allows both very high and very low table speeds with constant torque and very high efficiency. • cross and vertical movements are effected by a ball screw drive with incremental glass scale. • Single-point diamond dresser mounted on the table for aut. dressing cycle and aut. compensation • MPM automatic grinding wheel balancing device. • Mounted electromagnet plate 800 x 500 mm with adjustable holding force • Wet grinding facility with universal fleece belt filtration unit • Complete enclosure of the working area with electronically safeguarded sliding doors • sep. switch cabinet, sep. mobile control panel, various accessories, manuals , etc. Condition : very good, with the wide grinding wheel for large surface grinding ! Please click here to view soon a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We do always have a large selection of Grinding machines in stock – please let us know your requirements !

Condition: new, ROGI surface grinder type FSG-4080A Table size ----- 406 x 813 mm Longitudinal displacement of work table ----- 900 mm Cross displacement of worktable ----- 450 mm Unloading ----- 580 mm Max. permissible workpiece weight ----- 500 kg Grinding stone ----- 350×40×127 mm Motor ----- 4 KW Dcedpfjga T Iasx Abrsb Weight ----- 3400 kg Dimension machine ----- 3600×2630 mm

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm table-size 800 x 400 mm table speeds 1 - 25 m/min Dedpfx Abswgnz Asrjcb cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges.

Condition: excellent (used), Year of construction: 1999, Jung C-740-C Dcodpfxju I Rtio Abreb year of construction: 1999 control: siemens magnet: 700 x 400 mm max. grinding range: 880 x 460 x 550 mm ( x,z,y) magnet variable attraction force variable speed: 1500-3500 rpm max. load on the table: 800 kg top clamp bottom clamp 2x remote control balancer various grinding stones documentation machine is under power for inspection

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15135, grinding length: 800 mm, grinding width: 600 mm, grinding height: 500 mm, grinding wheel diameter: 400 mm, control type: NC control, TECHNICAL DETAILS Dedpfx Absxl Sifjrjcb Control: NC Ergomatic Grinding length: 800 mm Grinding width: 600 mm Grinding height: 500 mm Grinding wheel diameter: 400 mm EQUIPMENT Electromagnetic chuck Coolant purification system

Condition: new, Year of construction: 2025, 0800 mm 400 mm 342 mm 900x460 mm 355x38x127 mm Dedpowp Tflefx Abrecb 2400 U/min

Condition: used, Year of construction: 1997, grinding length 880 mm grinding width 510 mm Control Siemens max. turning speeds 4.300 min/-1 grinding wheel diameter 210 - 400 mm grinding wheel width 100 mm total power requirement 26 kW weight of the machine ca. 7,5 t In our opinion, the machine is in good used condition and can be inspected under power by appointment. Dedpfx Abjwwl N Serjcb Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: used, Surface grinding machine Brand: Ger Model: RS-75/35 3 automatic axes (X, Y, Z) Technical specifications Low column: - Maximum grinding area: 750x375mm (X, Y) - Table to grinding wheel center distance: 525mm - Table speed: 2 to 32m/min. Dsdowx Nlmjpfx Abrjcb - Maximum table travel: 800mm - Maximum workpiece weight: 500kg - Magnetic table: 700x250mm Cross travel: - Maximum cross travel: 350mm - Rapid cross feed: 1.5m/min. - Automatic cross feed: 2 to 60mm/rev. - Handwheel revolution: 3mm - Handwheel division: 0.02mm Vertical movement: - Rapid vertical feed: 200mm - Handwheel revolution: 0.24mm - Handwheel division: 0.002mm - Wheel dimensions: 300x50x76.2mm Motors: - Head: 6Hp - Pump: 3Hp - Feeds: 0.75HP - Total: 7.5KVA Weight: 3,700kg Dimensions: 2,400x1,850x2,300mm

Condition: ready for operation (used), Year of construction: 1987, Grinding length: 1000 mm Grinding width: 450 mm Workpiece height: 500 mm Magnetic chuck, electric: WxD=1000x400 mm Grinding wheel diameter: 350 mm Spindle motor power: 7.5 kW Year of manufacture: 1987 Djdpfxexm S I Ds Abrocb Machine weight approx.: 4.5 t Description - Universal surface grinding machine with rapid vertical feed - Hydraulic table drive - External control cabinet with oil cooling for improved machine dimensional stability - Accessories: Coolant system

Condition: used, Year of construction: 1999, grinding length 800 mm Djdpfx Abetz Evkorjcb grinding width 400 mm workpiece height 375 mm table surface area 840 x 400 mm table speeds m/min spindle speeds (infinitely variable) 1000 - 3000 U/min grinding wheel motor 3,7 kW grinding wheel size 300 x 50 x 76,2 mm cross adjustment 100 - 1250 mm/min rapid traverse vertical 180 mm/min table load max. 700 kg distance spindle center to table max. 525 mm weight of the machine ca. 2,8 t dimensions of machine L x W x H 3,14 x 1,78 x 2,50 m Accessories: magnetic plate 800 x 400 mm, grinding wheel with flange, wheel dressing attachment, wet grinding attachment with paper band filter

Condition: ready for operation (used), Year of construction: 1965, machine/vehicle number: 651239, flat grinding machine Dcsdpfx Aboklyz Uorob Robert Blohm Simplex 75

Condition: good (used), Jung surface grinding machine Dodpfx Aeq H Ap Tjbrocb X-path: 740 mm Bed: 725 x 170 mm Magnetic bed: 460 x 155 mm Dimensions: 162x130x190 cm LxWxH

Condition: new, Year of construction: 2025, Brand new CNC-controlled premium-class precision flat and profile grinding machine for production. Grinding area: 700 x 500 mm Maximum workpiece height with new grinding wheel: 420 mm Grinding wheel size: Ø 400/127 x width 75 mm Grinding wheel drive power: 9 kW Continuously variable table feed speed: 0.35 up to 35 m/min Dimensions approx. 3.2 x 2.75 x H 1.9 m Weight of base machine without magnetic chuck: approx. 4,000 kg Special design features: - Machine frame entirely made from Meehanite® cast iron - Hydrostatically guided longitudinal and transverse axes Dcedpfxsxdh U Uo Abrjb - Roller guides in recirculating ball cages for vertical movement - OMLAT® grinding spindle - HEIDENHAIN® glass scales Available options: - MARPOSS® measuring and inspection components - Dynamic grinding wheel balancing - FANUC® CNC controls

Year of construction: 1990, condition: reconditioned (used), tangential grinding machine Brand: Jakobsen Model: 1432 Year: 1990 rpm: 1400 Grinding area: 800x400mm Djdpfx Abjiv S Avjrjcb Table size: 1000x350mm Maximum load on table: 400kg Maximum piece height: 475mm Grinding wheel size: 350x50x127mm Heidenhain ND 221B height indicator. Magnet table 800x350mm electronic Selter with magnetization regulator. Maximum distance between table and grinding wheel: 650mm MONNET brand filter of the year 2007 Includes sets of wheels (See photos).

Year of construction: 1987, condition: good (used), machine/vehicle number: 544/87, Table: 300-1000 mm Made in Switzerland Hydraulik BP Energol HL68 Mobil DTE Heavy Medium Schmierung BP Maccurat 68 Mobil Vactra Oil Nr.2 Schleifspindel BP Energol HLP-D16 Dcjdpobqcaxsfx Abrjb Mobil Velocite Nr.3

Condition: used, Year of construction: 1990, grinding length 900 mm grinding width 510 mm workpiece height 400 mm table surface area 800 x 400 mm longitudinal feed of the table max. 980 mm table speed -stepless- 1 - 35 m/min grinding wheel size 355 x 51 x 127 mm cross feed of the table 460 mm Dcjdpfx Aetqqm Ajbrsb cross feed 1 - 40 mm/Hub vertical feed autom. 0,005 - 0,04 mm/Hub rapid traverse vertical 0,5 m/min grinding spindle speed 1450 U/min grinding spindle drive 5,6 kW table load capacity max. 1000 kg total power requirement 10 kW weight of the machine ca. 4,4 t Accessories: magnetic plate 800 x 400 mm, various grinding wheels with and without flanges, wet grinding attachment with paper band filter

Condition: good (used), Year of construction: 1980, A well-preserved surface grinding machine by BLOHM, model HANSEAT 75, machine no.: 11985, year of manufacture: 1980, with coolant tank. Magnetic chuck: 800x500 mm. Djdpfjw Am Akex Abrscb

Condition: good (used), Flat grinding machine Jung X-travel: 740 mm Dcjdpfx Ajk N D Urobrsb Bed: 725 x 170 mm Magnet bed: 460 x 155 mm Dimensions: 162x130x190 cm LxWxH

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, grinding length: 1,000 mm, grinding width: 550 mm, overall weight: 2,500 kg, Equipment: documentation/manual, rotational speed infinitely variable, Hydraulic surface grinding machine Renato Scarpini model RS 1000x550, used, fully overhauled, variable wheel speed, variable table speed, total weight approx. 2500 kg, equipped with magnetic chuck, complete with manual. Dcsdpfx Ajwu Rwvebrsb

Condition: ready for operation (used), Sanding length 800 mm Sanding width 350 mm Sanding height 350 mm Total power requirement approx. 5.5 kW Automatic depth feed Dcedpsu Aht Nofx Abrsb Automatic cross feed Machine weight approx. 2,600 kg

Condition: new, Year of construction: 2025, Grinding machine for continuous operation in production, tool shops and renovation departments. The machine has a modern, sturdy design. Its headstock operates on two pairs of guides. Hydraulic feeds for 2 axes, by default comes with a digital display. Description Double V-shaped guide Hydraulic feed in 2 axes Tempered and precisely ground linear feeding guides Central lubrication of guides Digital display Sturdy design High machining accuracy Technical data Table dimensions 800×400 mm Maximum table feed 800×415 mm Distance from table surface to spindle axis 600 mm Table mounting T-slot 1×14 mm Table longitudinal speed 3–20 m/min Rapid vertical feed speed 360 mm/min Dcodpfx Aekkddvobrsb Transverse travel equal to 1 grade on the vernier scale 0.01 mm Transverse travel equal to 1 wheel turn 2 mm Transverse feed addition 0–8 mm/min Transverse feed 600 mm/min Grinding wheel dimensions 300×30×76.2 mm Grinding wheel speed 2850 rpm Manual vertical travel equal to 1 grade on the vernier scale 0.01 mm Grinding accuracy 300:0.005 mm Grinding roughness Ra 0.32 Manual vertical travel for rotating 2 mm Main motor power 2.2 kW Flood coolant pump motor power 40 W Dimensions 1960×1480×1850 Weight 1800 kg Equipment dependent on the model Magnetic table Grinding wheel Grinding wheel fixture Cooling system Halogen lighting User manual EC declaration of conformity The price is a net price. Price does not include shipping costs. For more information, please contact us by phone or e-mail. We invite you to familiarize yourself with the offer on our website.

Condition: good (used), Year of construction: 2001, Table work area : 850×400 mm Table travel distance : 950×440 mm Distance table top to wheel bottom : 47.5 – 547.5 mm Standard chuck size : 800×400×105 mm Max workpiece weight : 700 kg (230 kg sur plateau magnétique) T-Slots (W×No.) : 17×3 Longitudinal feedrate : 3 – 25 mm/min Crosswise feedrate : 1 – 1000 mm/min Vertical feedrate : 1 – 1000 mm/min Min input increment (vertical) : 0.0002 mm Grinding wheel O.D.×W×I.D. : 355×38×127 mm Grinding wheel speed : 1500/1800 r.p.m. Wheel spindle drive motor : 3.7 / 4 kW Vertical feed motor : 0.3 kW Dedewuglvopfx Abrscb Cross feed motor : 0.3 kW Hydraulic pump motor : 2.2 / 4 kW Air-cooled oil cooler motor : 90 / 105 W Floor space (L×W×H) : 3310×2228×2713 mm Machine weight : 4000 kg Specifications are subject to change at any time without prior notice. No liability shall be assumed for errors or omissions.

Condition: good (used), Year of construction: 1995, Table work area : 850×400 mm Dodpfx Ajwuglisbrscb Table travel distance : 950×440 mm Distance table top to wheel bottom : 47.5 – 547.5 mm Standard chuck size : 800×400×105 mm Max workpiece weight : 700 kg (230 kg sur plateau magnétique) T-Slots (W×No.) : 17×3 Longitudinal feedrate : 3 – 25 mm/min Crosswise feedrate : 1 – 1000 mm/min Vertical feedrate : 1 – 1000 mm/min Min input increment (vertical) : 0.0002 mm Grinding wheel O.D.×W×I.D. : 355×38×127 mm Grinding wheel speed : 1500/1800 r.p.m. Wheel spindle drive motor : 3.7 / 4 kW Vertical feed motor : 0.3 kW Cross feed motor : 0.3 kW Hydraulic pump motor : 2.2 / 4 kW Air-cooled oil cooler motor : 90 / 105 W Floor space (L×W×H) : 3310×2228×2713 mm Machine weight : 4000 kg Specifications are subject to change at any time without prior notice. No liability shall be assumed for errors or omissions.
