Used throughfeed machining centers for sale (138)

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground, high-precision recirculating ball screws. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. This characteristic is important for ensuring balanced movement even in more complex tasks. The various axes are driven by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters, which can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different Nsdpfxevvi Rfs Af Sowr

Condition: used, Year of construction: 2024, 1 unit CNC Wood Router HOLZFRAESE AXOLOX 4021 Working area X 4000mm, Y 2100mm, Z 100mm, Rated voltage 230V, Infinitely variable spindle speed 1000-24000 rpm, PC with Windows 10, control software Beamicon2, vacuum table consisting of six individually adjustable elements, vacuum pump with a capacity of 160 m3/h, including piping, as shown in pictures and upon inspection, self-dismantling required Color: grey Year of manufacture: 2024 Machine number: SN: 0232024 Approximate weight in kg: 2500 Condition: used Payment method: advance bank transfer Item location: joinery/workshop hall 2 Shipping: Pickup only - Shipping is not offered for this item! Nedpfxox Ifhce Af Sewr

Condition: as good as new (ex-display), Year of construction: 2025, max. workpiece length X:: unlimited Min. workpiece length X: : 250mm Traversing speed X:: 0-25 m/min. Max. workpiece length Y: : 1,000 mm Min. workpiece width Y: : 85mm Traversing speed Y: 0-50 m/min.: 0-50 m/min. Max. tool thickness Z: : 60 mm Min. workpiece thickness Z: : 10 mm Traversing speed Z: : 0-20 m/min. Vertical spindles Y - direction: : 5 pieces Horizontal double drilling spindles X - direction: : 2 + 2 pieces Horizontal double drilling spindles Y - direction: : 1 + 1 piece Units: : 16 mm drilling head Special equipment: Clamex package, door package Drill spindle speed: : 4,000 rpm. Distance drill spindle: : 32 mm Motor power: : 1.7 kW Grooving saw: : X - direction Saw blade Ø: : 125 mm Suction connection Ø: : 150 mm Dimensions (LxWxH): : 1,920 x 2,818 x1,620 mm Njdpfx Aor Hbhvef Sowr Weight: : 1,500 kg

Condition: used, TF 100/20 - Year of manufacture: 2017 - Front and rear table - Workpiece height 60mm, maximum workpiece length unlimited - Maximum workpiece width 1000mm, minimum width 80mm - Traverse speed 0-25m/min - Air tables in the work area - 6-position tool changer - Ball screw and linear guides - DXF file import - Milling unit - Spindle speed 1000 to 18000 rpm - 3.3 kW - Drilling unit with 16 drills for 5-sided machining - Grooving saw unit - Weight: 1380kg - 400 Volts Nwodpfx Afex Ha Rps Sor - 15.8 kW

Condition: used, Workspace: 2,600 x 1,250mm X-axis: 2.700 mm Y axis: 1.600 mm Z-axis: 250 mm Spindle motor: 7,5 kW Nodjn A Dwgopfx Af Sswr feed: Max. 38 m/min Video: On demand CNC machining center SCM Routech R 3000 for processing plate material with automatic loading (vacuum destacker) and outlet. Special price for self-dismantling and self-collection.

Condition: new, Year of construction: 2022, The new numerical control universal drilling machine for woodworking shops and craftsmen with very good price / performance ratio. machine incl. options: sensor for work piece calibration / measuring Nedpfx Afofhy R Ne Sowr pressure booster for drilling spindles in Z - axis automatic lubrication system incl. SCM software "Maestro cnc" qwerty keyboard 10'' Touch Screen dDrilling head and grooving operations with 11 independent spindles and integrated blade in X direction max. workpiece dimensions X-Y-Z = 3000 x 900 x 50 mm min. workpiecedimensions X-Y-Z = 300 x 90 x 10 mm max. speed der X-Y axis 20 m/ min spindels in X-axis # 2 spindels in Y-axis # 2 spindels in Z-axis # 7 grooving unit saw blade DM 125 mm Advise used machines: • Technical data without obligation, mistake and intermediate sale reserve. • Price is considered ex-location price • All articles or machines are bought as seen without any entitlement on warranty. • It is left to the choice of the buyer to view the machines before at its location. • Special arrangements are possible but only valid in written form. (We answer your inquiries only with stated address + telephone number!)

Condition: used, Year of construction: 1999, Storage location: Nattheim Nedpfxevvi Rxe Af Sewr

Condition: excellent (used), CNC-Gantry Flexible Automatic through-feed Boring Machine with Dowels inserting system Movable panel (horizontal position of workpiece/panel), movable working head Numerical Control Power Control, Software WoodWOP Overall integral safety cabin (enclosure) of the machine Panels (workpieces) feeding by motorized belts 3 Feeding speed (m/min) 1 - 90 (ca.) Minimum workpieces dimensions (X - Y - Z) mm 250 x 100 x 12 Maximum workpieces dimensions (X - Y - Z) mm 3000 x 1400 x 60 Maximum stroke of the axis (X - Y - Z) mm 3580 x 1838 x 125 Two panels simultaneously processables (in Y axe) mm 600 + mm 600 Total installed power (Kw) 38 WORKING GROUPS (TOP): Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 38 + 3 special Independent horizontal boring spindles (No.) 6 Circular Grooving Saw (on X axis) dia. (mm) 100 Nwjdpfed Nvi Dox Af Sor Vertical electro-spindle (No.) 1 x SK 30 (Vertical electro-spindle motor power (Kw 6) Automatic Tools Changing System, Tools storage plate (No. 3 folds- positions) WORKING GROUPS (HORIZONTAL) Drilling heads with horizontal spindles (No.) 2 Horizontal drilling spindles - Right side (No.) 13 + Left side (No.) 13 Inserting nozzle and glue injectors (Right side) No. 2 + (Left side) No. 2 Storage tanks for automatic feeding of the dowels (No.) 1

Condition: used, machine/vehicle number: 007826, X axis working area: 5600 mm Y axis working area: 1200 mm Nwsdpfxjwgkt Ue Af Ssr Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 17 Total number of tool changer positions: 12

Condition: used, Year of construction: 2018, total length: 1,750 mm, total width: 1,800 mm, total height: 1,800 mm, Empty weight: 975 kg What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Year: 2018 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 173180025 - Main motor power [kW]: 3 Nodpsxzrfrofx Af Sowr - Working range X [mm]: 3000 - Working range Y [mm]: 3000 - Working range Z [mm]: 50 - Transport dimensions: 1750mm x 1800mm x 1800mm (l x w x h) - Transport weight [kg]: 975kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2011, Weight: approx. 4500 kg Nodpsvvi R Esfx Af Sowr Storage location: Nattheim

Condition: excellent (used), FLEXIBLE C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), static working head - Horizontal position of the panel (workpiece) Nodslkdpmjpfx Af Sswr Numerical Control PowerControl (Software woodWOP) Safety cabin (enclosure) of the working head Separate electric and command cabinet No. 2 Workpieces fixing clamps (for the panels introduction in the working area) WEEKE Prepositioning Unit - to position workpieces in machines with clamp grippers faster. In-feeding working table (panel support) and Out-feeding table (with motorized belts) With pushing system to automatically infeed the workpiece Minimum workpieces dimensions (X - Y - Z) mm 200 x 70 x 8 (2 x 4 mm) Maximum workpiece dimensions (X -Y- Z) mm 2500 x 1000 (option mm 1300) x 80 (2 x 40 mm) Two panels simultaneously processables (in Z axe) WORKING GROUPS (TOP): 2V32, 2H8X/Y2, N2 X-Y90,F2-ETP-6 KW No. 1 Vertical electro-spindle ETP-6 (power Kw 6) No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 23 Vertical drilling spindles (power Kw 2.3) No. 5 Horizontal drilling spindles (4 in X + 1 in y) WORKING GROUPS (BOTTOM) No. 1 Vertical electro-spindle ETP-6 (power Kw 6) No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 23 Vertical drilling spindles (power Kw 2.3) No. 5 Horizontal drilling spindles (4 in X + 1 in y)

Condition: used, Year of construction: 2019, Incl. tools CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and milling made for you! This numerically controlled machining center is equipped with a wide range of milling and drilling tools to meet every woodworking requirement. - Highly powerful - with 8,000 rpm drilling spindles and . technology, the most stable spindle available on the market, with more than 1,000 maintenance-free hours of use. - Optimally and comprehensively equipped - the vacuum cleaners can be individually configured with the TV FLEX work table to customize the machine to meet individual requirements. - Easy and understandable programming thanks to the integrated Cad-Cam MAESTRO CNC software - Easy to operate; the lowered machine frame makes the work table accessible at all times. The control cabinet and vacuum pump are integrated into the machine bed, and in the PRO SPACE version, no additional structural protective measures are necessary. Supporting structureThe supporting structure consists of a particularly strong monolithic steel base, ribbed and very robust. The particularly wide support was specifically designed to give the machine stability, ensuring constant precision in all working conditions. The machine does not need to be anchored to the ground. The base provides a large and solid support for the mobile column: the work unit is equipped with a balanced, stable and resistant support that can withstand the most extreme stresses, ensuring superior performance and greater precision. The mobile gantry consists of a solid single part anchored to the base and the work unit is fixed to it and moves along Y and Z axes, also on prismatic guides with ball return sliding blocks of the highest quality. The movement of the lower moving unit (X-axis) and the working unit along the crosshead of the moving unit (Y-axis) is achieved thanks to the power transmission via a rack and pinion with helical teeth; This creates a greater tooth-to-tooth thrust, which achieves greater acceleration and higher speed along the X and Y axes. The specially designed helical gearing ensures less wear on the mechanical components and less noise. The vertical Z axis is driven by a screw with ball return, which ensures perfect balance with dynamic loading and strong acceleration and deceleration. The main milling unit is directly coupled to the Z axis carriage and ensures very high quality finishing as vibrations are completely eliminated. Translation along the X-Y-Z axes is carried out by brushless motors driven by static inverters. These ensure:- Reduced machining times thanks to improved acceleration- Better positioning accuracy thanks to the high resolution encoder- Elimination of setup operations when switching on the machine thanks to absolute encoders- Elimination of general maintenance operations as there are no brushes with the "brushless" systemThe management of the axis displacement and in general of the working elements of the machine is done via e Nwjdevvi Scspfx Af Ssr

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Rubber-coated vertical rollers as fence and feeders during workpieces process In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Separate electric and command cabinet Total installed power (Kw) 35 Nwsdpfx Aeihfiijf Ssr WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Condition: used, Year of construction: 1995, Storage location: Supplier Nwodpfxjvvi Sis Af Sor

Condition: excellent (used), FLEXIBLE C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), static working head. Horizontal position of the panel (workpiece) Numerical Control Xilog Plus 2 (Software Xilog Plus 2) Safety cabin (enclosure) of the working head. Separate electric and command cabinet No. 2 Workpieces fixing clamps (for the panels introduction in the working area) With pushing system to automatically infeed the workpiece Nedpfxefz I Ufj Af Sswr In-feeding table (with motorized belts) and Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 250 x 70 x 10 (2 x 5 mm) Maximum workpiece dimensions (X -Y- Z) mm 3000 x 1300 x 80 (2 x 40 mm) Two (2) panels simultaneously processables (in Z axe) WORKING GROUPS (TOP): 2V32, 2H8X/Y2, N2 X-Y90,F2-ETP-6 KW No. 1 Vertical electro-spindle HSK63F (power Kw 7,5) No. 1 Circular Grooving Saw - dia. mm 125 No. 48 Vertical drilling spindles No. 10 Horizontal drilling spindles (8 in X + 2 in Y) WORKING GROUPS (BOTTOM) No. 1 Vertical electro-spindle HSK63F (power Kw 7,5) No. 1 Circular Grooving Saw - dia. mm 125 No. 48 Vertical drilling spindles No. 10 Horizontal drilling spindles (8 in X + 2 in Y) Inserting nozzle and glue injectors. Storage tanks for automatic feeding of the dowels

Condition: used, Storage location: Nattheim Nwsdpfxswkirqj Af Ssr

Condition: excellent (used), C.N.C. WORKING CENTER with 3 axes (X-Y-Z) - Goose-neck type Movable panel (workpiece), static working head, Horizontal position of the panel (workpiece) Numerical Control with Software BiesseWorks (Separate electric and command cabinet) Safety cabin (enclosure) of the working head, Front emergency carpets In-feeding working table (panel support) Nsdpfx Afswb Allj Sowr No. 2 Workpieces fixing clamps (for the panels introduction in the working area) Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 90 x 70 x 8 (ca.) Maximum workpieces dimensions (X - Y - Z) mm 3000 x 1300 x 60 (ca.) Total installed power (Kw) 24 BOTTOM WORKING UNITS: Independent vertical boring spindles (No.) 29 Independent horizontal boring spindles (No.) 10 (8 X + 2 Y) Circular Grooving Saw (on X axis) dia. (mm) 160 (1 x kw 3,5 ca.) Vertical electro-spindle (No.) ISO 30 (1 x kw 4,5 ca.) TOP WORKING UNITS: Indipendent vertical drilling spindles (No.) 29 Indipendent horizontal drilling spindles (No.) 10 (8 X + 2 Y) Circular Grooving Saw (on X axis) dia. (mm) 160 (1 x kw 3,5 ca.) Vertical electro-spindle (No.) ISO 30 (1 x kw 4,5 ca.)

Condition: used, Year of construction: 2009, Automatic central lubrication Milling unit 7833 2-stage, 11 kW power 1000 - 24000 rpm 1 double drilling spindle in X-direction 1 integrated sawing unit for sawing / grooving in X-direction, traveling Tool changer 7892, 16-way Linear Pick-up changer, permanently installed on the right-hand side of the machine Laser pointer consisting of 2 laser pointers for positioning the vacuum suction cups or tracing the workpiece contour Automatic console - suction cup positioning 6 consoles including 3 suction cup holders per console including 1 vacuum suction cup 80x80 mm per suction cup holder including 4 feeding aids Additional processing fields at the front for 6 consoles Basic unit pneumatics for frame clamping system 7974 (6 consoles) 2D barcode scanner Video camera in the processing head Vacuum pump 140 m³/h Vario tool Change changing unit package consisting of Consists of: Vector axis 7899 (C-axis), fully interpolating, 0-360° continuously rotatable, including pneumatic tool changer 7890, single-slot magazine pick-up system, permanently installed in front of the machine frame on the left. Tool changer 7894, 6-slot pick-up magazine specifically for Vario Tool Change tool holders, permanently installed in the machine frame on the left, can be equipped with a Vario Grip KSJ F 40 collet chuck, 3 Vario Grip KSJ F 40 tool holders (for 2-20 mm ER32 collets), 1 saw blade holder, 3 collets according to customer selection, 1 carbide circular saw blade, max. 220 mm diameter. Nwsdpfx Afovvi Spe Sjr Storage location: Nattheim

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) - Goose-neck type - Movable panel (workpiece), static working head - Horizontal position of the panel (workpiece) - Numerical Control with Software Biesse Works - Safety cabin (enclosure) of the working head - Front emergency carpets - No. 1 In-feeding table (with motorized belts) SX - No. 2 Workpieces fixing clamps (for the panels introduction in the working area) - No. 1 Out-feeding table (with motorized belts) DX Nsdpodh Tf Usfx Af Sjwr - Max. useful working area (X - Y - Z) mm 3000 x 1000 x 60 - Minimum workpieces dimensions (X - Y - Z) mm 200 x 70 x 8 (for longer panels than mm 2000, minimum thickness is mm 13) - Maximum workpieces dimensions (X - Y - Z) mm 3000 x 1000 x 60 - Total installed power Kw 20 BOTTOM WORKING UNITS: - No. 1 Vertical electro-spindle HSK D-50 (power HP 4.8) with Inverter - No. 1 Circular Grooving Saw (on X axe) dia. mm 150, power HP 2,3 with Inverter - No. 29 Vertical drilling spindles - No. 10 Horizontal drilling spindles (8 in X axe + 2 in Y axe) TOP WORKING UNITS: - No. 1 Vertical electro-spindle HSK D-50 (power HP 4.8) with Inverter - No. 1 Circular Grooving Saw (on X axe) dia. mm 150, power HP 2,3 with Inverter - No. 29 Vertical drilling spindles - No. 10 Horizontal drilling spindles (8 in X axe + 2 in Y axe)

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Nedpew Aifzofx Af Sjwr

Condition: used, Year of construction: 2006, · Working area: 2,650 x 1,240 mm · Travel distance X-Y: 2,995 x 1,385 mm · Z-axis travel length: 200 mm · Clearance height: 180 mm The basic frame structure is a monolithic construction made of thick-walled steel. It is reinforced across the entire machine bed with welded triangular plates, making it extremely stable. The use of the triangle shape with a broad base for load-bearing parts is the secret to permanent precision and stability. The layout of the machine allows the operator an optimal workflow while requiring minimal floor space. The resulting frame provides a balanced and secure base for the machining unit with outstanding load distribution. The mobile aggregate carrier is constructed as a solid monoblock. It is positioned along the X-axis on prismatically ground guides via recirculating ball carriages. The machining unit, in turn, is mounted to the mobile carrier using prismatic, ground rails and recirculating ball carriages. Description of aggregates and accessories (basic configuration) Drilling unit: Drill head with 12 + 6 spindles · 7 individually selectable vertical spindles in X · 5 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW Nwodpox Iwc Sjfx Af Sor · Grid: 32 mm · Drill mount: M10 with 11 mm fitting Grooving saw unit in X: · Integrated into the drill head · Grooving saw blade up to max. 120 mm diameter Main milling unit (position 2): · Tool holder HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S6) · Right/left rotation · Ceramic bearings · Includes: 4 tool holders (right), without collets R8L Tool changer Automatic tool changing system for 8 tools. Moves along with the rear aggregate carrier for quick tool access. · Number of tool slots: 8 · Max. tool diameter: 120 mm · Max. weight per tool: 4.5 kg · Max. total tool weight: 22 kg · Adapter for 1 angle gearbox · Travels in X direction Horizontal milling unit (position 1) Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 – 18,000 rpm, infinitely variable via inverter · 1 output for collet 3–20 mm (ER 32) · 1 output for saw/collet 3–12 mm (ER20) (for saw D=120 mm / 50 mm bore) · Motor power: 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER 32): 50 mm · Saw blade arbor diameter (ER 20): 12 mm Worktable The worktable is designed to provide the operator with maximum freedom of movement. The quick-action vacuum clamping system ensures maximum flexibility with precise positioning and optimal holding of the workpieces. · 6 supports, 1000 mm, steplessly adjustable pneumatically in X · 12 vacuum cups, round, D = 110 mm, steplessly adjustable in Y (2 pcs. per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (6 in total) · The retractable reference stops are CNC-controlled · Pendulum operation standard (2 working fields) --- other clamping systems optional --- Axis movement The drive system for X, Y, and Z axes uses ground recirculating ball screws of the highest precision class. The recirculating ball drive...

Condition: used, Year of construction: 2023, Technical Data Working Area I.M.S. I.U. Working area X axis 5515 mm (217") Working area Y axis 1620 mm (63¾") Material passage Y 1900 mm (74¾") Material passage Z 250 mm (9¾") Workpiece length for pendulum processing 2600 + 2600 mm (102" + 102") Traverse speed of X-Y axes PRO-SPACE 56 m/min (184 ft/min); Traverse speed of X-Y axes PRO-SPEED 78 m/min (256 ft/min). *For further details, please refer to the corresponding machine layout. With the 5-axis motor, the Y working area increases to 1680 mm (66") for JQX motor, or 1720 mm (67½") for KS/KT motor. Max. loadable panel width during horizontal drilling, spindle oriented vertically only, with no middle reference stops. Installation Data I.M.S. I.U.: Installed power: 23 – 28.5 KVA Electrical specifications: 400 V, 50 Hz, 3 phases Air consumption: 450 Nl/min Compressed air consumption: 4500 m³/h (2650 CFM) Extraction air speed: 30 m/s Extraction port diameter: 250 mm (9.8") Noise level VSA* / LAV*: Drilling 72.2 dB(A) / 74.6 dB(A), Milling 74.3 dB(A) / 80.7 dB(A) Nwodpfxoxwht Dj Af Ser Reference standard: EN ISO 11202:1995 *VSA = without load and without extraction *LAV = in operation, with extraction Location: Nattheim

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 MAIN FEATURES 5-AXIS MACHINING UNIT "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE MATIC PROGRAMMING" WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (inside stop) mm 3,680 Working area Y-axis (max. loadable piece on rear stops) mm 1,680 Workpiece passage Z / number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Travel speed X-Y axes Pro-Speed m/min 85 Z-axis speed m/min 30 INSTALLATION Installed power KVA 62÷82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL CHARACTERISTICS CNC-controlled drilling and milling center in gantry design and work table with workpiece supports, for carrying out: - vertical drilling on the panel surface - horizontal drilling on all four sides of the workpiece - groove milling with disc milling cutters - general milling work 3-4-5 axes MACHINE STRUCTURE The basic structure is a monolithic construction made of thick-walled steel. It is stiffened by welded reinforcements across the entire machine bed, making it extremely stable. The table shape used, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow with a minimum of space requirements. The mobile gantry support is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via recirculating ball slides. On this mobile unit carrier, the work unit is mounted on prismatic, ground guides and recirculating ball slides. All axes are moved on large-section prism linear guides and recirculating ball bearings with a large contact surface, ensuring optimal gliding even at the highest speeds and accelerations. Precise and rapid positioning of the movable gantry (X-axis) is achieved by a pinion and rack with helical teeth. Large-section recirculating ball screws ensure precise positioning of the work unit along the movable gantry (Y and Z axes). MOTORS, DRIVES AND INVERTERS Perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors, designed to achieve speeds of up to 90 m/min while ensuring the best finishing quality. CONTROL The control unit consists of a numerical control for milling and drilling machines with "Xilog Maestro" graphical user interface based on the Windows 7 Office operating system. 17-inch LCD color screen. QWERTY keyboard. Tilting control panel. Machine interface with Xilog Maestro software. Xilog Maestro Features Programming Parametric graphic programming Import of DXF files (2D; SPLINE, POLYLINE 3D geometries), linear or circular interpolation in three axes, linear in space, spiral in the selected plane. Programming with graphic and syntax aids for drilling and milling operations Automatic optimization of drilling operations and tool change cycles Possibility of Plate zero point shift for drilling on inclined or curved plate sides Nodpfxjxnldbj Af Sewr

Condition: used, Year of construction: 2023, Exhibition Machine Garbsen CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and Milling Made for You! This numerically controlled machining center is equipped with a comprehensive range of accessories and tools for milling and drilling, enabling it to meet every requirement in the field of wood processing. Highly efficient – with drilling spindles reaching up to 8,000 rpm – and featuring technology that includes the most robust spindle available on the market, offering more than 1,000 hours of maintenance-free operation. Fully equipped – the suction cups can be individually configured with the TV FLEX worktable to adapt the machine precisely to your requirements. Easy and intuitive programming thanks to the integrated Cad-Cam MAESTRO CNC software. User-friendly operation is ensured by the lowered machine frame, which provides unrestricted access to the worktable at all times. The control cabinet and vacuum pump are integrated into the machine base, and the PRO SPACE variant requires no additional structural safety measures. Robust Construction The supporting structure consists of an especially sturdy monolithic steel base, ribbed for stability and durability. The extra-wide bearing surface is purpose-designed to provide the machine with stability, ensuring constant precision in all working conditions. Anchoring to the floor is not required. The base forms a large, solid foundation for the moving gantry: the working unit is equipped with a balanced, stable, and resilient support, withstanding the highest stress, which ensures superior quality performance and greater accuracy. The moving gantry is a solid single piece anchored to the base, running on high-quality prismatic guides with ball bearing carriages. The working unit is mounted to this and moves along the Y and Z axes on prismatic guides with ball bearing carriages as well. Movement of the lower movable unit (X-axis) and the working unit along the gantry (Y-axis) is driven by a helical toothed rack and pinion system; this produces greater tooth-by-tooth thrust, achieving higher acceleration and increased speed on the X and Y axes. The specially designed helical gearing ensures reduced wear of mechanical components and quieter operation. The vertical Z-axis is driven by a recirculating ball screw, providing perfect balance under dynamic load and withstanding significant acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage, enabling superior surface finish quality as vibrations are completely eliminated. Travel along the X-Y-Z axes is achieved with brushless motors powered by static inverters. These provide: - Reduced processing times due to improved acceleration - Increased positioning accuracy due to high-resolution encoders - Elimination of setup tasks at machine startup thanks to absolute encoders - Elimination of general maintenance tasks, as the brushless system has no brushes Axis movement management and general operation of the working elements... Nsdpsx A Dfgefx Af Sjwr
