Used Ras for sale (68)

Condition: used, Year of construction: 2014, functionality: fully functional, MiniBendCenter RAS 79.05 Fully automatic panel bending center for small parts - General Information: Direct from manufacturer Manufacturer’s warranty Maintenance included Latest possible software version - General technical data (in mm): Blank length: 50–600 Blank width: 40–600 Sheet thickness max. (400 N/mm²), tool-dependent: 3.0 Upper beam stroke max.: 500 mm Minimum flange height (reference value, tool-dependent): 5 × s Max. flange height: 127 Weight of bending cell: 10 tons Weight of enclosure and electrics: approx. 2,027 kg Weight of machine elements: approx. 945 kg - Machine-specific data: Motor operated; 400V, 50/60 Hz, 3-phase Year of manufacture: 2014 Condition: Refurbished – good used condition - Machine Configuration: Bending cell: - Automatic sheet thickness adjustment - Automatic tool clamping - Blank scanner Main manipulator: - 3 servo motors for X, Y, Z axes - 1 servo motor for lower rotary axis + separate drive for rotary axis - Double sheet detection Tool changer: - 3 servo motors for X, Y, Z axes - 1 pneumatic swivel drive for rotary axis - Tool gripper - Two-level tool magazine - Automatic tool clamping in tool magazine Enclosure: - Bending cell, front and rear Mobile operating panel: - 18" Touch & More control Intelligent loading robot Combined camera-scanner system Analysis software Transfer table, Sauerfeld (52x9 mm) suction row (7x20 mm) Pallet station: - Roller conveyor and heavy-duty chain conveyor - 1 position for new pallets (parts to be processed) Blsdpfxex Hyhus Acfjp - 1 position for "pallet in process" - 2 positions for finished pallets (empty or with remaining parts) Curved transport conveyor with 6 connection stations Finished part output enclosure Complete tool set RAS CAM-Office software incl. SolidWorks license and 2-year maintenance contract - Sample images Sample video available on request -

Condition: used, functionality: unexamined, Year of construction: 2015, machine/vehicle number: 6233, Technical data: Maximum sheet thickness (sheet steel) 3mm Maximum sheet thickness (chrome steel) 2mm Maximum sheet thickness (aluminum) 4mm Maximum bending length 3200mm Maximum four-sided bending part height 300mm Minimum base area of a finished bent part 185mmx210mm Upper beam stroke 650mm Maximum bending beam travel distance 150mm Positioning accuracy of PosLift stop system 0.01mm Working height 1000mm Machine width with PosLift stop system in rectangular shape approx. 3000mm Machine width with PosLift stop system in J-shape approx. 4700mm Machine length approx. 6700mm Maximum machine height approx. 2600mm Net weight approx. 13000kg Air pressure 5.5 bar Total drive power 14kW Speeds: Bjdpfx Aevxz Tqecfjlp Bending beam 140°/s Upper beam 95mm/s

Condition: used, functionality: fully functional, Rollformer used for Pittsburgh seams, not CE, RAS 22.07. Bledpfszh E A Dex Acfjp

Condition: excellent (used), Profiling system Ras Inventory no. 3949 Manufacturer: Ras Type: Ras 29.03 * 11 stations * Shaft diameter 28 mm * Strip width: 150 mm Blsdpfszyytzex Acfjp * Strip thickness: 1.5 mm * Flying hydraulic shear * Connected power: 11.5 kW

Condition: used, functionality: fully functional, Used 6-meter swiveling bending machine from RAS. Bedpo Ahgtbsfx Acfolp Type: 76.60 Capacity: 6050 x 2 mm Manual back gauge system.

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 12/50, sheet thickness (max.): 2 mm, power: 18 kW (24.47 HP), working width: 1,500 mm, working length: 2,160 mm, control type: CNC control, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working width: 1,500 mm Working length: 2,160 mm Sheet thickness: 2 mm Bodpj Af Smljfx Acfjlp Engine power: 18.0 kW Control system: CNC MACHINE DETAILS Weight: 22,000 kg EQUIPMENT Complete loading system Documentation available CE marking available

Condition: like new (used), functionality: fully functional, Year of construction: 2012, operating hours: 7,000 h, Equipment: CE marking, documentation/manual, RAS Multibend Center 79.26–2 Bsdpfxoz Ig Tus Acfjlp Maximum board length: 2560 mm Maximum board width: 1500 mm Maximum bending height (four-sided): 203 mm Up and down bending Tool changer Board feeder for robot loading KUKA loading robot KR 150-2K Various tools for sheet metal thickness 1-2.5 mm Only approximately 7,000 operating hours! Absolutely like new condition, evident, among other things, in the hardly worn original tools. Inspection while the machine is powered on is possible. Price is ex works; the buyer is responsible for dismantling.

Condition: used, Year of construction: 2007, sheet width 3190 mm plate thickness 6,3 mm back stop - adjustable 5-1000 mm work height max. 930 mm 30-50 cutting angle 1,2 ° total power requirement 18,5 kW weight 6800 kg Bjdpfxe Agclae Acfjlp

Condition: used, Year of construction: 1994, Technical details: sheet width: 3200 mm plate thickness: 4 mm distance between columns: 3200 mm connected load: 9 kW connection voltage: 380 V Total power requirement: 7,5 kW bending angle max.: 180 ° air-pressure connection: 6 bar depth stop: 10 - 1550 mm adjustment speed: 200 mm/sec Weight approx.: 5800 kg dimension machine approx.LxWxH: 4,6 x 2,1 x 2,6 m Control system: RAS Multibend 9000 CNC with color monitor RAS 74.30 – Hydraulic Folding Machine The RAS 74.30 is a robust, hydraulically operated folding machine manufactured by the German company Reinhardt Maschinenbau GmbH (RAS), based in Sindelfingen. The machine is designed for precise bending and folding of sheet metal in industrial applications.With a working and bending length of 3,200 mm and a maximum sheet thickness capacity of 4 mm for steel, the machine is particularly suitable for manufacturing long profiles, cladding panels, housings, ducts and general sheet metal constructions.During the folding process, the workpiece is clamped between the upper and lower beams. The folding beam then performs a swivelling movement, forming the sheet metal to the required angle. This process enables controlled bending while minimizing material stress, particularly when processing large-format sheet heavy-duty machine construction, with a net weight of approximately 5,800 kg, ensures excellent stability during the bending process. The installed drive power is 7.5 kW. Bljds Agnm Repfx Acfsp *

Condition: excellent (used), functionality: fully functional, Cutting length: 2520 mm Sheet thickness at 400 N/mm²: 4.0 mm Strokes per minute: 47 Rear stop, approx.: 750 mm Overhang: 350 mm Equipment: Side stop on the left, 750 mm Bljdpfxs Ady Hae Acfjp Cutting gap adjustment Rear stop with vernier scale; blades are sharp and not yet shimmed.

Condition: excellent (used), functionality: fully functional, Year of construction: 2014, control type: CNC control, Equipment: CE marking, Used Cnc folder Ras XL Center 63.30 cnc folder up down folder 3metre For Sale Capacity: 126-inch / 3.2 metre (3,200 mm) folding length and can handle up to 16-gauge (1.5 mm) mild steel. Bi-directional Folding: The machine folds parts both up and down, which minimizes material handling by the operator and increases production speed. Precision Technology: It is equipped with five servo-regulated motors for high-speed operation and includes programmable gripper positions for creating tapered or conical parts. Software Control: Features a multi-touch PC control system where operators can draw profiles directly on the monitor; the software then automatically calculates the folding sequence and provides 2D/3D simulations. Bodpfxeym T Ias Acfjlp Design Flexibility: Offers 300 degrees of free space in front of the folding beams, allowing for the creation of complex part designs that standard machines might struggle to accommodate.

Condition: good (used), functionality: fully functional, Year of construction: 2000, working width: 3,200 mm, sheet thickness (max.): 4 mm, sheet thickness steel (max.): 4 mm, sheet thickness stainless steel (max.): 3 mm, sheet thickness aluminum (max.): 6 mm, back gauge adjustment: CNC-controlled, power: 7.5 kW (10.20 HP), Equipment: documentation/manual, Very well-maintained and technically upgraded RAS 74.30 folding machine with a working length of 3200 mm. The machine has been specifically modernized and is immediately ready for production – ideal for metal construction and sheet metal processing. Technical data: Working length: 3200 mm Max. sheet thickness: 4.0 mm (steel) Year of manufacture: 2000 Power: 7.5 kW Weight: approx. 5800 kg Equipment / Highlights: Motorized backgauge with swing fingers Travel path up to 2500 mm with stop extension Refurbished power supply Upgraded control system New SD card slot New flat screen (not yet visible in the photos) Reliable, robust industrial machine The machine runs smoothly and can be inspected under power. Blsdpfjy A Ewmex Acfsp

Condition: good (used), functionality: fully functional, Universal folding machine, type 22.10, sheet metal thickness 1.5 mm, drive power 3 HP. Bjdpfx Acj Aa Azfefolp

Year of construction: 2016, condition: excellent (used), Used modern, very clean & fully serviced RAS UpDownBend 78.40 cnc Folding System for sale Bledpfx Asnnz Apecfjp 4metre up and down cnc folding machine with U shape back gauge as highlighted per photograph Year 2016 Technical Data: Material Thickness max. (Mild Steel) 3.0mm Material Thickness max. (Stainless Steel) 2.0mm Material Thickness max. (Aluminium) 4.0mm Working Length 4060mm / 4metre Gauging Depth ("U" shape) 95-3270 (4150)mm Stop Finger Units (fix - telescope - fix) 2 + 10 + 2 Gauging System Accuracy -/+ 0.1mm Open Height Upper Beam max. 600mm Telescopic Gauging System (Travel Range) 640 – 1520mm Pivot Point Adjustment +/- 15mm Folding Beam Height Adjustment 150mm Folding Beam Travel Range 180 deg Working Height 1000mm Speeds: Upper Beam 75mm/s Folding Beam 110 deg/s Gauging System from min to max 2.2s

Condition: excellent (used), functionality: fully functional, Year of construction: 2003, control type: CNC control, actuation type: electric, controller model: System 6000, working width: 3,200 mm, type of crowning: CNC-controlled, sheet thickness (max.): 3 mm, sheet thickness steel (max.): 3 mm, back gauge: 3,000 mm, Equipment: CE marking, emergency stop, Used Ras Flexibend 73.30 Cnc Folding Machine For Sale with 3metre back gauge Motorized Swivel Bending Machine Blsdpew T Sc Aofx Acfep Make: RAS Model: Flexibend 73.30 Year of Manufacture: 2003 Technical Specifications Manufacturer: RAS Model: 73.30 Year: 2003 Useful bending length: 3200 mm Sheet thickness: 3.0 mm Upper beam opening width: 300 mm CNC adjustable bending beam travel, max.: 80 mm CNC adjustable lower beam travel, max.: 80 mm Speeds: Bending beam, max.: 90 degrees/sec Upper beam, max.: 40 mm/sec Back gauge 10–1550 mm: 2 sec Equipment • Control: Touch & More System 6000 - NEW TOUCH SCREEN FITTED • CNC-controlled back gauge, 3metre J version / J shape back gauge • Motorized lower beam adjustment and bending beam adjustment • Support table A good selection of tooling, segmented and full length

Condition: used, Year of construction: 2003, XXL-Center RAS 75.06-2 long bending center for fully automatic positive and negative bending, where it is not necessary to turn the sheet metal. Usable length 6400 mm Maximum sheet metal thickness (400 N/mm²) 1.5 mm Four motorized and extremely fast axes controlled by CNC (no hydraulics) For: • Upper and lower bending beam speed: 126 degrees/s • Upper beam speed: 60 mm/s • Back gauge travel: 12-750 mm • Back gauge speed: 350 mm/s • Bending accuracy (depending on the quality of the sheet metal): up to +/- 1 degree Blsdpfozru Nzox Acfsp

Year of construction: 2012, condition: excellent (used), Used Ras 62.25 CNC Folder Model: 62.25 Ras Year 2012 RAS 62.25 CNC folder Capacity: 2540mm x 2.5mm CNC Auto Bending Machine (Year 2012) Complete with fitted System 6000 Touch screen control (screen recently replaced) Bedpen Tnzfefx Acfolp 3.2 Metre J shape back gauge Twin Foot Pedal Control MACHINE GUARD SOLUTIONS Light Guards Complete with segmented and straight tools

Condition: good (used), functionality: fully functional, RAS: Cutting length 1040 mm Sheet metal thickness in steel: 2.5 mm Sheet metal thickness in stainless steel (700 N): 1.5 mm Back gauge distance: up to 550 mm .....FASTI: Capacity 1020 x 2 mm with pneumatic weight compensation for the bending arms and with finger stop Bsdpfszvcbajx Acfjlp Package price: EUR 4,900.00 net

Condition: good (used), Year of construction: 2002, machine/vehicle number: 27/5, Offer 26238 Technical specifications: - Max. working width: 3190 mm - Max. material thickness at 40 kg/mm² tensile strength: 6.3 mm - Cutting angle: 1.2° - CNC cutting gap adjustment - Strokes: 30 to 64 1/min Bsdpjzwm Hijfx Acfelp - Stand extension: 100 mm - Table height: approx. 800 mm - Number of clamps: 16 pcs - Back stop: 5 - 1000 mm; - 3 pcs front support arms: 1500 mm - E-foot pedal - Rear tilting roller table - Drive: 400 V / 18.5 kW - Space requirement: approx. W 3900 x H 1800 x D 2100 mm - Weight: approx. 6800 kg - Includes: - CNC control system RAS - Rear tilting roller table / sheet metal lifting device - Movable material collection container - Electronic rear safety device / light curtain

Condition: used, machine/vehicle number: ubk., No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Information Machine type: Swivel bending machine Condition: good Machine weight: approx. 6.75 t Working area Sheet metal width: 6,060 mm Sheet metal thickness: 2 mm Blodpfx As Aa Ngnjcfjp Performance data Total power requirement: 7.5 kW Dimensions Length: approx. 7.0 m Width: approx. 2.0 m Height: approx. 2.5 m EQUIPMENT Motor-driven back gauge

Condition: excellent (used), Profiling machine by Ras Inventory number: 3954 Manufacturer: Ras Type: Ras 22.12 * 11 stations * Shaft diameter: 28 mm * Band width: 150 mm * Band thickness: 1.2 mm * Flying hydraulic shear * Connected power: 5.5 kW Blsdpfx Aszyy N Ajcfjp

Year of construction: 2007, condition: excellent (used), RAS Turbo bend plus 62.25 New gearboxes fitted from Ras Bending length 2540mm / 2.5 metre Material thickness max 2.5mm Bledpfx Ajgd Dgqocfjp Four extremely dynamic and fast ramp-driven movements under CNC System 6000 CNC touch screen – New control fitted in 2016 Extended back supports Light guards Portable tooling rack New / Year of manufacture 2007 Complete with: J shape back gauge Complete with segmented and straight tools and tooling rack Tooling (supplied with the machine): Standard ‘sharp’ upper tooling – 3x lengths 845mm Bottom tooling single length – 1x 2.54m length 10mm wide Bottom tooling single length – 1x 2.54m length 20mm wide Goats foot segmented upper tooling – 110 height section 200mm wide – 10 lengths 60mm – 1 length 55mm – 1 length 50mm – 1 length 45mm – 1 length 40mm – 1 length 35mm – 1 length 30mm – 1 length 120/90mm LH Box end – 1 length 120/90mm RH Box end – 1 length Segmented bottom tooling 200mm wide – 10 lengths 120mm – 2 lengths 60mm – 1 length 55mm – 1 length 50mm – 1 length 45mm – 1 length 40mm – 1 length 35mm – 1 length 30mm – 1 length Tool cart supplied

Condition: refurbished (used), Year of construction: 2010, XXL-Center RAS 75.06 - General technical data in mm: Bending length: 6400 mm Max. sheet thickness (400N/mm2): 1.5 mm Max. sheet thickness (750N/mm2): 1.0 mm Max. sheet thickness (200N/mm2): 2.0 mm Gripper claws travel range: 10 – 750 mm Clearance in front of the jaws up to: 300 ° Extendable loading tables: yes Gripper claws: yes Programming: automatic via Bendex Machine dimensions incl. safety fence approx.: 9400 x 3000 Weight: 12.5 tons - Machine-specific data: Motor-driven; 400V, 50/60 Hz, 3-phase Year of manufacture: 2010 Condition: Will be completely overhauled - Images are examples Bledpfx Acox Hf Tvjfjp -

Condition: excellent (used), functionality: fully functional, Year of construction: 2004, Used 6metre Ras up and down bend cnc folding machine for sale Ras XXL Centre 75.06 System 9002 cnc control RAS TECHNICAL DATA: DIMENSION 75.06 Max. Sheet thickness (Steel 58000 PSI) gauge 16 Max. sheet thickness (Aluminium 29000 PSI) gauge >14 Max. sheet thickness (Stainless Steel 109000 PSI) gauge 18 Working length max. inch 251,97 / 6.4metre Grippers Travel Range inch 0,47 – 29,53 Grippers Positioning Accuracy inch +/- 0,004 Distance between 2 Grippers min. inch 7,09 Stops and Grippers Quantity 8 Free Space in front of the folding be-ams up to degree 300 Working Height inch 37,40 Machine Width inch 59,05 Machine Length without contori cabinet inch 257,48 Machine Height inch 70,87 Weight approx.. lbs 27 600 Compressed air bar 5,5 Drive Power Upper Beam hp 2,95 Drive Power Upper Folding Beam hp 2,95 Drive Power Lower Folding Beam hp 2,95 Speeds: Upper and Lower Folding Beam degree/s 126 Bjdpfjgpk R Esx Acfjlp Upper Beam inch/s 13,78 Grippers inch/s 13,78 Max. sheet thickness (Steel 400 N/mm2) mm 1,5 Max. sheet thickness (Stainless Steel 750 N/mm2) mm 1,25 Max. sheet thickness (Aluminium 200 N/mm2) mm 2,0 Working length max. mm 6400 Grippers Travel Range mm 12-750 Grippers Positioning Acuracy mm +/- 0,1 Distance between 2 Grippers min. mm 180 Stops and Grippers Quantity 8 Free space in front of the folding beams up to degree 300 Working Height mm 950 Machine Width mm 1500 Machine Length without control cabinet mm 6540 Machine Height mm 1800 Weight approx.. N 125 000 KG 12 500 Compressed air bar 5,5 Drive Power Upper Beam kW 2,2 Drive Power Upper Folding Beam kW 2,2 Drive Power Lower Folding Beam kW 2,2 Speeds: Upper and Lower Folding Beam degrees 126 Upper Beam mm/s 60 Grippers mm/s 350 Ideal for the manufacture of roofing products

Condition: good (used), You are bidding on a branded plate shear from the well-known German manufacturer Schröder and a swing bending machine from the top manufacturer RAS from Sindelfingen. Device features: RAS bending machine Capacity: 2.5mm steel - aluminum and more Bending length: slightly over 2m Adjustable back gauge from the front, also ideal as a sheet metal support Hand and foot controls The machine comes from a reputable company and has been professionally inspected before sale. Weight: see image Optionally, a segmented segment beam from RAS is also available in stock. Invoice with VAT shown I can arrange shipping with a freight forwarder if desired. A matching plate shear from Schröder or Schechtl is available - or a mechanical RAS model up to 1.5mm. Free loading as shown in the pictures. Inspection and testing are possible after scheduling an appointment by phone. Payment in cash upon collection - if I can do anything else for you, please call me - thank you. Collection should take place within 8 days after the end of the auction. Blodpfx Acsxqpiyofsp Location: 97261 Güntersleben
