Used other sheet metal working machinery for sale (229)

Year of construction: 2022, condition: ready for operation (used), controller manufacturer: SIEMENS, table load: 3,000 kg, Automated sheet metal storage system manufactured in 2022. This TRUMPF Automated Sheet Metal Production System features a storage height of 7,900 mm and a maximum load per storage location of 3,000 kg. It includes 266 storage locations and supports sheet formats of 3,050 x 1,525 mm. If you are looking to get high-quality automated storage capabilities, consider the TRUMPF Automated Sheet Metal Production System we have for sale. Contact us for further details. • Storage system: STOPA Compact II • Type: Automated sheet metal storage system with chaotic storage management • Storage height: 7,900 mm • Sheet format: 3,050 x 1,525 mm • Maximum load per storage location: 3,000 kg • Number of storage locations: 266 Iedpfx Aiszu Sugsgoba • Total storage capacity: 798 t • Configuration: 8 sections/towers, up to 37 storage levels per section • Pallet format: GF 3050 x 1525 x 90 mm • Pallet types: SPO, SPMgl • Loading heights: 185 / 275 / 460 mm • Functions: Automatic material storage and retrieval; automatic material supply to connected production cells; storage interface for integrated production machines • Storage control • Server operating system: Windows Server 2022 • Central storage management and automated material flow management • Integration with TRUMPF production equipment • Connected production cells • TRUMPF TruLaser 5030 fiber (L76) • Machine type: CNC 2D fiber laser cutting machine • Working area: 3,000 x 1,500 mm • Laser source: TruDisk 6001, 6,000 W • CNC control: Siemens SINUMERIK 840D sl • TRUMPF TruMatic 6000 fiber • Machine type: Combined CNC punching and fiber laser cutting machine • Working area: 3,050 x 1,550 mm • Laser source: TruDisk 3001, 3,000 W • Maximum punching force: 180 kN • Linear tool magazine: 25 positions • TRUMPF TruBend Center 7030 (B34) – Cell 1 • Machine type: Automatic panel bending center • Max bending length: 3,123 mm • Max thickness: structural steel 3.0 mm; stainless steel 2.2 mm; aluminum 4.0 mm • Max box height: 220 mm • TRUMPF TruBend Center 7030 (B34) – Cell 2 • Same specifications as Cell 1 • System functionality (summary) • Central automated storage and retrieval of raw sheet material • Automatic supply of material to connected laser, punch-laser, and panel bending cells • Automatic transfer between storage and production stations • Centralized, high-capacity sheet handling • Main system configuration • 1 x STOPA Compact II automated sheet storage system • 1 x TRUMPF TruLaser 5030 fiber 2D laser cutting cell • 1 x TRUMPF TruMatic 6000 fiber punching and laser cutting cell • 2 x TRUMPF TruBend Center 7030 automatic panel bending cells Additional equipment • For TRUMPF TruLaser 5030 fiber (L76) • Automatic pallet changer • LiftMaster Compact 1530 (automatic loading and unloading) • STOPA storage connection/interface • For TRUMPF TruMatic 6000 fiber • SheetMaster 3000 x 1500 mm (automatic sheet handling) • GripMaster 3000 x 1500 mm • Storage system integration/interface • For TRUMPF TruBend Center 7030 (both cells) • 2-axis part manipulator • 5-axis rear stop • Rotary manipulator • ToolMaster Bend • Automatic loading and unloading • Storage interface • System-wide • Central storage management server (Windows Server 2022)

Year of construction: 2002, condition: ready for operation (used), overall weight: 4,500 kg, cutting length (max.): 2,080 mm, sheet thickness (max.): 6 mm, Hydraulic shearing machine manufactured in 2002. This HERA TS 2000x6 features a maximum sheet thickness of 6 mm and a cutting length of 2080 mm. It operates with a stroke rate of 18 strokes per minute and is powered by an 11 kW motor. If you are looking to get high-quality shearing capabilities, consider the HERA TS 2000x6 machine we have for sale. Contact us for further details. - Stroke Rate: 18 1/min- Motor Power: 11 kW- Noise Level: < 70 dB(A)- Current Type: 3~ AC- Operating Voltage: 400 VAC- Control Voltage: 24 VDC- Frequency: 50 Hz- Fuse / Backup Protection: 32 A Isdpfx Aiezr H Nmogeba

Year of construction: 2019, condition: used, machine/vehicle number: 37943, Maximum capacity: 2,200 kN, working width: approx. 400 cm, automatically adjustable stops, automatic tool changer, 1-level rolling carriage with accessories. Ibedjzqzakopfx Aigja

Year of construction: 2023, operating hours: 2,980 h, condition: used, machine/vehicle number: 140497, Fiber laser cutting system for large-format sheets, frame construction, sheet size up to 4,065 x 2,025 mm, travel ranges: x: 4,200 mm, y: 2,070 mm, z: 130 mm, powerful IPG laser source with 10 kW power, highly developed cutting head with automatic adjustment of the focus position, automatic pallet changer system, integrated control and drive system, Touch-L control with a 19" flat screen, scrap conveyor with collection container, large-format automation type FL for loading and unloading pallets for formats up to 4,000 x 2,000 mm in 2 levels, including Thermotec cooling unit and Camfil filter unit. Ijdpszqzb Uefx Aigoba

Year of construction: 2024, operating hours: 6,782 h, condition: used, machine/vehicle number: 40499, Fiber laser cutting system for large-format sheets, frame construction, sheet size up to 4,065 x 2,025 mm, travel ranges: x: 4,200 mm, y: 2,070 mm, z: 130 mm, powerful IPG laser source with 10 kW power, highly developed cutting head with automatic adjustment of the focus position, automatic pallet changer system, integrated control and drive system, Touch-L control with a 19" flat screen, scrap conveyor with collection container, large-format automation type FL for loading and unloading pallets for formats up to 4,000 x 2,000 mm in 2 levels, including Thermotec cooling unit and Camfil filter unit. Ibodpfx Ajzqzcfjigoa

Year of construction: 2022, operating hours: 8 h, condition: ready for operation (used), controller manufacturer: SIEMENS, controller model: SIMATIC HMI, Fully electric CNC tube bending machine manufactured in 2022. This BLM E-TURN 52B features a Siemens Simotion CNC control system and offers advanced bending capabilities, including fixed radius, variable radius, and multi-radius bending. It is designed for low energy consumption and includes programmable booster and tooling stacks for enhanced performance. If you are looking to get high-quality tube bending capabilities, consider the BLM E-TURN 52B machine we have for sale. Contact us for further details. • Number of axes: 14 • Energy consumption: Low • Bending direction: Right and left bending in-process (automatic direction change) • Bending capability: Fixed radius, variable radius, and multi-radius • Tool configuration: 3 tooling stacks + 3 additional tooling stacks • Tool stack height: 60 mm (2.4") • Tube capacity: • Carbon steel (FE37): max diameter 50.8 mm (2.0"), max wall thickness 1.5 mm (0.06"), based on RM 1.5D, Vy50% • Stainless steel (AISI 304): max diameter 50.8 mm (2.0"), max wall thickness 2.0 mm (0.08"), based on RM 2D, Vy50% • VGP3D software features: • 3D graphical programming Ibsdpfxozqtzgj Aigsa • Part feasibility verification with collision detection • Automatic cycle time calculation • Automatic machine cycle generation • Faster quotation preparation and production planning • Standard equipment: • Electrically driven pressure dies • Left and right counter-die supports • Programmable booster / variable-radius unit (booster force 20,000 N; booster speed 1,000 mm/min) • Mandrel bars: 10 mm (0.39"), 16 mm (0.63"), 24 mm (0.94") • CE compliant Additional equipment • WELDET-07: Programmable weld seam positioning system (optical weld seam detection based on color contrast; compatible with ET30, ET35, ET40, ET52) • MC1052-01: Blind hole detection device

Year of construction: 2022, operating hours: 24 h, condition: ready for operation (used), controller manufacturer: SIEMENS, controller model: SIMATIC HMI, This 9-axis BLM DH4010 fully electric CNC wire bending machine was manufactured in 2022. It features a dual-head design with a maximum wire diameter capacity of up to 12 mm for wire with tensile strength of 600 MPa. The machine includes advanced programming software, realistic 3D simulation, and automatic wire feeding. If you are looking to get high-quality wire bending capabilities, consider the BLM DH4010 machine we have for sale. Contact us for further details. • Machine type: Fully electric CNC wire bending machine with automatic wire feeder • Number of axes: 9 • Configuration: Dual-head design with two wire bending heads • Maximum wire diameter: • Up to 12 mm (1/2") for wire with tensile strength of 600 MPa (87,000 psi) • Up to 10 mm (3/8") for wire with tensile strength of 1,000 MPa (145,000 psi) • Maximum distance between bending heads: 3,070 mm (121")The machine is equipped with VGP3D 3D graphical programming software featuring: • Realistic 3D simulation for part feasibility verification • Automatic collision detection • Cost estimation • Automatic machine cycle generation • Automatic optimization of the bending sequence Standard and Included Equipment Ibjdozqtgvepfx Aigea • Centrally positioned 3D manipulator • Head-mounted grippers for workpiece holding and ejection • Variable-radius bending • 6-position bending turret • Automatic wire feeding unit • End-processing carriage with linear orthogonal wire cutting unit • Wire cutting capacity: up to 12 mm (1/2") for wire with a tensile strength of 600 MPa (87,000 psi) • Wire chamfering unit • CE compliantDH4005-03 • Tube straightener and RV straightening unitDHSD4-02 • Straightening rollers (9+9) with V-groove for wire diameters from 2 to 4 mmDHSD6-02 • Straightening rollers (9+9) with V-groove for wire diameters from 4 to 6 mm

Condition: ready for operation (used), Year of construction: 1979, Available immediately ex-works: Swivel bending machine, Lotze Ibjdpszukhrofx Aigea Type 161 / 2500 / 6 Year of manufacture 1979 Bending length 2550 mm Material thickness up to 6 mm Drive power 7.5 kW Weight 6 tons Price: EUR 6,750.00 plus VAT, ex-works.

Condition: ready for operation (used), Year of construction: 1982, Available immediately, ex works: Shearing machine, Schröder Capacity: 2500 x 4 mm Isdpfx Aiszukhljgoba Cutting length: 2550 mm Material thickness: up to 4 mm Electric back gauge: 1000 mm Drive power: 5.5 kW Weight: 3.5 tons Price: EUR 4,750.00 plus VAT, ex works

Year of construction: 2018, condition: ready for operation (used), Brazing line manufactured in 2018. This SCAME BRAZING LINE 50-20-350-GI-DR features a maximum temperature of 1150 °C and operates with an electric power source of 85 kW. The continuous longitudinal conveyor system efficiently moves parts along a passage chamber measuring 50 x 20 x 350 cm. If you are looking to get high-quality brazing capabilities, consider the SCAME BRAZING LINE 50-20-350-GI-DR machine we have for sale. Contact us for further details. • Power source: Electric • Connected thermal load: 85 kW • Supply voltage: 3 x 400 V @ 50 Hz • Maximum temperature: 1150 °C • Operating temperature: 1120 °C • Gas pressure: 30–50 mbar • Atmosphere used: Endothermic Gas (ENDO) • Production capacity: Variable (kg/h) Iodpfx Aozqctxsigjba • Passage dimensions (W x H x L): 50 × 20 × 350 cm • Drive & motion system: Continuous longitudinal conveyor system moving parts along the 350 cm passage chamber at controlled speed (no conventional CNC cartesian axes)

Condition: excellent (used), Year of construction: 2013, operating hours: 55,200 h, functionality: fully functional, machine/vehicle number: A0035A0294, Machine type: TruPunch 3000-1300 (S11) TruPunch 3000-1300 (S11), medium format 1250/2500 We are the first and only owner of the machine. Machine with complete history and service documentation. Machine is in fully working order and in continuous operation. Technical data: Width 6500 mm Depth 6203 mm Height 2252 mm Max. punching sequence (E = 1 mm) 1000 1/min Max. punching sequence – marking 2500 1/min Punching mode, X-axis 2500 mm Punching mode, Y-axis 1250 mm Max. sheet thickness 6.4 mm Max. workpiece weight 160 kg Max. punching force 180 kN Multitool tool change time 0.3 sec Number of tools/sheet clamps | 18 pcs / 2 pcs Max. part size, part flap when punching 500 mm x 500 mm Max. part size, rigid slide for punching (with sliding table) 80 mm x 50 mm Average power consumption with active automatic shutdown 0.3 kW Average power consumption during production 5.6 kW Additional, non-standard machine equipment: 1) Thread forming function with thread counter and thread forming tool damage control: chip-free thread forming is possible in both structural steel and stainless steel and aluminum. The threading tool is mounted like all other tools in the head. Thread size to be machined ranges from M 2.5 to M10. A thread sensor enables control of the threading tool damage. User-friendly operation, including lubricant level control. 2) Marking/surface embossing function: fast marking using appropriate tools. High-quality knurling can be performed at high speed. 3) Lowerable die: the lowerable die enables scratch-free processing because it moves downward when positioning the sheet metal. 4) Additional clamping device: recommended for processing very thin sheets and when using roller tool machining technology. An additional 2 clamping devices can be installed. In combination with the SheetMaster Compact, a third clamping device is recommended. 5) 3 x Option - vertically movable clamping device: the clamping devices move vertically (maximum stroke 12 mm); enables direct processing of the sheet metal at the clamping devices. This option reduces scratches from high forming dies. 6) Sensor in the slide for small parts: control of the slide for small parts (included in the "Nibbling-free machining" option). 7) Second locating pin: the pin is located on the outside on the right side. 8) RTC tool cassettes: 17 tool cassettes with die plates, enabling quick machine retooling. 9) Brush table with unloading and loading assistance: a brush table is recommended for processing particularly delicate materials. Vertically moving balls embedded in the table facilitate the loading and unloading process. We invite you to contact us. Ibsdpjzd U D Nsfx Aigoa

Year of construction: 1997, condition: ready for operation (used), A complete punching line with Helmerding eccentric press is available. 1) Eccentric press Helmerding KDH 100, year of manufacture: 1997, power: 11kW, pressing force 30° before and after: 100t, stroke adjustment: 8mm-110mm, ram adjustment: 80mm, stroke rate: 40-140 strokes/min, length: 2100mm, width: 1500mm, weight: approx. 12000kg. 2) Kohler 1000.1 reel, year of manufacture: 1983, power: 1kW, load capacity: 1000kg, length: 1500mm, width: 1100mm. 3) Straightener Kötje RM-7-300-60, year of manufacture: 1998, power: 3kW, max. strip width: 300mm, straightening roller diameter: 60mm, number of straightening rollers: 7, length: 1400mm, width: 1200mm. 4) Roller feed Kötje EWV 80-50-S, year of manufacture: 1998, power: 4kW, length: 750mm, width: 700mm. Documentation available. On-site inspection is possible. Ibedjvnd Snepfx Aigja

Year of construction: 1987, condition: ready for operation (used), A three-roll plate bending machine Kramer is available. Working width: 2000mm, max. plate thickness: 3mm, power: 3kW. An on-site inspection is possible. Isdpfxoyttv Rs Aigsba

Year of construction: 2017, condition: ready for operation (used), An asymmetrical three-roll plate bending machine MG is available. Working width: 2000mm, roller diameter: 130mm, max. plate thickness: 3mm, power: 6kW, weight: approx. 2000kg. An on-site inspection is possible. Ibsdeyttwbspfx Aigja

Year of construction: 2008, condition: ready for operation (used), X-axis: 2500mm, Y-axis: 1270mm, positioning speed X-axis/Y-axis: 80/90m/min, simultaneous axis speed: 100m/min, punching capacity: 200kN, number of turret stations: 51, max. material thickness mild steel: 3.2mm, max. material weight at traverse speed F1/F4: 50/150kg, positioning accuracy: ±0.1mm, stroke rate X-axis: 350/min, stroke rate Y-axis: 260/min, max. stroke length: 42mm, max. feed speed X-axis/Y-axis: 80/60m/min, turret speed: 30rpm, compressed air requirement: 500l/min, operating air pressure: 5bar, connected load: 19kVA, length: 4165mm, width: 5120mm, height: 2082mm, height with mirror: 3028mm, weight: 13t, operating hours: 4531h, regularly maintained by the manufacturer, with documentation, without punching tools. An on-site inspection is possible. Ibodpfx Asza E S Djigea

Year of construction: 2005, condition: ready for operation (used), A hydraulic CNC plate shear Baykal is available. Cutting length: 3060mm, max. sheet thickness (St42): 10mm, operating pressure: 260bar, stroke rate: 12/min. Machine dimensions X/Y/Z: approx. 4000mm/2600mm/2000mm, weight: approx. 9600kg, control system: Delem DAC 310. Documentation available. On-site inspection is possible. Ibodpfx Asya Hwzjigea

Year of construction: 1991, condition: ready for operation (used), Working width: 4040mm, max. sheet thickness steel/stainless steel: 5mm/3mm, back gauge: 1000mm, weight: approx. 7000kg, control system: Elgo, working hours: approx. 22051h. An on-site inspection is possible. Iodpfx Aeyu T Eboigsba

Year of construction: 2000, condition: ready for operation (used), A hydraulic 4-roll plate rolling machine Promau (Prümau) is available. Working width: 3000mm, bending capacity: 13mm, pre-bending capacity: 10mm, rolls: 4. An on-site inspection is possible. Iedpjzhw Tuefx Aigeba

Condition: ready for operation (used), Year of construction: 2006, A blank turner for sheet metal blanks is available. Max. Blank dimensions X/Y: 1600mm/1100mm, max. blank stack height: 190mm, max. stack weight: 1500kg, max. stack inclination: 15°, cycle time with pallets: approx. 30s, machine dimensions X/Y/Z: approx. 3500mm/2500mm/2500mm, weight: approx. 3000kg. Documentation available. On-site inspection is possible. Iodpov I Dcgefx Aigjba

Year of construction: 2010, condition: ready for operation (used), A CNC turret punching machine Amada and an automatic loading and unloading unit LKI Käldman (Amada) are available. 1) CNC turret punching machine Amada EMZ3610, year of manufacture: 2010, pressing force: 300kN, travel X/Y: 2500mm/1525mm, travel X/Y with repositioning: 5000mm/1525mm, max. material thickness: 4.5mm, max. table load: 160kg. Traversing speed X/Y: 100m/80m/min, axis speed: 128m/min, positioning accuracy: +/-0.1mm. Turret stations 45, auto-index stations: 2xB/2xC, turret speed: 30rpm, stroke rate: 1000 strokes/min, machine weight: approx. 21000kg. 2) Loading and unloading system LKI Käldman (Amada) MP Sheetcat 3015, year of manufacture: 2017, min. sheet dimensions X/Y: 1000mm/300mm, max. sheet dimensions X/Y: 3050mm/1525mm, sheet thickness: 0.8mm-6mm, max. sheet weight per pallet: 3000kg, suction cups: 34, machine dimensions X/Y/Z: approx. 8400mm/3600mm/3100mm. Documentation available. On-site inspection is possible. Isdpfsv Rp Tcsx Aigjba

Year of construction: 1987, condition: ready for operation (used), An EHT hydraulic guillotine shear refurbished in 2023 is available. Cutting length: 3000mm, max. sheet thickness steel/VA: 4mm/2mm, backgauge: 10mm-1000mm, adjustment speed: 180mm/s, stroke rate: 18-31 strokes/min, oil volume: 160l. Machine dimensions X/Y/Z: approx. 3700mm/2100mm/2150mm, weight: approx. 4800kg, operating hours: 44024h. The cylinders, blades and hoses were overhauled in 2023. On-site inspection is possible. Ibodpfx Ajwrhwujigea

Year of construction: 1990, condition: ready for operation (used), An old GEKA (Georg Eckart) guillotine shear is available. The emergency stop of the machine is defective. On-site inspection is possible. Isdpfxsuxdife Aigoba

Year of construction: 2022, condition: ready for operation (used), A GSW decoiler is available. Load capacity: 3000kg, strip width: 650mm, max. strip cross-section: 107.5mm/0.35mm, machine dimensions Y/Z: approx. 1150mm/2000mm. An on-site inspection is possible. Ibsdsyz Apwspfx Aigea

Year of construction: 1990, condition: ready for operation (used), A hydraulic Euromac notching machine is available. Notching capacity steel/stainless steel: 6mm/5mm, blade length: 220mm, working angle: 90°, angle adjustment: 30°-140°, stroke rate: approx. 50/min. Machine dimensions X/Y/Z: approx. 1100mm/950mm/1300mm, weight: approx. 800kg. An on-site inspection is possible. Ibedpfxezd Ei Ao Aigsa

Year of construction: 1998, condition: ready for operation (used), A hydraulic 3-roll plate rolling machine Omcca is available. Working length: 2050mm, max. plate thickness rolling/pre-bending: 8mm/6mm, roll diameter: 200mm. Machine dimensions X/Y/Z: approx. 3200mm/900mm/1500mm, weight: approx. 3300kg. On-site inspection is possible. Iodsycwrzjpfx Aigeba
