CNC Machine Centres For Routing, Drilling And Edgebanding.

VITAP ECLIPSE

Condition: used, Year of construction: 2016, Vitap Eclipse Edgebander for round shaped, curved workpieces Semi-automatic edge banding machine for large round or curved workpieces with a panel thickness between 10 and 60 mm and a belt thickness between 1 and 3 mm. The 60 mm height is only possible with an edge banding thickness of 1 mm. If the edge band is thicker, it depends on the quality of the band and must be tested beforehand in connection with the cutting unit. Description; Two copy rollers for the shape of the workpiece to be scanned Gluing station Glue tray with a capacity of 1 kg Two 800W heating elements with electronic temperature display via the PLC Glue application via glue roller Glue tray made of aluminum for heat distribution Glue supply can be adjusted by means of a button Automatic cutting unit for edge banding material on the roll from 3 to 45 mm Aggregate is activated by a sensor for closed edge tape with a perfect connection or by an encoder if only 1 side is pasted Laser system for length determination, no pre-measurement necessary On-off capability for throughput Height-adjustable table for narrow panels On-off capability for milling aggregate Two copy rollers for the shape of the workpiece to be scanned Milling unit equipped with 2 x 0.5 kW (15000 rpm high frequency) with top, bottom and front copy rollers Milling unit equipped with blades R=2, Phase 15°, D=69, Z=6 Large panel turntable with vacuum to hold product (All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!) (Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten! Keine Garantie auf gedruckte Daten!) Gbedpfxjwgb Hxe Afzsk Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: new, Vacuum lifter BARBARIC B3 swiveling, incl. crane - Exhibition unit - Including: - Vacuum lifter BARBARIC uniWood UWL 3, 150 kg Vertical and horizontal transportation of flat commercial commercially available boards (coated boards, natural wood panels) up to a panel size of 3,000 x 2,100 mm - a tilting range of 90° with pneumatic tilting mechanism - Complete with hoist and corresponding safety devices safety devices (vacuum manometer and manual manual slide valve with mechanical safety device) - uniWood traverse with 2 suction pads Ø 270 mm on an adjustable traverse (traverse length: 1,500 mm) Includes: - Optional reinforced BARBARIC uniWood version for easily permeable boards Load capacity: 250 kg with 2 oval suction pads 500 x 250 mm on an adjustable cross beam (cross beam length: 1,250 mm) and reinforced vacuum pump for permeable sheets. The reinforced design enables lifting materials weighing up to 250 kg. Includes: - BARBARIC uniWood comfort operation option All controls for the lifting gear and for the vacuum the vacuum lifter are integrated in one control unit - our special handling handle is accommodated. This makes it possible to operate the system and guiding the load in one-handed operation. The lifting process can be steplessly controlled by a frequency converter. The comfort version comes complete with hoist and corresponding safety devices (vacuum pressure gauge and 2-button safety control for releasing the load). Includes: - BARBARIC column-mounted slewing jib crane Lifting capacity on the lifting device: 250 kg Godpfou R Szasx Afzebk The lifting capacity is the specified working load on the lifting device. Barbaric slewing jib cranes are designed for handling tasks in all areas of application and are extremely lightweight. SSK consisting of column, bracket and smooth-running jib. jib. Slewing and trolley travel by hand. The prerequisite for attachment is a suitably concrete floor (C20/R5, min. 20 cm). The static inspection of the floor must be carried out on site and documented accordingly. For fastening on cracked concrete or less load-bearing substrate, we offer enlarged base plates enlarged base plates on request. Fastening: Supplied with adhesive anchor for concrete floor When ordering without lifting gear, please specify the cable or hose type! Delivery includes: incl. sliding trolley, power supply and compressed air connection. - new exhibition machine -

Condition: new, Year of construction: 2025, Gannomat Concept 70 Eco Lamella - carcass press with rapid traverse Technical data: Lamella carcass press from our showroom; Working range: width from 150 - 2.500mm , height from 150 - 1.400mm; depth 700mm; - lamella press beam top with 6 elements, lamella press beam side with 5 elements - lamella press beam with practice-proven tolerance compensation for tightly pressed carcass joints - Counterpressure surfaces are 40 mm thick, coated continuous support plates - The pressing force of the pressing bars is infinitely variable electronically controlled by 2 potentiometers and adjusted via frequency converter, therefore the torque transmission is absolutely wear-free. - Pressing force for horizontal press bars min. 500 daN (kg) to infinitely variable max. 2200 daN (kg) - Pressing force for vertical press bars min. 300 daN (kg) to stepless max. 2200 daN (kg) - Including option: Gbsdpfx Aeiidm Nofzsk Rapid traverse speed for fast positioning of the press bars, controlled by automatic workpiece recognition with sensors in the press bars, press speed 5/10/25 mm/sec. and rapid traverse speed 50 mm/sec, the sensors can be switched off for pressing special parts. - Jog mode for precise positioning of the two pressing beams e.g. for low pressing forces, drawers and carcasses 45 degrees. Simple operation via 6 separate pushbuttons, freely adjustable pressing time preselection with automatic opening, loading height 300 mm. Machine is in our showroom and can be delivered immediately. Location: ex stock 54634 Bitburg - immediately available -

Condition: used, Year of construction: 2021, MEGA 300 TS Numerical Control Panel height 60 mm PVC/Abs mm 3 Feed speed up to 22 m/min Working height adjustable electronically by C.N. Motorized rubber belt with higher pressure Introduction system for small panels Panel support guide with electronic adjustment by C.N. Side roller conveyor with idle wheels for panel support Anti-adhesive group Rectifier unit with two motors electronically adjustable by C.N. Roll holder plate for delicate edges Edge magazine with 2 positions Gluing unit for EVA glue with glue tank and pre-melter Edge pressure group on straight profiles with pressure rollers electronically adjustable by C.N Non-stick group Trimming unit with 2 motors with automatic inclination adjustment Gedpfxjt Hal De Afzebk Trimming unit with 2 superimposed motors Trimming / gleaning group with 2 tilting motors electronically adjustable by C.N. Rounding unit with 4 motors Edge scraper unit electronically adjustable by C.N. Glue scraper unit Oscillating brush group Hairdryer group

Year of construction: 2024, condition: new, Return System Gbsdpfx Asw Nadmsfzek Year of manufacture: 2024 The RTS Compact is a standalone system that can be connected to any edgebanding machine (KAM), regardless of the manufacturer. The feed speed is continuously adjustable to match the speed of the edgebander. The RTS Compact is supplied complete with a control cabinet and is ready for operation immediately after installation. Optional: "RTS Compact Conveyor Extension" for easy rotation of parts during cross-edge banding. Optional: "RTS Compact Ergonomics Package" available. A lift table and air cushion table are used at the end of the return conveyor. This option enables ergonomic operation. - Compatible with edgebanders from all manufacturers - Allows single-operator control of the edgebander - Maximum ergonomics - Reduced personnel costs - Gentle material handling - Installation time approx. 0.5 day - Turning device for small parts - With conveyor belt L 4500 x W 800 mm Single-track roller rail RTS Compact control, optional control box Availability: short-term Location: Flörsheim

Year of construction: 2001, condition: used, - heating plate size (mm): approx. 1500 x 2700 - usable area max. (mm): 1250 x 2450 Gjdpfx Afokt N Huszebk - loading side (mm): 1500

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, operating hours: 5,383 h, The HOMAG DRILLTEQ V-200 is a compact and highly efficient CNC vertical machining center designed for precise drilling, grooving and routing operations in furniture and cabinet production. Gbedpfx Aeym Ny Sofzjk Thanks to vertical processing, the machine requires minimal floor space while offering high flexibility and productivity. It is ideal for batch size 1 production as well as serial manufacturing. The machine is in very good technical condition and can be inspected under power.

Condition: excellent (used), Numerical Control Type NC 400 (with work cycle management software) Through-feed motorized conveyoring belts (No.) 2 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Gbjdpsi D D Tfefx Afzok No. 4 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 2 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 25 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops OPTION: Front feed hopper/loader (for narrow pieces: Min 60mm - Max 260mm)

Condition: new, Year of construction: 2021, machine/vehicle number: 0-250-87-1000, functionality: fully functional, Equipment: CE marking, NEW THROUGHFEED DRILLING MACHINE DRILLTEQ V-200 (BHX 055) Standard features •Drilling head with 13 spindles •Horizontal drilling head with 4 spindles in X-direction •Horizontal drilling head with 2 spindles in Y-direction •Grooving saw D=100 mm (X-direction) •Stop cylinder for workpiece positioning •Workpiece clamping system •Workpiece length: 3050 mm •Workpiece thickness: 12-60 mm Machine operation Godew U Ty Sepfx Afzobk •WOODWOP 7 FOR MACHINE •Milling motor with frequency inverter 5kW (ETP) Documentation •Selected language: Polish, English, German •Documentation on data carrier, paper documentation General information •Year of manufacture: 2021 •Control: POWERCONTROL with POWERTOUCH system •CE-marked •Status: Ready for operation / can be demonstrated •Available in stock

Condition: like new (used), functionality: fully functional, Dowel Hole Drilling and Inserting Machine SCHEER BS 5102-V The BS 5102-V is a powerful, electronically controlled machine designed for precise and efficient face-end drilling and accurate insertion of wooden dowels. It is ideally suited for industrial wood processing—especially in furniture and carcass production. Condition & Service: Condition: As new (completely overhauled & newly painted) Functionality: Fully operational Warranty: 12 months CE compliant / Dust-tested Main Technical Data & Features: Workpiece width: min. 60 mm / max. 1200 mm (Pendulum operation: max. 600 mm) Workpiece thickness: 15 – 60 mm Drilling depth: max. 45 mm Vertical stroke of the support: 7.5 – 50 mm Min. lateral drilling distance: 10 mm Drilling unit: 9,000 – 18,000 rpm (adjustable), 1.5 kW Drilling system: M10 external (Scheer system) Servo motor: 0.54 kW, max. 60 m/min feed rate Dowel size: 8 x 30 / 8 x 50 mm, DIN 68150 Form A Glue system: 1:1 diaphragm pump, max. 7 bar Glue container: spiral conveyor, 3.5 liter capacity Extraction connection: Ø 80 mm | Extraction airflow: 540 m³/h at 30 m/s Clamping cylinders: 4 short-stroke cylinders (Ø 63 mm), angular clamping Power supply: 400 V, 50 Hz Machine Construction & Operator Comfort: Controlled X-axis with machine frame as workpiece support X-support with linear guide and rack-and-pinion drive Servo drive for feed system Clamping portal with 4 adjustable clamping cylinders—controllable in 2 groups Stop rulers: left, right, and center on the table Drilling depth and dowel projection are adjustable directly on the support Offcut Unit & Safety Systems: Safety hood locking Lamella safety curtain Integrated extraction channels Control & Operation: PC with Siemens PLC controller User interface: WP-Studio—dialog-oriented programming Operating system: Windows 10 Display: 17" color monitor Separate workpiece programs for left & right operating sides (mirrored possible) Glue quantity can be individually defined per program Network capable (LAN/WLAN), compatible with Windows, Linux, Mac, Novell Remote maintenance & software updates possible Optional Equipment: Y-axis: automatic adjustment of drilling and glue units Electronic glue monitoring: ensures controlled glue flow Additional drilling unit for surface-side drilling: • Drilling motor: 1.5 kW at 18,000 rpm • Drill feed: pneumatic • Drill stroke: max. 25 mm • Depth limit: via spindle & SIKO display • Drill distance from reference edge: 5 – 35 mm • Holder: M10 external, max. Ø 35 mm • Workpiece length: min. 70 / 90 mm Warranty & Reliability: Gbodeunvg Tjpfx Afzjk We are convinced of the stability and manufacturing quality of our machines—that’s why you receive a 7-year warranty on the machine construction, especially on the supporting structure and guide mechanism. Excluded are electrical supply components as well as normal wear parts. Additionally, we provide a 1-year warranty on the complete machine (including control, hydraulics, pneumatics, etc.). Conclusion: This machine combines state-of-the-art control technology, high manufacturing quality, and user-friendly operation. Ideal for precise dowel hole drilling and automated dowel insertion—reliable and efficient for continuous operation. 📞 Contact us for an individual offer or to schedule a demonstration. Available from stock. Delivery, commissioning, and training available as options.
