Used Horizontal machining centers with through-feed (wood) for sale (140)

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, workpiece height (max.): 30 mm, TECHNICAL DETAILS Axis: 920 mm Kelhcszkt A Rocqrjlw X-axis: 3,000 mm A-axis: 360° Material thickness Z: 12 mm - 30 mm Feed rate: 20 m/min Minimum dimensions (plate): X: 300 mm Y: 120 mm Z: 12 mm Maximum/minimum hole diameter: 3 mm - 35 mm Maximum cutting depth with saw blade: 10 mm MACHINE DETAILS Motor power: 0.75 HP Voltage: 400 V Required extraction capacity: 2,300 m³/h EQUIPMENT 4-position drill chuck Saw blade in the X direction

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Kljlhjwuz Ekoccqrsw Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: used, Year of construction: 2014, Working dimensions: X = 3425 mm, Y = 1287 mm, Z = 325 mm. Max. workpiece height: 180 mm. Max. clearance under the hood: Y = 1450 mm / Bumper version = 1370 mm. Includes CabinetControl Base, 1 machine license, and 1 office license. Milling head 7830, 1-stage, power 6.5 kW, air-cooled, n(max.) 1000 - 18000 min-1, infinitely adjustable. Max. power at 12000 min-1 to 18000 min-1 with HSK-F 63 tool holder, with collet chuck with HSK shank. Drilling unit 7884, 14 spindles, 10 vertical spindles individually accessible, arranged in an L-shape, 6 in the X direction and 4 in the Y direction. Drive power 3 kW, 32 mm pitch. Sawing unit: Integrated sawing unit for sawing/grooving in the X direction, n(max.) 1000 - 5650 min-1, infinitely adjustable. Tool holder: A = max. DM = 125 mm. Kljlhcoy Tpz Rscqrew Location: Supplier.

Condition: used, Year of construction: 2015, total height: 1,850 mm, total length: 2,300 mm, total width: 1,950 mm, Colour: White Empty weight: 1.240 kg - Year: 2015 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AB/222595 - Main motor power [kW]: 2.2 - Number of controlled axes [pcs]: 12 - Working range X [mm]: 3050 - Working range Y [mm]: 800 - Working range Z [mm]: 60 - X-axis max stroke [mm]: 1040 - Y-axis max stroke [mm]: 1030 - Z-axis max stroke [mm]: 100 - Number of milling spindles [pcs]: 8 - Spindle diameter [mm]: 10 - Min. spindle speed [rpm]: 1000 - Max. spindle speed [rpm]: 4000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 6 - Max. drilling depth [mm]: 18 - Vertical drilling unit: Yes - Vertical drilling spindles [pcs]: 8 Kloljzavvgjhccqrow - Max. drilling depth [mm]: 30 - Saw unit present: Yes - Safety feature: - Voltage [V]: 400 - Current consumption [A]: 10 - Transport dimensions: 2300mm x 1950mm x 1850mm (l x w x h) - Transport weight [kg]: 1240kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Kolhccex Twd Hsqrjlw Location: Nattheim

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 KEY FEATURES 5-AXIS MACHINING HEAD "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL" XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE PROGRAMMING MATIC WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (stop inner side) mm 3,680 Working area Y-axis (max. loadable workpiece on rear stops) mm 1,680 Workpiece passage Z / Number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Traverse speed X-Y axes Pro-Speed m/min 85 Speed Z-axis m/min 30 INSTALLATION Installed power KVA 62 ÷ 82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL FEATURES CNC-controlled drilling and milling center in a portal design and worktable with workpiece supports, for performing: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutters - general milling operations 3-4-5 axes MACHINE STRUCTURE The base structure is a monolithic construction made of thick-walled steel. It is reinforced by welded-in supports over the entire machine bed, making it extremely stable. The table design, with a large base, is the secret to ensuring lasting precision and stability. The machine layout enables the user to have an optimal workflow with a minimum of space requirements. The mobile portal beam is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via ball screw slides. On this mobile aggregate carrier, the working aggregate is in turn attached to prismatic, ground guides and ball screw slides. AXIS MOVEMENT The displacement of all axes takes place on prism linear guides with a large cross-section and ball screw shoes with a large contact surface, which ensure optimal sliding even at the highest speeds and accelerations. The precise and fast positioning of the moving portal (X-axis) is achieved by a pinion and rack with helical teeth. Ball screws with a large cross-section ensure the accurate positioning of the work unit along the moving portal (Y and Z axes). MOTORS, DRIVES AND INVERTERS The perfect mechanical dynamics and maximum positioning accuracy are controlled by the high-quality drives and brushless motors, which are designed to achieve a speed of up to 90 m/min while maintaining the best surface finish. CONTROL The control unit consists of a numerical control for the milling and drilling machine with "Xilog Maestro" graphical user interface on a Windows 7 operating system - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine operating interface with Xilog Maestro software Xilog Maestro Features Programming - parametric graphical programming - Import of DXF files (2D; the geometries "SPLINE", "POLYLINE 3D", lines or circle interpolation in three axes, linear in space, spiral in the selected plane - supported programming with graphics and syntax aids for drilling and milling operations - automatic optimization of drilling operations and tool changes - cycles - possibility of panel zero-point shift to perform drilling on inclined or curved panel sides Kjlhccqoy Dta Serjlw

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Kolhox Twdyoccqrslw

Condition: used, Year of construction: 2006, * Work area: 2,650 x 1,240 mm * X-Y travel: 2,995 x 1,385 mm * Z-axis travel: 200 mm * Clearance height: 180 mm C-axis deactivated - 3-axis machine The structure of the base body is a monolithic construction made of thick-walled steel. It is reinforced throughout the machine bed by welded triangular plates, making it extremely stable. The triangular shape used for the supporting parts, with a large base, is the key to long-lasting precision and stability. The machine's layout allows the user an optimal workflow despite minimal space requirements. The base body, constructed in this way, provides the machining unit with a balanced and secure base with particularly good load distribution. The mobile unit carrier is made from a solid monoblock. It is positioned in the X-direction on prismatically ground guides via ball screw slides. The machining unit is, in turn, attached to the mobile unit carrier on prismatic, ground guides and the ball screw slide. Description of units and accessories (base) Drilling unit: Drilling head with 12 + 6 spindles * 7 individually selectable vertical spindles in X * 5 individually selectable vertical spindles in Y * 4 horizontal spindles in X (2+2) * 2 horizontal spindles in Y (1+1) * Speed: 4,000 1/min * Power: 2.2 kW * Grid: 32 mm * Drill chuck: M 10 with Morse taper No. 11 Nut saw unit in "X": * Integrated in the drilling head * Nut saw blade with a diameter of up to max. 120 mm Main milling unit (Position 2): * Tool holder HSK 63F * Speed 1,500 - 24,000 1/min, stepless via inverter * Motor power 4.4 kW (6 hp) from 12,000 1/min (S1) * Motor power 6.6 kW (9 hp) from 12,000 1/min (S6) * Right/left rotation * Ceramic bearings * Scope of supply: 4 pcs. tool holder (right) without collet Tool changer R8L Automatic tool changing device for 8 tools. Mounted on the rear unit carrier for quick access to the tools. * Number of tool positions: 8 * Max. tool diameter: 120 mm * Max. weight per tool: 4.5 kg * Max. total weight of all tools: 22 kg * Holder for 1 angular gear * Mounted and moving in X Horizontal milling unit (Position 1) Horizontal unit with two opposite outlets for milling and grooving. * Speed 9,000 - 18,000 1/min, stepless via inverter Klolhjx Twccsccqrsw * 1 outlet for collet 3-20 mm (ER 32) * 1 outlet for saw/collet 3-12 mm (ER20) (For saw D=120 mm / bore 50 mm) * Motor power 3 kW (4 hp) * Max. tool diameter, front milling: 20 mm * Max. tool length, front milling: 110 mm * Max. tool diameter, rear milling: 12 mm * Max. tool length, rear milling: 80 mm * Max. saw blade diameter: 100 mm * Bore in saw blade (ER 32): 50 mm * Arbor diameter, saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum "freedom of movement". The vacuum quick-clamping system offers maximum flexibility with precise positioning and optimal workpiece clamping. * 6 supports 1000 mm, stepless pneumatically adjustable in X * 12 vacuum suction cups, round D = 110 mm, steplessly adjustable in Y (2 pcs. per support) * 2 stops in X (1 x left / 1 x right) * 1 stop in Y per support (total 6 pcs.) * The retractable reference stops are CNC-controlled * Pendulum machining standard (2 working areas) --- other clamping systems are available as optional extras --- Axis movement The drive system in X, Y and Z is via ground ball screws.

Condition: used, Year of construction: 2018, Delivery time approx. 5 months. Machine from educational use – TOP condition, low hours (edging unit unused). No tools included. Dismantling, delivery, assembly, commissioning, and training not included in the price. Includes Maestro 3D and Pro View. MORBIDELLI P200 Working area X-Y: 3,110 x 1,620 mm, workpiece height Z180 mm Edge banding made for you: The CNC machining center is equipped with a comprehensive selection of edge banding tools to meet any woodworking requirement. MAIN ADVANTAGES · High performance with the advanced H80C edge banding unit, 8,000 rpm drilling spindles. The most robust spindle technology on the market, offering over 1,000 maintenance-free operating hours. · Better equipped: Suction cups can be disabled and configured via the FLEX worktable to optimally adapt the machine to requirements. · Easier, more intuitive programming thanks to the integrated CAD-CAM module for edge banding technologies “MAESTRO EDGE”. · Easier operation: The lowered frame ensures the worktable is always accessible. The control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, no safety barriers are needed. Base structure: The base frame is a monolithic construction made from thick-walled steel, reinforced across the entire machine bed with welded square plates for exceptional rigidity. The bed’s shape, with a wide base, is the secret to lasting precision and stability. The load-bearing structure consists of a particularly robust, monolithic steel base, heavily ribbed and highly stiffened; the extra-wide support was specially designed to give the machine maximum stability, ensuring lasting precision regardless of operating conditions—with no need for floor anchoring. The base provides a large, solid support for the moving gantry: the working unit is thus equipped with a balanced, stable, and resilient support capable of handling the highest loads, ensuring top-quality performance and greater accuracy. The moving gantry is made from a robust single piece anchored to the base, sliding along top-quality prismatic guides with recirculating ball carriages. The working unit is attached and moves along the Y and Z axes on prismatic guides with recirculating ball carriages. Movement of the lower carriage (X-axis) and the working unit along the moving carriage (Y-axis) is enabled by rack-and-pinion transmission with helical teeth. This design results in greater tooth-on-tooth engagement, delivering higher acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures reduced wear on mechanical components and quieter operation. The vertical Z-axis is driven by a ball screw, ensuring perfect balance with dynamic loads and smooth acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage for maximum finishing quality. Kjlhoyuw Srjccqrelw

Condition: used, Year of construction: 2013, total height: 2,700 mm, total length: 2,000 mm, total width: 2,600 mm, Colour: White Empty weight: 1.500 kg Price: On request - Year: 2013 Kelhccqszldzyorolw - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 72122 - Main motor power [kW]: 4 - Number of controlled axes [pcs]: 3 - Working range X [mm]: 2500 - Working range Y [mm]: 900 - Working range Z [mm]: 70 - Number of milling spindles [pcs]: 1 - Tool holder interface: ISO30 - Min. spindle speed [rpm]: 12000 - Max. spindle speed [rpm]: 24000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 6 - Vertical drilling unit: Yes - Vertical drilling spindles [pcs]: 10 - Manual operation: Yes - Saw unit present: Yes - Safety feature: - Spindle speed control: Continuously adjustable - Voltage [V]: 400 - Current consumption [A]: 22 - Fuse [A]: 32 - Power [kW]: 12.0 - Transport dimensions: 2000mm x 2600mm x 2700mm (l x w x h) - Transport weight [kg]: 1500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: new, Year of construction: 2024, Axis distance: 920 mm X-axis: 3000 mm Material thickness: Z 12 mm - 30 mm Feed rate: 20 m/min. A-axis: 360 degrees Minimum dimensions: Plate: x = 300 mm Y = 120 mm z = 12 mm The machine is equipped with a 4-position drill chuck and a saw blade. Maximum and minimum hole diameters that can be drilled: 3 - 35 mm The saw blade moves in the X-direction. Max. cutting depth with saw blade: 10 mm Kslhccscnz H Hoqrelw Motor: 0.75 HP, 400 volts Required extraction capacity: 2300 m3/h Location: In stock, 54634 Bitburg - immediately available -

Condition: used, machine/vehicle number: 008495, X axis working area: 3050 mm Y axis working area: 1400 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Klolhccqoy Edqqsrew Number of controlled axes: 4 axes Maximum edge height: 45 mm Total number of drilling spindles: 21 Total number of tool changer positions: 12

Condition: used, machine/vehicle number: 007842, X axis working area: 5000 mm Y axis working area: 1200 mm Working Table: Pod and Rail Koloyhbiushccqrjlw Main Electrospindle power: 18 KW Number of controlled axes: 4 axes Maximum edge height: 64 mm Total number of drilling spindles: 14 Total number of tool changer positions: 18

Condition: used, machine/vehicle number: 007841, X axis working area: 4200 mm Y axis working area: 1300 mm Working Table: Pod and Rail Main Electrospindle power: 18 KW Klolhccqjyg Ef Dsrsw Number of controlled axes: 4 axes Maximum edge height: 64 mm Total number of tool changer positions: 18

Condition: used, Year of construction: 2013, .30 Base machine ACCORD 30 FX N. 1 CONCEPTCNC machining center with a moving gantry and a fixed worktable for processing various sheet-like materials: chipboard, MDF, laminated solid wood, plastic materials, and light alloys. STRUCTUREThe machine is developed using the best three-dimensional CAD systems for solid modeling. The machine bed and moving crossbeam represent the two main elements of the machine structure and are manufactured in the company's own foundry. All mechanical machining operations are carried out on special production equipment in a single setup to ensure optimal precision and to minimize tolerances during machining. The control cabinet is mounted directly on the machine bed, allowing for a very compact design and easy access. CONTROL UNITThe control unit consists of an industrial NC control system with an integrated office PC (desktop computer). The CNC solution with an office PC combines all the features of numerical control with the typical user-friendliness of an office PC, which greatly simplifies the control of the machine by enabling the use of the XILOG MAESTRO user interface, i.e., the software developed by SCM for simple and fast programming, even for non-experts. GENERAL FEATURESPassage height: - 250 mm with H50 accessories- 190 mm with H110 accessoriesPendulum machiningAutomatic lubrication of the axesAir conditioning system to maintain the correct internal temperature in the control cabinet. Software for remote customer serviceOperator interface Xilog MAESTRO with integrated CAD/CAM, which allows for the extremely simple execution of products even with special shapes.A number of advanced functions allow for: - programming via macros- creating and managing subprograms- optimizing machining- managing all machine functions- creating and managing a database of tools93.07.31 Voltage 400 EU 93.12.01 Frequency 50 Hz R0.00.03 LINGUA P.C. GERMAN 02.12.57 ACCORD 30 FX - Worktable X-Y = 3680x1380 56.05.25 No. 6 Support rail MATIC - L1300 The worktable is equipped with: - no. 2 lateral fixed supports- no. 6 aluminum supports, motor-driven and movable along the X-axis- motorized conveyor belt for unloading chipsEach movable support has: - no. 3 motor-driven support rails for clamping cylinders and vacuum suction cups- air blower for cleaning on each movable support- pneumatic locking/release for quick replacement of the clamping cylinders and vacuum suction cups- preparation for lifting devices- preparation for reference stopsThe workpiece vacuum clamping system is divided into 2 independent worktables.23.02.19 DUO Prisma K working unitThe working unit with 5 interpolating axes is located on the moving crossbeam, which provides maximum stability during milling and thus also ensures optimal machining quality of the workpieces, even with high material removal rates. It allows for rotation around the axes arranged at 50° to each other and has many advantages over traditional 5-axis working units, such as: - the full use of the work areas both with 5 axes and with a vertical spindle- spindle external dimensions outside the working area- a particularly light design for horizontal machiningThe unit has a central chip extraction system. Kslhccqozl Ap Nerslw

Condition: used, Year of construction: 2018, CNC-CONTROLLED MACHINING CENTER AUTHOR M 200 AUTHOR M200 3710x1620 Z250 - CNC-controlled machining center 1 Technical data Work area I.M.S. I.U. Work area X-axis 3710 mm * 146" * Work area Y-axis 1620 mm * 63¾" * Workpiece passage Y 1900 mm 74¾" Workpiece passage Z 250 mm 9¾ Workpiece length for pendulum machining 1700 + 1700 mm 67" + 67" Travel speed of the X-Y axes PRO-SPACE 56 m/min 184 ft/min Travel speed of the X-Y axes PRO-SPEED 78 m/min 256 ft/min * Distance covered by all tools in the X and Y direction; see the corresponding layout for further details. With a 5-axis motor, the dimension in Y increases to 1680mm (66"), for motor JQX or 1720mm (67½") for motor KS/KT max. Width of the loadable plate for horizontal drilling, electric spindle only oriented vertically, no central reference stops Installation data I.M.S. I.U. Installed power 23 - 28.5 KVA Electrical standard specifications 400 Voltage 50 Hz 3 phases Air consumption 450 Nl/min Compressed air consumption 4500 m³/h 2650 CFM Extraction air velocity 30 m/sec Extraction nozzle diameter 250 mm 9.8 Inches Noise level VSA * LAV * Drilling 72.2 74.6 Milling 74.3 80.7 Reference standard EN ISO 11202:1995* VSA = unloaded and without extraction * LAV = in operation with extraction Structure of the base body: The CNC machining center can be equipped flexibly with different milling units as well as multi-spindle drilling heads and many other units, up to dowel drilling units. In order to meet all requirements in the field of wood and plastic processing, as well as the demands of the users, each machine can be equipped with 3, 4 or 5 machining axes. The selection of drilling units extends to up to 34 drilling spindles with an integrated groove saw for the back panel groove or rabbet machining. The possibility of using this high-quality CNC machining center both as a cantilever table machine and with an aluminum grid table underscores the flexible range of applications and the performance of the M100 and M200 series. Powerful drilling heads, with individually selectable drilling spindles, max. RPM 8,000, and implemented in . technology, "the most robust drilling spindles on the market", with more than 1,000 maintenance-free application hours (lubrication interval of the drilling spindles). The possibility of being able to replace the drilling spindles within a very short time, "even without a technician", through the technology, without disassembling the drilling gear, sets a benchmark in the industry and is already standard on your machining center. Imagine your CNC machine performing hinge drilling in just one drilling operation (option), instead of the usual 3. An option that underscores our claim to offer you robust and high-performance units on our machines. Ideally and flexibly equipped for a wide variety of requirements. Whether manual or automatic, the FLEX cantilever work table allows vacuum cups and mechanical clamping elements, such as pneumatic clamps for window or curtain wall constructions (option), to be quickly, safely and cost-effectively adjusted to any material and clamping requirements, making your day-to-day work easier. Differently sized vacuum cups and clamping elements, which were developed in close cooperation with customers and users, are available as an option. Klslezk E Hujhccqrew

Condition: used, Year of construction: 2014, Machine design: Continuous/Reciprocating Working area in X-direction: 1000 mm Working area in Y-direction: unlimited Working thickness (Z-dimension): 60 mm Number of main spindles: 1 Main spindle power: 3.3 kW Clamping system: HSK-63 F Tool changer: Pick-up tool changer Number of tool change stations: 3 Back wall grooving units: fixed in the Y-direction Vertical drilling spindles - in the X-direction: 5 Vertical drilling spindles - in the Y-direction: 5 Spindle speed, vertical drilling spindle: 4000 rpm Horizontal double drilling spindle in the X-direction: 2 Horizontal double drilling spindle in the Y-direction: 1 Spindle speed, horizontal drilling spindle: 4000 rpm Monitor size: 17" Control type: PC control Operating system: Windows XP Typewriter keyboard: Yes Mouse: Yes Programming system: Masterwork DXF interface: Yes Klolhccqozndmhorow Online connection possible: Yes CD-ROM drive: Yes Table design: Fixed table with rollers Weight approx.: 1300 kg Dimensions: 2200x2470x1590 mm Location: Customer

Condition: used, Year of construction: 2016, operating hours: 5,613 h, total height: 2,350 mm, total length: 4,300 mm, total width: 1,880 mm, Colour: Grey Empty weight: 1.310 kg - Year: 2016 - Documentation available: Yes Kjljzh Hkcohccqrolw - CE marking present: Yes - CE certificate present: No - Serial number: AB/226310 - Operating hours: 5613 - Main motor power [kW]: 5.5 - Number of controlled axes [pcs]: 1 - Working range X [mm]: 3050 - Working range Y [mm]: 900 - Working range Z [mm]: 60 - Number of milling spindles [pcs]: 1 - Tool holder interface: ISO30 - Max. spindle speed [rpm]: 18000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 6 - Max. drilling depth [mm]: 35 - Vertical drilling unit: Yes - Vertical drilling spindles [pcs]: 12 - Max. drilling depth [mm]: 60 - Manual operation: Yes - Control: SCM Xilog - Software: Xilog Plus - Saw unit present: Yes - Safety feature: - Spindle speed control: Continuously adjustable - Transport dimensions: 4300mm x 1880mm x 2350mm (l x w x h) - Transport weight [kg]: 1310kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2023, New demonstration machine! List price: €86,567 net. Basic machine, complete in standard configuration for drilling and grooving: Detailed technical data, see data sheet for ProTec Type 0571. Processing unit with: PowerBlock with 21 spindles and 1 grooving saw - 13 vertical drilling spindles - 6 horizontal drilling spindles in Y - 2 horizontal drilling spindles in X - 1 grooving unit in Y. 4th-axis drilling in Y. Workpiece sizes and weights: - Workpiece width (X): min. 60 mm / max. 1000 mm - Workpiece thickness (Z): min. 6 mm / max. 60 mm - Workpiece length (Y): min. 250 mm in through-feed mode, max. 5600 mm programmable workpiece length in software - Workpiece weight: max. 75 kg. Milling unit Profit HSK63F with 3-position magazine for automatic tool change, motor 5.5 kW (S1), 1000-20000 rpm with frequency inverter, right and left rotation, for tool holder HSK63F with collet 462E/OZ25, milling cutter length up to 130 mm. Information: Processing unit MultiUnit with PowerBlock with 21/23 spindles, grooving saw, and optional milling unit Profit. Connection power 12 kVA. Rated current 17.5 A. Fuse 32 A. Voltage 400 V, 50 Hz, 3-phase (without transformer). Power supply TN or TT. Pneumatics connection 7 bar (102 psi). On the machine: Coupling plug (quick coupling) ¼, DN7.2, brass, factory-side. For the machine: Coupling socket (quick coupling) ¼, DN7.2, brass, customer-side. Supply line, hose inner diameter 12 mm (min.). Compressed air requirement: Continuous air consumption approx. 230 L/min (approx. 3.8 L/sec) (compressed air). Extraction connection: 3x extraction nozzle, dia. 80 mm. Extraction speed: 30 m/sec - measured at the extraction nozzle. Extraction requirement: min. approx. 2500 m3/h min. Machine weight: approx. 1650 kg (with options!). Machine installation location: As a rule, a ProTec can be fixed to the floor with screws. A concrete floor (or foundation) is assumed (at least at the 4 machine edges/machine feet). Equipment: Protec 571 Profit HSK63F with 3-position magazine. Roller table 765 mm (Y-axis), foldable, for the front of the machine, width 500 mm. Roller table 765 mm (Y-axis), foldable, for the back of the machine, width 500 mm. Auxiliary stop 600 mm with integrated rollers for roller tables. Additional safety device via a louver curtain. Requirement for horizontal milling for Lamello P-system (without tools for Lamello P-system). Drill set for Protec, shank ø 10 mm with clamping surface (JSO) 1 HW-countersink drill bit 5x70mm (NL 35mm), LI # 30566-5-05035-L3. 1 HW-dowel drill bit 5x70mm (NL 35mm), RE #30540-5-05035-R4. 1 HW-dowel drill bit 5x70mm (NL 35mm), LI #30540-5-05035-L3. 1 HW-dowel drill bit 8x70mm (NL 35mm), RE #30540-5-08035-R. 1 HW-dowel drill bit 8x70mm (NL 35mm), LI #30540-5-08035-L2. 1 HW-dowel drill bit 10x70mm (NL 35mm), LI #30540-5-10035-L1. 1 HW-pot drill bit 15x70mm (NL 35mm), LI #30300-5-15070-L1. 1 HW-pot drill bit 20x70mm (NL 35mm), RE #30300-5-20070-R1. 1 HW-pot drill bit 35x70mm (NL 35mm), RE #30300-5-35070-R. 1 HW-grooving cutter ø 125/30 mm, grooving cutter width (SB) 4.0 mm, Z=12, LI, Leitz. Only for chipboard and MDF, solid wood on request and by arrangement. Tool holder HSK63 F 3.0 pcs. For collet 462E/OZ25. Collet 462E/OZ25 for shank 25 mm, 3.0 pcs. Indexable carbide shank milling cutter, Z1+1, 1.0 pcs. with WP drilling insert ø20, S25, LI 120, L2/L3 58 mm. Grooving cutter HW indexable inserts Z1, 1.0 pcs. with WP drilling insert, D Ø 10 mm, d Ø 10 mm, L1 75 mm, L2 25 mm, L3 40 mm, RE (the a Keljw Tfzfjhccqrjlw

Condition: used, Year of construction: 2005, Processing size: 3000 x 1600 x 180 mm High-pressure pump 60 HP / 45 kW Model E-60 Operating pressure 4,130 BAR Water consumption 4.69 liters/min. Software: Watercad-CAM Automatic cutting optimization Storage location: customer Kljljxgfbqehccqrow

Condition: used, machine/vehicle number: 008389, X axis working area: 8417 mm Y axis working area: 1930 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 40 Klsleyqxxrehccqrew Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 007247, Maximum edge height: 3 mm Kjlhjt H Twyoccqrolw

Condition: good (used), Year of construction: 2018, working length X 1.600 mm Klslhccqoyku Uvsrow working length Y 800 mm working depth Z 190 mm Motor output 2,2 kW Weight ca. 450 kg Year 2018

Condition: used, Year of construction: 2011, AXES Working area X-Y-Z axes * mm 3050-1300-180 Workpiece length in swivel machining mm 1390 Stroke X-Y-Z axes mm 3460-1735-250 Max. travel speed of the X-Y axes m/min 60 WORKING TABLE Number of workpiece supports and vacuum cups 6 / 2 Standard type Standard End stops / Position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles Std/Number/Speed 1/min 12 (8X-5Y) / 4000 Ksloyymz Ushccqrolw Horizontal spindles Std/Number/Speed 1/min 6 (4X-2Y) / 4000 Integrated slotting/sawing unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power Std. / Opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer mounted on the unit carrier in X 4 positions, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction nozzle diameter mm 150+150 (200) Machine weight Kg 3000 * X Distance between the stops - Y Milling center as reference point; Z Workpiece passage GENERAL FEATURES CNC-controlled boring and milling center, in C-frame design and working table with adjustable workpiece supports and vacuum cups, for performing: - Vertical drilling on the surface of the panel - Horizontal drilling on all four sides of the workpiece - Slot milling with disc cutter in "X" direction - General milling operations Self-supporting structure and working table Structure made of a steel welded construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV supports. Movable unit carrier Box construction made of cold-rolled steel with internal reinforcing ribs, protective devices with bumpers. Working unit Consisting of a drilling head with vertical spindles, horizontal spindles, an integrated slotting and sawing unit and an SCM electrospindle with tool quick-change system type HSK 63 F. Travel paths of the portal and the unit carrier Movement in the X, Y and Z axis takes place on linear prismatic ball-bearing guides with the aid of pre-tensioned linear guides. The power transmission of the X-axis (movable stand) takes place via a pre-tensioned, backlash-free rack and pinion drive with diagonal movement. The movement of the unit carrier in Y and Z direction takes place via pre-tensioned linear guides. The positioning of the working units and the control of the machine functions takes place via "Brushless" three-phase servomotors and digital drives. CNC CONTROL The control unit consists of a numerical control for the milling and drilling machines and a pre-connected personal computer with a graphical user interface "XILOG PLUS". PC -Office- operating system Windows XP - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine interface software Xilog Plus Xilog Plus features Programming - parametric, graphical and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation in three axes, linear in space, spiral in the chosen plane - Supported programming with graphic and syntax aids for drilling and milling operations - Automatic optimization of drilling operations and tool changes - cycles - Possibility of plate zero-point shift for performing drilling on inclined or curved plate sides - Complete compatibility with CAD/CAM Routocam (SCM) - AlphaCam Integrated additional functions - Calculator for direct transfer of the calculated data.

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Kelhoxy Tmnjccqrslw
