Used folding machines / bending brakes (motor-driven) 2000-2999mm for sale (69)

Condition: ready for operation (used), functionality: fully functional, working width: 2,500 mm, bending angle (max.): 90 °, sheet thickness (max.): 4 mm, overall weight: 4,300 kg, TECHNICAL DETAILS Bending angle: 0 - 90 degrees Bending width: 2,500 mm Max. bending thickness: 4 mm Max. jaw opening: 100 mm MACHINE DETAILS Weight: approx. 4,300 kg Caodpfx Aex A Uf Dodusa EQUIPMENT Additional tools (as per images) Wiring diagram

Condition: used, Year of construction: 2000, Empty weight: 22.000 kg Price: On request Working width: 1500mm Working length: 2160mm Max. thickness: 2mm With Supply-station infeed. Csdpfx Asww Eqcsdusaa - Year: 2000 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 12/50 - Control: CNC - Motor power: 18.0kW - Transport weight [kg]: 22000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, functionality: fully functional, Year of construction: 1975, Mechanical Swing Bending Machine Make: FASTI Model: 208 2040x3mm Year: 1975 Technical Data Manufacturer: Fasti Model: 208-20-3 Year of Manufacture: 1975 Working length: 2040 mm Sheet thickness: 3 mm Upper beam stroke: 200 mm Stroke speed: approx. 7 mm/s Dimensions: Weight: Equipment • Swiveling upper beam Cajdsx An Tuepfx Aduea • Motorized upper beam • Maximum upper beam opening: 200 mm • Lower beam adjustable beneath pivot point, 100 mm • Bending beam adjustable beneath pivot point, 100 mm • Bending beam swivels up to 180° • Backgauge adjustable from 0 to 600 mm • Various bending rails as shown in photo All information provided without guarantee. A powered demonstration is available at any time in our exhibition hall.

Condition: used, Max. bending length: 2040 mm Max. sheet thickness: 3 mm steel Manual and automatic bending process possible Bending angle adjustable via potentiometer Lifting height of the upper beam and material thickness can be preselected via dip switch Codpfxsxz Emve Aduoaa Manual backgauge with spring fingers Weight: approx. 2300 kg

Condition: ready for operation (used), Year of construction: 1977, Immediately available from site: Hydraulic folding machine Köllschen Type AM 2500/5 Year of manufacture: 1977 Bending length: 2550 mm Material thickness: 5 mm Back gauge Additional new bending rails Drive: 7.5 kW Weight: 5 t Price: EUR 4,000 plus VAT ex works Csdpfx Asx Ab Ededujaa

Condition: good (used), functionality: fully functional, Bending capacity at 400 N/mm²: 8 mm Usable length: 2500 mm Upper beam stroke: 450 mm Cedpsx A S D Rjfx Adujaa Lower beam: 125 mm Bending beam: 125 mm Price: EUR 9,900,-- net

Condition: used, Year of construction: 1985, sheet thickness: 2,25total power requirements: 1,1sheet length: 2025 Working length: 2025 mm Kl. Tail width: 5 x s Kl. Inner radius: 1.5 - 2 x s Adjustability of the lower and bending beams: 90 mm Caedpfovaatfjx Adusa for round bends: 90 mm Highest working position of the upper beam: 190 mm large opening width of the upper beam: 290 mm Duration of a workflow: 7.0 sec. External dimensions approx.: 3000 x 1000 x 1650 mm with: - Control panel on the right side of the machine - Simple bending angle adjustment on the control panel - Choice of switching to automatic, semi-automatic or typing mode - Potentiometer for degree adjustment -Foot switch used, in good condition

Condition: used, Year of construction: 2006, total length: 1,850 mm, total width: 1,700 mm, total height: 1,300 mm, Empty weight: 1.000 kg Working width: 1050mm Max. sheet thickness: 4mm Backgauge: 900mm - Year: 2006 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 2607 - Control: Conventional - Transport dimensions: 1850mm x 1700mm x 1300mm (l x w x h) - Transport weight [kg]: 1000kg - Transport packages [pcs.]: 1 Csdpfx Adewk Iqlsuoaa Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Year of construction: 2001, condition: excellent (used), Article number: MA1058 Manufacturer: Fasti Type: vertical bending machine Cjdpfx Adsd Avc Ejusaa Year of construction: 2001 Machine number: 00726004 Bending length [mm]: 3000 Control: Delem DZ-65 - VA3D Length [mm]: 5350 Width [mm]: 2300 Height [mm]: 2200 Weight [kg]: 6510 Power supply: 380V / 17 KW Usable height [mm]: 250 Maximum sheet thickness [mm]: 4 Table size Lxw: Backgauge 1500 CNC controlled Accessories: manual / schematics

Condition: used, Bending length: 2000 mm Cajdetwnlnepfx Aduea Manufacturer: FASTI

Condition: used, Max. bending length: 2540 mm Max. sheet thickness: 2.5 mm steel Manual and automatic bending mode possible Bending angle adjustment via potentiometer Polished bending rail Csdsxrt Rkepfx Aduoaa Weight: 1,700 kg

Condition: used, Year of construction: 1980, sheet width 2050 mm plate thickness 8 mm electrical . weight of the machine ca. 6,3 t +++++ Please note: Cjdpfx Adekxhrhjujaa The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Year of construction: 2007, condition: excellent (used), RAS Turbo bend plus 62.25 New gearboxes fitted from Ras Bending length 2540mm / 2.5 metre Material thickness max 2.5mm Four extremely dynamic and fast ramp-driven movements under CNC System 6000 CNC touch screen – New control fitted in 2016 Extended back supports Light guards Portable tooling rack New / Year of manufacture 2007 Complete with: J shape back gauge Complete with segmented and straight tools and tooling rack Tooling (supplied with the machine): Standard ‘sharp’ upper tooling – 3x lengths 845mm Bottom tooling single length – 1x 2.54m length 10mm wide Bottom tooling single length – 1x 2.54m length 20mm wide Goats foot segmented upper tooling – 110 height section 200mm wide – 10 lengths 60mm – 1 length 55mm – 1 length 50mm – 1 length 45mm – 1 length 40mm – 1 length 35mm – 1 length 30mm – 1 length 120/90mm LH Box end – 1 length 120/90mm RH Box end – 1 length Segmented bottom tooling 200mm wide – 10 lengths Cedpfsgd Dgqsx Adueaa 120mm – 2 lengths 60mm – 1 length 55mm – 1 length 50mm – 1 length 45mm – 1 length 40mm – 1 length 35mm – 1 length 30mm – 1 length Tool cart supplied

Condition: used, Year of construction: 1965, Press brake, folding bench, bending press Model: Hydraulic Caedewnhu Espfx Aduea Manufacturer: RAS Type: 70/1 Working width: 2040mm Capacity: 5mm Max opening height: 90mm Back-gauge: 600mm Hydraulische Motor: 3kW Machine-dimensions: 3500x1300x2350mm Machine-weight: 3500kg - Year: 1965 - Documentation available: No - CE certificate present: No - Serial number: 16212 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1988, Technical details: plate width: 2050 mm plate thickness: 2 mm distance between columns: 2400 mm knife length: 2050 mm stroke adjustment: oben 250 mm adjustment of stroke: unten 100 mm bending angle max.: 180 ° Cajdju Ib Dfjpfx Aduja back gauge - adjustable: mit Aufnahmeschienen mm working pressure: 5,0 MPa total power requirement: 2,2 kVA weight of the machine ca.: 2,3 t dimension machine xH: 3,5 x 1,0 x 2,2 m dimensions of hydaulic: 0,75 x 0,55 x 0,80 mm HYDRAULIC FOLDING MACHINE operation via control panel with boom as well as via foot switch bending angle: sharp bending = up to 135° with 2mm sheet metal stroke of the upper beam = 250mm stroke of the lower beam = 100mm bending jaw stroke = 100mm bending gap = 7mm with scale display *

Condition: used, functionality: fully functional, Year of construction: 2007, control type: CNC control, actuation type: electric, back gauge adjustment: CNC-controlled, back gauge: 1,550 mm, input voltage: 400 V, type of input current: three-phase, Equipment: emergency stop, foot remote control, We offer a used RAS 62.25 folding machine, a robust and precise solution for sheet metal bending. This machine combines German build quality with user-friendly operation, making it a solid choice for workshops and production facilities. Specifications: Model: RAS 62.25 Year: 2007 Capacity: 2,550 mm x 2.5 mm Backgauge: 1,550 mm CNC-controlled Installed tool: Segmented “goat’s foot” rail, 110 mm height Included tooling: - Sharp rail - 10 mm bending rail - 20 mm bending rail Condition & Service: - Fully serviced and tested – ready for immediate operation - Well maintained with complete inspection carried out Casdpfx Adexd Tfrouea - Excellent working condition Benefits: - High precision bending for a wide range of sheet thicknesses - CNC backgauge ensures accurate and repeatable production - Comes with multiple tooling options for flexibility in use - German quality machine – built to last

Condition: used, Year of construction: 1999, Max. bending length: 2540 mm Max. sheet thickness: 3 mm steel Manual and automatic bending process possible Bending angle adjustable via potentiometer Lifting height of the upper beam and material thickness can be preselected via dip switch Cajdpfx Aexrt Hleduoa Polished bending rail Weight: 3400 kg

Condition: used, Belano sheet metal sheet stiffening and profiling machine. In good condition. For stiffening sheet metal used in the manufacture of ventilation ducts, where the metal needs to be reinforced to avoid unwanted vibration. If you have any further questions, we will be happy to answer them. Caodpfx Adjrhkkyjusa

Year of construction: 2012, condition: excellent (used), Used Ras 62.25 CNC Folder Model: 62.25 Ras Year 2012 RAS 62.25 CNC folder Capacity: 2540mm x 2.5mm CNC Auto Bending Machine (Year 2012) Complete with fitted System 6000 Touch screen control (screen recently replaced) 3.2 Metre J shape back gauge Twin Foot Pedal Control MACHINE GUARD SOLUTIONS Light Guards Casdsn Tnzfepfx Aduoa Complete with segmented and straight tools

Condition: used, Year of construction: 2020, sheet width 2100 mm plate thickness 3,0 mm distance between columns 2450 mm daylight opening 160 mm max. 150 ° back stop - adjustable 6,0 - 1000 mm Control CNC total power requirement 5,37 kW dimensions 3250 x 2450 x 2100 mm weight of the machine ca. 3850 kg Caodot Smm Eepfx Aduja ORIGINAL PRICE: ~ 60,000 EURO Features: - ERBEND 15.6" CNC control panel operating unit - Electric backgauge from 6.0 to 1,000 mm * Material support table with ball rollers * Drive with servo motors - LED machine lighting - 1x 30° upper tool - radius 1.0 mm - 1x bending rail 15 mm / 1x bending rail 25 mm - Electric safety device at the front (light barriers) - Freely movable foot control - Operating instructions - CE declaration Special accessories included: - Split gooseneck upper tool, height = 90 mm - CNC electric motorized lower beam adjustment - Manual crowning of the bending beam

Year of construction: 1969, condition: used, Swivel bending machine Albert steel TYpABK 400 /5 Caedpfxjh Rkh De Aduja useful length 2530 mm Sheet thickness 5 mm

Condition: excellent (used), Swing bending machine Brand: Fasti Working width: 1000 mm Codpfx Adsxcx Hrjuoaa Sheet thickness approx. 1.5 mm Width: 1320 mm Depth: 650 mm Height: 1020 mm

Condition: good (used), Year of construction: 1988, Bending machine, folding machine, swivel bending machine, die bending machine -Handover: in the current condition as viewed -Function: Manual operation (no automatic operation) -Manufacturer: RAFAMET folding machine type KM-4 -Drive: mechanical -Max. working width: 2020 mm -Max. sheet thickness: 4 mm Casdpfxov Tpxqe Aduoa -Stop depth: 750 mm -Connected load: kW -Dimensions: 1540/3350/H1510 mm -Weight: 3900 kg

Condition: ready for operation (used), Year of construction: 1985, sheet width 2540 mm plate thickness 2.5 mm distance between columns 2600 mm adjustment of lower beam ca. 25.0 mm upper clamping bar adjustment ca. 275 mm work height max. 915 mm bending angle max. 180 ° total power requirement 6.5 kW weight of the machine ca. 3500 kg range L-W-H 3700 x 2150 x 1600 mm from a maintenance workshop (university hospital) Caedpfx Asxgibhjduea Features: - Robust/electric motor-driven swivel bending machine - Electric bending angle preselection with analog angle display - Manual and semi-automatic modes selectable - Manual lower beam adjustment - 1x freely movable foot control - 2x emergency stop buttons at the front - original operating instructions * Special accessories included: - 1x split set of goat's foot tools (upper tool) - 2x extra bending rails - top - 2x extra bending rails - bottom

Condition: good (used), Year of construction: 2003, sheet width 2520 mm plate thickness 2.50 mm ST thickness at "Niro-steel" 1.50 mm upper clamping bar adjustment 160 mm adjustment speed 100 mm/sec Adjustment folding beam 80.0 mm Bending speed 120 Grad/sec compressed air 6.0 bar work height max. 869 mm control POS 2000 voltage 400 V total power requirement 7.2 kW weight 3430 kg range L-W-H 4120 x 2400 x 2090 mm Caedjxbh Euopfx Adusa Current new price ~ 100.000 euros From a maintenance workshop With very good equipment (!!) Equipment: - CNC electric motor-driven universal swivel bending machine * High-precision mechanics with modern control technology * For individual and series production * Robust high-speed machine with high axis speeds * Torsion-free welded construction - Rotatable upper beam / as automatic tool change system * With 2x tool stations (sharp and goose foot bending rail) * Reduces set-up and idle times * Eliminates time-consuming tool changes and adjustments - SCHRÖDER CNC control model POS 2000 * Control panel at front right (operable with PC mouse) * Color display * USB interface * Automatic cutting calculation * Material and tool library * Dimensionally accurate bending simulation * Windows XP operating system * Swivel control, front right - Servo converter-controlled drives * for bending/upper beam & electric backgauge - CNC motorized lower beam adjustment - CNC electric motorized backgauge * Travel speed 300 mm/sec. - with rear sheet metal support surface, including ball rollers - 1x freely movable double foot switch - Operating instructions (PDF)
