Used hydraulic presses double column / four column presses for sale (291)

Condition: ready for operation (used), Year of construction: 2000, machine/vehicle number: 65056, functionality: fully functional, pressing force: 5,000 t, stroke length: 900 mm, table width: 4,520 mm, table length: 2,150 mm, overall weight: 319,000 kg, Equipment: safety light barrier, Pressure build-up time: 3.6 s Pressure relief time: 1.5 s 6-axis industrial robot, manuf. ABB, type IRB6640 M2004 Control cabinet array, 12-door, SN 6/5056 Operator panel, water-based hydraulic unit Tool change device Bwjdpfoxb Tpljx Akpen Mesh safety enclosure with light curtains

Condition: used, Year of construction: 1980, Technical details: pressure: ca. 100 t Bwsdpju Nfhdsfx Akpen distance between columns: 500 mm throat: bis Mitte Stößel / up to center ram: 350 mm dayligth: 450+100 mm min. ram stroke: 26 mm max. ram stroke: 152 mm ram adjustment: möglich/possible mm ram surface area: 550 x 400 mm clamping table: 1020 x 710 mm total power requirement: 10 kW weight of the machine ca.: ca.7 t space requirement approx.:: L:2,0 x B:1,7 x H:3,2 m WITHOUT drawing cushion Can be demonstrated in idle run. i.D. *

Condition: used, Year of construction: 1997, Technical details: pressure: 160 t distance between columns: 1000 mm stroke: 250 mm Bwodpfx Akou Nfmmepon dayligth: 600 mm distance table/ram: 600 mm table height over floor: 550 mm table surface area: 810 x 860 mm clamping surface ram: T x B: 720 x 580 mit T-Nuten mm total power requirement: 15 kW weight of the machine ca.: ca. 16,0 t The machine isn't installed yet. The pictures are from the origin location of the former owner. further details: - sideway passage W: 520 x H: 620mm - passage front side W:660mm x H: 600mm equipment: - walkable platform arround the machine= height over floor approx. 2400mm, platform approx. 2700 x 2600 x 1050mm - hydraulic pack - oil cooler i.D. *

Condition: used, Technical details: Bodpfx Aeu Nfnwokpswn pressure: 80 t dayligth: 600 mm ram stroke: 200 mm pressure: 30 t dayligth: 680 mm ram stroke: 300 mm distance between columns: 1060 mm base plate surface area: 1060x600 mm table above floor: 720 mm ram stroke speed: Stößel/ Ram 1: 40 mm/sec ram stroke speed: Stößel/ Ram 2: 95 mm/sec base plate surface area: Dm=150 mm total power requirement: 13 kW weight of the machine ca.: 4,5 t space requirement approx.:: L:1,6xB:1,1xH:3,4 m - Press with two ram with 30 t + 80 t - foot control - documentation *

Condition: good (used), pressure 250 t passage width 700 mm stroke 850 mm table surface area 2000 x 1000 mm mould height - Max./min. 355 / 1200 mm total power requirement 30 kW weight of the machine ca. 25 t Bwodsxcblwopfx Akpsn dimensions of the machine ca. 4,2 x 2,1 x 5,5 m

Condition: good (used), Year of construction: 1981, pressure 300 t Bedpfx Ajx Uru Nekpswn passage width 1100 mm stroke 950 mm table width 1050 mm table depth 1200 mm dayligth 1180 mm weight of the machine ca. 20 t dimensions of the machine ca. 2,8 x 3 x 4,5 m

Condition: good (used), Year of construction: 2002, FOR SALE Double Crank Press ARISA 630 Tons Brand: ARISA (Spain) Model: S2-630-350-150-ES Bwodpfx Ajy Sl Rlokpjn Year of Manufacture: 2002 Type: Double crank mechanical press (S2) – High performance Technical Specifications (Certified Data): This press is a heavy-duty production unit designed for extremely high precision on large workpieces. Nominal Force: 630 tons (6,300 kN) Table Dimensions: 3,500 mm x 1,500 mm Slide Dimensions: 3,500 mm x 1,500 mm Slide Stroke: 200 mm Slide Adjustment: 150 mm Working Speed: Variable from 20 to 50 strokes/minute Maximum Force Point: 13 mm before the bottom dead center Electrical & Mechanical Specifications: Motor Power: 92 kW Total Machine Weight: 145,000 kg (145 tons) Striking Energy: Ideal capacity for deep drawing and progressive cutting applications Clutch/Brake System: Pneumatic (required pressure 5.5 – 6 bar) Balancing: Adjustable pneumatic counterbalance Power Supply: 380 V Key Features: Large Working Area: 3.5-meter table allows for complex or multiple tooling setups S2 Stability: Double crank design ensures uniform pressure distribution, preventing slide tipping Condition: 2002 machine compliant with modern safety and control standards.

Condition: used, Year of construction: 1982, pressure 40 t distance between columns 695 bzw. 215 mm stroke 100 mm table surface area 650 x 440 mm ram surface 580 x 285 mm Bwjdpotqqq Rsfx Akpjn dayligth 400 mm total power requirement 15 kW weight of the machine ca. t dimensions of machine L x W x H 1,63 x 1,05 x 2,61 m - with die cushion - with light bareer make SICK

Condition: new, Year of construction: 2026, functionality: fully functional, power: 11 kW (14.96 HP), pressing force: 80 t, stroke length: 350 mm, table width: 1,400 mm, table length: 840 mm, oil tank capacity: 230 l, total width: 1,600 mm, total height: 3,600 mm, overall weight: 8,000 kg, Equipment: CE marking, safety light barrier, NEW EXNER hydraulic testing press, type PG 80 Bwedpsza Em Uofx Akpsn Number of press cylinders: 2 Nominal force (adjustable): 2 x 400 kN Retraction force: 2 x 150 kN Ram stroke: 350 mm Ram width: 1400 mm Ram depth: 840 mm Guide length: 750 mm Ram speed, load up to 100%: approx. 0-10 mm/s Ram speed, retraction: approx. 0-20 mm/s T-slots, table/ram according to DIN 650 = 22 mm Installation height – stroke at top: 600 mm Table width: 1400 mm Table depth: 840 mm Column clearance, front: 1000 mm Column clearance, side: 600 mm Table height above floor: 1100 mm Nitrodyne control / retraction, spring force to be compensated under spring tools: max. 150 kN Accuracy: Maximum deviation of plan parallelism from the ram surface to the table surface (from right to left) in free travel (absolute) < 0.05 mm in eccentric loading with maximum force (absolute) < 0.10 mm Table/ram deflection at nominal force and 2/3 surface coverage: 0.10 mm Starting accuracy U.T. without mechanical depth stop: ± 0.05 mm Optionally, a servo roll feed can be offered and installed.

Condition: like new (used), Year of construction: 2018, functionality: fully functional, Pressing force 300 to Stroke 500 mm Area between the columns 1250x1000 mm Installation height 1000 mm Rapid traverse 22 mm/s Working speed 2 mm/s Bwodpfx Ajvgncnekpon Motor 7.5 kW Length 2000 mm Width 1500 mm Height 3300 mm 4-column guide Round ram guide Table and ram with T-slots 2-hand operation Operating instructions Siemens touchscreen control and electric control panel NEW , 50 programs storable, for programming of: - Upstroke and downstroke rate - Pause time in the floor - Decompression time - Setting the working pressure - Piece counter - Prestop in upward and downward movement - Setting for manual and automatic movement - Management of alarms and anomalies

Condition: used, Double column hydraulic press SMG type HBP 200 - 2000 / 2000 make no. 7.4117 year of construction 1986 - rebuild 2000 pressure force 200 ton. Stand passage front 2050 mm Bwsdpfxjdzp Tce Akpsn column passage sideways 2030 mm table area 2800 x 2000 mm ram area 2000 x 2000 mm ram stroke 700 mm installation height max. 1850 mm Table height above floor 750 mm ram retraction force 33 ton. Rapid feed speed 500 mm/s Pressing speed 72/36 mm/s Return stroke speed 420 mm/s Safety distance 230 mm Motor power main motor 75 kW Motor power control pump 11 kW Mains connection 380 Volt, 50 Hz - 8-fold flat guide for the ram - Clamping plate with 22 mm T-slots at the ram, 2000 x 1900 mm, thickness 60 mm - Hydraulic ram locking at TDC - Measuring system with glass scale - Electrical control renewed in 2000 with SIEMENS SPS S7 - adjacent switch cabinet - 2-hand control panel adjacent - ground level installation - central lubrication - Operating instructions with circuit diagrams Space requirement of the press standing L x W x H 3700 x 2900 x 5900 mm Machine height complete with motor 5900 mm Space requirement for horizontal transport L x W x H 5900 x 3250 x 2950 mm weight 38 ton. The machine was used as a production press at Volkswagen until 2000. From 2000 the machine was used as a tool testing press in a tool shop. good condition

Condition: ready for operation (used), Year of construction: 1979, Immediately available ex-location: Hydraulic high-speed press Lauffer Type EPT 25 Year of manufacture: 1979 Bwodpezap Tljfx Akpjn Inspected according to UVV Press force 25 t Stroke 160 mm Installation height 320 mm Throat depth 230 mm Table 500 x 360 mm Ram 250 x 210 mm Weight 2 t Drive power 7.5 kW Price: EUR 2,750 plus VAT, ex-location.

Condition: good (used), Year of construction: 1970, pressure 80 t passage width 350 mm Bwedpfx Akovwgqropjn stroke 600 mm table dimension - longitudinal 400 mm dimensions of the machine ca. 1400 x 1050 x 2350 m

Condition: good (used), Year of construction: 1990, Bending length: 14,000 mm Column width: 10,500 mm Control: CYBELECCNC 7000 with graphic Table width: 1,000 mm Distance between table and press beam: 1,800 mm Bedpeza Ap Hefx Akpjwn Controlled axes: Y1; Y2; X1; X2 Control system was renewed in 2012 Total power requirement: 75 kW Machine weight approx. min.: 465 t Space requirement approx.: 14,600 x 4,200 x 7,200 mm Additional information - Distance between table and press beam: 1,800 mm

Condition: new, Year of construction: 2019, machine/vehicle number: DF0362, pressing force: 250 t, pressure:250 t passage width:1800 mm stroke:600 mm total power requirement:22 kW weight of the machine ca.:24 t dimensions:ca. 3390 x 3400 x 3800 mm Bwsdpfx Aofxyinskpon column diameter:160 mm return capacity:25 t max. working heidht:800 mm Table dimensions:1800 x 1600 mm :2350 x 1600 mm table height over floor:900 mm hydraulic table shift:25 mm/sec table load:5 t pre-running speed:10 mm/sec pressure speed:10 Return Speed:25 mm/sec speed rapid traverse:10 mm/sec :600 l Oil cooling (electric):1,5 kW (max) :46er / 10 my Monitor SIEMENS:10 Zoll

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 135 t, It has a cylinder for 10 to 135 T and a small additional cylinder for 1500 kg to 7 T. Empty speed 2-10mm second pressing speed 2 mm second table size 1100x650x120mm 800 mm maximum open height table height max. 900 mm travel of the cylinder is 400 mm total height 2900 mm weight 2,3 T 200 L tank Pump with 60 L capacity 5 KW main motor Bodpfx Akjigg E Hepjwn Control system PLC SIEMENS or PILZ RSS4000- S 7 1200 Safety control system PILZ Communication operator/press Color touch screen 10" OMRON/SIEMENS

Condition: as good as new (ex-display), Year of construction: 2022, pressing force: 400 t, Press design double column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 4000 kN Free ripping force max. 400 kN Pressure build-up time Closed die steel to steel Max. 4 sec. Dimensions 3,800 mm long and 4,475 mm wide Max. Opening width 800 mm Stroke 800 mm Table height above floor 1100 mm Height above floor (headroom) approx. 4300 mm Hall height min. 5500 mm parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.2 mm/m Weight Total weight of press without operating materials and table plate approx. 28 t Press table Table size 1500x1500 mm Speeds Fast closing with 100 mm sec. Pressing speed 8 - 3 mm sec. Sound pressure Bodjph Uk Nspfx Akpewn Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders/driving cylinders 1 pc. Operating pressure max. 300 bar Pressing pressure build-up time 4 sec. Pressure accuracy during pressing stroke +/- 3 bar Main pump BOSCHREXROTH axial piston pump approx. 145 L/min Oil volume approx. HLP 46 MW 1000 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Auxiliary pump BOSCHREXROTH, gear pump 10 L/min Pressure stabilization for up to 300 sec. Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Connection hydraulics main motor 40 kW Sliding table press with 400 T capacity, Closing speed up to 100 mm/ ( adjustable via touch screen ) Opening speed up to 100 mm/sec ( adjustable via touch screen ) Starting press speed 10 mm/sec ( adjustable via touch screen ) table top size 1500x1500mm ram size approx. 1600x1500mm Oil temperature monitoring 55 degree warning, 60 degree shutdown Automatic lubrication ( adjustable via touch screen ) Free positioning of the ram ( adjustable via touch screen ) SICK/PILZ light barriers 14 mm, front, up to 1800 mm height Hydraulic and mechanical ram protection Circuit oil cooling ( adjustable via touch screen ) Ejector in table, 20 T press force, 350mm travel Ejector moves outwards with the table Table plate milled flat, with DIN 22 T grooves Pressure adjustment from 60 T to 400 T ( adjustable via touch screen ) Travel limitation either by pressure or position Set-up mode, single stroke and cycle sequence ( adjustable via touch screen ) Swiveling control panel on the cabinet Two-hand operation, with opening button, manual/single stroke/cycle switchover button Installation, commissioning, instruction against separate charge The control is supplied by SIEMENS. ( S 7 1200 ) Also the touch screen monitor with 9 inch. The remote maintenance unit SECOMEA -Ethernet is included in the delivery. The side of the press has two 1000 mm high and 800 mm wide windows with double doors. (sliding table press, hydraulic press, hydraulic press, double column press)

Condition: new, pressing force: 100 t, pressure:100 t passage width:700 mm stroke:450 mm weight of the machine ca.:6 t dimensions:ca. 3000 x 1210 x 3100 mm return capacity:10 t :22 kW Max Working height:850 mm :1 - 100 mm speed of return flow:1 - 100 mm/sec :1 - 10 mm/sec. pestle plate:1090 x 600 mm table plate:1090 x 600 mm positioning accuracy:0,1 mm table height over floor:800 mm :300 l Oil cooling (electric):1,5 kW (max) ejector:d=100 mm ejector stroke:210 mm pressure of ejector:100 t Bwedpfxefxyhqe Akpsn no. of ejector pins:1 Stück Monitor WEG:15 Zoll :2.000,-- ? :2.400,-- ? :3.000,-- ? :2.400,-- ? :5.800,-- ?

Condition: used, Year of construction: 2016, machine/vehicle number: 4303, pressing force: 500 t, pressure:500 t passage width:2100 x 1500 mm stroke:1000 mm total power requirement:62 kW weight of the machine ca.:39 t dimensions:5100 x 2800 x 4040 mm return capacity:40 t Main cylinder:2 Stück column diameter:Hauptzylinder 360 mm Table dimensions:2100 x 1500 with T-Nute mm Ram size:2100 x 1500 mm table height over floor:850 mm pre-running speed:300 mm/sec return speed:300 (bei 20T Stößelgewicht) mm/sec Pressure Speed:200T = 28 mm/sec Oil Tank Capacity:ca. 1000 l Auxiliary cylinder:2 Stück column diameter:Hilfszylinder 120 mm Total size Table Tops:ca. 2750 x 1600 mm Total size of plunger plates:ca. 2750 x 1600 mm Pressure Speed:300T = 20 mm/sec Bwodpfx Aodyynvjkpjn Pressure Speed:500T = 6 mm/sec Retract force of the plunger:40 t Tension of the control chain:24 V voltage:400 V Frequency:50 Hz Axial piston pump (REXROTH/Bosch A4VSO125):290 lt/min Daylight Opening:1500 mm Hydraulic block:REXROTH pressure control:über PLC (Mindestdruck 50T) Cylinder:4 x ?90 x 70 mm stroke length max.:300 über PLC einstellbar mm Outejection speed forward:95 mm/sec. Outejection speed return:240 mm/sec. Capacity:4 x 15T bei 250 bar t Pressure setting:über Monitor von 50-500T t Pressure constant posture:0-900 sec Hydraulics tank:2000 l Siemens Control System:S7 300 Storage capacity:200 Programme Electronics from German manufacturers:SIEMENS/MÖLLER Tax desk:auf Schwenkarm Light sensors sick:1500 auf der Vorderseite mm

Condition: like new (used), Year of construction: 2016, pressing force: 400 t, passage width 2500 mm stroke 900 mm Total power requirement 62 kW machine weight approx. 27,5 t dimensions L x W x H approx. 3950 x 2200 x 4850 mm retraction force 40 t Main cylinder 2 pieces column diameter 220 mm installation height 1300 mm table size 2500 x 1600 mm ram size 3100 x 16000 mm table height above floor approx. 900 mm forward speed 200 mm/sec return speed 200 mm/sec working speed 5 - 15 mm/sec oil tank 1500 l oil quantity 1200 l pressure control adjustable from up to 50 - 400 t thermoforming cushion 1400 x 800 mm thermoforming unit capacity 30 - 60 t deep drawing cushion stroke 250 mm thermoforming cushion speed 5 - 80 mm/sec robust machine body with solid welded construction low maintenance and reliable piston rod with induction hardening and chrome plating T-slots according to customer requirements, if not specified 22mm according to DIN CE certificate manufactured according to EU standards operating instructions, technical documentation, documentation in German language engineering steel LCG ASTM A36 T-slots in table and ram according to DIN 650-22 Travel control adjustable via monitor Light sensors front + rear: Sick 1300mm Hydraulic components Bosch Rexroth Monitor Siemens 12 inch Electrical control box for wall mounting Interior of the press illuminated with LEDs Hydraulic block monitored by safety PLC Energy control system: Reduction of the idle consumption of the pump to approx. 2 kw Remote control for remote maintenance Two-hand operation on movable stand Further information: Pressure build-up up to 400 T within max. 4 seconds after closing the die. Left side of the press closed by door 1000 x 800 mm with cross bars Ø 20 mm Bwjdpfsin Et Nex Akpsn Right side of the press closed by door 1000 x 800 mm with cross bars Ø 20 mm Operation of the press can be manual, semi-automatic or fully automatic

Condition: used, Year of construction: 2021, functionality: fully functional, pressing force: 500 t, ME-Pressen Portal Straightening Press – 500 t – 2,000 × 850 mm – Stroke 1,300 mm For sale is a hydraulic portal straightening press from ME-Pressen with a pressing force of 500 t. This machine is specifically designed for straightening and bending operations and is equipped with an integrated tooling clamping device as well as parallel control for bending blades. Thanks to its movable table, sliding cylinder, and robust construction, it is ideally suited for flexible applications in toolmaking and series production. ==== Technical Data & Information: Hydraulic Portal Straightening Press – 500 t ==== General Specifications - Manufacturer: ME-Pressen - Model: Portal Straightening Press - Design: Gantry press - Machine type: Sliding table press / Straightening press - Pressing force: 500 t (5,000 kN) - Machine weight: approx. 25 t - Dimensions (L × W × H): approx. 1,500 × 3,000 × 4,300 mm - Number of operator sides: 3 ==== Working Area - Max. opening width: 1,500 mm - Stroke: 1,300 mm - Min. opening: 200 mm - Table height above floor: approx. 850 mm - Open height: 1,500 mm ==== Table & Movement - Table size: 2,000 × 850 mm - Table hydraulically traversable: 700 mm outward - Table in grid construction - Cylinder horizontally traversable via rack and pinion ==== Speeds - Closing speed: up to 17 mm/s - Opening speed: up to 44 mm/s - Pressing speed: depending on load ==== Hydraulics & Performance - Pressure setting: 80–500 t via rotary control - Pressure build-up time: max. 3 sec. - Free breakout force: max. 800 kN - Oil temperature monitoring available - Lubrication via grease nipples Bsdpfx Akjwgakvjpewn ==== Construction & Features - Integrated tool clamping device - Parallel holding for bending blade - Induction-hardened cylinder - Machine body powder-coated / double painted - T-slots to customer specification ==== Operation & Safety - Remote control - Robust construction for industrial applications ==== Accuracy - Deflection: ≤ 1.2 mm/m (at 70% load) ==== Straightening operations, bending processes, toolmaking, series production, heavy-duty forming Hydraulic press, portal press, straightening press, sliding table press, industrial press, forming press Looking for a hydraulic press tailored to your application? Contact us for a custom offer. Our hydraulic presses are constructed according to German machinery guidelines as well as European Machinery Directive (2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements as they fully comply with the Brazilian national safety standard NR 12, which builds on these standards. Our core strengths are special purpose machine construction and press automation. We offer customized hydraulic presses at surprisingly competitive prices. For the hydraulics, we predominantly use components from leading European manufacturers.

Condition: like new (used), Year of construction: 2025, functionality: fully functional, pressing force: 40 t, table width: 1,000 mm, table length: 600 mm, Hidrobrasil Double Column Press – 40 t – 1,000 × 600 mm – Stroke 500 mm For sale is a hydraulic double column press (H-frame) manufactured by Hidrobrasil, featuring an adjustable pressing force from 6 to 40 t. This machine is designed for calibration, assembly, and small series applications, and stands out thanks to its compact design, robust guidance system, and precise control. Ideal for flexible production processes with changing requirements. ==== Technical data & information: Hydraulic Double Column Press – 40 t ==== General information - Manufacturer: Hidrobrasil - Model: Double Column Press - Design: H-frame / Double Column Press - Designation: Small Batch Press / Calibration Press - Pressing force: 6–40 t (adjustable) - Machine weight: approx. 3,500 kg - Dimensions (L × W × H): approx. 2,100 × 1,600 × 3,500 mm ==== Working area - Max. installation height: 700 mm - Stroke: 0–500 mm (adjustable) - Table height above floor: 800 mm ==== Table & Slide - Table size: 1,000 × 600 mm - Slide area: 1,000 × 600 mm - Guide columns: Ø 100 mm (4 units) - T-slots and holes: as per customer specification ==== Speeds - Rapid traverse speed: 80 mm/s - Pressing speed: 9 mm/s - Return speed: 90 mm/s ==== Hydraulics & drive - Hydraulic pump: ASC, 67 + 8 l/min - Motor power: 4 kW - Total connected load: approx. 6 kW - Operating pressure: max. 260 bar - Pressure accuracy: ± 5 bar - Hydraulic manifold and valves: Duplomatic - Air and oil filters: Filtrec - Electronic oil level switch - Air cooling for hydraulic system - Pressure adjustment via pressure switch - Hydraulic unit mounted at top rear ==== Control & Safety - Control via sensors - Safety light sensors - Safety cover (door) at rear - Work area interior lighting - Pressure display via manometer ==== Electrical - Main supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz - Components: Siemens, Allen Bradley, SICK ==== Electrical cabinet - Protection class: IP54 - Spare capacity: approx. 30% - Cooling: air cooling - Interior lighting: fitted - Operating mode selector: lockable ===== Bsdpfsxrby Hex Akpewn Calibration, assembly work, small batch production, forming technology, flexible production Hydraulic press, double column press, H-frame press, calibration press, assembly press, industrial press Looking for a hydraulic press tailored to your application? Contact us for a customised offer. Our hydraulic presses are manufactured in accordance with German machinery directives, as well as European machinery directives (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed Canadian and European safety requirements as they fully comply with the Brazilian national safety standard NR 12, which builds upon these. Our key strength lies in special-purpose machine engineering and press automation. We supply customised hydraulic presses at surprisingly competitive prices. All presses are equipped with hydraulic components primarily from leading European manufacturers.

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 400 t, Hydraulic 400 to column press suitable for continuous shift operation, with these basic data: a) Closing speed 100 - 450 mm/sec. b) Opening speed 50 - 250 mm/sec ( adjustable via touch screen ) c) Pressing speed 5 - 60 mm/sec ( adjustable via touch screen ) d) Piston accumulator with approx. 4 nitrogen bottles e) Table size (clamping surface) 2700 x 1700mm ( seen from the front, between the columns ) f) Total table size 3400 x 1700mm g) 28 T-slots according to customer requirements h) Table, ram and press head are annealed stress-free. i) column diameter 250 mm j) slide size 3400 x 1700mm (clamping surface 2700 x 1700mm ) k) Total size of the machine approx. 3900 x 2200 ( at the bottom ) x 5700 mm height l) Oil temperature monitoring ( adjustable via touch screen ) m) Automatic lubrication ( adjustable via touch screen ) n) Free positioning of the ram ( adjustable via touch screen ) o) KEYENCE light barriers 14 mm on front and rear side p) Circuit oil cooling ( adjustable via touch screen ) q) Pressure holding valve 0 to 600 sec. ( adjustable via touch screen ) r) Table top size 3400 x 1700mm, plane milled s) Laterally monitored doors, 1200mm high, 1000mm wide t) RITTAL control cabinet, 2200 mm wide, up to 20 m from the press u) Pressure setting from 50 to 400 tons ( adjustable via touch screen ) v) Travel limitation optionally via pressure or position w) Programming mode, set-up mode, single stroke + continuous stroke (adjustable via rotary switch ) x) Swivelling control panel with 15 inch touch screen monitor y) Two-hand operation on both sides z) Prepared for automatic material feed ( SIEMENS S 7 1500 ) aa) Machine body primed and painted Bjdpsg Iihwjfx Akpswn bb) assembly, commissioning, instruction against separate charge The hydraulics of the presses we offer are completely based on BOSCH-REXROTH/Parker/HAWE components. In the switch cabinet only components are used (SIEMENS) which are easily available in Germany. The safety technology comes completely from SICK except for the light barriers. The control system is supplied by SIEMENS. ( S 7 1500 ) as well as the touch screen monitor with 15 inch. The SIEMENS remote maintenance unit SECOME -Ethernet is included in the scope of delivery. SPECIAL FEATURE: the design chosen by us with two press cylinders and the piston accumulator make it possible to supply the full power with a main motor of 90 kW. Below under 1.3 the technical details Technical data Press design Press design Column press Thermally neutral 80 - 120 °C Number of operating sides 2 sides Forces Pressing force max. 4,000 kN Free ripping force max. 600 kN Pressure build-up time Closed tool steel to steel Max. 2 sec. Dimensions - intended minimum tool height 600 mm Max. Opening width 1600 mm Stroke and min. opening 1000/600 mm Table height above floor 820 mm Height above floor (headroom) approx. 5700 mm Hall height min. 7000 mm Parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.17 mm/m Weight Total weight of the press without operating materials approx. 52 To Speeds ( see attached cycle diagram ) Fast closing 100 - 450 mm/s Pressing speed At F max.

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 20 t, Double column press 20 T capacity, a) Closing speed up to 10 mm/sec b) opening speed up to 30 mm/sec c) table size between columns 1400x1100 mm d) ram size between columns 1400x1100 mm e) Manual lubrication (via grease nipple) f) UKF pump-cooling-filtration ( electrical cooling ) g) Pressure adjustment from 4 T to 20 T ( adjustable via rotary control ) h) Travel adjustable via slide control Type of construction Press design Double column press ,hydraulic Thermally neutral 80 - 120 °C Number of operating sides 1 side Bwodpfxjhmbhqe Akpen Forces Pressing force max. 200 kN Free ripping force max. 20 kN Pressure build-up time Closed tool Steel on steel Max. 4 sec. Dimensions Max. Opening width 500 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 2800 mm Hall height min. 3,500 mm Parallel deviation at 20°C #ERROR! mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.4 mm/m Weight Total weight of the press without operating materials approx. 3 to Table cut-out Size 1100x850 mm Speeds Fast closing with 9 mm sec. Pressing speed 9 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of press/driving cylinders 2 pcs. Operating pressure max. 280 bar Pressing pressure build-up time 3-5 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH/PARKER approx. 35 L/min Oil volume approx. HLP 46 D 150 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Circulation pump for cooling ACS approx. 6.5 L/min Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 5 kW

Condition: like new (used), Year of construction: 2019, pressing force: 400 t, pressure:400 t stroke:900 mm Table dimensions:1200 x 1200 mm Bwodpfsfh Izmex Akpen Deep-Drawing Pillow:150 t travel away deep-drawing pillow:280 mm Daylight Opening:1100 mm
