Agro pellet production line !
Year - 2012
Capacity - 10t/h
- Line Ai B for transporting bales, command bridge and lane - 2 pieces
- Rotary crusher - 1 pieces
- Rotogrind - 1 pieces
- Pneumatic transport with fan - 2 pieces
- Cyclone - 2 pieces
- Bunker for mixing materials - 2 pieces
- A line- 2 spirals for passing material - 1 pieces
- line- 2 turnstiles for passing material - 1 pieces
- Line A dryer with four cyclones - 1 pieces
- Line B dryer with four cyclones - 1 pieces
Mixed briquetting and pelletizing line - sawdust briquettes 600-900 kg/hour and pellets 500-700 kg/hour,
density of straw briquettes at the outlet up to 1250 kg / m.cubes,
briquette diameter 72-74mm
The complete briquette briquettes line contains:
+ Minicomplex pellet press model: GFD-0.7 series "PellTech" - Soft-starter
mechanical briquetting press model: BT-070-800Max series "BriqTech" + Radiator and fan oil cooling system and oil heating
+ Lighter head cooling system that will keep the temp...
This line allows the manufacture of wood pellets from sawdust, shavings and small chips (shredded wood).
The production capacity is 300/350 kg/h depending on the material.
The pellet press is of the "flat die" type and is equipped with 4 rollers with automatic lubrication.
See the details of the line's components below.
SUPER COMPACT LINE composed of:
- wood chip extractor with auger ECP-2000L, assembled
with CRT-25 amendment dispenser
- humidification pump with tank and nozzle KIT UMD
Sell automated pellet production line
Year of production 2022
Complete technology from moving floor to robotic packaging system - capacity of 2.5t/hour
The line consists of, among others:
- GP530 granulator
- drum dryer
- 1MW boiler
- 45kW mill
- robotized packaging system ( ABB irb 660 )
Line new ( unused )
Technical Details :
For sale complete plant for wood pellet production, made from CPM, capacity 6t/h. A most of the machines from line are produced in between 2008-2010.y., except presses for making pellets (its bit older then rest of the line, but complete renewed before restarting. Line is consisting from: 1.Chain conveyor for logs transport. 2.Lift with angle platform for dosing material. 3.Entrance belt transporter with magnetic section for detection of iron. 4.Grinder (hammer mill) BRUKS 5...
Granulator for sawdust series "PellTech" model: GFD-0.2 Fermier
Evenly pressing pellet head with 4 rollers, roller lubrication without stopping production.
Pellet production up to 250 kg / h
Frequency converter 18.5 kW
Pellet diameter: sawdust 6 mm or straw 8 mm
Productivity up to: 250 kg / h depending on raw materials.
Working diameter of rotating dies mold: 280mm
Die thickness: 36 mm
Die rotations: +/- 155 rpm
Pinch roller diameter: 133mm
Large drive pulley diameter:...
Complete pellet plant, capacity 3t/hour.
Included all equipment from chipping station to palletizer.
Rudnick&Enners chipper 90kw
Swiss Combi rotatiom drier with chipps stove completley automated
Hammer mill Buhler 110kw
Pellet press Munch 220kw
Pellet press Balerini 90kw
Pellet cooler 3t/hour
Filling and paletizing sistem Moller.
Complete plant is covered with inverters, all machines!
Siemens controll unit for whole plant(PLC, touch screens).
All PLC programs are available.
We produce non-standard products:
Pellet lines 500kg / h to 10t / h
Pellet presses TSF - motor powers from 55 kw to 500 kw
Basic pelleting press consisting of:
split cast housing with cooling fins in the drive area
drive consisting of worm shaft and worm wheel (made of bronze), in good condition
main shaft with grooves and new fether keys
main bearing / worm shaft bearings + seals in the gear unit completely revised / checked
new oil system installed with oil pump, filter, flow meter, thermometer and dirt trap
knifes holder and knifes below the die revised and checked
die seat revised and checked
pelleting press du...
Wood pellet granulator OGM 1,5 made by AB Radviliškis factory-Lithuania.
Full set, engine motor 75 kw, new GRAF ring die/matrix 8mm,with roller.
It is made new electricity box with all safety parts, reactive energy savings. It is possible to test before buying.
Capacity: 1 -1,5 t/hour
PRICE: 17 500 EUR
Rapeseed or Straw pelletizing line 500-800 kg/hour, straw pellets 6mm or 8 mm, output pellet density up to 1350 kg/m.cub
The complete rapeseed or straw pelletizing line contains:
- Complex for chopping rectangular or round bales with additional food belt model: CGS-1
- Raw material homogenization hopper - Volume 3 m.cubes, overload sensor, feed auger
- Minicomplex pellet press model: GFD-0.7 - Soft-starter
- Semi-automated bag dosing system with automated bag bagging, bag gluing with foot pedal,...
Granulator TSF200 with two rollers, rotating matrix
Productivity ~ 60-300 kg / h
Engine power 7.5kW (depending on raw material)
The thickness of the matrix is 3.2 cm
Pellet diameter (specify when ordering) standard 6mm
Number of pressing rollers 2pcs
Machine weight ~ 250kg
Granulator TSF230 with two rollers, rotating matrix
Productivity ~ 100-350 kg / h
Engine power 11kW (depending on raw material)
Matrix thickness 3.5 cm
Pellet diameter (specify when ordering) standard 6mm
Number of pressing...
A complete line for the production of wood pellets with a capacity of 1.2 tons per hour from wood chipping and handling to the final product of wood pellet packed in nylon bags.
The complete line was designed by Italian engineering company FIDA who also has its own transport equipment, silos and conveyers. All the drawing and schematics and documentation is available. The project was financed by EU and was valued at about 1.3 million EUR which documentation confirms.
Compleete line was inspe...
Minicomplex pellet press Series "PellTech" model: GFD-0.7 rotary flat mold
Pellet productivity up to: 400 - 700 kg / hour depending on the raw material.
Flat mold diameter: 400 mm
Pellet diameter: 4-6-8-10-12 mm
Adjustable pellet length: 15 - 30 mm
Main Engine - 1 X 45 kW - Soft-starter
Total installed power - 55 kW
Three-phase current - 400V, coil voltage 24V / 230V within the limits of +/- 5%, frequency 50 Hz
Dimensions: 7500 X 2500 X 3000
