Eccentric press

WEINGARTEN

Condition: used, Technical details: plate width: 1000 mm plate thickness: 3,0 mm smallest sheet thickness: 0,5 mm distance between columns: 920 mm Number of Straightening rolls: oben 4x unten 4x Stück / pieces roll diameter: ca. 75 mm number of rollers: 2 oben und 2 unten St. weight of the machine ca.: 6,5 t dimensions L x W x H: 3,8 x 2,2 x 2,1 m Complete as coil line (reel+loading device+straightening machine+straightening machine with hydraulic feed) can optionally be sold together with stock no. 0100572. further features: -4 units top rollers, stroke 20mm, hydraulic -4 units bottom rollers, fixed, hydraulic operation -4 units pull-out rollers, 2x top / 2x bottom, top roller adjustable approx. 20mm; hydraulic operation C0Du8Kjzfa Additional Equipment: Hydraulic system *

Condition: excellent (used), Year of construction: 1950, . Crack tested ; mechanical condition = very good ! Tzxggetis . Type XRR 150 III sp Delivered 1956 --> --> Table size 1150 x 1000 mm throat 500 mm --> --> ram size 1150 x 800 mm - Weight approx. 13 tons . VIDEO`S included in the offer . ..... Ongoing purchase of used German machines without NC or CNC control .

Condition: repair required (used), Year of construction: 1972, Manufacturer WEINGARTEN Model VK.1250.46.76 Condition Used Warehouse number cod.323 Structure Double upright Used press Qg2Insrhe Thrust: 1,250 ton. Thrust points n°4 Plunger kinematics Slide stroke 762 mm. VERTICAL LIGHT from the mold holder, CBRA 1,530 mm. Slide - registration 610 mm. Mold holder surface size 4,460 x 2,400 mm. Extractable carriage n°2 lateral exit (possible mold of 5,000 mm) Mold holder surface height 400 mm. Number of strokes/min 8/18 Front useful passage 4,400 mm. Sheet metal passage in the upright 2,400 mm. Hydraulic safety Present

Condition: used, Year of construction: 1967, CONTROLS .. conventional PRESS DESIGN .. drive system: eccentric / crank .. frame design: C-frame, single sided PRESS FORCES .. total force (nominal): 100 to SLIDE .. slide force: 100 to .. stroke rate (max.): 72 /min SLIDE (MECHAN. PRESS) Brjic3Owxd8 .. slide adjustment: 80 mm .. stroke adjustment: yes .. stroke min.: 8 mm .. stroke max.: 112 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 407 mm ATTACHMENTS (PRESSES) .. 2-hand engagement: yes for safe tools only

Condition: excellent (used), Year of construction: 2019, Functionality: fully functional, machine/vehicle number: 126182, Technical Details - (2019) WEINGARTEN Lamination Press CONSISTS OF THE FOLLOWING MACHINES: Weingarten 315 Pressline Press: Weingarten HS 315; Serial Number: 126182 Feeder: Weingarten Mechanical integrated with press Straightener: Weingarten RAS 40 Nr. 140123 Welding / Scissors: LSRB2 Nr. PS16-6/1207 Uncoiler: ServoPresse SMD 400 T5 Nr. 1100061 Press Line Specifications: Press Model: Weingarten HS 315 Feeder: Weingarten mechanical integrated with press Straightener: Weingarten RAS 40 Welding/Scissors System: LSRB2 Uncoiler: ServoPresse SMD 400 T5 Technical Data: Model: HS 315 Year of Manufacture: 2019 Press Force [kN]: 3150 Supported Sheet Widths and Feeding Stroke [mm]: 180, 200, 250, 280, 315 Br0S00Rbfyq Number of Punches [PPM]: 80-160 Tool Length [mm]: 900-2100 Tool Width [mm]: 650-1100 Bed Dimensions [N x O, mm]: 2200 x 1100 Maximum Opening of the Machine [mm]: 370-450 Press Stroke [mm]: 40 Press Stroke Rate [H/min]: 60-280 Stator Mandrel Diameters [mm]: 150, 165, 190, 215 Rotor Mandrel Diameters [mm]: 53, 60, 70

Condition: used, Year of construction: 1976, Capacity: 200 ton Throat depth: 460 mm Ram stroke: 28 - 192 mm Slide adjustment: 110 mm Shut height (stroke down, adjustment up): 470 mm Operating height: 900 mm Table surface area : 1090 x 800 mm Slide area: 740 x 540 mm Number of strokes: 30 x 60 s.p.m. Required power: 22 kW Dimensions L x W x H: 2720 x 1700 x 4000 mm Dqv3Ob Weight of machine approx.: 13 ton Standard configuration Control system was modernised to SIEMENS S7 in 2003with light barriers

Condition: excellent (used), Year of construction: 1993, Müller Weingarten blanking line Pressing force 5,000 kN Stroke rate 15-60. rpm Stroke 255 mm Dqw3Ed Stroke adjustment 140 mm Installation height 930 mm Table surface 4,000 x 2,500 mm Plunger area 4,000 x 2,500 mm Belt conveyor Belt width 500-2000 mm Belt thickness 0.5-2.0 mm Reel load capacity 30,000 kg

Condition: good (used), Year of construction: 1977, Functionality: fully functional, throat depth: 440 mm, ram adjustment: 110 mm, total height: 18,200 mm, table width: 800 mm, table length: 1,100 mm, total width: 24,000 mm, total length: 37,200 mm, overall weight: 12,600 kg, pressing force: 200 t, distance table to ram: 400 mm, power: 15 kW (20.39 HP), ram stroke: 40-180 mm Boismnkiwbs incl. Helmerding feed, 400 mm x 4 mm Strokes: 40 + 60 1/min Distance table/ram - adjustment top/stroke bottom: 400 mm Table opening: 450 mm diameter

Condition: used, Year of construction: 1985, Pressure 080 t throat 345 mm Dqqkwr stroke 20 - 160 mm no. of strokes 65 /min distance table/ram, max. stroke up, adjustment up 495 mm table surface area 920 x 610 mm table height over floor 800 mm Hole in the table 280 mm passage to the back 670 mm ram surface 650 x 400 mm ram adjustment 50 mm power capacity 10,0 kW weight 7,7 t Dimensions (WxDxH) 1,5 x 2,2 x 3,15 m permitted for manual put-in according to the German Safety Regulations (UVV) with motor, pneumatic clutch, hydraulic overload protection in ram, manual stroke adjustment, motoric ram adjustment, motoric centralized lubrication, two-hand operation

Condition: used, Technical details: plate width: 800 mm coil weight: 12 t sheet width - max.: 800 mm sheet width - min.: 300 mm thickness of strip/band: max. 5,0 mm band speed: 4,5 / 25 m/min work height max.: 1700 mm Payload: 12,0 to (Coil) Weight approx.: 7,3 + 6,62 t dimensions of coil: 3,2 x 1,9 x 2,7 m dimension machine xH: 2,5 x 2,6 x 2,45 m Decoiler with loading device Can optionally be sold together with stock no. 0100571. straightening unit: Infeed rollers: 2 x Ø 144 x 850mm Straightening rolls: 3 x bottom rolls, rigid, Ø 100 x 850mm, 30mm adjustable 3 x top rollers, Ø 110 x 850mm; 30 mm adjustable Coil unwinding machine: Outer Ø 1.500mm Strip width max. 800mm Load capacity max. 12 to Clamping Ø 470 - 630 / 570 - 730mm Transport unit LxWxH: 1700 x 1500 x 1000mm; crosswise running, with prism support 1000 x1000mm Machine will be offered and sold with Stock no. 0100521 as a decoiling and streightening line. Cyyv9I8R *

Condition: good (used), Year of construction: 1976, Technical data : Power 40 to 2 lifting speeds 57 + 86 H/min Projection 250 mm . Further data according to offer . Delivered with new press test incl. new test report. . Cimjx092Ze

Condition: used, Year of construction: 1964, pressure 16 t throat 210 mm stroke 8-68 mm table: 480 x 380 mm Dqosdj strokes per minute 150 ram adjustment 50 mm total power requirement 3 kW weight of the machine ca. 2 t

Condition: used, Single-column eccentric press WEINGARTEN type EV 63 Machine. No. 738 / 61 Year of construction 1962 Cvfsfqmqlt Pressure capacity 63 ton. throat 260 mm Table surface 630 x 530 mm Table opening Ø 210 mm ram surface 315 x 260 mm Plunger stroke adjustable 8-100 mm Plunger adjustment 63 mm Installation height max 450 mm Stroke rate 115 strokes / min. Compressed air requirement min. 4.5 bar Motor power 4 kW Mains connection 380 Volt, 50 Hz Table height above floor approx. 750 to 900 mm - Electric lift release via foot switch or two-hand operation - Overload protection by breaker plate - Clutch/brake combination with WEINGARTEN friction threaded clutch with TDC overrun protection - Front crankshaft support bearing - Press table height-adjustable via 2 threaded spindles - Manual central grease lubrication - Control cabinet adjacent - UVV for manual insertion work Space requirement L x W x H 1750 x 1600 x 2430 mm Weight 4.5 tons good condition

Condition: not inspected (used), Year of construction: 1961, machine/vehicle number: 64/61, Müller Weingarten press 1600 kN, pitch 8 ER 160 Year of construction 1961 Blg2Ccribwg Pressing force 1600 kN Maximum sheet thickness 14 mm Ram stroke 20-120 mm Ram adjustment 100 mm Stroke rate 45 / min

Condition: used, Year of construction: 1981, pressure 080 t throat 345 mm stroke 8 - 112 mm Stroke rate 65 / min Distance table/ram, max. stroke up, adjustment up 472 mm Table surface area 840 x 610 mm Hole in the table 280 / 315 mm Table height above floor 800 mm Passage to the back 500 mm Ram surface 650 x 400 mm Ram adjustment 70 mm Cyxxstx77O Power capacity 7,5 kW Weight 6,8 t Dimensions (WxDxH) 1,2 x 1,95 x 3,05 m permitted for manual put-in according to the German Safety Regulations (UVV) with pneumatic clutch, mechanical overload protection in ram, pneumatic counterbalance in ram, centralized lubrication, two-hand operation

Condition: used, Single-column eccentric press WEINGARTEN type ER 63 Machine. No. 52A / 63 Year of construction 1963 Pressure capacity 63 ton. throat 280 mm Table surface 630 x 530 mm Ddqzl2V ram stroke adjustable 8-100 mm ram adjustment 63 mm Stroke rate 65 strokes / min. Motor power 4 kW Mains connection 380 Volt, 50 Hz - Clutch/brake combination with WEINGARTEN friction threaded clutch - Electric lift release via foot switch - Wheel reduction gear - Overload protection by breaker plate - Front crankshaft support bearing Space requirement L x W x H 1500 x 1100 x 2500 mm Weight 4.5 tons good condition

Condition: used, Year of construction: 1977, pressure 080 t throat 280 mm stroke 8 - 112 mm no. of strokes 30 - 120 /min distance table/ram, max. stroke up, adjustment up 500 mm table surface area 840 x 580 mm hole in the table 150 mm table height over floor 910 mm passage to the back 640 mm Cyxvxamy30 ram surface 560 x 300 mm ram adjustment 80 mm power requirement 7,5 kW weight 8,0 t dimensions (WxDxH) 1,6 x 2,3 x 3,3 m permitted for manual put-in according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch, hydraulic overload protection in ram, motoric ram adjustment, inclineable, two-hand operation press can be inspected in running condition in our warehouse

Condition: used, Single-column eccentric press WEINGARTEN type ARP 100 Machine no. No. 122481 Year of construction 1984 Pressure capacity 100 ton. throat 400 mm Table size 920 x 660 mm ram surface 700 x 450 mm Rear upright width 735 mm Stroke adjustment 20 - 160 mm Plunger adjustment 80 mm Installation height with 160 mm stroke max. 355 mm (without intermediate table top) Installation height with 20 mm stroke max. 425 mm (without intermediate table plate) Stroke rate 60 strokes/min. Table surface intermediate table top 920 x 610 mm Thickness of intermediate table top 90 mm Hole in intermediate table top Ø 210 / 180 mm Through-hole in machine table Ø 210 / 180 mm Table height above floor 800 mm (without intermediate table top) T-slot width in table and ram 22 mm Clamping pin bore 50 mm Motor power 11 kW Mains connection 400 Volt, 50 Hz - Hydraulic overload protection in ram - ORTLINGHAUS pneumatic clutch/brake combination - Electromotive ram adjustment with counter - Clamping pin bore with clamping piece Bslaeiu8Iq0 - Front crankshaft support bearing - Gear reduction gears in closed oil bath gearbox - Two pneumatic tappet compensation cylinders - WOERNER automatic central grease lubrication - Lift release via electric foot switch or two-hand control panel - Electrical control cabinet permanently attached to the machine - Operating instructions and circuit diagram - UVV for manual insertion work Space requirement L x W x H 2200 x 1600 x 3250 mm Weight 8.3 tons Good condition

Condition: used, Year of construction: 1987, Pressure 080 t throat 380 mm stroke 8 - 112 mm no. of strokes 60 /min distance table/ram, max. stroke up, adjustment up 472 mm table surface area 840 x 610 mm table height over floor 800 mm passage to the back 520 mm ram surface 650 x 400 mm ram adjustment 70 mm power capacity 7,5 kW weight 6,9 t Dimensions (WxDxH) 1,1 x 2,15 x 3,2 m Dqplqx permitted for manual loading according to the German Safety Regulations (UVV) with pneumatic clutch/brake combination, mechanical overlaod protection in ram, tie rods to improve rigidity of the press body, two-hand operation as is where is, WITHOUT putting into operation in our warehouse, WITHOUT electrical cabinet Price for commissioning (with new electric control) on request

Condition: used, Single column eccentric press WEINGARTEN type ERV 40 Machine No. 537 / 65 Year of construction 1965 Compressive force 40 ton. throat 230 mm table size 570 x 470 mm ram surface 250 x 200 mm clamping spigot bore Ø 40 mm installation height max. approx. 520 mm stroke adjustment 8 - 88 mm slide adjustment travel 63 mm Stroke rate 70 strokes per minute Drive power 3 kW Mains connection 380 Volt, 50 Hz - Table height adjustment - Overload protection by crushing plate Gv8Grg - clutch-brake combination by WEINGARTEN friction thread clutch - electric 2-hand operation and foot switch - central lubrication via hand pump space requirement L x W x H 1600 x 1150 x 2300 mm weight approx. 2,6 ton.

Condition: used, Year of construction: 1959, pressure 063 t throat 280 mm stroke 8 - 100 mm no. of strokes 65 /min distance table/ram, max. stroke up, adjustment up 550 mm table surface area 630 x 500 mm hole in the table 230 mm table height over floor 740 mm table adjustable 200 mm ram surface 320 x 260 mm Dqplm9 ram adjustment 63 mm power capacity 5,5 kW weight 4,6 t Dimensions (WxDxH) 1,4 x 1,8 x 2,4 m permitted for manual loading according to the German Safety Regulations (UVV) with motor, friction clutch, mechanical overload protection in ram, manual stroke adjustment, manual ram adjustment, adjustable table, manual centralized lubrication, two-hand operation Press is currently under revision

Condition: used, Single-column eccentric press WEINGARTEN type E 40 Machine. No. 643/62 Year of construction 1963 Pressure capacity 40 ton. throat depth 250 mm Table opening 150 x 80 and Ø 200 mm Table surface 560 x 460 mm ram surface 250 x 200 mm Plunger stroke adjustable 8-88 mm Plunger adjustment 63 mm Installation height 320 mm Clamping pin bore Ø 40 mm Stroke rate 100/130 strokes / min. Motor power 2.2 / 3 kW Mains connection 400 Volt, 50 Hz Table height above floor 840 mm - Clutch/brake combination with WEINGARTEN friction threaded clutch with TDC run-through protection - Electric lift release via two-hand control - Overload protection by breaker plate - Manual central grease lubrication - Front crankshaft support bearing - Control cabinet adjacent Sd8Wccguen - UVV for manual insertion work Space requirement L x W x H 1800 x 1500 x 2200 mm Weight 3.1 tons

Condition: used, Year of construction: 1985, pressure 500 t distance between columns 3100 mm Ctoq27G8Es stroke fix 300 mm no. of strokes 20 - 70 Hub/min dayligth (stroke and adjustment up) 1000 mm column travel -side 1400 mm table surface area 2800 x 1600 mm hole in the table mm table height over floor mm ram surface 2800 x 1450 mm power requirement 90,0 kW weight of the machine ca. 100,00 t required space 5,75 x 3,2 x 7,8 m ram adjustment 100 mm height over floor 6,4 mm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch (Ortlinghaus), hydraulic overload protection in ram, pneumatic counterbalance in ram, motoric ram adjustment as is where is, WITHOUT putting into operation, stored in dismantled condition (no PLC + main motor available)

Condition: used, Year of construction: 1977, pressure 063 t throat 250 mm stroke 8 - 100 mm no. of strokes 56 / 84 /min distance table/ram, max. stroke up, adjustment up 415 mm table surface area 710 x 500 mm hole in the table 320 mm table height over floor 800 mm passage to the back 320 mm ram surface 450 x 280 mm ram adjustment 63 mm Dqnbhh power requirement 4,0 kW weight 4,1 t dimensions (W x D x H) 1,35 x 2,0 x 2,6 m year of manufacture 1964 installation of moving screen 1977 permitted only for safe tools or fixed screen according to the German Safety Regulations (UVV) with motor for two speed, friction clutch, mechanical overload protection in ram, manual stroke adjustment, manual ram adjustment, inclineable, manual centralized lubrication, foot operation as is where is , WITHOUT putting into operation in our warehouse Price for commissioning (in given condition) on request

Condition: used, Year of construction: 1962, nominal force 400 t stroke 140 - 400 mm no. of strokes 24 - 36 /min distance between columns 800 / 700 mm distance table/ram, max. stroke up, adjustment up 900 mm table surface area 700 x 700 mm blow die to die t Allowed max. force t ram surface 630 x 630 mm spindle diameter 220 mm power capacity 26,0 kW weight 18,5 t Brsouzysaoy Dimensions (WxDxH) 1,85 x 2,5 x 4,3 m only permitted for warm forming work with gear drive, single impact / double impact device, impact regulation
